LTI

1
Complete law enforcement mapping solution!
2
CrashZone 2D / 3D Crash and Crime Scene
Diagramming with 2D/3D Animation Tools
3
Pocket Zone Data Collection Option
Allows you to see your data live as you
shoot it with a laser or total station
system
TDS Resellers
4
PocketZone data collection advantage

• Real-time display reduces errors omissions
• Automated lines, curves and arcs
• Easy station moves and instrument repositioning
• Customizable description library with predefined
  layers, line types and symbols automates drawing
• Save common intersections to use as templates
• Files open directly into CrashZone in one step as
  a true 3D coordinate drawing file
• Coordinate and raw data list print outs

5
CrashZone software to create accurate collision
reconstruction diagrams
records x,y,z coordinates and imports directly
6
100 Custom Line Types in 2D/3D
7
Includes 6000 unique 2D/3D symbols!
8
CrashZone Tools make your work efficient easy
9
Powerful 3-D Body Poser
10
Vehicle Specs database

• Includes
• data printout
• displays center of gravity, wheel base wheel
  centers
• - online free updates

11
Skid Analysis Momentum calculation tools
12
Accurate Crush depiction and depths using actual
measured points
13
Easy Profile creates an instant profile view in
seconds for sight lines
14
Reconstructionist Bobby Jones, TNUsing LTI
Laser, PocketZone data collection and CrashZone
software
Case Head-on collision driver of van killed
and the DUI driver of the Toyota injured.
View Southbound Van
15
Courtroom Presentations the combination 2D and 3D
rendering can be beneficial - Provides Witness
and Participant vantage points - Potential sight
obstructions can be identified - Easier for
jurors to visualize incident
16
Crash, crime, fire and marine applications all in
one
17
Incorporate digital images in diagrams and also
work on air and satellite photos
18
Vertical Wall Evidence tool draw and accurately
map on vertical surfaces!
19
Save Print functions

• Opens/save dxf dwg drawing files
• Built in PDF driver saves direct to pdf file
• Easy print functions print to scale, fit to
  paper, tile mode, etc. all in one simple dialog
  box
• Export 3D surfaces and symbols to animation
  programs or AutoCAD direct

20
3D Viewer screen shots

• The 3D Snap Shots save directly into a jpg
  format
• Use these jpg files in reports, print them
  separately or insert into your diagram
• Export 3D surfaces to other programs to generate
  sophisticated animations or simulations

21
B
A
A
B
22
2D and 3D Animations provide fast and easy key
frame animations with coordinate print out and
frame options. Movies play with Windows Movie
Maker
23
CAD ZONE Complete, affordable and easy to use
forensic mapping system
