Self-tuning Histograms Building Histograms Without Looking at Data

1
Self-tuning HistogramsBuilding Histograms
Without Looking at Data
By Ashraf Aboulnage Surajit Chaudhuri
Represents By Miller Ofer
2
Traditional histograms

• Histograms impose little cost at queries ,
  especially in a large data base.
• The cost of building histograms from database is
  significant high and prevent us from building
  useful histograms .
• Data modification causes to lost of histogram
  accuracy .

3
Self-Tuning histogram

• Similar in structure to traditional histogram.
• Builds without looking or sampling the data.
• Uses free information from the queries results.
• Can be refined in an on-line mode ( The overall
  cost of building self tuning histogram is very
  low).
• Their accuracy depends on how often they are
  used, the more it is use , the more it is refined
  , the more accurate it becomes

4
The main steps in building the ST-histogram

1. Initial the histogram.
2. Refining the bucket values (frequencies).
3. Restructuring moving the buckets boundaries.

5
Initial The Histogram

• Data requirement
• B Number of histogram buckets
• T Number of tuples
• Min/max min and max values of attribute .
• Assuming uniformity of the data distribution and
  initial each of the buckets as T/b tuples.

6
ST-histogram after initialization
tuples
frequency
buckets
7
The Algorithm for refining the buckets
frequencies. (second step )

• begin
• Finds set of k buckets that overlapping the
  selection range .
• Let est be the estimated results size of the
  selection range using histogram h .
• Let act be the actual result size.
• Compute the estimation error by act-est , denote
  by esterr .
• ?

8
?
last overlap bucket

• 5. for i 1 to k do
• 8. endfor
• end UpdateFreq

proportion
average assumption
9
Refinement example
act 60 rangehigh 25 Rangelow 12.5 high(b1)
15 low(b1) 5
0.5
5/25
35
10
Restructuring Algorithm

• Motivation
• Frequencies are approximated by their average.
  Thus , high frequent value will be contain in
  high frequent buckets , but they may be grouped
  with low frequency values .
• When the range of query adapts to the range of
  histogram bucket , no average assumption is
  needed.

11
Restructuring Algorithm
Merging step

• For every consecutive runs of buckets , find the
  maximum differences in frequency between a bucket
  in the first run and the buckets in the second
  run.
• Find the minimum of all these maximum difference
  , denote by mindiff.
• if mindiff lt mT then
• Merge the two runs of buckets corresponding to
  mindiff into one run.
• Look for other runs to merge .goto line 1.
• endif

12
Restructuring Algorithm
Splitting step

• ksb b the rest of the buckets that
  havent been chosen .
• Find the set with k highest frequency .
• Compute the splitting extra bucket of each one by

• split(bi)
• where totalfreq is the sum of all the bucket to
  be split
• and B is the number of extra bucks
• 8. Each buckets freq gets the old freq divided to
  split(bi)1.

13
Restructuring example
mT ? 3 SB ? 2
merge?1
merge?2
split
split
10
13
17
14
13
11
25
70
10
30
10
1
6
7
8
9
5
4
3
2
15
15
10
24
23
23
25
38
17
23
10
1
7
8
9
5
4
2
3
6
14
Multi-dimensional ST-histogram

• Initialization
• Assuming a complete uniformity and independence.
• Using existing one-dimensional ST-histograms
  assuming independence of the attribute .

15
Refining the buckets frequencies
Multi-dimensional

• The refining algorithm for multi-dimensional is
  identical to the algorithm for one-dimensional
  except the two following changes
• Finding the overlap selected range, now require
  examining a multi-dimensional structure.
• The fraction of a bucket overlapping the
  selection range is now equal to the volume of the
  region divided by the volume of the region
  represented by the whole bucket.

16
Restructuring
Multi-dimensional

• Merge find the max difference in freq between
  any two corresponding buckets of the same line,
  merge if the difference within mt . ( mlt1 ).
• Split the frequency of partition ji in
  dimension i is
• compute by

1,5 6,10 11,15 16,20 21,25
Max S 50
10 5 8 20 7
14 9 7 19 11
1,10
11,20
Max diff 4
Max S 60
17
Accuracy of ST-histogram
Due to the same memory limit and the complex of
MHIST-2, st-histogram have more buckets.
18
Adapting to Database Updates
R1 relation before update with skew 1 . R2 -
Update the relation by deleting 25 of its
tuple and inserting an equal number of tuples.
19
Accuracy dependence of the frequent queries.
20
Conclusions

• Better than assuming uniformity and independence
  for all values of data skew (z).
• For low data skew the st-histograms found to be
  sufficient accurate comparing to the traditional
  histograms.
• Attractive for multi-dimensional histogram since
  the high cost of building them .
• For high data skew, st-hist much less accurate
  than Mhist-2 .
• Combination between traditional hist and st-hist
  for all the range of data skew can yield the best
  of each concept .
