Lecture 16 Speaker Recognition

1
Lecture 16 Speaker Recognition
Information College, Shandong University _at_
Weihai
2
Definition

• Method of recognizing a Person form his/her
  voice.
• Depends on Speaker Specific Characteristics
• To determine whether a specified speaker is
  speaking in a given segment of speech
• This task is the one closest to biometric
  identification using speech

3
Voice is a popular Biometric

• Voice Biometric
• Natural signal to produce
• Does not require a specialized input device
• Can be used on site or remotely
• Telephone banking, Voice mail browsing, .
• Security
• Keys, card, ...
• Passwords, PIN, ...
• Fingerprint, voiceprint, Iris-print

4
Similar Tasks

• Speaker Verification
• Extract information from the stream of speech.
• Verifies that a person is who she/he claims to
  be.
• One-to-one comparison.
• Speaker Recognition
• Extract information from the stream of speech.
• Assigns an identity to the voice of an unknown
  person.
• One-to-many comparison.
• Speech Recognition
• Extracts information from the stream of speech.
• Figures out what a person is saying.

5
Task of Today

• Speech Recognition
• History
• Scheme
• Speaker Features
• Methods

6
Recognition Milestone

• 1920, first electromechanical toy Rex',
  (Elmwood Co. )
• Late 1940s, US Defense, Automatic Translation
  Machine
• Project failed, but sparked the research at MIT,
  CMU, commercial institutions.
• During 1950's, first system capable of
  recognizing digits spoken over the telephone was
  developed by Bell Labs.
• 1962, Shoebox form IBM

• In early 1970's, the system HARPY capable of
  sentences, limited grammar, by Carnegie-Mellon
  University.
• HARPY required so much computing power as in 50
  contemporary computers.
• Moreover, the system recognized discrete speech,
  where words are separated by longer pauses than
  usual.

7
Recognition Milestone

• In the 1980s, significant progress in speech
  recognition technology
• Word error rates continue to drop by factor of 2
  every two years.
• IBM in 1985, in real time, isolated words from
  set of 20,000 after 20-minute training, with
  error rate lt 5.
• ATT, call routing system, speaker independent
  word-spotting technology, few key phrases.
• Several very large vocabulary dictation systems
• require speakers to pause between words.
• Better for specific domain.
• In 1990's
• VoiceBroker deployed by Charles Schwab, stock
  brokerage, in 1996.
• ViaVoice by IBM, first distributed with the now
  almost forgotten operating system OS/2 in 1996.
• 1997, Dragon introduced Naturaly Speaking, first
  continuous speech recognition package
• Today
• Airline reservations with British Airways,
• Train reservation for Amtrak,
• Weather forecasts telephone directory
  information

8
Terminology of Speech Recognition

• Speaker Dependent Recognition
• The recognition system is designed to work with
  just one or a small number of individual speakers

• Speaker Independent Recognition
• These systems are designed to work with all the
  speakers from a given linguistic community

9
Terminology of Speech Recognition

• Large Vocabulary Recognition
• Example are domain specific recognition systems
  such as used by medical consultants for
  dictating notes on their ward rounds
• Very difficult to make accurate large vocabulary,
  speaker independent systems
• Small Vocabulary Recognition
• Typically recognition of a few keywords such as
  digits or a set of commands.
• Example voice operated telephone number dialing

10
Terminology of Speech Recognition

• Isolated Word Recognition
• Systems which can only recognize individual words
  which are preceded and followed by relatively
  long period of silence
• Connected Word Recognition
• Systems which can recognize a limited sequence of
  words spoken in succession (e.g. Ninety-eight
  thirty-five four thousand)
• Continuous Word Recognition
• These systems can recognize speech as it occurs
  and recognize the speech in real time. Such
  system usually work with large vocabulary, but
  with moderate accuracy.

11
Speech Recognition Scheme

• Three steps in Speech recognition are performed
  in ANY recognition system
• Feature Extraction
• Measurement of similarity
• Decision making

12
Recognition Systems
Pattern matching is constrained in many ways,
e.g. the rules of language (grammar), spelling
and possible pronunciations
Derive a compact representation of the speech
waveform
reference patterns
accept/ reject
speech
feature extraction
pattern matching
decision rule
test pattern
Find the word with the greatest similarity to the
input speech
c0(t)
...
c1(t)
cM(t)

?cM(t)
?c1(t)
?c0(t)

?2c0(t)
?2c1(t)
?2cM(t)
13
Speech Model Features
14
Speaker Recognition Features

• The features are low-level speech signal
  representation parameters that convey complete
  information about the signal.
• High-level characteristics like accent,
  intonation, etc. are encoded within the
  representation in a very complex and cryptic
  manner.
• The features contain speaker-dependent
  components.
• Uniqueness and permanence of the features is
  problematic.

15
Questions

• Do the features that uniquely characterize people
  exist?
• Uniqueness and permanence of most of the features
  used in biometric systems have not been proven.
• Is the humans ability to identify a person a
  limit that no automatic system can overcome?
• Automated systems might be able to identify
  people better than average person can do. In
  practice, expert systems do not perform the task
  better than the experts who built them.

16
Questions

• How important are the algorithms versus the
  knowledge of features and their relationships to
  achieve high identification accuracy?
• Knowledge of features and their relationships is
  fundamental for accurate biometric systems. The
  algorithms play an important, still secondary,
  role in the process as no algorithm can
  compensate for the lack of the adequate features.

17
Speaker models

• Used to represent the speaker specific
  information conveyed in the feature vectors
• Several different modeling techniques have been
  applied
• Template Matching
• Nearest Neighbor
• Neural Networks
• Hidden Markov Models
• State-of-the-art speaker recognition algorithms
  are based on statistical models of short-term
  acoustic measurements on the input speech signal

18
Speaker models

• Use long-term averages of acoustic features
  (spectrum, pitch) first and earliest Idea
• To average out the factors influencing
  intra-speaker variation, leave only the speaker
  dependent component.
• Drawback required long speech utterance(gt20s)
• Training SD model for each speaker
• Explicit segmentation HMM
• Implicit segmentation VQ,GMM

19
Speaker models

• HMM
• Advantage Text-independent
• Drawback A significant increase in
  computational complexity
• VQ
• Advantage Unsupervised clustering
• Drawback Text-dependent
• GMM
• Advantage Text-Independent, Probabilistic
  framework (robust), Computationally efficient,
  Easily to be implemented.

20
Speaker models

• Discriminative Neural Network
• Model the decision function which best
  discriminate speakers
• Advantage
• Less parameters, higher performance compared
  to VQ model.
• Drawback
• The network must be retrained when a new
  speaker is added to the system.

21
Progressing
VQ NN
HMM VQ NN
GMM HMM VQ NN
1985
1995
Easy
Word Error Rate
Hard
21
State of the Art Speech Recognition
22
QV Example
distortion
This sample has less distortion for A than for B
Acoustic Space 2
Speaker A
Speaker B
Acoustic Space 1
23
HMM Example

• Two model of tomato

Word in the vocabulary is presented with
phonemes. Each phoneme is viewed as an HMM A
word model is constructed by combining HMMs for
the phonemes
24
Gaussian Mixture Model (GMM)
Speech Recognition
(GMM) State Level
25
Gaussian Mixture Model (GMM)
Speaker Recognition
Speaker k



26
Limits

• The best performing algorithms for
  text-independent speaker verification use
  Gaussian Mixture Models (GMM) (single state HMM)
• The linguistic structure of the speech signal is
  not taken into account and all sounds are
  represented using a unique model
• The sequential information is ignored
• There is a recent trend in using High-level
  features
• Large Vocabulary Continuous Speech Recognition
  System
• Good results for a small set of languages
• Need huge amount of annotated speech databases
  (an enormous amount of time and human effort )
• Language and task dependent
