Outbreak Investigation in the Bioterrorism Setting

1
(No Transcript)
2
Session VI

• Writing an Outbreak Report

3
Session Overview

• Outbreak report function and critical components
• Case studies
• E. coli 0157H7 at the NC State Fair, 2004
• Multistate Outbreak of Monkeypox, 2003

4
Learning Objectives

• Understand the role of outbreak investigation
  reports
• Recognize the different types of reports
• Recognize elements to include in outbreak
  investigation reports

5
Basic Steps of an Outbreak Investigation

• Verify the diagnosis and confirm the outbreak
• Define a case and conduct case finding
• Tabulate and orient data time, place, person
• Take immediate control measures
• Formulate and test hypothesis
• Plan and execute additional studies
• Implement and evaluate control measures
• Communicate findings

6
Why Communicate the Findings?

• Document for action
• Share new insights
• Record of performance
• Substantiate recommendations
• In order to
• Prevent future outbreaks
• Assist in investigation and control of similar
  incidents
• Provide a document for potential legal issues

7
Why are Outbreak Reports Crucial to Public
Health?

• Example Foodborne outbreak
• Hepatitis A contamination of green onions in TN,
  NC, GA, and PA, Sept-Nov 2003
• Food and Drug Administration (FDA) advisory
  report and MMWR alerted the public and assisted
  with traceback

8
Why are Outbreak Reports Crucial to Public
Health?

• Example Respiratory disease outbreak
• Legionnaires Disease (LD) Associated with a
  Whirlpool Spa Display Virginia, Sept-Oct 1996
• Case-patients were likely exposed by walking by
  or spending time near the spa
• The Virginia Department of Health issued
  recommendations for the inspection and
  maintenance of display spas

9
Why are Outbreak Reports Crucial to Public
Health?

• Example Respiratory disease outbreak
• Legionnaires Disease (LD) outbreak at a flower
  show in the Netherlands, 1999
• Source whirlpool spa on display
• Lawsuit raised against Dutch government for
  negligence
• Failure to act on available knowledge (MMWR 1996)

10
Some Reports are a Part of History

• John Snow

11
Some Reports are a Part of History

• Morbidity and Mortality Weekly Report (CDC), June
  5, 1981

12
When is the Report Written?

• When the investigation is complete
• When the investigation is ongoing
• Further analysis of data collected in this
  investigation may require revision of these
  findings and recommendations.
• Because of the preliminary nature of this
  investigation, future correspondence, MMWR
  articles, or other published reports might
  present results, interpretations, and
  recommendations that are different.

13
Who Writes the Report?

• The field epidemiology / outbreak team
• Visiting EIS officer
• Other authors as assigned
• All participating agencies must agree with
• what is in the report.

14
What are the Types of Reports?

• Complaint form
• Internal report
• Record that outbreak occurred and investigation
  was conducted
• State publication
• Newsletter, Website, statewide alert
• MMWR http//www.cdc.gov/mmwr/
• Peer-Reviewed Journals
• Epidemiology and Infection, Emerging Infectious
  Diseases, Journal of Hospital Infection

15
Peer-Reviewed Articles
http//www.ncbi.nlm.nih.gov
16
Research Outbreak Updates

• MMWR mailing list
• www.cdc.gov/mmwr/mmwrsubscribe
• FoodNet
• www.cdc.gov/foodnet/
• ProMED-mail listserve
• www.promedmail.org

17
Basic Report Structure

• Summary
• Introduction and Background
• Outbreak Description
• Methods and Results
• Discussion
• Lessons Learned
• Recommendations
• Acknowledgements
• Supporting Documentation

2 - 3pages
18
Summary

• 1 - 2 paragraphs
• Overview of the investigation
• WHO, WHAT, WHERE, WHEN, WHY/HOW
• What caused the outbreak or the causal hypothesis
  based on the evidence
• Key recommendations
• Ongoing actions
• Pending / required actions

19
Introduction and Background

• Surveillance trends and similar outbreaks
• Include specific events that led to the
  investigation
• How the outbreak was first reported
• Steps taken to confirm the outbreak
• Those who became involved in the outbreak
  investigation
• Description of the area / site / facility

20
Methods

• Epidemiologic
• Case definition and ascertainment
• Study design
• Microbiological / Toxicological
• Clinical and environmental specimen collection
• Where specimens sent
• Types of analyses performed
• Environmental
• Site visit risk assessment
• Traceback of food products or other items

21
Results

• Epidemiological
• No. of questionnaires sent / returned
• No. of cases and descriptive clinical data on
  cases
• Geographic distribution of cases
• Epidemic curve
• Risk factor analysis
• Attack rates by age, sex, exposure

22
Results

• Microbiological / Toxicological
• Laboratory findings, e.g. genotyping, DNA
  fingerprinting via PFGE, culture results
• Environmental
• Results of any risk assessments
• Results of any traceback investigation

23
Discussion

• Discuss main hypotheses
• Justify conclusions and actions
• Explain action to protect public health

24
Discussion

• Highlight any lessons learned
• Problems encountered
• Mistakes made
• Limitations of the study
• Useful lessons for planning future investigations

25
Recommendations

• Control Measures
• To control this outbreak
• To prevent future outbreaks
• To improve management of future outbreaks
• Be specific about problems
• Investigation obstacles and shortcomings
• Outbreak causes
• Aim to educate fellow public health professionals
  and inform policy makers

26
Supporting Documentation

• Also include the following
• Graphs and tables
• Inspection reports
• Blank samples of surveys
• Letters to management
• Menus
• Copies of posted notices
• Testing results
• Press releases
• Maps

27
Case Studies
28
Case Study 1
Outbreak of E. coli O157H7 at the North
Carolina State Fair, 2004Epi Notes, December
2004-February 2005http//www.epi.state.nc.us/epi/
pdf/en2004-4.pdf
29
Case Study 1

• Condensed version of a more detailed report
• Includes all important components
• Outbreak description
• Methods and results
• Discussion
• Lessons learned
• Recommendations

30
Case Study 1

• October 2004 E. coli O157H7 infection
  associated with state fair attendance.
• Case-control study design with 45 confirmed cases
  and 188 controls.
• Data analysis and public health laboratory
  results (PFGE) revealed petting zoo activities at
  the fair as the source of infection.

31
E. coli O157H7 at the NC State FairEpidemic
Curve
32
E. coli O157H7 at the NC State FairResulting
Legislation

• Aedins Law - July 2005
• Permitting process and rules for animal
  exhibitions at state-sanctioned fairs
• Educational campaign about diseases associated
  with contact with animals

33
Case Study 2
Multistate Outbreak of Monkeypox Illinois,
Indiana, Kansas, Missouri, Ohio, and Wisconsin,
2003MMWR June 13, 2003http//www.cdc.gov/mm
wr/preview/mmwrhtml/mm5223a1.htm
34
Multistate Monkeypox Outbreak Background and
Outbreak Description

• CDC received reports of patients with a febrile
  rash illness in Illinois, Indiana and Wisconsin
• As of June 10, a total of 53 cases identified
• Many reported close contact with pet prairie dogs
  and other animals
• Laboratory tests indicated the causative agent
  was a poxvirus

35
Multi-state Monkeypox OutbreakMethods

• MMWR write-up includes combined data from
  multiple states
• Methods are not detailed
• Laboratory investigation to identify the virus
• Case-patient interviews to determine exposures,
  symptoms, and obtain clinical specimens
• Traceback investigation to identify original
  source of illness

36
Multistate Monkeypox OutbreakLaboratory Results

• CDC tests concluded the virus was monkeypox

37
Multistate Monkeypox OutbreakEpidemiologic
Results

• Demographic information included in report
• 29 cases (49) male
• Median age 26 years (range 4 - 53 years)
• 14 cases (26) hospitalized
• Earliest onset of illness was May 15

38
Multistate Monkeypox Outbreak Epidemiologic
Results
39
Multistate Monkeypox Outbreak Epidemiologic
Results
40
Multistate Monkeypox OutbreakResults
41
Multistate Monkeypox Outbreak Results

• All patients had contact with animals
• 51 of 53 cases reported direct or close contact
  with prairie dogs
• One patient reported contact with a Gambian giant
  rat
• One patient had contact with a rabbit that became
  ill after exposure to an ill prairie dog at a
  veterinary clinic

42
Multistate Monkeypox OutbreakTraceback Results

• Common distributor - prairie dogs and Gambian
  giant rats housed together
• Imported animal records - Gambian giant rats
  shipped from Ghana to a wildlife importer in TX
  and sold to the distributor
• The shipment contained 800 small mammals of 9
  different species

43
Traceback Investigation
44
Multistate Monkeypox OutbreakDiscussion and
Recommendations

• Preliminary findings suggested that the primary
  route of transmission is from close contact with
  infected mammalian pets
• However, the possibility of human-to-human
  transmission cannot be excluded
• Interim guidelines for infection control in the
  community and in health care settings were issued

45
Control Measure Guidelines
46
Comparison of Case Study Reports

• Both outbreak reports included the major
  elements
• Introduction and Background
• Outbreak Description
• Methods and Results
• Lessons Learned
• Recommendations
• Complexity of the report depends on the type of
  investigation, the extent of the outbreak, and
  the audience of the report

47
Summary

• Outbreak reports are the final step in completing
  your investigation.
• Outbreak reports serve many purposes, both
  internally and externally.
• Though outbreak reports may differ in purpose and
  audience, reports generally follow a basic
  structure.

48
References and Resources

• Ashford DA, Kaiser RM, Bates ME, Schutt K,
  Patrawalla A, McShan A, Tappero JW, Perkins BA,
  Dannenberg AL. Planning against biological
  terrorism Lessons from Outbreak Investigations.
  Emerg Infect Dis 20039515-9.
• Conducting an Outbreak Investigation. The North
  Carolina Communicable Disease Control Manual,
  North Carolina Division of Public Health.
  Accessed at http//www.epi.state.nc.us/epi/gcdc/ma
  nual/outbreakinvest.pdf
• Consumers Advised That Recent Hepatitis A
  Outbreaks Have Been Associated With Green Onions.
  FDA Talk Paper. November 15, 2003. Assessed
  10/13/2004 http//www.fda.gov/bbs/topics/ANSWERS/2
  003/ANS01262.html
• Den Boer JW, Yzerman PF, Schellekens J, et al. A
  large outbreak of Legionnaires disease at a
  flower show, the Netherlands, 1999. Emerg Infect
  Dis 2002837-43.

49
References and Resources

• Fontham ETH, Correa P, Wu-Williams A, Reynolds P,
  Greenberg RS, Buffler PA, et al. Lung cancer in
  nonsmoking women a multicenter case-control
  study. Cancer Epidemiol Biomarkers Prev
  1991135-43.
• Gaudet, M. (2003). Suggestions for Critically
  Evaluating an Epidemiologic Study Report.
  Handout developed for the UNC Chapel Hill School
  of Public Health EPID 160 course Principles of
  Epidemiology.
• Goode B. Outbreak of E. coli 0157H7 at the North
  Carolina State Fair 2004. EpiNotes, North
  Carolina Department of Health and Human Services,
  Division of Public Health. Accessed at
  http//www.epi.state.nc.us/epi/pdf/en2004-4.pdf
• Gordis, L. Epidemiology. 2nd ed. Philadelphia WB
  Saunders Company 2000.

50
References and Resources

• Greenberg RS, Daniels SR, Flanders WD, Eley JW,
  Boring JR. Medical epidemiology. 3rd ed. New
  York McGraw-Hill 2001.
• Guidelines for EPI-AID Investigations. Division
  of Applied Public Health Training, Epidemiology
  Program Office, CDC.
• Hepatitis A Outbreak Associated with Green Onions
  at a Restaurant --- Monaca, Pennsylvania. MMWR
  200352(47)1155-1157
• International Committee of Medical Journal
  Editors. Uniform requirements for manuscripts
  submitted to biomedical journals writing and
  editing for biomedical publication. Updated
  November 2003. http//www.icmje.org/ Accessed
  August 19, 2004.
• Last JM, editor. A dictionary of epidemiology.
  4th ed. Oxford University Press 2001.

51
References and Resources

• Levine, S. Redinger, C. and Robert, W. (September
  / October 2001). Community Exposure Assessment
  and Intervention Effectiveness at Trinity
  American Corporation, Glenola, North Carolina.
  American Industrial Hygiene Association Journal.
  62 649-657.
• Massachusetts Foodborne Illness Investigation and
  Control Reference Manual. http//www.state.ma.us/d
  ph/fpprefman.htm
• Millikan B. How to read a scientific article.
  http//cbcs.med.unc.edu/howto.htm Accessed July
  26, 2004.
• Pneumocystis Pneumonia Los Angeles. 1981 MMWR
  30(21)1-3.
• PubMed database, National Library of Medicine.
  Available online at http//www.ncbi.nlm.nih.gov/en
  trez/query.fcgi
• Reigelman RK. Studying a study and testing a
  test how to read the medical evidence. 4th ed.
  Philadelphia Lippincott Williams Wilkins 2000.

52
References and Resources

• Rothman KJ. Modern epidemiology. Boston Little,
  Brown and Company 1986.
• Savitz DA. Interpreting epidemiologic evidence
  strategies for study design and analysis. Oxford
  University Press 2003.
• The Outbreak Investigation Report, power point
  presentation by Arnold Bosman and Meirion Evans.
  Epiet. Accessed at www.epiet.org/course/presentati
  ons2003.html
• Update Multistate Outbreak of Monkeypox
  Illinois, Indiana, Kansas, Missouri, Ohio, and
  Wisconson, 2003. MMWR 52(23)537-540
• Zhong L, Goldberg MS, Parent M, Hanley JA.
  Exposure to environmental tobacco smoke and the
  risk of lung cancer a meta-analysis. Lung Cancer
  2000273-18.
