Title: Automated Electromagnetic Crane


1
Automated Electromagnetic Crane
  • Greg DeKing
  • Fran Simmonds

2
Principles of Design
  • Functionality
  • Mechanical Design
  • Sensor Design
  • Embedded Design
  • Cost
  • Problems
  • Questions

3
Functionality
  • The Automated Electromagnetic Crane locates,
    acquires, and removes steel blocks from a target
    area to a designated container in an
    uninterrupted sequence.

4
Specifications
  • Runs in fully automated mode.
  • User may pause operation and move blocks.
  • All blocks are relocated after every grab
    operation.
  • Closest-to-bucket order of pickup.

5
Limitations
  • All blocks must be fully inside target area.
  • If a block is dropped the drop operation will
    still proceed.
  • Blocks must be of a conductive material with a
    strong magnetic field.

6
Designer imposed constraints
  • High success rate.
  • Sensors.
  • Low cost.
  • Stationary.
  • Battery power.

7
Components
  • HC12
  • Duramag ER1-071 Electromagnet
  • 3 12V Stepper Motors
  • 8 74151 8-1 Mux
  • OPB 745 Optoisolator

8
Duramag ER1-071 Electromagnet
9
Motors
  • 12V Airpax stepper motor
  • 2 12V NMB stepper motors
  • Stepper interface boards

10
Optoisolator
  • Inductive spike caused from switching magnet off.
  • 25.5 Volt magnitude.
  • Separate 12V source.
  • Magnet on/off controlled by optoisolator circuit.

11
Mechanical Design
12
Mastercam side view
13
Mechanical Design
14
Tower Support
15
Mastercam -- top view
16
Sensor Placement
17
Sensor Design
  • Conductive rings separated by non-conductive
    material
  • Inside rings of row in series
  • Outside rings of column in series

18
Sensor Function
  • Input signal applied to inner ring
  • Block completes circuit
  • Corresponding mux control
  • HC12 reads voltage hit

1 0
19
Interfacing
HC12
PORT A
PORT B
PORT T
PORT AD
PORT P
8
8
3
4
PAUSE
MULTIPLEXER SYSTEM
8
MOTOR CONTROL BOARDS
OPTOISOLATOR
SENSORS/ TARGET AREA
MOTORS
DIRECTION
DISTANCE
VERTICAL
20
MULTIPLEXER SYSTEM
PORT AD
3
8-1
8-1
8-1
8-1
8-1
8-1
8-1
8-1
COLUMN 0-7
8
SENSORS / TARGET AREA
21
Sensor Map
  • 37 bytes.
  • Each byte 1 Column.
  • Each bit represents row number.
  • Sensor sweep will fill sensor map one row at a
    time.
  • When all 37 columns for each row complete next
    row will begin.

22
Embedded Design
  • begin read AD
  • store AD in TEMP
  • change MUX controls
  • Loop ITERATION 1
  • bit test bit 0
  • branch bit not set to next
  • set bit MAP_POINTER BIT_POINTER
  • next MAP_POINTER 1
  • Shift TEMP
  • Test ITERATION
  • branch less than 8 to loop
  • ITERATION 0
  • Test MAP_POINTER
  • Branch less than 37 to begin
  • BIT_POINTER 1
  • Test BIT_POINTER
  • Branch less than 8 to begin
  • BIT_POINTER 0

23
Foreseeable Problems
  • Multiplexing of I/O.
  • Blocks contacting multiple sensors.
  • Two Blocks on same sensor.

24
Cost
  • Electromagnet 40.00
  • Motors 15.00
  • Circuit Boards 30.00
  • Muxs 15.00
  • Aluminum 60.00
  • Total 180.00

25
Questions
  • Any Questions ?
