Topic 1: Introduction to Enterprise Systems Engineering

1
Topic 1 Introduction to Enterprise Systems
Engineering

• Chin-Sheng Chen
• Florida International University

2
Outline

• Course objective and goal
• ESE definition
• Business environment
• Enterprise operation modes
• Enterprise production process
• Enterprise systems
• Enterprise operation system of future

3
Course Objective Goal

• Study the nature, behavior, and function of an
  enterprise operation
• Build a theoretical and scientific science
  foundation for study of (the integrative and
  collaborative nature of) enterprise behavior in
  global economy.
• Develop frameworks and components for building an
  enterprise system

4
Enterprise Systems Engineering (ESE)

• Definition
• ESE develops and applies systems engineering
  tools and techniques to planning, specification,
  modeling, analysis, design, implementation, and
  operation of an enterprise system in its life
  cycle.

5
Enterprise system layers

• Layers (subsystems)
• Physical system
• In physical existence in a company
• Managerial system
• A manual system put in place to run a company
• It may choose not to manage some physical system
  elements
• Certain computer tools may be in use to assist
  the manual managerial system
• Computerized managerial system
• It computerizes the managerial system as a
  replacement and/or to supplement the manual
  system.
• It may be equipped with on-line application tools
  and decision support systems.
• Interfaces
• Between/within the physical, manual, and
  computerized systems
• Communication
• Data collection/entry
• Report
• Control

6
Major operation modes

• Make-to-stock (MTS)
• Accept no back orders
• Continuous
• Batch
• Just-in-time
• Accept back-orders
• Make-to-order (MTO) for back orders only
• Assemble-to-order (ATO)
• Build-to-order (BTO)
• Engineer-to-order (ETO)
• Develop-to-order (DTO)

7
MTS Background

• Traditional operation assumptions
• Repetitive demand for a product
• Real orders come from distribution centers
• Product is optimally designed and thus a bill of
  materials (BOM) is available
• Process plan is optimally designed for volume
  production of a fixed lot size.
• Production facility is set up for continuous or
  repetitive (batch) production.
• Labor are single skilled and readily trained
• SQC is used to manage the quality and the
  throughput quantity of each production.

8
MTS
9
Paradigm Shift

• Todays business environment
• Innovation
• Shortened product life cycle shortened product
  development cycle
• concurrent engineering
• Frequent changes agile operations
• mass customization
• Smaller lots and just-in-time production
• lean manufacturing/thinking
• Core business and supply network
• Internet and wireless integration
• Global economy and corporate intelligence

10
Concurrent engineering concurrent operations

• Shortened work lead time
• Incremental/parallel work planning
• Re-active/dynamic work scheduling
• On-line monitoring
• Real-time control
• Shortened material lead time
• Shortened acquisition lead time
• Incremental material planning
• Pro-active material acquisition
• SCM

11
Mass customization

• Product development
• Unique product design of known family
• Unique production process with known operation
  types
• No extra product and few spare parts made
• Frequent engineering (product process) changes
• Project management
• Tight and rigid delivery commitment
• Hierarchical work structure
• Progressive work planning execution

12
Lean Manufacturing/Concept

• Create value through its value stream by
  eliminating waste
• A waste is an activity that consumes resources
  but creates no values.
• The value stream may reach products entire
  supply and service chains.
• Much related to the ABC and the life cycle concept

13
Expanded Life cycle concept

• Product life-cycle phases
• Customer need
• Product specification
• Product functional design
• Production (process) design
• Component fabrication
• Product assembly
• Product delivery
• Product in operation (service)
• Product disposal

14
MTO Categorization
15
(No Transcript)
16
Order Fulfillment Process
17
Comparison of Operation Modes
18
MTO differentiation

• Work contents
• ATO
• Only assembly effort
• Components available
• Product and process available
• BTO
• ATO component manufacturing
• Product and process available
• ETO
• BTO engineering
• Product specification available
• DTO
• ETO product specification
• Customer need available

19
ATO
20
BTO
21
(No Transcript)
22
DTO
23
Hierarchical and Incremental Planning
24
(No Transcript)
25
(No Transcript)
26
Capacity Planning
Resources are grouped in buckets, by production
phase and timeline
27
Capacity Planning
Buckets are refined to smaller sizes by smaller
resources and time units, as work is being
decomposed into smaller units (deliverables,
tasks and operations)
28
Detailed scheduling
Each resource instance is associated with a
specific work unit, abiding by the two classical
scheduling principles. That is, each machine can
process only one job and each job can be on one
machine at a time
29
Operation control

• Project control (work orders)
• Control of quality, lead time, and cost of work
  within a project
• Shop floor control (resources)
• Control of the use of resources for work orders

30
PLM

• Project data management
• Sales data
• Product data
• Manufacturing/test data
• Operation/service data
• Workflow management
• Work flow during
• Work flow during operation/service

31
Current PDM systems

• Evolution
• CAD
• PDM
• PLM
• Commercial systems
• Matrix-one
• Windchill/ProE
• Iman/Metaphase/MFG Center/UG
• Enovia/Catia

32
Current ERP Systems

• Evolution
• MRP I
• MRP II
• ERP I
• ERP II
• Systems
• SAP
• Oracle/Peoplesoft/JD Edwards
• Baan

33
Current Project Management Systems

• Evolution
• Individual user
• Enterprise user
• Commercial systems
• M/S project
• Primevera

34
Current MES Systems

• Evolution
• Shop floor monitoring control
• Manufacturing execution
• From production order
• To shipping
• Commercial systems
• Real-track
• Valor

35
Enterprise operations system of future

• Integrative functions of
• MRP/ERP
• MES
• PDM/PLM
• Project management

36
Impact to the society

• Automation (mechanization and computerization)
• NC/CNC/CAM affects/replaces labor and skilled
  workers
• CAD/PDM affects/replaces technicians and
  engineers
• ERP affects/replaces middle-layer supervisors and
  managers
• Supply chains (outsourcing) affect/replace
  non-core departments
• Global sourcing
• Affects/eliminates many domestic manufacturing
  industries
• Started affecting some service industries as well
• Opportunity
• Certain manufacturing industries
• That require proximity to the market or have
  national security concerns.
• Most service industries
• New product and technology development, market
  study (need analysis)
• Entrepreneurship

37
T1 Homework

• Develop a diagram that integrates all business
  functions to enable the support for various
  operation modes as discussed in class.
• View FIU as a business of education,
• identify its mission, value, vision, goal, and
  strategy
• Identify its core business, major business
  functions, and operation mode(s)
• Develop a framework (diagram) for one of its core
  business (and its operation mode (as an as-is
  model).
• Use the flowchart diagrams given in class as a
  template
• Framework is a basic arrangement, form, system,
  or systematic taxonomy of concepts for relating
  things in the real world to a presentation (in
  the computer world).
• Critique/justify the framework effectiveness in
  support for the above vision and goal/objective,
  considering FIUs business environment (referring
  to the paradigm shift slide) and competitors
• Due date Next Week
