Title: Bandwidth Metrics and Measurement Tools


1
Bandwidth Metrics and Measurement Tools
  • Xin, Lu
  • High-Performance Computing Group
  • Computer Science University of Windsor

2
Bandwidth Metrics
  • NMWG divide bandwidth into four sub-metrics
  • Bandwidth Capacity
  • Achievable Bandwidth
  • Available Bandwidth
  • Bandwidth Utilization

FOR MORE INFO...
http//www-didc.lbl.gov/NMWG http//www-didc.lbl.g
ov/NMWG/docs/measurements.pdf
3
Other Metric Terms
  • Throughput
  • Throughput is the same as achievable bandwidth.
  • Bulk Transfer Capacity (BTC)
  • Defined by RFC 3148
  • BTC data_sent / elapsed_time
  • The throughput of a persistent TCP transfer.
  • Each of these metrics can be used to describe
  • the entire path (end-to-end) as well as paths
  • link (hop-by-hop)characteristics.

4
Bandwidth Capacity vs. Achievable Bandwidth
  • Capacity is the maximum amount of data per time
    unit that the link or path has available, when
    there is no competing traffic.
  • Achievable bandwidth is the maximum amount of
    data per time unit that a link or path can
    provide to an application, given the current
    utilization, the protocol and operating system
    used, and the end-host performance capability and
    load. (Throughput )
  • Reference 2

5
Bandwidth Capacity vs. Achievable Bandwidth Cont.
  • If a path consists of several links, the link
    with the minimum transmission rate determines the
    capacity of the path.
  • While the link with the minimum unused capacity
    limits the achievable bandwidth. i.e. at
    high-speed networks, hardware configuration or
    software load on the end hosts actually limit the
    bandwidth delivered to the application.

6
Available Bandwidth vs. Bandwidth Utilization
  • Available bandwidth is the maximum amount of data
    per time unit that a link or path can provide,
    given the current utilization.
  • Utilization is the aggregate capacity currently
    being consumed on a link or path.
  • Available Bandwidth
  • Bandwidth Capacity Bandwidth Utilization
  • Reference 2

7
BTC vs. Available Bandwidth
  • Available Bandwidth is the amount of usable
    bandwidth without affecting cross-traffic,
    whereas, the BTC is measured by sending as much
    packets as possible, limiting other traffic.
  • BTC is simulating steady state persistent
    flow, taking considerable time and overhead.

FOR MORE INFO...
RFC 3148 A Frame Work for Defining Empirical
Bulk Transfer Capacity Metrics
8
BTC vs. Available Bandwidth Cont.
  • The BTC definition assumes an ideal TCP
    implementation, actually, this doesnt exist,
    and what BTC measured is the variant of
    achievable bandwidth.

FOR MORE INFO...
RFC 3148 A Frame Work for Defining Empirical
Bulk Transfer Capacity Metrics
9
Passive vs. Active measurement
  • Active measurement means that the tool actively
    sends probing packets into the network.
  • Passive measurement tools monitors the passing
    traffic without interfering.
  • Passive measurement is appreciated, however, less
    reliable than active, as it cant extract any
    data pass through it.

10
Receiver-based vs. Sender-based techniques
  • Receiver-based (end-to-end) techniques usually
    use the one-direction TCP stream to probe the
    path bandwidth.
  • Sender-based (echo-based) techniques force the
    receiver to reply the ICMP query, UDP echo or
    TCP-FIN.

11
Sender-based technique
  • Advantage
  • Flexible deployment.
  • Clock neednt synchronized at two ends.
  • Disadvantage
  • ICMP and UDP echo packets usually be rate-limited
    or filtered out by some routers.
  • Round-trip is much more possibility influenced by
    cross-traffic than that of one-way delay
  • Response packets may come back through a
    different path

12
Receiver-based technique
  • Advantage
  • More accurate than sender-based technique.
  • Disadvantage
  • Difficult to deployment.
  • The clock have to be synchronized at two ends.

13
Bandwidth Measurement Technology
  • Packet Dispersion technology
  • packet pair and packet train
  • Self-Loading Periodic streams (SLOPS)
  • Variable Packet Size (VPS) technology
  • VPS even/odd
  • Tailgating technique

14
Packet Dispersion Technique
  • Sender sends two same-size packets back-to-back
    from source to sink.
  • The packets will reach the sink dispersed by the
    transmission delay of the bottleneck links if
    there is no cross traffic.
  • Measuring the dispersion can infer the
    bottleneck link bandwidth capacity.
  • Note Bottleneck link can refer to the link with
    smallest transmission rate, its also can refer
    to the link with minimum available bandwidth. We
    refer the bottleneck link to the first case.

15
Packet Dispersion Technique Cont.
  • Bottleneck bandwidth packet size/ t

16
Packet Dispersion Technique Cont.
  • If sender sends the packets as one observation
    sample more than two, called packet train.
  • Tools usually apply robust statistical filtering
    techniques to find valid samples.

17
Packet pair vs. packet train
  • Packet train is more likely to be interfered by
    cross traffic than packet pair.
  • Packet train can be used to measure the
    bottleneck link that is multichannel while packet
    pair cant deal with.
  • Packet train can reduce the limitation of clock
    resolution.
  • Sophisticated tools apply both methods in their
    implementation. i.e. Pathrate

18
Packet Dispersion Technique Cont.
Tool Name Active/ Passive Method-ology Protocol Metrics Path/Per-link
bprobe Active Packet pair ICMP Bandwidth Capacity Path
cprobe Active Packet pair ICMP Bandwidth utilization Path
Netest Active Packet pair UDP Bandwidth capacity Path
FOR MORE INFO...
Bprobe and cprobe http//cs-people.bu.edu/carter/t
ools/Tools.html Nettest http//www-didc.lbl.gov/pi
pechar
19
Packet Dispersion Technique Cont.
Pathrate Active Packet pair, packet train UDP Bandwidth capacity Path
Pipechar Active Packet train UDP Available bandwidth Per-link
Sprobe Active Packet pair TCP Bandwidth capacity Path
FOR MORE INFO...
Pathrate http//www.cc.gatech.edu/fac/Constantinos
.Dovrolis Pipechar http//www-didc.lbl.gov/pipecha
r SProbe http//sprobe.cs.washington.edu
20
Self-Loading Periodic Streams(SLOPS)
  • Sender sends series of packets to the sink at the
    rate of larger than the bottleneck link available
    bandwidth.
  • Every packets get a timestamp at sender side.
  • Compare the difference of successive packets
    timestamp and their arrival times to infer the
    available bandwidth.
  • Rate-adjustment adaptive algorithm to converge to
    the available bandwidth.

21
Self-Loading Periodic Streams Cont.
Tool Name Active/ Passive Method-ology Protocol Metrics Path/Per-link
pathload Active SLOPS UDP Available bandwidth Path
FOR MORE INFO...
Pathload http//www.cc.gatech.edu/fac/Constantinos
.Dovrolis
22
Variable Packet Size (VPS) Technique
  • Step1. Sender set TTL1, send out the packet, and
    wait for the ICMP TTL-exceeded packet back.
  • Step2. Upon receiving ICMP, estimate the RTT.
    Estimate the RTT multiple times for various size
    packets.The minimum RTT of various packets are
    believed to be the valid sample.
  • Step3. The first link capacity is C1/b , b is
    slope of RTT graph.
  • Set the TTL2,3n, repeat the process of step1 to
    3, to
  • Calculate the C1/ bi bi-1

23
VPS technique cont.
24
Even-odd VPS
  • The VPS probing technique is not altered,
    Mathematical trick to improve reliability.
  • For each of the probing sizes, divide the set of
    samples into even and odd numbers.
  • Calculation is based on even-odd samples. i.e.
    the even sample of link i, the odd sample of link
    i1.

25
Tailgating Technique
  • Tailgating technique divides into two phrase
  • Phase one Like VPS probing, but for entire path
    instead of per link.
  • Phase two (tailgating phase) The largest
    possible non-fragmented packet followed by a
    tailgater which is the smallest possible packet
    size (i.e 40 bytes). This causes the smaller
    packet always queue behind the larger packet.
  • Reference Kevin Lai, Mary Baker Measuring Link
    Bandwidths Using a Deterministic Model of Packet
    Delay ACM SIGCOMM 2000

26
Tailgating Technique cont.
  • The following condition should met
  • The large packet should not be queued due to
    cross traffic.
  • The large packet should have a TTL field set to L
    (1n).
  • The tailgater packet should be queued directly
    after the large packet on link L.
  • The tailgater packet should not queued after
    having passing link L.

27
VPS Technology
Tool Name Active/ Passive Method-ology Protocol Metrics Path/Per-link
bing Active VPS ICMP Bandwidth capacity, loss, delay Path
clink Active VPS/ even-odd UDP Bandwidth capacity, Loss Path
Pchar Active VPS UDP, ICMP Bandwidth capacity, Loss, delay Per-link
Bing http//www.cnam.fn/reseau/bing.html Clink
http//rocky.wellesley.edu/downey/clink/ Pchar
http//www.emplyees.org/bmah/software/pchar
28
VPS Technology Cont.
Tool Name Active/ Passive Method-ology Protocol Metrics Path/Per-link
Nettimer Active, Passive VPS/tailgating TCP Bandwidth capacity Per-link
pathchar Active VPS/even-odd UDP, ICMP Bandwidth capacity, Loss, delay Per-link
FOR MORE INFO...
Nettimer http//mosquitonet.stanford.edu/laik/pro
ject/nettimer Pathchar ftp//ftp.ee.lbl.gov/pathch
ar/
29
TCP Simulation and Path Flooding
  • TCP simulation operates at two mode UDP/ICMP
    with low TTL or ICMP echo/reply. It simulates the
    TCP of using slow-start algorithm.
  • Path flooding method injects TCP/UDP packets into
    the net as fast as possible within the specific
    time.
  • To some degree, both TCP simulation and path
    flooding are associated with Bulk Transfer
    Capacity (BTC)metrics.

30
TCP Simulation and Path Flooding Cont.
Tool Name Active/ Passive Method-ology Protocol Metrics Path/Per-link
TReno Active TCP simulation UDP, ICMP BTC Path
ttcp Active Path flooding TCP, UDP Achievable bandwidth Path
iperf Active Path flooding TCP, UDP Bandwidth capacity, Loss Path
Netperf Active Path flooding TCP, UDP BTC, delay throughput Path
31
TCP Simulation and Path Flooding Cont.
  • TReno
  • http//www.psc.edu/networking/treno_info.html
  • Iperf
  • http//dast.nlanr.net/Project/Iperf
  • Netperf
  • http//www.netperf.org/netperf/NetperfPage.html
  • ttcp part of OS
  • ftp//ftp.arl.mil/pub/ttcp/

32
Bandwidth Measurement Tools Con.
  • Reference
  • 1.http//www.caida.org/tools/
  • 2. Bruce Lowekamp, Brain Tierney, Les Cottrell,
    Richard Hughes-Jones, Thilo Kielmann and Martin
    Swany. A Hierarchy of Network Measurements for
    Grid Applications and Services Document (draft)
    Global Grid Forum NMWG Feb 17, 2003.
  • 3. Rody Schoonderwoerd Network Performance
    Measurement Tools a comprehensive comparison
    Nov., 2002
