Geometry Surface Area of Pyramids and Cones

1
Geometry Surface Area of Pyramids and Cones
2
Warm Up
3
Surface Area of Pyramids and Cones
The vertex of a pyramid is the point opposite the
base of the pyramid. The base of a regular
pyramid is a regular polygon, and the lateral
faces are congruent isosceles triangles. The
slant height of a regular pyramid is the distance
from the vertex to the midpoint of an edge of the
base. The altitude of a pyramid is the
perpendicular segment from the vertex to the
plane of the base.
Next page
4
The lateral faces of a regular pyramid can be
arranged to cover half of a rectangle with a
height equal to the slant height of the pyramid.
The width of the rectangle is equal to the base
perimeter of the pyramid.
5
Lateral and surface Area of a regular pyramid
The lateral area of a regular pyramid with
perimeter P and slant height l is L
1/2Pl. The surface area of a regular pyramid
with lateral area L and base area B is S L B,
or S ½ pl B.
6
Finding Lateral and surface Area of Pyramids
Next page
7
b.)Find the lateral area and surface area of each
regular pyramid.
Step 1
Find the lateral area. L ½ Pl
Lateral area of a regular pyramid ½
(24)(7) 84 m Substitute 24 for P and 7 for
l.
Step 2
8
Now you try!
1) Find the lateral area and surface area of a
regular triangular pyramid with base edge length
6 ft and slant height 10ft.
9
The vertex of a cone is the point opposite the
base. The axis of a cone is the segment with
endpoints at the vertex and the center of the
base. The axis of a right cone is perpendicular
to the base. The axis of an oblique cone is not
perpendicular to the base.
Next page
10
The slant height of a right cone is the distance
from the vertex of a right cone to a point on the
edge of the base. The altitude of a cone is a
perpendicular segment from the vertex of the cone
to the plane of the base.
11
Lateral and Surface Area of a right cone
12
Finding Lateral Area and Surface Area of right
cones
A) A right cone with radius 2 m and slant height
3 m.
Next page
13
B)
Step 2
Find the lateral area and surface area.
14
Now you try!
2) Find the lateral area and surface area of the
right cone.
15
Exploring Effects of Changing Dimensions
The radius and slant height of the right cone
tripled. Describe the effect on the surface area.
16
Now you try!
3) The base edge length and slant height of the
regular square pyramid are both multiplied by 2/3
. Describe the effect on the surface area.
17
Finding Surface Area of Composite
Three-Dimensional Figures
Find the surface area of the composite figure.
Next page
18
(No Transcript)
19
Now you try!
4) Find the surface area of the composite figure.
20
Electronics Application
Tim is replacing the paper cone of an antique
speaker. He measured the existing cone and
created the pattern for the lateral surface from
a large circle. What is the diameter of the cone?
21
Now you try!
5) If the radius of the large circle were 12 in.,
what would be the radius of the cone?
22
Now some problems for you to practice !
23
Assessment
1) Describe the endpoints of an axis of a cone.
24
2) Find the lateral area and surface area of each
regular pyramid.
b.
a.
25
b.
a.
26
4) Describe the effect of each change on the
surface area of the given figure.
b. The dimension are tripled.
a. The dimensions are cut in half.
27
5) Find the surface area of each composite figure.
b.
a.
28
6) Anna is making a birthday hat from a pattern
that is ¾ of a circle of colored paper. If Annas
head is 7 inches in diameter, will the hat fit
her? Explain.
29
Lets review
30
Surface Area of Pyramids and Cones
The vertex of a pyramid is the point opposite the
base of the pyramid. The base of a regular
pyramid is a regular polygon, and the lateral
faces are congruent isosceles triangles. The
slant height of a regular pyramid is the distance
from the vertex to the midpoint of an edge of the
base. The altitude of a pyramid is the
perpendicular segment from the vertex to the
plane of the base.
Next page
31
The lateral faces of a regular pyramid can be
arranged to cover half of a rectangle with a
height equal to the slant height of the pyramid.
The width of the rectangle is equal to the base
perimeter of the pyramid.
32
Lateral and surface Area of a regular pyramid
The lateral area of a regular pyramid with
perimeter P and slant height l is L
1/2Pl. The surface area of a regular pyramid
with lateral area L and base area B is S L B,
or S ½ pl B.
33
Finding Lateral and surface Area of Pyramids
Next page
34
b.)Find the lateral area and surface area of each
regular pyramid.
Step 1
Find the lateral area. L ½ Pl
Lateral area of a regular pyramid ½
(24)(7) 84 m Substitute 24 for P and 7 for
l.
Step 2
35
The vertex of a cone is the point opposite the
base. The axis of a cone is the segment with
endpoints at the vertex and the center of the
base. The axis of a right cone is perpendicular
to the base. The axis of an oblique cone is not
perpendicular to the base.
Next page
36
The slant height of a right cone is the distance
from the vertex of a right cone to a point on the
edge of the base. The altitude of a cone is a
perpendicular segment from the vertex of the cone
to the plane of the base.
37
Lateral and Surface Area of a right cone
38
Finding Lateral Area and Surface Area of right
cones
A) A right cone with radius 2 m and slant height
3 m.
Next page
39
B)
Step 2
Find the lateral area and surface area.
40
Exploring Effects of Changing Dimensions
The radius and slant height of the right cone
tripled. Describe the effect on the surface area.
41
Finding Surface Area of Composite
Three-Dimensional Figures
Find the surface area of the composite figure.
Next page
42
(No Transcript)
43
Electronics Application
Tim is replacing the paper cone of an antique
speaker. He measured the existing cone and
created the pattern for the lateral surface from
a large circle. What is the diameter of the cone?
44
You did a great job today!
