Metamorphic Rocks

1
Metamorphic Rocks
2
Metamorphism

• Literally translates to change of form
• In geology it refers to solid-state changes in
  mineral assemblages of a rock, and/or the texture
  of these minerals
• Due to changes in temperature and/or pressure

3
Sources of Heat for Metamorphism

• Heat from Earths interior
• Geothermal gradient is the increase in
  temperature with depth
• Typical continental geothermal gradient is
  25-30C/km
• Volcanically active areas have geothermal
  gradients of 30-50C/km
• Oceanic trenches have geothermal gradients as low
  as5-10C/km

4
Sources of Heat for Metamorphism

• Heat from magma
• Emplacement of magma chambers will add heat to
  the immediately surrounding rock
• Gabbroic magma 1300C
• Granitic magma 700C

5
Pressure Associated with Metamorphism

• Lithostatic pressure the confining pressure
  created by the material that sits above a
  particular location. Lithostatic pressure is
  equal in all directions and compresses the volume
  of rock.
• Basalt 3 g/cm3 (3000 kg/m3)
• Granite 2.7 g/cm3 (2700 kg/m3)
• The lithostatic pressure at a 10 kmdepth is 3
  kbar 0.3 GPa

6
Pressure Associated with Metamorphism

• Directed pressure pressure is imposed in a
  particular direction due to a regional stress
  field.
• Directed pressure affectsthe shape and
  arrangementof the  minerals
• Directed pressure varies with tectonic
  environment
• Compressional environments Horz gt Vert Pressure
• Extensional environments Vert gt Horz Pressure

7
Types of Metamorphism

• Contact Metamorphism
• Thermal variation controls processes
• Regional Metamorphism
• Orogenic Metamorphism
• Combination of temperature and directed pressure
• Burial Metamorphism
• Combination of temperature and lithostatic
  pressure
• Fault-Zone Metamorphism
• Directed pressure controls processes (GEOL 41.1)

8
Contact Metamorphism

• Occurs adjacent to igneous intrusions
• Temperature contrast between magma chamber and
  host rock
• Most evident in low-pressure (near-surface)
  environments

9
Regional Metamorphism

• Increase in temperature is accompanied by an
  increase in pressure
• Usually there is directed pressure, so rock
  deformation increases with metamorphic grade

10
Development of Foliations
Recrystallization
Pressure Solution
Rotation
Remobilization
11
Metamorphic Zonesand Facies
12
Mineral Zones of G.W. Barrow (1893)

• Barrow noted that pelitic rocks of the Scottish
  Highlands had distinct mineral zones (Gt, Ky,
  Sil)
• He concluded that this was the result of
  increasing metamorphic grade (T)
• Tilley (1925) added the low-grade Biotite and
  Chlorite zones
• Bt, Gt, St, Ky, and Sil are Index Minerals in
  metapelitic rocks

Excerpted From Gillen (1982) Metamorphic Geology.
An Introduction to Tectonic and Metamorphic
Processes.
13
Index Mineral Isograds

• The line that defines the first appearance of an
  index mineral corresponds to a line of equal
  metamorphic grade
• Introduction of the concept of an isograd

14
Eskola and Metamorphic Facies

• Eskola (1914, 1915) noted that metapelitic rocks
  in southern Finland (Orijärvi) contained the
  assemblage Bt-Ms whereas near Oslo, rocks
  contained the compositionally equivalent mineral
  assemblage Kf-Cd
• If rocks are the same composition, then the
  mineralogical difference must be due to a
  difference in physical conditions

2 KMg3AlSi3O10(OH)2 6 KAl2AlSi3O10(OH)2 15
SiO2 ? 3 Mg2Al4Si5O18 8 KAlSi3O8 8 H2O
15
Eskola and Metamorphic Facies

• Eskola (1915) introduced the concept of
  metamorphic facies
• In any rock or metamorphic formation which has
  arrived at a chemical equilibrium through
  metamorphism at constant temperature and pressure
  conditions, the mineral composition is controlled
  only by the chemical composition.
• A metamorphic facies is a set of repeatedly
  associated metamorphic mineral assemblages
• If you find a specified mineral assemblage, then
  you can assign a metamorphic facies to the area,
  and thereby assign a range of pressure and
  temperature conditions.

16
Eskola and Metamorphic Facies

• In 1920, Eskola introduced five metamorphic
  facies that were defined by mineral assemblages
  in metabasites
• Greenschist
• Amphibolite
• Hornfels
• Sanidinite
• Eclogite
• In 1939, Eskola added an additional 3 metamorphic
  facies
• Granulite
• Epidote-amphibolite
• Glaucophane-schist (now called Blueschist)
• In 1959 and 1960, Coombs added two additional
  metamorphic facies
• Zeolite
• Prehnite-Pumpellyite (now called Subgreenschist)

17
(No Transcript)
18
Progressive Metamorphism of Shales
Increasing Temperature
Gneiss
Schist
Slate
Phyllite
19
Non-Foliated Metamorphic Rocks
