INTERCONNECT MODELING M.Arvind 2nd M.E Microelectronics

1
INTERCONNECT MODELINGM.Arvind2nd M.E
Microelectronics
2
OVERVIEW

• Introduction to On-Chip interconnects
• Modeling the parasitics
• Elmore Delay Model
• Repeater insertion
• Min delay condition
• Power Model
• Optimizing Power

3
Introduction to On-chip interconnects

• Wires linking the transistors together
• Three types of interconnects
• Local
• Semi-global and
• Global interconnect

4
Introduction to On-chip interconnects

• Can be modeled as R, RC, LC, RLC or RLGC network.

Power lines R,RL
Signal lines C, RC
Clock lines buses RLC
5
Modeling a piece of wire
6
Capacitance Modeling

• Capacitance
• cw 2 (cg cf cc )
• cf is the coupling factor

7
Capacitance Modeling (cont)

• cg has 2 components cg1, cg2

8
Simplified Capacitance Model

• For a circuit designer
• ILDT, h and e are fixed. Therefore,

9
Fringing Effects
10
Modeling Wire Resistance

• Resistance

11
Pros and Cons of Cu

• Pros
• Better electro-migration resistance
• Cons
• Cu atoms diffuses into SiO2
• Cladding layers of TiN, Si3N4 used to prevent
  this
• Increases the resistance

12
Elmore Delay Model

• Delay of a RC network is given by

13
Delay of a long wire

• Delay grows quadratic
• Hence need repeaters

14
Repeater Insertion

• Repeaters are placed to reduce delay

15
Repeater Insertion (cont)

• Delay grows linear

16
Modeling the repeater

• Repeater is a large inverter (5-25µm) placed
  in-between interconnect lines.
• Cgate, Cp a size of the repeater
• RT VDD/2Iavg, where Iavg ?Iddt in the
  interval Td

17
Modeling the repeater (cont)
18
Delay equations

• Delay of an interconnect segment is
• Total delay is

19
Optimal Repeater Size and Spacing

• The minimum delay condition

20
Power modeling

• Total power dissipated in the interconnect
  network is given by
• Ptotal Pdy Psc Pleak
• Pdy ?Ctotal V²ddf
• Psc ?Isc per µm Vdd Wtotalftt
• Pleak Ileak per µm WtotalVdd
• Where ? is the switching factor, tt is the time
  taken for the input to transit from Vthn to
  Vdd Vthp

21
Power modeling (cont)
22
Optimizing power

• Min delay does not imply min power

23
Techniques to Reduce Power

• Can be reduced by decreasing
• Supply voltage
• Size of repeaters
• Number of repeaters

24
Optimal Power Delay Tradeoff
25
References

• William J.Dally John W.Poulton., Digital Systems
  Engineering Cambridge University Press,1998
• Kaustav Banerjee et al., A power-optimal
  insertion methodology for global interconnects in
  nanometer designs IEEE TRANSACTION ON ELECTRON
  DEVICES, VOL. 49, NO. 11, NOVEMBER 2002
• Kaustav Banerjee et al., A global interconnect
  optimization scheme for nanometer scale VLSI with
  implications for latency, bandwidth, and power
  dissipation IEEE TRANSACTION ON ELECTRON
  DEVICES. VOL. 51, NO.2, FEBRUARY 2004.

26

• Thank You
