Kaushik Lakshminarayanan

1
Transactional Memory Hybrid Hardware/Software
Approaches

• Kaushik Lakshminarayanan
• Michael Rozyczko
• Vivek seshadri

2
Transactional Memory

• Lock-free data structures
• Atomic code sections
• Abstraction what instead of how
• Ideas from database community
• Means a lot to parallel programming

3
Hardware vs Software TM

• Hardware Transactional Memory (HTM)
• Modify cache coherence protocol, ISA extensions
• Best-effort (bounded resources)
• Transactions cannot exceed processor resources
• UTM (unbounded resources)
• Supports large transactions hard to realize
• Software Transactional Memory (STM)
• Software bookkeeping
• Overhead
• Hybrid Transactional Memory (?)
• Combine benefits of both models

4
Hybrid TM Design Issues

• Naming ?
• Hardware support
• Software mechanism
• Policy
• ISA extensions
• Other issues

5
HyTM Overview

• HyTM
• Peter Damron, Alexandra Fedorova, Yossi Lev,
  Victor Luchangco, Mark Moir and Daniel Nussbaum

6
Overview of Implementations II

• RTM
• Arvindh Shriraman, Michael F. Spear, Hemayat
  Hossain, Virendra J. Marathe, Sandhya Dwarkadas
  and Michael L. Scott

Application
Handler
HTM
7
Overview of Implementations III

• SigTM
• Chi Chao Minh, Martin Trautmann, JaeWoong Chung,
  Austen McDonald, Nathan Bronson, Jared Casper,
  Christos Kozyrakis, Kunle Olukotun

STM
Hardware Bookkeeping (Signatures)
8
Hardware Support/Software Mechanisms

• HyTM
• Does not assume any hardware support
• Runs on existing HTM (if one exists)
• Full-fledged STM library
• Object records (for every word in memory)
• Meta-information about the state of the word
• Handlers
• Conflict management
• Hardware/Software interface

9
Hardware Support/Software Mechanisms

• RTM
• Cache coherence protocol modifications TMESI
• Additional registers (transaction metadata)
• Application-specific handlers
• Conflict detection
• Aborted hardware transactions

10
Hardware Support/Software Mechanisms

• SigTM
• Hardware signatures (bookkeeping)
• Bloom filter
• User-level configuration registers (policy)
• Slight modification to cache coherence
• Hardware check on signature hits
• Software handlers to handle hits (based on
  policy)
• Software write-set bookkeeping
• Required to update on successful commit

11
Policy

• Upon conflict/eviction, something must be done to
  resolve the situation
• Conflict detection write-read, write-write
• When to do conflict detection? Eager/Lazy
• What to do when conflict encountered? Which to
  abort.
• Retrying aborted transactions
• Immediate retry vs. back off
• HyTM hardware vs. software transaction
• SigTM API policy management

12
RTM Policy

• RTM flexible policy
• Application-specific handlers
• Speculative execution
• Application can decide to allow read-write and
  write-write
• Programmable Data Isolation (PDI)
• Can configure exclusivity of data
• Alert on Update (AOU)
• Inform application when a conflict/eviction occurs

13
ISA extensions

• Hybrid TM generally use special instructions to
  interface compiler and TM hardware
• Instructions to delimit beginning and ending of
  transactions (Most implementations)
• Instructions to set application-specific handlers
  (RTM)
• Instructions to check whether the hardware can
  read or write (HyTM)
• Update the signatures of addresses (SigTM)

14
Other Issues

• False sharing
• Cache lines unwanted abort and retries
• Unnecessarily shared variables
• Collecting statistics
• Memory allocation/Freeing
• Malloc and free in aborted transactions
• Deadlocks
• Issue with lock based mechanisms
• Strong isolation and ordering
• Interaction with non-transactional writes

15
Transactional Memory Hybrid Hardware/Software
Approaches

• Kaushik Lakshminarayanan
• Michael Rozyczko
• Vivek seshadri
