Kim Breivik

1
EUR Flight Planning Guidance

• Kim Breivik
• Operational Requirements
• Network Management
• EUROCONTROL

2
Filing the Nav Capability
From a PBN perspective As a Pilot or Flight
Dispatch
Identify which to PBN NAV spec approvals you
hold for each phase of flight (from Oceanic to
Approach)
Step 1
Slide 3
Step 2
File R for PBN in Item 10
Enter PBN/ in Item 18 and apply the rules to
reduce the number of indicators in item 18 (max 8)
Step 3
Slide 4
Identify the specific NAV equipment supporting
each Nav Spec and file in Item 10 ensuring
conformity with the content of Item 18
Step 4
Slides 11 12
3
Step 1. - Identify Ops Approvals to PBN Nav Specs.

• Identify all the relevant codes (if any) per
  flight phase

Note () P-RNAV is to be filed as RNAV 1 Note
As P-RNAV is not exactly the same as RNAV 1
operators have a duty of care to ensure they meet
RNAV 1 equipments in other ICAO regions. See
ICAO Doc 9613 for clarification.
4
Step 3. - Apply the rules to reduce the number of
PBN/ indications

• For RNAV 10 and RNP 4, file respectively A1 or L1
• RNAV 5 (B-RNAV)
• B1 to be filed instead of B2, B3, B4, B5 (LORAN
  is not needed/required)
• B6 (LORAN) to be explicitly indicated if ever
  applicable
• For RNAV 2, RNAV 1 and RNP 1
• If DME/DME and DME/DME/IRU capable then only
  file C4, D4 or O4
• e.g. file C4 if C3 and C4 apply, D4 for D3 and D4
  and O4 for O3 and O4
• If all sensors but IRU capable then only file
  C1, D1 or O1
• e.g. file C1 instead of C2 and C4, D1 for D2 and
  D4 and O1 for O2 and O4.
• For RNP APCH only file S1 or S2 (subject to
  capability)
• For RNP AR APCH only file T1 or T2 (subject to
  capability)

5
Step 3 cont. - Apply the rules to reduce the
number of PBN/ indications

• If the number of PBN/ capabilities remains
  greater than 8
• Identify the indications considered to be least
  relevant for the planned flight (from Oceanic to
  Approach)
• e.g.
• Oceanic requirements (A1) for a flight planned
  entirely within continental EUR airspace
• Add Z to Field 10a and insert the least
  relevant indication(s) within NAV/ in Field 18

6
Step 4. - Ensure Item 10 in conformity with PBN
content

• Sensors must be reflected in Field 10 otherwise
  FPL rejection
• For any Nav Spec
• If all sensors or GNSS filed then G must be in
  Field 10
• If all sensors or DME/DME filed then D must be
  in Field 10
• If all sensors or INS/IRU filed then I must be
  in Field 10
• If DME/DME/IRU filed then D and I must be in
  Field 10
• Specific rules relating to RNAV 5 (B-RNAV)
• If filing B1 or B4 then O or S and D must be in
  Field 10

7
(No Transcript)
8
Filing Surveillance Capability (Field 10b)

• Within each of the following categories of
  surveillance capability
• Transponder (Modes A, C, S)
• Only one of the published indicators is required
• ADS-B
• Either B1 or B2, and/or
• Either U1 or U2, and/or
• Either V1 or V2
• ADS-C
• D1 and/or G1
