• Algorithms on Rings of Processors

2
Algorithms on Rings of Processors

• When using message passing, it is common to
  abstract away from the physical network and to
  choose a convenient logical network instead.
• This chapter presents several algorithms
  intended for the logical ring network studied
  earlier
• Coverage of mapping logical networks map onto
  physical networks are deferred to Sections 4.6
  and 4.7
• Rings are linear interconnection network
• Ideal for a first look at distributed memory
  algorithms
• Each processor has a single predecessor and
  successor

3
Matrix-Vector Multiplication

• The first unidirectional ring algorithm will be
  the multiplication y Ax of a n?n matrix A by a
  vector x of dimension n.
• 1. for i 0 to n-1 do
• 2. yi ? 0
• 3. for j 0 to n-1 do
• 4. yi yi Ai,j ? xj
• Each outer (e.g., i) loop computes the scalar
  product of one row of A by vector x.
• These scalar products can be performed in any
  order.
• These scalar products will be distributed among
  the processors so these can be done in parallel.

4
Matrix-Vector Multiplication (cont.)

• We assume that n is divisible by p and let r
  n/p.
• Each processor must store r contiguous rows of
  matrix A and r scalar products.
• This is called a block row.
• The corresponding r components of the vector y
  and x are also stored with each processor.
• Each processor Pq will then store
• Rows qr to (q1)r -1 of matrix A of dimension r?n
• Components qr to (q1)r -1 of vectors x and y.
• For simplicity, we will ignore the case where n
  is not divisible by p.
• However, this case can be handled by temporarily
  adding additional rows of zeros to matrix and
  zeros to vector x so the resulting nr. of rows is
  divisible by p.

5
Matrix-Vector Multiplication (cont.)

• Declarations needed
• var A array0..r-1,0..n-1 of real
• var x, y array 0..r-1 of real
• Then A0,0 on P0 corresponds to A0,0 but on P1
  to Ar,0.
• Note the subscript are global while array indices
  are local.
• Also, note global index (i,j) corresponds to
  local index (i - ?i/r?, j) on processor Pk where
  k ?i/r?
• The next figure illustrates how the rows and
  vectors are partitioned among the processors.

6
(No Transcript)
7
Matrix-Vector Multiplication (cont.)

• The partitioning of the data makes it possible to
  solve larger problems in parallel.
• The parallel algorithm can solve a problem
  roughly p times larger than the sequential
  algorithm.
• Algorithm 4.1 is given on the next slide.
• For each loop in Algorithm 4.1, each processor Pq
  computes the scalar product of its r?r matrix
  with a vector of size r.
• This is a partial result.
• The values of the components of y assigned to Pq
  is obtained by adding all of these partial
  results together.

8
(No Transcript)
9
Matrix-Vector Multiplication (cont.)

• In the first pass through the loop, the
  x-components in Pq are the ones originally
  assigned.
• During each pass through the loop, Pq executes
  the scalar product of the appropriate part of the
  qth block of A with Pq s current components of
  x.
• Concurrently, each Pq sends its block of x-values
  to Pq1 (mod p) and receives a new block of
  x-values from Pq-1 (mod p).
• At the conclusion, each Pq has its original block
  of x-values, but has calculated the correct
  values for its y-components.
• These steps are illustrated in Figure 4.2.

10
(No Transcript)
11
Analysis of Matrix-Vector Multiplication

• There are p identical steps
• Each step involves three activities compute,
  send, and receive.
• The time to send and receive are identical and
  concurrent, so the execution time is
• T(p) p max r2w, Lrb
• where w is the computation time for multiplying
  a vector component by matrix component adding
  two products,
• b is the inverse of the bandwidth, and L is
  communications startup cost.
• As r n/p, the computation cost becomes
  asymptotically larger than the communication cost
  as n increases, since
•
  (for n large)

12
Matrix-Vector Multiplication Analysis (cont)

• Next, we calculate various metrics and their
  complexity
• For large n,
• T(p) p(r2w) n2w/p or O(n2/p) ? O(n2) if p
  constant
• The cost (n2w/p)p n2w or O(n2)
• The speedup ts/T(p) cn2 (p/n2w) (c/w)p
  or O(p)
• However if p is constant/small, the speedup is
  only O(1)
• The efficiency ts/cost cn2/ (n2w) c/w or
  O(1)
• Note efficiency tsp/tp ? O(1)
• Note that if vector x were duplicated across all
  processors, then there would be no need for any
  communication and parallel efficiency would be
  O(1) for all values of n.
• However, there would be an increased memory cost

13
Matrix-Matrix Multiplication

• Using matrix-vector multiplication, this is easy.
• Let C A?B, where all are n?n matrices
• The multiplication consists of computing n scalar
  products
• for i 0 to n-1 do
• for j 0 to n-1 do
• Ci,j 0
• for k 0 to n-1 do
• Ci,j Ci,j Ai,k ? Bk,j
• We will distribute the matrices over the p
  processors, giving each the first processor the
  first r n/p rows, etc.
• Declaration
• var A, B, C array0r-1, 0r-1 of reals.

14
(No Transcript)
15
Matrix-Matrix Multiplication Analysis

• This algorithm is very similar to the one for
  matrix-vector multiplication
• Scalar products are replaced by sub-matrix
  multiplication
• Circular shifting of a vector is replaced by
  circular shifting of matrix rows
• Analysis
• Each step lasts as long as the longest of the
  three activities performed during the step
  Compute, send, and receive.
• T(p) p max nr2w, Lnrb
• As before, the asymptotic parallel efficiency is
  1 when n is large.

16
Matrix-Matrix Multiplication Analysis

• Naïve Algorithm matrix-matrix could be achieved
  by executing matrix-vector multiplication n times
• Analysis of Naïve algorithm
• Execution time is just the time for matrix-vector
  multiplication, multiplied by n.
• T(p) p ? max nr2w, nL nrb
• The only difference between T and T is that term
  L has become nL
• Naïve approach exchange vectors of size r
• In the algorithm while in the algorithm developed
  in this section, they exchange matrices of size r
  ? n
• This does not change asymptotic efficiency
• However, sending data in bulk can significantly
  reduce the communications overhead.

17
Stencil Applications

• Popular applications that operate on a discrete
  domain that consists of cells.
• Each cell holds some value(s) and has neighbor
  cells.
• The application uses an application that applies
  pre-defined rules to update the value(s) of a
  cell using the values of the neighbor cells.
• The location of the neighbor cells and the
  function used to update cell values constitute a
  stencil that is applied to all cells in the
  domain.
• These type of applications arise in many areas of
  science and engineering.
• Examples include image processing, approximate
  solutions to differential equations, and
  simulation of complex cellular automata (e.g.,
  Conways Game of Life)

18
A Simple Sequential Algorithm

• We consider a stencil application on a 2D domain
  of size n?n.
• Each cell has 8 neighbors, as shown below
• NW N NE
• W c E
• SW S SE
• The algorithm we consider updates the values of
  Cell c based on the value of the already updated
  value of its West and North neighbors.
• The stencil is shown on the next slide and can be
  formalized as
• cnew ? UPDATE(cold, Wnew, Nnew)

19
(No Transcript)
20
A Simple Sequential Algorithm (cont)

• This simple stencil is similar to important
  applications
• Gauss-Seidel numerical method algorithm
• Smith-Waterman biological string comparison
  algorithm
• This stencil can not be applied to cells in top
  row or left column.
• These cells are handled by the update function.
• To indicate that no neighbor exists for a cell
  update, we pass a Nil argument to UPDATE.

21
Greedy Parallel Algorithm for Stencil

• Consider a ring of p processors, P0, P1, ,
  Pp-1.
• Must decide how to allocate cells among
  processors.
• Need to balance computational load without
  creating overly expensive communications.
• Assume initially that p is equal to n
• We will allocate row i of domain A to ith
  processor, Pi.
• Declaration Needed Var A Array0..n-1 of
  real
• As soon as Pi has computed a cell value, it sends
  that value to Pi1 (0 ? i lt p-1).
• Initially, only A0,0 can be computed
• Once A0,0 is computed, then A1,0 and A0,1can be
  computed.
• The computation proceeds in steps. At step k, all
  values on the k-th anti-diagonal are computed.

22
(No Transcript)
23
General Steps of Greedy Algorithm

• At time ij, processor Pi performs the following
  operations
• It receives A(i-1,j) from Pi-1
• It computes A(i,j)
• Then it sends A(i,j) to Pi1
• Exceptions
• P0 does not need to receive cell values to update
  its cells.
• Pp-1 does not send its cell values after updating
  its cells.
• Above exceptions do not influence algorithm
  performance.
• This algorithm is captured in Algorithm 4.3 on
  next slide.

24
(No Transcript)
25
Tracing Steps in Preceding Algorithm

• Re-read pgs72-73 CLR on send receive for
  sych.rings.
• See slides 35-40, esp. 37-38 in slides on
  synchronous networks
• Steps 1-3 are performed by all processors.
• All processors obtain a array A of n reals, their
  ID nr, and the nr of processors.
• Steps 4-6 are preformed only by P0.
• In Step 5, P0 updates the cell A0,0 in NW top
  corner.
• In Step 6, P0 sends contents in A0 of cell A0,0
  to its successor, P1.
• Steps 7- 8 are executed only by P1 with since it
  is only processor receiving a message. (Note this
  is not blocking receive, as would block all Pi
  for igt1.)
• In Step 8. P1. stores update of A0,0 from P0 in
  address v.
• In Step 9, P0. uses value in v to update value in
  A0 of cell A1,0.

26
Tracing Steps in Algorithm (cont)

• Steps 12-13 are executed by P0 to update the
  value Aj of its next cell A0,j in top row and
  send its value to P1.
• Steps 14-16 are executed only by Pn-1 on bottom
  row to update the value Aj of its next cell
  An-1,j.
• This value will be used by Pn-1 to update its
  next cell in the next round.
• Pn-1 does not send a value since its row is the
  last one.
• Only Pi for 0ltiltn-1 can execute 18-19.
• In Step 18, Pi executing 18-19 on j-th loop are
  further restricted to those receiving a message
  (i.e., blocking receive)
• In Step 18, Pi executes the send and receive in
  parallel
• In Step 19, Pi uses the received value to update
  the value Aj of the next cell Ai,j.

27
Algorithm for Fewer Processors

• Typically, have much fewer processors than nr of
  rows.
• WLOG, assume p divides n.
• If n/p rows are assigned to each processor, then
  at least n/p steps must occur before P0 can send
  a value to P1.
• This situation repeats for each Pi and Pi1,
  severely restricting parallelism.
• Instead, we assign rows to processors cyclically,
  with row j assigned to Pj mod p.
• Each processor has following declaration
• var A array0...n/p, 0..n-1 of real
• This is a contiguous array of rows, but these
  rows are not contiguous.
• Algorithm 4.4 for the stencil application on a
  ring of processors using a cyclic data
  distribution is given next.

28
(No Transcript)
29
Cyclic Stencil Algorithm Execution Time

• Let T(n,p) be the execution time for preceding
  algorithm.
• We assume that receiving is blocking while
  sending is not.
• The sending of a message in step k is followed by
  the reception of the message in step k1.
• The time needed to perform one algorithm step is
  ?bL, where
• The time needed to update a cell is ?
• The rate at which cell values are communicated is
  b
• The startup cost is L.
• The computation terminates when Pp-1 finishes
  computing the rightmost cell value of its last
  row of cells.

30
Cyclic Stencil Algorithm Run Time (cont)

• Number of algorithm steps is p-1 n2/p
• Pp-1 is idle for first p-1 steps
• Once Pp-1 starts computing, it computes a cell
  each step until the algorithm computation is
  completed.
• There are n2 cells, split evenly between the
  processors, so each processor is assigned n2/p
  cells
• This yields
• Additional problem
• Algorithm was designed to minimize (time between
  a cell update computation) and (its reception by
  the next processor)
• However, the algorithm performs many
  communications of small data items.
• L can be orders of magnitude larger than b if
  cell value small.

31
Cyclic Stencil Algorithm Run Time (cont)

• Stencil application characteristics
• The cell value is often as small as an integer or
  real nr.
• The computations to update the cells may involve
  only a few operations, so ? may also be small.
• For many computations, most of the execution time
  could be due to the L term in the equation for
  T(n,p).
• Spending a large amount of time in communications
  overhead reduces the parallel efficiency
  considerably.
• Note that Ep(n) Tseq(n) / p?Tpar(n) n2w /
  p?Tpar(n)
• Ep(n) reduces to the below formula. Note that as
  n increases, the efficiency may drop well below
  1.

32
Augmenting Granularity of Algorithm

• The communication overhead due to startup
  latencies can be decreased by sending fewer
  messages that are larger.
• Let each processor compute k contiguous cell
  values in each row during each step, instead of
  just 1 value.
• To simplify analysis, we assume k divides n, so
  each row has n/k segments of k contiguous cells.
• To avoid above, let the last incomplete segment
  spill over to the next row. The last segment of
  last row may have fewer than k elements.
• With this algorithm, cell values are communicated
  in bulk, k at a time.

33
Augmenting Granularity of Algorithm (cont)

• Effect of bulk communication k items on algorithm
• Larger values of k produce less communication
  overhead.
• However, larger values of k increase the time
  between a cell value update and its reception in
  the next processor
• In this algorithm, processors will start
  computing cell values later, leading to more idle
  time for cells.
• This approach is illustrated in next diagram.

34
(No Transcript)
35
Block-Cyclic Allocation of Cells

• A second way to reduce communication costs is to
  decrease the number of cell values that are being
  communicated.
• This is done by allocating blocks from r
  consecutive rows to processors cyclically.
• To simplify the analysis, we assume r?p divides
  n.
• This idea of a block-cyclic allocation is very
  useful, and is illustrated below

36
Block-Cyclic Allocation of Cells (cont)

• Each processor computes k contiguous cells in
  each row from a block of r rows.
• At each step, each processor now computes r?k
  cells
• Note blocks are r?k (r rows, k columns) in size
• Note Only those values on the edges of the block
  have to be sent to other processors.
• This general approach can dramatically decrease
  the number of cells whose updates have to be sent
  to other processors.
• The algorithm for this allocation is similar to
  those shown for the cyclic row assignment scheme
  in Figure 4.6,
• Simply replace rows by blocks of rows.
• A processor calculates all cell values in its
  first block of rows in n/k steps of the
  algorithm.

37
Block-Cyclic Allocations (cont)

• Processor Pp-1 sends its k cell values to P0
  after p algorithm steps.
• P0 needs these values to compute its second
  block of rows .
• As a result, we need n ? kp in order to keep
  processors busy.
• If n gt kp, then processors must temporarily store
  received cell values while they finishing
  computing their block of rows for the previous
  step.
• Recall processors only have to exchange data at
  the boundaries between blocks.
• Using r rows per block, the amount of data
  communicated is r times smaller than the previous
  algorithm.

38
Block-Cyclic Allocations (cont)

• Processor activities in computing block
• Receive k cell values from predecessor
• Compute kr cell values
• Sends k cell values to its successor
• Again we assume receives are blocking while
  sends are not.
• The time required to perform one step of
  algorithm is
• krwkbL
• The computation finishes when processor Pp-1
  finishes computing its rightmost segment in its
  last block of rows of cells.
• Pp-1 computes one segment of a block row in each
  step

39
Optimizing Block-Cyclic Allocations

• There are n2/(kr) such segments and so p
  processors can compute them in n2/(pkr) steps
• It takes p-1 algorithm steps before processor
  Pp-1 can start doing any computation.
• Afterwards, Pp-1 will computer one segment at
  each step.
• Overall, the algorithm runs for p-1n2/pkr steps
  with a total computation time of
• The efficiency of this algorithm is

40
Optimizing Block-Cyclic Allocations (cont)

• However, this gives the asymptotic efficiency of
• Note that by increasing r and k, it is possible
  to achieve significantly higher efficiency.
• However, increasing r and k reduces
  communications.
• The text also outlines how to determine optimal
  values for k and r using a fair amount of
  mathematics.

41
Implementing Logical Topologies

• Designers of parallel algorithms should choose
  the logical topology.
• In section 4.5, switching the topology from
  unidirectional ring to a bidirectional ring made
  the program much simpler and lowered the
  communications time.
• The message passing libraries, such as the ones
  implemented for MPI, allow communications between
  any two processors using the Send and Recv
  functions.
• Using a logical topology restricts communications
  to only a few paths, which usually makes the
  algorithm design simpler.
• The logical topology can be implemented by
  creating a set of functions that allows each
  processor to identify its neighbors.
• Unidirectional Ring only needs NextNode(P)
• Bidirectional Ring would need also need
  PreviousNode(P)

42
Logical Topologies (cont)

• Some systems (e.g., many modern supercomputers)
  provide many physical networks, but sometimes
  creation of logical topologies left to the user.
• A difficult task is matching the logical topology
  to the physical topology for the application.
• The common wisdom is that a local topology that
  resembles the physical topology of application
  should produce a good performance.
• Sometime the reason for using a logical topology
  is to hide the complexity of the physical
  topology.
• Often extensive benchmarking is required to
  determine the best topology for a given algorithm
  on a given platform.
• The local topologies studied in this chapter and
  the next are known to be useful in the majority
  of scenarios.

43
Distributed vs Centralized Implementations

• In the CLR text, the data is already distributed
  among the processors at the start of the
  execution.
• One may wonder how the data was distributed to
  the processors if whether that should also be
  part of the algorithm.
• There are two approaches Distributed
  Centralized.
• In the centralized approach,one assumes that the
  data resides in a single master location.
• A single processor
• A file on a disk, if data size is large.
• The CLR book takes the distributed approach. The
  Akl book usually takes the distributed approach,
  but occasionally takes the centrailized approach.

44
Distributed vs Centralized (cont)

• An advantage of the centralized approach is that
  the library routine can choose the data
  distribution scheme to enforce.
• The best performance requires that the choice for
  each algorithm consider its underlying topology.
• This cannot be done in advance
• Often the library developer will provide multiple
  versions of possible data distribution
• The user can then choose the version that bet
  fits the underlying platform.
• This choice may be difficult without extensive
  benchmarking.
• The main disadvantage of the centralized approach
  is when user applies successive algorithms using
  the same data.
• Data will be repeatedly distributed
  undistributed.
• Causes most library developers to opt for
  distributed option.

45
Summary of Algorithmic Principles(For
Asynchronous Message Passing)

• Although used only for ring topology, the below
  principles are general. Unfortunately, they often
  conflict with each other.
• Sending data in bulk
• Reduces communication overhead due to network
  latencies
• Sending data early
• Sending data as early as possible allows other
  processors to start computing as early as
  possible.

46
Summary of Algorithmic Principles(For
Asynchronous Message Passing)-- Continued --

• Overlapping communication and computation
• If both can be performed at the same time, the
  communication cost is often hidden
• Block Data Distribution
• Having processors assigned blocks of contiguous
  data elements reduces the amount of communication
• Cyclic Data Distribution
• Having data elements interleaved among processors
  makes it possible to reduce idle time and achieve
  a better load balance
