Title: ECE 480


1
ECE 480 Team 6
Capacitive Rain Sensor for Automatic Wiper Control
  • In Order of Presentation
  • Ishaan Sandhu
  • Danny Kang
  • Arslan Qaiser
  • Eric Otte
  • Anuar Tazabekov

2
Outline
  • Introduction
  • Design Requirements
  • Proposed Design Solution
  • Testing Results
  • Budget
  • Demonstration
  • Conclusions

3
Introduction
  • Automotive Safety and Convenience
  • Automatic Headlights
  • Hands-Free Calling
  • Automatic Braking
  • Automatic Windshield Wipers
  • Currently Optical (Expensive, Inaccurate)
  • DT6 Proposes Using a Capacitive Based Sensor

4
Capacitive Sensor Basics
5
Design Requirements
  • Functionality
  • Detect rain through 6 mm of glass
  • Output control signals to wipers
  • Accuracy
  • Differentiate multiple levels of rain
  • Ignore false stimuli on windshield, i.e.
    hands and dirt
  • Compatibility
  • Fit in existing housing area (1250 mm2)
  • Mount via adhesive to windshield
  • Cost
  • Production cost lt 16 per unit

6
System Block Diagram
7
Design Flowchart
Control Unit
8
Sensor Traces
  • COMSOL
  • 3D Modeling Software
  • Visual User Interface
  • Calculates the base capacitance
  • Can model dielectrics
  • Top layer
  • Bottom Layer
  • Simulates electric field lines
  • Sensitivity

9
Capacitance-to-Digital Converter
Make text larger
  • Analog Devices AD7745
  • Industry-leading accuracy down to 4 fF change in
    capacitance
  • Interfaces with sensor traces to monitor
    capacitance (/- 4 pF)
  • Converts changing capacitance to 24-bit digital
    output signal
  • Output routed to PIC using the I2C communication
    system

10
Microcontroller
Make text larger
  • Microchip PIC16F1826
  • 8-bit microcontroller, programmable in C code
  • Initializes and configures AD7745 for operation
  • Streams data from AD7745 and compares to known
    data ranges
  • Data falling in range will activate appropriate
    wiper control signals

11
Budget
COMPONENT COST
PIC16F1826 Microcontroller 0.90
AD7745 CDC 4.50
ADP3301-5 Voltage Regulator 1.40
Surface-mount Passive Components 0.10
Two-layer PCB Production and Assembly 4.00 (est)
Plastic Enclosure 0.50 (est)
Total 11.40 (est)
12
Capacitive vs. Optical
Design Team 6 Supplier (TRW) Change
Technology Capacitive Optical
Cost per Unit 11.40 16.41 31 ?
Physical Size 1,750 mm2 3,850 mm2 46 ?
Detection Area 960 mm2 560 mm2 72 ?
Clear line of site No need Required
13
Software
14
Demonstration
15
Conclusions
  • Successful completion of the project
  • Exceeds all design requirements
  • Higher accuracy
  • Larger sensing area
  • Smaller enclosure
  • Significant savings

16
Q A
17
Thank You
