COSCAP-SA

1
COSCAP-SA
DCPCourse
2

• Course Objectives
• Validate DCP authority
• Promote standardization
• Review standards and
• procedures
• Review flight testing
• procedures

3

• Course Schedule
• Introduction
• ICAO SARPS
• General Conditions
• DCP Qualifications
• DCP Terms of Reference

4

• Course Schedule (cont)
• Principles of Testing
• Principles of Assessment
• Conducting a PPC
• PPCTolerances
• Assessment Scenarios
• Discussion Groups

5

• Course Schedule
• Introduction
• ICAO SARPS
• General Conditions
• DCP Qualifications
• DCP Terms of Reference

6
Introduction

• Course Instructor
• Captain Len Cormier
• COSCAP-SA

7
. Participation . Tea Break .
Promptness . Washrooms ..enjoy the course
8
(No Transcript)
9
(No Transcript)
10
(No Transcript)
11
(No Transcript)
12

• Course Schedule
• Introduction
• ICAO SARPS
• General Conditions
• DCP Qualifications
• DCP Terms of Reference

13
ICAO SARPs

• Annex 6, 9.4.4 - Pilot Proficiency Checks
• An operator shall ensure that piloting technique
  and the ability to execute emergency procedures
  is checked to demonstrate competency
• If under instrument flight rules the pilots
  competence to comply with such rules is
  demonstrated
• Either a check pilot of the operator or to a
  representative of the State of the Operator
• Performed twice within any period of one year..

14
ICAO Guidance

• DOC 8335 - Pilot Proficiency Checks
• when properly controlled by the CAA, the
  designation of qualified operator personnel to
  assist in some inspection functions, such as
  periodic pilot proficiency checks, route checks,
  etc., can be acceptable
• it must be stressed that the designated operator
  personnel, when performing their duties, must be
  kept under the supervisory and technical control
  of the CAA.

15
ICAO Guidance

• DOC 8335 - Pilot Proficiency Checks
• Proficiency checks are carried out in accordance
  with the standards and frequency prescribed in
  the regulations
• The CAA inspector should possess the appropriate
  licence and be currently qualified in the
  specific type of aircraft to be used for the
  check
• Alternatively, the CAA inspector may choose to
  observe or monitor such checks conducted by an
  appropriately designated check pilot

16
ICAO Guidance

• DOC 8335 - Pilot Proficiency Checks
• The CAA inspector should observe or monitor a
  sufficient number of checks conducted by such
  personnel each year in order to ensure positive
  CAA quality control of check procedures
• The pilot proficiency check should be conducted
  in such a manner that the pilot demonstrates
  knowledge, skill and judgment relative to
• the aircraft, its systems and components
• pilot performance in accordance with the
  procedures and limitations contained in the
  manufacturer's AFM, AOM, Operations Manual, etc.

17

• Course Schedule
• Introduction
• ICAO SARPS
• General Conditions
• DCP Qualifications/Adm
• DCP Terms of Reference

18
General Conditions

• Delegation Policy
• Perform checks on behalf of CAA
• Restricted to certain checks
• Approved by CAA

19
General Conditions

• Conflict of Interest (Perceived or real)
• Financial interest in the company or family ties
• Privileges or favors which could bias DCP
• Company to review and advise CAA
• To avoid a real conflict of interest, imperative
  to adhere to DCP Manual

20

• Course Schedule
• Introduction
• ICAO SARPS
• General Conditions
• DCP Qualifications/Adm
• DCP Terms of Reference

21
DCP QUALIFICATIONS

• CURRENCY TRAINING REQTS
• a DCP must hold a valid ATPL with rating endorsed
  on type
• a DCP must have completed an DCP Course
• attend a refresher DCP Course every 5 yrs
• conduct at least 10 checkrides a year
• 1000 HRS PIC on appropriate aeroplanes -500hrs
  on type (Type A)
• Minimum of six months experience as Line Captain
  on the aircraft

22
DCP Qualifications contd

• Loss of Medical
• advise CAA
• perform checks in simulator only
• complete requirements of training programme
• every 6 months monitor four sectors

23
DCP Administration DCP Approval Monitoring
DCP Air Operator Responsibilities
24
DCP Approval

• DCP Application from air operator
• Determine need for DCP
• number/variety of aircraft
• location of bases/simulators
• type of operation
• number of DCPs employed

25
DCP Approval

• Inspector briefings
• procedures/techniques for checks
• techniques/standards for assessment
• briefing/debriefing procedures
• completion of forms
• contents of publications

26
DCP Approval

• Monitoring DCP
• Initial DCP Monitors (2), Conducts (1)
• Conduct 12 month PPC on Type A DCP
• Monitoring DCP conducting check every 12 month
• Monitoring activities (reports, etc.)

27
DCP Approval

• Air Operator Responsibilities
• Monitor DCP validity
• Maintain records for audit purposes
• Monthly schedule to CAA
• Advise CAA of due dates
• Submit check report to CAA

28
Limits of Authority
Recurrent PPC Recurrent IRT Line Checks Line
Indoc 1200/600 RVR T/O Cat 2/ Cat 3 Ops
29
Limits of Authority
.

• Semi-annual PPC on Supervisor
• Retest of failed PPC/IRT (CAA advised)
• Recurrent Trng/Checking with approval
• Not Allowed
• initial or upgrade training followed by check by
  same individual
• DCP conducting check ride on Inspector

30
THE APPENDICES

• A. Nomination Form
• B. DCP Approval
• C. Pilots Line Check Report
• D. Schedule of Flight Checks
• E. Check Pilot Monitoring Report
• F. Sample Check Pilot Report
• G. Summary of PPC Standards

31
Professional Update
FMS-FACF -Approaches Approach Changes
GPS-Operations -Requirements
-Testing -Approaches
-Differential GPS RNAV-Direct Routes
-Certification -Approaches
32
GPS Operations
Short Term - Non-Precision approaches - Domestic
enroute/terminal - Oceanic Long Term - CAT I
approaches - Possibly CAT II and III IFR
Approval - US and Canada concurrently
33
GPS Requirements
With RAIM - use GPS for "overlay" and
"standalone" - conventional navaids must work at
alternate - MNPS requirements - 1 GPS and 1 other
RNAV system - need a TSO C129 receiver - no need
to monitor navaids Without Raim - must monitor
navaids - not approved for IFR RAIM - Receiver
Autonomous Integrity Monitoring
34
GPS OVERLAY APPROACHES
approach to use published name (NDB 24) approach
must be in database no monitoring required (with
RAIM) NAVAIDS and a/c receivers
operating requested and approved as GPS
approach (GPS 24) RAIM must be available ground-ba
sed navaids at destination can be inoperative
but navaids at alternate operative
GPS STANDALONE APPROACHES
35
Differential GPS
Wide area Local Integrity and availibity Accuracy
36
Professional Update Designated Check Pilot
Course NAVIGATION WEATHER AIRSPACE
RNAV Direct Routes
37
RNAV Direct Routes
Presently 3 types of route are available 1)
Random direct FL 390 and above 2) City pair
T-routes FL 310 and above 3) MMT routes FL 350
- FL 390 Random routes to be available in
future MMT-Minimum Time Track
38
RNAV Approaches
Multi-Sensor RNAV RWY 08 YTZ Certification of
receivers a problem All approaches could be
RNAV Type of sensor - determine limits All info
must be in database
and operator certified for use
39
FMS FACF
FINAL APPROACH COURSE FIX
Required by FMS databases On final about 8 NM
from threshold Prior to vnav/FAF ICAO 5-letter
pronounceable name For all ILS and LOC approaches
40
FMS Approaches

• Database Jeppesen
• Types of FMS Approaches




GPS RNAV VOR,VOR/DME NDB,NDB/DME LOC/BC LOC ILS
with advanced EFIS
41
Approach Changes
NAME CHANGES soon to be RNAV and then MDA will be
based on the type of sensor POSITION
REPORTS During approaches at controlled
airports - Make requested reports only - Report
position only - Expect report at FAF
42
Approach Changes
Pass altitude on departure - Initial call add
passing altitude and give cleared altitude If
pilot cannot make an altitude restriction -
Pilot actions ask for instructions
enter hold if no instructions - Controller
actions protect holding airspace
43

• Course Schedule
• 1/2
• Introduction
• Forms and Administration
• DCP Quals/Reqts/Terms
• Canadian Aviation Regs
• Instrument procedures

44
Instrument Procedures 1 Outline 1. Flight
Planning 2. Departure 3. Enroute 4.
Holding 5. Arrival 6. Approach 7. Missed
Approach 8. Circling 9. Landing
45
Instrument Procedures 1 Outline 1. Flight
Planning 2. Departure 3. Enroute 4.
Holding 5. Arrival 6. Approach 7. Missed
Approach 8. Circling 9. Landing
46
Definitions
Shall Imperative, procedure is
mandatory Will Mandatory, comprehensive, and
dispositive in nature Must Primarily
mandatory, not the only meaning, used for both
permissive and mandatory sense May
Speculation, uncertainty, permissive Should
Implying duty of obligation, also
permissive Practical Available or useful in
practice - inclined or suited to action
rather than speculation Practicable Physically
possible The above definitions are
summarized/paraphrased from Black's
Law Dictionnary except "Practical" which was
copied from the Concise Oxford Dictionary.
47
New Altimeter Error Policy
"An aircraft altimeter which has the current
altimeter setting applied to the subscale should
not have an error of more than 50ft when
compared on the ground against a known
aerodrome/runway elevation. If the error is more
than 50 ft the accuracy of the altimeter is
questionable and the problem should be
investigated." (CAP.GEN)
48
Fly Runway Heading
When instructed to fly runway heading or when
flying a SID for which no specific heading is
published, pilots are expected to Fly runway
heading Do not apply drift correction FMS
fly track
49
Standard Climb Gradient
50
Obstacle Clearance after T/O
VFR climb (Y/N) Departure procedure(Y/N) Missed
approach procedure(Y/N) Sector altitudes(Y/N) Topo
maps or local knowledge(Y/N) SID- pilot and nav

51
Holding Pattern
52
Max Holding Speeds
Jet - 14K and below - 230 kt - above 14 K
- 265kt - in climb - 175
kt Prop - 175 kt Turbulence -
280kt/ Mach .80
53
Instrument Procedures 2 Outline 1. Flight
Planning 2. Departure 3. Enroute 4.
Holding 5. Arrival 6. Approach 7. Missed
Approach 8. Circling 9. Landing
54
Speed Limits
200kts below 3,000 ft within 10 NM of tower 250
kts below 10,000 ft (exemptions)
55
Minimum IFR Alttudes (Controlled Airspace)
a) Minimum Enroute Altitude (MEA) b) Minimum
Obstruction Clearance Altitude (MOCA) c)
Geographic Area Safe Altitude (GASA) d) Minimum
Sector Altitude (MSA) e) Safe altitude 100 NM f)
Minimum vectoring altitude g) Transition
altitude ATC is not permitted to approve or
assign any IFR altitude below the minimum IFR
altitude
56
Altitude Correction Chart
A/D Height above the elevation of the altimeter
Source
Temp oC 200 300 400 500 600
700 800 900
0o 0 20 20 20 20
40 40 40 -10o 20 20
40 40 40 60 80
80 -20o 20 40 40 60
80 80 100 120 -30o 40 40
60 80 100 120 140
140 -40o 40 60 80 100 120
140 160 180 -50o 40 80
100 120 140 180 200 220
Note Values should be added to published
altitudes
57
Altimeter Settings Requirements

• Before commencing an IFR approach, set
• current altimeter setting
• Altimeter setting can be local or remote
• Readings are considered current for up to 90
• minutes
• If pressure falling rapidly, may add value to
• published DH/MDA
• Correction factor to be applied for remote
• altimeter source
• Temperature correction to be applied
• in all cases

58
Visual Approach
VFR approach while on IFR flight plan Weather -
VFR (300m- 5km) ATC may give radar vectors to
gain operational advantages Weather - ceiling
200m above min vector altitude - ground vis at
least 5 km Condition pilot shall be in visual
contact with the airport and/or traffic Pilot is
responsible for - Wake turbulence separation -
noise abatement - Obstacle clearance
59
Cleared for an Approach
Cleared for an approach Can fly any published
inst. approach Can descend to minimum IFR
altitudes Three route options - cleared
route - transition - direct Must advise ATC
which route and approach
60
Straight-In Approach
No PT published straight-ins ATC radar-vectored
straight-ins Can not do straight-in otherwise
61
(No Transcript)
62
Aircraft Approach Category

• Category A B C D
  E
• Speeds UP to 91kt- 121- 141-
  Above
• 90kt 120kt 140kt 165kt
  165kt
• All rotocraft are Category A
• Use speed flown on approach to determine
  category
• Use Minima for category flown

63
Glidepath Fails During ILS
Advise ATC Determine new minima Change beacon
X-ing alt Time and descent rate to MDA If in
doubt, overshoot
64
Light Settings and RVR
RVR readouts compensate for the setting of the
runway edge lights. At setting 5 the RVR will
give the highest reading. This will affect the
RVR readout even if the runway lights are
off. ATC should advise pilots when the
runway light intensity is at setting 4 or 5.
65
Missed Approach During Circling
Commence climb Advise ATC Turn toward airport
(normally) Fly published procedure Use local
knowledge and plate to make a safe procedure
66
Circling Approach Area Radii

• Approach
• Category
• A
• B
• C
• D
• E

Radius (Miles) 1.3 1.5 1.7 2.3 4.5
Keep runway in sight Stay at MDA until normal
landing assured
67
Landing Minima
Landings are governed by published
DH/MDAs. Pilots of aircraft on instrument
approaches are prohibited from continuing the
descent below DH or MDA, unless the required
visual reference is established and maintained in
order to complete a safe landing.
68
Visual References
At least one of the following a) The runway or
runway markings b) The runway threshold or
threshold markings c) The touchdown zone or
touchdown zone markings d) The approach
lights e) The approach slope indicator
system f) The runway identification lights
(rils) g) The threshold and runway end
lights h) The touchdown zone lights i) The
runway edge lights or j) The runway centreline
lights.
69
Harvard Mk.iv
Questions?
