Chapter 28: The Reproductive System

1
Chapter 28 The Reproductive System

• BIO 211 Lecture
• Instructor Dr. Gollwitzer

2

• Today in class we will
• Compare the male and female reproductive systems
• Discuss cell division
• Compare and contrast mitosis and meiosis
• Discuss gametogenesis (spermatogenesis) in the
  male
• Spermiogenesis
• Spermiation
• Capacitation
• Anatomy of a spermatozoon
• Structures involved in spermiogenesis and their
  roles
• Describe the composition of seminal fluid
• Identify the glands whose secretions contribute
  to the production of seminal fluid
• Discuss male reproductive endocrinology
• Endocrine structures and hormones that regulate
  male reproductive function

3
Reproductive System

• Only organ system not essential to life
• Ensures continued existence of human species
• Produces, stores, nourishes, and transports male
  and female reproductive cells (gametes)
• Produces reproductive hormones

4
Male and Female Reproductive Systems

• Functionally very different
• Female produces 1 gamete/month
• Retains and nurtures zygote
• Male produces large quantities of gametes
• 500M/day!
• Begins at puberty and continues past age 70

5
Male

• Testes (male gonads)
• Produce male gametes (spermatozoa, sperm)
• Produce hormones
• Male sex hormones (androgens, primarily
  testosterone)
• Inhibin
• Emission
• Movement of mature spermatozoa move through male
  duct system, are mixed with secretions of
  accessory glands
• Semen
• Sperm mixed with accessory gland secretions

6
Female

• Ovaries (female gonads)
• Release 1 immature gamete (oocyte) each month
• Produce hormones
• Female sex hormones (estrogens, progestins)
• Inhibin
• Uterine tube carries oocyte to uterus
• If sperm reaches oocyte in uterine tube
• Fertilization is initiated
• Oocyte matures into ovum

7
Reproduction

• During sexual intercourse, ejaculation introduces
  semen into vagina
• Spermatozoa ascend female reproductive tract
• Seek out oocyte (generates heat, attracts sperm
  like heat-seeking missile)
• If fertilization occurs in uterine tube
• sperm ovum ? zygote
• Zygote travels to uterus
• Uterus encloses/supports developing embryo
• Embryo grows into fetus and prepares for birth

8
Gametogenesis

• Involves mitosis and meiosis
• Mitosis
• Process of somatic cell division
• Produces 2 diploid daughter cells
• Have same number of (paired) chromosomes as
  parent cell, i.e., 46 (23 x 2)
• Meiosis reduction division
• Special cell division involved in gamete
  production
• Produces 2 haploid daughter cells
• Have one-half (unpaired) the number of
  chromosomes in the parent cell, i.e., 23

9
Chromosomes in Mitosis and Meiosis
Figure 286
10
Gametogenesis

• Meiosis
• Involves two cycles of cell division
• Chromosomes (each with two chromatids) pair up
  tetrad
• During first division, tetrads split
• During second division, chromatids split
• Produces gametes with one-half the number of
  chromosomes, i.e., 23
• Fusion of male gamete (sperm) and female gamete
  (oocyte) produces cell with correct number of
  chromosomes (diploid), i.e., 46 (23 from each
  parent)

11
Gametogenesis
Stem cell Spermatogonium Oogonium
Mitotic division ? Primary spermatocyte Stem cell Primary oocyte
Meiosis I ? Secondary spermatocytes Secondary oocyte polar body
Meiosis II ? Spermatids (undifferentiated Male gametes) Ovum polar body (after fertilization)
Spermiogenesis ? Spermatozoa (sperm)
12
Spermatogenesis

• Occurs in seminiferous tubules (ST) in testes
• 3 integrated processes
• Mitosis
• Meiosis
• Spermiogenesis

13
Spermatogenesis

• Mitosis
• Spermatogonium (stem cell) ? spermatogonium
  primary spermatocyte
• Primary spermatocyte pushed toward lumen of ST
• On-going throughout lifetime
• Meiosis
• Primary spermatocyte ? first division ? secondary
  spermatocytes ? second division ? spermatids
  undifferentiated male gametes
• Each primary spermatocyte ? 4 spermatids

14
Spermatogenesis

• Spermiogenesis
• Last stage of spermatogenesis
• Begins with spermatids
• Small, relatively unspecialized cells
• Physical maturation of spermatids
• Involves major structural changes
• Differentiate into mature spermatozoa
• Highly specialized cells

15
Figure 28-7, 7th edition
16
Spermiation

• When spermatozoa
• Detach from Sertoli cells
• Enter lumen of ST
• From spermatogonium to spermiation
• 9 weeks

17
Seminiferous Tubules
Figure 285a
18
Seminiferous Tubules
Figure 285d
19
Spermiogenesis and Spermatozoon Structure
Figure 288
20
Anatomy of a Spermatozoon

• Head nucleus with chromosomes (DNA)
• Acrosomal cap contains enzymes to dissolve
  oocyte wall
• Middle piece contains mitochondria for energy
  to move tail
• Tail flagellum (only 1 in human body) provides
  motility
• Loses all other organelles to make light weight
• No energy reserves must use nutrients from
  surrounding fluid (primarily fructose)

21
Interstitial (Leydig) Cells

• Large cells in interstitial spaces between ST
• Stimulated by LH ? androgens (testosterone, T)
• Testosterone
• Stimulates spermatogenesis and spermatozoa
  maturation
• Affects CNS, including libido (sexual drive)
• Stimulates metabolism, especially protein
  synthesis, muscle growth
• Establishes/maintains secondary sex
  characteristics, e.g., facial hair
• Maintains male accessory glands and organs

22
Seminiferous Tubules
Figure 285b,c
23
Sustentacular (Sertoli) Cells

• Nurse cells
• Extend between other cells from ST capsule to
  lumen
• Surround developing spermatocytes and spermatids
  in ST
• 6 major functions
• Maintain blood-testis barrier
• Support mitosis and meiosis
• Support spermiogenesis
• Produce inhibin
• Produce androgen-binding protein (ABP)
• Secrete Mullerian-inhibiting factor (MIF)

24
Sustentacular (Sertoli) Cells

• Maintain blood-testis barrier
• Cells joined by tight junctions
• Isolates STs
• Support mitosis and meiosis
• Cells stimulated by FSH (and presence of T)
• Promote spermatogenesis
• Support spermiogenesis
• Provide nutrients for development
• Phagocytize cytoplasm shed by spermatids

25
Sustentacular (Sertoli) Cells

• Produce inhibin
• Stimulated by factors released by developing
  spermatozoa
• Provides feedback control of spermatogenesis
• Inhibits (decreases) production of FSH by AP
• Produce androgen-bind protein (ABP)
• Stimulated by FSH
• Binds T in ST fluid, elevates levels
• Produce Mullerian-inhibiting factor (MIF)
• Causes regression of fetal ducts that form
  uterine tubes and uterus

26
Epididymis

• Spermatozoa in ST functionally immature
• Incapable of fertilization or locomotion
• Become functionally mature in epididymis (but,
  not motile)
• Fluid currents (from cilia lining efferent
  ductules) transport immobile gametes into
  epididymis
• Functions
• Monitors and adjusts composition of ST fluid
• Recycles damaged spermatozoa
• Stores/protects spermatozoa and facilitates
  functional maturation
• Transit time two weeks

27
Figure 28-9a, b
28
NOTE

• To become motile, spermatozoa must undergo
  capacitation
• Become motile when mixed with seminal vesicle
  fluid
• Capable of successful fertilization when exposed
  to female reproductive tract

29
Ductus (Vas) Deferens

• Transport spermatozoa from epididymis to urethra
• Store spermatozoa (several months)
• In state of suspended animation
• Low metabolic rates

30
Figure 28-10a
31
Seminal Fluid

• A mixture of secretions from several glands
  including
• Seminal vesicles (60)
• Prostate gland (20-30)
• Bulbourethral glands (10-20)

32
Seminal Vesicles

• Secretions contain
• High concentrations of fructose (easily
  metabolized by spermatozoa)
• Prostaglandins stimulate smooth muscle
  contractions in male and female reproductive
  tracts
• Fibrinogen forms temporary clot in vagina after
  ejaculation (seminal plug)
• Secretions make functional spermatozoa motile
  (flagella begins beating)
• Secretions discharged into ejaculatory duct at
  emission (due to contractions in ductus deferens,
  SVs, and prostate gland)

33
Prostate Gland

• Produces prostatic fluid
• Contains seminalplasmin antibiotic that may
  help prevent urinary tract infections
• Ejected into prostatic urethra

34
Bulbourethral (Cowpers) Glands

• Mucous glands
• Secretions
• Help neutralize urinary acids remaining in
  urethra
• Lubricate glans (tip of) penis

35
Semen

• Ejaculate 2-5 mL of semen
• Contains
• Spermatozoa
• Sperm count 20 100 million/mL semen (ideally
  gt 60 million/ejaculate)
• Seminal fluid mixture of glandular secretions
  from
• SV (60)
• Prostate (30)
• Bulbourethral glands (5)
• Sustentacular cells and epididymis (5)
• Enzymes
• Protease helps dissolve vaginal mucous
  secretions
• Seminalplasmin (from prostate)
• Prostatic enzyme - converts fibrinogen to fibrin
  after ejaculation
• Fibrinolysin liquefies clotted semen

36
Male Reproductive Endocrinology

• Hypothalamus ? GnRH ? ant pit
• Ant pit ?
• LH (ICSH) ? interstitial (Leydig) Cells ?
  testosterone (T)
• FSH
• Testosterone FSH ? sustentacular cells ?
• Synthesis of ABP
• Stimulation of spermatogenesis and spermiogenesis
• Factors released by developing spermatozoa ?
  sustentacular cells ? inhibin ? inhibits
  (decreases) FSH production by AP

37
Physiological Effects of Testosterone

• Stimulates spermatogenesis (with FSH)
• Maintains male accessory glands and organs
• Establishes/maintains secondary sex
  characteristics
• Stimulates anabolic metabolism, especially bone
  and muscle growth, RBC formation
• On CNS, including libido (sexual drive)

38
Male Reproductive Endocrinology

• In males, GnRH pulse frequency relatively steady
  ? narrow range of plasma FSH, LH, T
• T secretion accelerates at puberty ?
• Sexual maturation
• Appearance of secondary sex characteristics
• Negative feedback controls T production
• Inc T ? inhibits release of GnRH ? dec LH ?
  dec T

39
Figure 28-12
40

• Today in class we will discuss
• The female reproductive system
• Gametogenesis (oogenesis) in the female
• Compare oogenesis to spermatogenesis
• The events and structural changes associated with
  the ovarian cycle
• The structure and histology of the uterus
• The events and structural changes associated with
  the uterine (menstrual) cycle
• Discuss female reproductive endocrinology
• Endocrine structures and hormones that regulate
  female reproductive function
• Aging and the reproductive system of males and
  females

41
Female Reproductive System

• Produces gametes and reproductive hormones
• Protects and supports developing embryo
• Nourishes newborn infant

42
Oogenesis

• Ovum production
• Begins before birth, accelerates at puberty, ends
  at menopause
• Occurs monthly between puberty and menopause

43
Gametogenesis
Stem cell Spermatogonium Oogonium
Mitotic division ? Primary spermatocyte Stem cell Primary oocyte
Meiosis I ? Secondary spermatocytes Secondary oocyte polar body
Meiosis II ? Spermatids (undifferentiated Male gametes) Ovum polar body (after fertilization)
Spermiogenesis ? Spermatozoa (sperm)
44
Oogenesis vs. Spermatogenesis

• Before birth
• Mitotic divisions complete
• Oogonia (stem cells) ? primary oocytes (vs.
  ongoing throughout lifetime in males)
• Primary oocytes begin meiosis I
• Cytoplasm of oocyte unevenly distributed during 2
  meiotic divisions produces
• One functional ovum (with most of original
  cytoplasm)
• 2-3 polar bodies nonfunctional cells that later
  disintegrate (vs. primary spermatocyte ? 4
  spermatozoa)
• Ovary releases secondary oocyte instead of mature
  ovum
• Meiosis not completed unless/until fertilization

45
Figure 28-15, 7th edition
46
Primary Oocytes

• Are daughter cells of oogonia (stem cells)
• Located in ovarian cortex in clusters (egg nests)
• Surrounded by follicle cells primordial
  follicle
• 2 M primary oocytes at birth
• Meiosis I (primary oocyte ? secondary oocyte)
• Begins during fetal development
• Stops early in meiosis I (suspended development)
• Doesnt continue until after puberty (numbers
  reduced to 400,000 due to atresia)

47
Ovarian Cycle

• Begins after puberty when groups of primordial
  follicles develop into primary follicles each
  month
• Process begins due to increased FSH at puberty
• Involves 2 phases
• Follicular (preovulatory) phase
• Luteal (postovulatory) phase

48
Ovarian Cycle
Figure 28-16
49
Ovarian Cycle Follicular Phase

• Formation of primary follicles
• Every month AP ? FSH ? some primordial follicles
  (with primary oocyte) ? primary follicles (with
  primary oocyte)
• Zona pellucida glycoprotein layer around
  primary oocyte
• Granulosa cells rounded, larger follicle cells
  outside zona pellucida
• Thecal cells layer of follicle cells adjacent
  to ovarian stroma
• Granulosa thecal cells work together ? estrogen
  (continues in all follicles)

50
Ovarian Cycle Follicular Phase

• Formation of secondary follicles
• Each month, only a few (1-3) primary follicles
  become secondary follicles
• Primary oocyte increases in size
• Follicle wall thickens
• Granulosa cells secrete follicular fluid
• Follicle enlarges rapidly as follicular fluid
  accumulates

51
Ovarian Cycle Follicular Phase

• Formation of tertiary follicle
• 8-10th day after start of ovarian cycle, ovaries
  usually contain 1 secondary follicle
• On 10-14th day, forms large tertiary (Graafian)
  follicle
• Tertiary follicle spans cortex? bulge on surface
  of ovary
• Oocyte projects into antrum (central chamber of
  follicle)

52
Ovarian Cycle Follicular Phase

• At end of tertiary follicle development, inc LH ?
  primary oocyte
• Completes meiosis I (just before ovulation)
• Primary oocyte ? (meiotic division) ? secondary
  oocyte and polar body
• Secondary oocyte enters meiosis II then stops
  (not completed unless fertilization occurs)
• Day 14 (of 28-day cycle), secondary oocyte and
  surrounding granulosa cells (corona radiata) lose
  connections with follicular wall

53
Ovulation

• Tertiary follicle (ovarian) wall ruptures
• Secondary oocyte released into pelvic cavity
• Sticky follicular fluid keeps corona radiata
  attached to ovary surface
• Comes in contact with fimbriae, or
• Fluid currents transfer secondary oocyte to
  uterine tube
• Marks end of ovarian follicular phase and start
  of luteal phase

54
Ovarian Cycle Luteal Phase

• Involves formation and degeneration of corpus
  luteum (CL)
• Empty tertiary follicle collapses, ruptured blood
  vessels leak into antrum ? corpus hemorrhagicum
  (bloody body)
• LH stimulates remaining granulosa cells ?
  proliferate ? corpus luteum (CL, yellow body)
• CL ?
• Progesterone principle ovarian hormone after
  ovulation
• Small amount of estrogen (principle hormone
  before ovulation)

55
Ovarian Cycle Luteal Phase

• Progesterone
• Primary function is to prepare uterus for
  pregnancy
• Stimulates
• Development of uterine lining (endometrium)
• Secretions of uterine glands

56
Ovarian Cycle Luteal Phase

• In absence of fertilization
• CL begins to degenerate 12 days after ovulation
• Estrogen and progesterone levels fall
• Fibroblasts invade corpus luteum ? corpus
  albicans (white body)
• Disintegration (involution) of corpus luteum
  marks end of ovarian cycle
• FSH ? new cycle and new follicular phase
• Another group of primordial follicles form
  primary follicles

57
Uterine Tube

• Lined with mucosal membrane ? mucus
• Mucosa surround by layers of smooth muscle
• Secondary oocyte transport involves
• Ciliary movements
• Peristaltic contractions
• From infundibulum to uterine cavity
• Normally takes 3-4 days
• Fertilization
• Occurs near boundary between ampulla and isthmus
• Must happen during first 12-24 hours
• Nutrients (lipids, glycogen) supply spermatozoa
  and developing oocyte

58
Uterine Wall

• Provides for developing embryo (weeks 1-8) and
  fetus (week 9 through delivery)
• Protection
• Nutritional support
• Waste removal
• Has 3 layers
• Perimetrium
• Myometrium
• Endometrium

59
Uterine Wall

• Perimetrium
• Serous membrane that covers outer surface of
  uterus
• Continuous with peritoneal lining of
  abdominopelvic cavity
• Myometrium
• Thick layers of smooth muscle
• Longitudinal, circular, oblique layers
• Provides force needed to move fetus out of uterus
  and into vagina
• Arteries
• Arcuate ? radial arteries (in myometrium) ?
  straight ? spiral (endometrium)

60
Figure 28-19
61
Uterine Wall

• Endometrium
• Thin glandular, vascular layer
• Lines surface of uterine cavity
• Supports physiological demands of (potential)
  fetus
• Under influence of estrogen
• Uterine glands, blood vessels, and epithelium
  change with phases of monthly uterine cycle
• Has 2 zones
• Basilar
• Functional

62
Uterine Wall

• Basilar zone
• Outer zone, adjacent to myometrium
• Attaches endometrium to myometrium
• Contains
• Terminal branches of uterine glands
• Straight arteries
• Structure remains constant over time
• Functional zone
• Closest to uterine cavity thickest
• Contains most of uterine glands
• Blood supply provided by spiral arteries
• Undergoes cyclical changes in response to sex
  hormones
• Degeneration, sloughing ? menses

63
Uterine (Menstrual) Cycle

• Repeating series of changes in structure of
  endometrium
• In response to ovarian hormones (E and P)
• Average length 28 days (range 21-35)
• 3 phases
• Menses - occurs during early follicular phase of
  ovarian cycle
• Proliferative phase - occurs during later
  follicular phase of ovarian cycle
• Secretory phase corresponds to luteal phase of
  ovarian cycle

64
Figure 28-20, 7th edition
65
Uterine (Menstrual) Cycle

• Menses
• Marks beginning of uterine cycle (Day 1)
• Degeneration and loss of entire functional zone
  of endometrium
• Caused by constriction of spiral arteries ?
  reduced blood flow to endometrium ? no O2 or
  nutrients
• Secretory glands deteriorate
• Arterial walls rupture
• Blood cells and degenerated tissues break away
  and enter uterine lumen, vagina

66
Uterine (Menstrual) Cycle

• Menstruation
• endometrial sloughing
• Lasts 1-7 days
• Lose small amount of blood (35 50 mL)
• Dysmenorrhea
• Painful menstruation
• Due to uterine inflammation and contraction (due
  to prostaglandins)
• Other conditions of pelvic structures

67
Uterine Cycle

• Proliferative phase
• After menses (Days 8-14)
• Increase in basilar uterine gland cells
• Further growth and vascularization ? restoration
  of functional zone
• Occurs at same time as enlargement of primary and
  secondary follicles in ovary (follicular phase)
• Phase stimulated and sustained by E from ovarian
  follicles

68
Uterine Cycle

• Secretory phase
• Begins at ovulation (Day 14)
• Lasts as long as CL (14 days)
• Occurs in response to CL ? P and E
• Endometrial glands enlarge
• Arteries elongate and spiral through functional
  zone
• Secretory activities peak 12 days after ovulation
• CL stops producing P and E
• Glandular activity declines over next 1-2 days
• Uterine cycle ends (Day 28, 14 days after
  ovulation)
• New cycle (Day 1) begins with disintegration of
  functional zone ? menses

69
Uterine Cycle

• Menarche
• First uterine cycle at puberty (approx age 11-12)
• Amenorrhea no menses
• Primary amenorrhea
• Secondary amenorrhea

70
Uterine Cycle

• Primary amenorrhea
• Failure to initiate menses no menarche
• Caused by
• Developmental abnormalities (e.g. nonfunctional
  ovaries, absence of uterus)
• Endocrine or genetic disorder
• Malnutrition
• Secondary amenorrhea
• Menses interrupted for gt 6 months
• Caused by
• Physical stresses (e.g., drastic weight loss,
  anorexia nervosa, intensive physical training
  (marathon runners))
• Emotional stresses (e.g., severe depression,
  grief)

71
Female Reproductive Endocrinology

• Female reproductive tract under control of
  pituitary and ovaries
• Much more complicated than in males (have to
  coordinate both ovarian and uterine cycles)
• If not coordinated, infertility results
• Uterus normal but do not ovulate
• Ovulate but uterus abnormal

72
Hormones and Female Reproductive Function

• GnRH from Hth regulates reproductive function
  (like males)
• But, GnRH amount and release frequency changes
  throughout ovarian cycle (constant in males)
• GnRH ? FSH and/or LH depending on pulse frequency
  and amount secreted
• Change in GnRH controlled by estrogen and
  progesterone

73
Figure 28-25-1
74
Hormones and Female Reproductive Function

• FSH
• ? Monthly development of some primordial
  follicles into primary follicles
• As secondary follicles develop, FSH dec due to
  negative feedback effects of inhibin (produced by
  granulosa cells)
• Follicular development/maturation continues,
  supported by FSH, E, and LH

75
Hormones and Female Reproductive Function

• Estrogens (E)
• Follicle and thecal cells work together ? E
• Dominant hormones prior to ovulation
• Rise sharply as tertiary follicle begins forming

76
Hormones and Female Reproductive Function

• Physiological effects of E
• Stimulates endometrial growth and secretion
• Maintains accessory glands and organs
• Establishes/maintains female secondary sex
  characteristics
• Body hair distribution, fat deposits
• Stimulates bone and muscle growth
• Affects CNS (esp. Hth ? E inc sex drive)

77
Hormones and Female Reproductive Function

• LH
• Sudden surge released in response to high E
• Triggers
• Completion of meiosis I by primary oocyte (in
  tertiary follicle) ? secondary oocyte
• Rupture of follicular wall
• Ovulation (9 hours after LH peak)

78
Hormones and Female Reproductive Function

• Progesterone
• Secreted by CL in response to LH peak
• Dominant hormone after ovulation (as P inc, E
  dec)
• Primary function prepare uterus for possible
  pregnancy
• Increases endometrium functional zone
• Growth
• Secretion
• Blood supply
• Remains high for 7 days
• Declines as CL degenerates (when pregnancy
  doesnt occur)
• Decreased P and E initiates menses and inc GnRH
• GnRH stimulates FSH, etc.

79
Hormones and Female Reproductive Function

• Inhibin
• Secreted by follicular cells
• Inhibits FSH production and secretion

80
Figure 28-25-5
81
Hormones and Body Temperature

• Monthly hormonal fluctuations affect core body
  temperature
• Basal body temp lower during follicular phase,
  when E dominant hormone
• Decreases at ovulation
• Large increase during luteal phase, when P
  dominates
• Use to plan/avoid fertilization

82
Figure 28-25-6
83
Successful Function of Female Reproductive System

• Ovarian and uterine cycles must coordinate
  properly
• Ovulation and oocyte transport must occur
  normally
• Environment of reproductive tract must support
• Survival and movement of sperm
• Fertilization of oocyte
• Maintenance of pregnancy
• Embryonic and fetal development

84
Successful Function of Male Reproductive System

• Sperm count must be adequate
• Semen must have correct pH and nutrients
• Erection and ejaculation must function properly
• Physiology of Sexual Intercourse
• Coordinated by complex neural reflexes
• FYI - see text (p. 1068-1069)

85
Aging and the Reproductive System

• Menopause
• Occurs at age 45-55
• Time when ovulation and menstruation cease
• No primordial follicles left to respond to FSH
• E and P decrease
• GnRH, FSH, LH increase
• Accompanied by variety of physiological effects
  (p. 1069-1070)

86
Aging and the Reproductive System

• Male climacteric (andropause)
• Occurs at age 50-60
• Period of declining reproductive function
• T decreases
• FSH and LH increase
• Sperm production continues (into 80s) but sex
  drive reduced
