The Knee Complex

1
The Knee Complex
2
The Knee Complex

• General Structure Function
• Structure Function of Specific Joints
• Muscular Considerations

3
General Structure
4
(No Transcript)
5
Joints of the Knee Complex
6
General Function

• Provides very mobile link in an otherwise stable
  lower extremity
• Transmits loads from tibia/fibula to femur

7
(No Transcript)
8
(No Transcript)
9
Knee Complex Movements
10

• Transverse plane
• Medial and lateral
• rotation

• Sagittal plane
• Flexion, extension

11
Knee Complex Movements

• Frontal plane
• Varus, valgus
• Anteroposterior translation
• Mediolateral translation

12
The Knee Complex

1. General Structure Function
2. Structure Function of Specific Joints
3. Muscular Considerations

13
Structure Function of Specific Joints

1. Tibiofibular Joint
2. Patellofemoral Joint
3. Tibiofemoral Joint

14
Tibiofibular Joint Bony Structure
Amphiarthrodial membranous syndesmosis joint
15
Structure Function of Specific Joints

1. Tibiofibular Joint
2. Patellofemoral Joint
3. Tibiofemoral Joint

16
Purpose of Patella

• Increase leverage of QF
• Protect joint during knee flexion
• ? pressure and distribute forces on femur
• Prevent Fcompression on PT in resisted knee
  flexion
• Disadvantage ? ANT shear of QF

17
Patella Structure

• Medial facet
• Lateral facet
• Odd facet (30)

M
L
18
PF Articular Surfaces

• Largest sesamoid bone
• Least congruent joint
• Articular cartilage
• Vertical ridge
• Facets

19
PF Articular Surfaces

• Largest sesamoid bone
• Least congruent joint
• Articular cartilage
• Vertical ridge
• Facets
• Angle of femoral sulcus

20
Patellar Motion

• INF SUP Sliding
• Patellar tilt
• 11? MT as KN FL

21
Patellar Motion

• Lateral rotation
• ACC MR of femur
• 6? through KN FL
• Medial rotation
• ACC LR of femur

22
Patellalectomy

• ? MA of QF (? strength 49)
• ? Q tendon friction
• ? compressive stress on groove by Q tendon
• Most evident in closed chain EXT
• ECC QF in CC
• Coupled w/ assisted by hip ankle movement
• QF not needed in erect posture of CC

23
Extension
Little effect overall
24
Slight Flexion
Noticeable weakness
25
Extreme Flexion
Noticeable weakness
26
From 0 to 60 of Knee Flexion
27

• 0?-60?
• Contact area ?
• ? MA of QF ? 60?
• ? ANT shear of QF

• 0?-60?
• Facet contact at 20?

28
From 60 to 140 of Knee Flexion
29

• 60?-140?
• ? contact area
• ? MA of QF
• No leverage in full FL

30

• Overall
• Medial facet most contact
• Odd facet least contact

31
During Full Extension

• Full EXT
• ? MA of QF
• ? QF length
• Patella very unstable

32
PF JRF

• Amount of knee FL
• Strength of QF contraction

33
(No Transcript)
34
PF Compressive Forces
Descending stairs 4000 N
Max isometric extension 6100 N
Kicking 6800 N
Parallel squat 14,900 N (7-8X BW)
Isokinetic knee extension 8300 N
Rising from chair 3800 N
Running/jogging 5000 N (3-4X BW)
Ascending stairs 1400 N
Walking 840-850 N (0.5-1.5X BW)
Cycling 880 N
35
Compensatory Mechanisms for Compressive Force
Distribution

• Contact area ? with knee flexion
• Medial facet contact from 30?-70?
• Thickest hyaline cartilage in body

36
(No Transcript)
37
Compensatory Mechanisms for Compressive Force
Distribution

• Contact area ? with knee flexion
• Medial facet contact from 30?-70?
• Thickest hyaline cartilage in body
• Largest QF MA 30?-70?
• ?QF torque as MA decreases
• QF tendon contacts condyles 70?-90?

38
Normal Patella Tracking

• Maintains maximum congruence
• Passive restraints
• Active restraints

39
Abnormal Patella Tracking

• ? congruence
• Stretches capsule retinacula
• ? contact area

Lateral
Medial
40
Causes of Abnormal Tracking

• Skeletal abnormalities
• Strength imbalance in QF
• Strength imbalance in fibrous tissues
• Compensatory movements in knee due to abnormal
  foot movement

41
Causes of Abnormal Tracking

• Skeletal abnormalities
• Strength imbalance in QF
• Strength imbalance in fibrous tissues
• Compensatory movements in knee due to abnormal
  foot movement

42
Skeletal Abnormalities Q-angle
43
Skeletal Abnormalities Genu Varum Genu Valgum

• Q angle ? w/ age
• Varum common in very young children
• Valgum seen in growing children
• Menisectomy effects

44
Skeletal Abnormalities Patella Alta Patella
Baja

• Index of Insall Salviti
• LT/LP
• Normal 1.0
• Patella alta 0.8
• Patella baja 1.2
• Women ? ratio

45
Skeletal Abnormalities Patella Surface Lateral
Border

• Appositional forces ? in full extension
• Prominence of lateral border prevents lateral
  displacement
• Underdevelopment common in children as growing

46
Skeletal Abnormalities Femoral Tibial Torsion

• Lateral tracking

47
Causes of Abnormal Tracking

• Skeletal abnormalities
• Strength imbalance in QF
• Strength imbalance in fibrous tissues
• Compensatory movements in knee due to abnormal
  foot movement

48
QF Strength Imbalance
49
Causes of Abnormal Tracking

• Skeletal abnormalities
• Strength imbalance in QF
• Strength imbalance in fibrous tissues
• Compensatory movements in knee due to abnormal
  foot movement

50
Fibrous Tissue Strength Imbalance
IT
51
Causes of Abnormal Tracking

• Skeletal abnormalities
• Strength imbalance in QF
• Strength imbalance in fibrous tissues
• Compensatory movements in knee due to abnormal
  foot movement

52
Compensatory Movement

• Pronation of foot accompanied by medial rotation
  of tibia ? medial rotation medial translation
  of patella
• Pronation coupled w/ forceful quadriceps femoris
  leads to anterior tilt
• EX jumping, landing, running

53
Summary
