The Neutrino Flux At MiniBooNE.

1
The Neutrino Flux At MiniBooNE.
2
The BooNE Collaboration

• Y. Liu, I. Stancu
• University of Alabama, Tuscaloosa, AL 35487
• S. Koutsoliotas
• Bucknell University, Lewisburg, PA 17837
• E. Hawker, R. A. Johnson, J. L. Raaf
• University of Cincinnati, Cincinnati, OH 45221
• T. Hart, R. H. Nelson, E. D. Zimmerman
• University of Colorado, Boulder, CO 80309
• A. A. Aguilar-Arevalo, L. Bugel, J. M. Conrad,
• J. Formaggio, J. Link, J. Monroe, D. Schmitz,
• M. H. Shaevitz, M. Sorel, G. P. Zeller
• Columbia University, Nevis Labs, Irvington, NY
  10533
• D. Smith

• D. Cox, A. Green, H. Meyer, R. Tayloe
• Indiana University, Bloomington, IN 47405
• G. T. Garvey, C. Green, W. C. Louis, G. A.
  McGregor,
• S. McKenney, G. B. Mills, V. Sandberg, B. Sapp,
• R. Schirato, N. Walbridge, R. Van de Water, D. H.
  White
• Los Alamos National Laboratory, Los Alamos, NM
  87545
• R. Imlay, W. Metcalf, M. Sung, M. O. Wascko
• Louisiana State University, Baton Rouge, LA 70803
• J. Cao, Y. Liu, B. P. Roe
• University of Michigan, Ann Arbor, MI 48109
• A. O. Bazarko, P. D. Meyers, R. B. Patterson,
• F. C. Shoemaker, H. A. Tanaka
• Princeton University, Princeton, NJ 08544

3
MiniBooNE Overview
The FNAL Booster delivers 8 GeV protons to the
MiniBooNE beamline. The protons hit a beryllium
target producing pions and kaons. The magnetic
horn focuses the secondary particles towards the
detector. The mesons decay, and the neutrinos
fly to the detector.

• Signal from pm nm then nm ne which
  produces e- in the detector.

4
Meson Production in the Target

• Sanford-Wang parameterizations (pions)
• Cho Fit.
• K2K Fit.
• JAM Fit (MiniBooNE internal).
• MARS Monte Carlo (pions and kaons).
• GFLUKA Monte Carlo (pions and kaons).

MARS does not store neutral kaons and so these
are constructed from K using the GFLUKA K0L/K
yield ratio.
5
Sanford-Wang Parameterization

• Empirical parameterization with 8 free
  parameters

where Pp is the momentum of the pion. Pp is the
momentum of the proton. Tp is the production
angle of the pion in the lab frame. c1-8 are the
parameters determined by fitting to available
data.
6
Detector Pion Acceptance
momentum
angle
MARS production model used.
7
S-W Fit Results
MiniBooNE fit (Jocelyn Monroe, Columbia
University) used the following data Vorontsov,198
3. Cho, 1971. Marmer, 1969. Dekkers, 1964
(subset).
8
Vorontsov 1983.
9
Cho 1971.
10
Marmer 1969.
11
Dekkers 1964.
12
Beamline Modeling

• GEANT 4 Monte Carlo used for beam simulations.
• Meson productions models from external sources
  (MARS, GFLUKA, S-W etc.) are implemented within
  G4.
• GEANT 4 implementation principally by Michel
  Sorel, Columbia University.
• Neutrino flux which intersects the detector is
  boosted by redecaying mesons.

13
GEANT 4 Geometry
14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
Horn Field Simulation

• Horn provides a 7 increase in the flux and it is
  therefore necessary to check the motion of
  charged particles in its magnetic field.
• Horn field was mapped during testing 300
  positions between inner and outer conductor were
  mapped.
• G4 results have been checked, and agree, with a
  standalone calculation based on the CERNLIB
  routine DRKNYS (numerical integration routine).

20
(No Transcript)
21
(No Transcript)
22
G4 Neutrino Flux Predictions
23
E910 Data

• Data taken on Au, Cu, Pb, U and Be.
• Be data taken at momenta of 17.5, 12.3 and
  6.4GeV.
• About 1M events at 12.3GeV.
• Unfortunately only about 5k events at 6.4GeV.
• Currently analyzing 12.3 and 6.4GeV data.
• Initial Sanford-Wang parameterization results
  look encouraging.

24
HARP (PS214) Data
Secondary particle production from 8 GeV protons
on an actual MiniBooNE target has been measured
at HARP.
Over 5 million interactions have been
recorded. Analysis of data has started.
25
Detector Response

• NUANCE Monte Carlo used to model particle
  production in the MiniBooNE detector.
• BooDetMC used to simulate detector response
  (GEANT 3 based).
• Uncertainties associated with each of these.

26
CC ?µ Quasi-elastic data

• Abundance 40.
• Simple topology.
• Kinematics give E? and Q2 from Eµ and Tµ.

27
preliminary
CC ?µ Quasi-elastic
Selection based on PMT hit topology and timing.
Variables combined in a Fisher discriminant,
yielding 88 purity in remaining dataset. Data
and MC relatively normalized.
Yellow band Monte Carlo with current uncertaintie
s from

• flux prediction.
• sCCQE
• optical properties.

28
preliminary
CC ?µ Quasi-elastic
CC ?µ energy resolution.
lt10 for E?gt800 MeV
29
Resistive Wall Monitor
30
Utilizing RWM Timing
The goal is to combine the RWM bunch timing with
the reconstructed event time in the detector to
identify different classes of events.

• Given that
• all mesons do not travel at the same speed.
• prompt detection of interaction does not always
  occur.

The timing distributions of events with respect
to the beam may vary for different event samples.
Intrinsic smearing and resolutions may be a
problem to achieve powerful discrimination.
31
The RF Bucket Structure
unofficial

• t1 and t2 are the midpoints to adjacent buckets.

32
Muon Sample Example
unofficial
33
Conclusions

• Lots of work ongoing on the neutrino beam
  simulation.
• Shape agreement between data and MC is
  reasonable.
• E910 and especially HARP data should provide an
  accurate description of target meson production.

34
n Flux at the Detector
preliminary
Pion contribution from JAM S-W parameterization.
MARS/GFLUKA for kaon contribution.
