Observational Surveys: Implementation and Analysis

1
Observational Surveys Implementation and Analysis
2
Observational Surveys - Speakers

• William W. Stenzel, D.Sc.
• Associate Director, Center for Public Safety
  (Management Consulting)
• Roy E. Lucke
• Director, Research and Development for the Center
  for Public Safety

3
Notebook Materials

• A hardcopy of all of the PowerPoint slides for
  this session (Observational Surveys) can be
  found in the seminar notebook.

4
Why Use Observational Surveys?

• For the Illinois Traffic Stop Statistics Study,
  disparities are going to be calculated by
  comparing
• the racial composition of traffic stops
• the racial composition of the driver population.
• The racial composition of the driver population
  is going to estimated by using adjusted census
  data at the city and county level.

5
Why Use Observational Surveys?

• What options does an agency have if there is
  concern that the adjusted census data will not
  provide accurate information about the racial
  composition of the driver population in its
  jurisdiction?
• One option is to obtain a better estimate of the
  racial composition of the driver population with
  the use of observational surveys.

6
Center for Public Safety Experience with
Observational Surveys

• The Center for Public Safety has conducted three
  observational surveys for agencies in Illinois
• Highland Park (Sept-Oct 2001 Stenzel)
• Hinsdale (May 2004 Lucke)
• Schaumburg (August 2004 Lucke)

7
Observational Survey Topics

• Observational Surveys
• Topic 1 Data Collection
• the nuts and bolts of how to conduct a survey
• Topic 2 Data Summarization
• putting the survey data into a format suitable
  for review and analysis
• Topic 3 Data Analysis
• comparing and assessing the survey and traffic
  stop data

8
Observational Surveys - Topic 1

• Topic 1 Data Collection
• The nuts and bolts of how to conduct a survey

9
Conducting Observational Studies

• Once the decision is made to do an observation
  study, there are three major tasks
• Determining what data to collect
• Identifying data collection sites
• Recruiting and training observers

10
Conducting Observational Studies

• In addition to the three major tasks, other steps
  include
• Scheduling data collection
• Equipping the data collectors
• Developing forms, data entry and data analysis
  procedures

11
Preliminary Information

• It is only possible to obtain good driver
  demographic information from stopped vehicles
• Observations can only be made at intersections
  with traffic signals or stop signs
• Efforts to observe drivers on controlled-access
  roadways were not successful

12
Site Selection

• Primary Criteria
• Conduct observations at or near intersections
  that are among the agencys high traffic stop
  locations.
• Agency should try to identify locations for all
  stops, not just where citations are issued
• Also identify times of day and days of week for
  stops so observation times can be matched as well
  as possible

13
Site Selection, Continued

• Site must provide a good view of stopped vehicles
• Steep shoulders may raise observers too high
• Sweeping right turn lanes might keep observers
  too far from lanes to see
• No limit on number of lanes observers need only
  check lanes they can clearly see
• Site must be safe for observers
• There must be a shoulder or sidewalk curbs are
  desirable
• Observers must be free from potential harassment

14
Survey Sessions

• Session is a 2 or 3 hour observation period
• Sessions should be distributed across all days of
  the week, according to traffic stop information
• Sessions can be done
• Mornings
• Afternoons
• Early evenings
• Again, dependent on stop information and
  available daylight
• Surveys should be done in both directions of
  travel

15
The Survey Team

• Three individuals are needed for each session
• Observer
• Recorder
• Counter

16
The Survey Team, Continued

• Team members can be recruited from a number of
  possible sources.
• Agency volunteers or auxiliaries
• College students (e.g., criminal justice
  students)
• Crossing guards
• Temporary labor pools
• Etc.

17
The Survey Team, Continued

• Training must be provided to survey team members
• Classroom instruction covering the nature of the
  project and what they will be expected to do
• Practice sessions under guidance of project
  leaders
• Team members must be scheduled in groups of
  threes at dates and times identified for surveys.

• Have substitutes available
• Project leaders should oversee all observation
  sessions

18
Sample Agenda for Observer Training

• Agenda
• Review Agenda
• Complete Forms
• Driver Survey
• Vehicle Counter
• Field Work
• Schedule/Signups

19
Survey Team Equipment

• Safety vests
• Traffic counting devices (or digital cameras)
• Clipboards and pencils
• Rain gear (ponchos, umbrellas, writing pouches)

20
Data Items to be Recorded

• Each agency must decide what data items they
  believe are important to capture. Candidates
  items include
• Driver race/ethnicity
• Driver gender
• Driver age
• Number of passengers in vehicle
• Driver residency
• Type of vehicle

21
Data Collection

• Paper check mark form
• Scantron form
• Palm or other hand-held device
• Tablet-type personal computer
• Each session should be stored as a separate file,
  either in a physical packet or data file

22
Sample Data Collection Form
23
Number of Observations

• The number of data collection sessions can be
  affected by
• Traffic volume
• Roadway configuration (number of lanes)
• Stop signs or traffic signals
• Number of data items to be collected
• General observations
• Higher capture rates (75 - 100 of drivers) at
  stop signs, but usually lower traffic volumes
• Lower capture rates (20 - 75) at signalized
  intersection depending on volume, number of
  lanes, and signal timing

24
Observation Limitations

• Can be done only during daylight hours
• Glare from windows (or window tinting) can affect
  observation
• Weather (rain, snow, excessive heat)
• Subjective decisions be observers
• Cost of doing surveys (labor intensive activity)

25
Topic 2 Data Summarization

• Data Summarization
• Recordkeeping
• Data Entry
• Data Base Software

26
Topic 2 Data Summarization

• Recordkeeping - additional information that
  should/can be added to each observation (record)
• Location (should)
• Day of the week (should)
• Time of day (should)
• Direction of traffic (optional)
• Data collectors (optional)

27
Topic 2 Data Summarization

• Data Entry - getting the data into an electronic
  format
• The old fashion way keying the data in
• Use machine-readable data collection forms (e.g.,
  Scantron)
• Download from a file created at the time of data
  collection (e.g., from a Palm Pilot or a PC
  tablet)

28
Topic 2 Data Summarization

• Data Base Software - a computer program that can
  be used to
• Manipulate the data (i.e., sort and filter)
• Display the data (i.e., print summary tables and
  charts)
• Describe the data (i.e., compute various
  descriptive attributes)
• number of observations
• Average value
• Minimum and maximum values
• Examples (Access, EXCEL)

29
Topic 2 Data Summarization

• Example of a printout

30
Observational Surveys - Topic 3

• Topic 3 Data Analysis
• Comparing and assessing the survey and
• traffic stop data

31
Topic 3 Data Analysis

• Data analysis consists of comparing two sets of
  data
• Traffic stop data
• Driver survey data
• And addressing the question Are differences
  between the two sets of data important?

32
Data Analysis A Sample Comparison
5
Two data sets

• Question Are the differences in the percentages
  between the traffic stop data and the driver
  survey data in the each racial category
  important?
• Are differences due only to natural variation, or
• Are differences due to the some outside influence
  on the officers decision about whom to stop
  (e.g., race)?

33
Statistical Benchmarking

• Statistical benchmarking consists of
• Comparing two sets of data
• Encounter data the racial composition of drivers
  in traffic stops, and
• Survey data the racial composition of drivers
  who are potential participants in a traffic stop
• A procedure for assessing the significance of
  differences in the percentages between the two
  data sets

and
34
Statistical Benchmarking

• Highland Park
• Statistical benchmarks were used to assess the
  importance of the differences in the percentages
  in the driver survey and traffic stop data.
• The benchmarks were determined using a
  statistical procedure called confidence
  intervals.

35
Confidence Interval Example

• Example Is the difference between the two
  percentages for Hispanics (i.e., 24.0 and 18.6)
  important?
• One way to address this is to determine a range
  of values (i.e., a confidence interval) for the
  expected number of traffic stops involving
  Hispanic drivers.

36
Confidence Interval Example

• Example The confidence interval for the number
  of Hispanics in the traffic stop data shown above
  is
• 64, 96.
• This interval can be interpreted as follows
• If the decision about who to stop is not
  influenced by race, then the expected number of
  Hispanics stopped, due to normal variation,
  should fall between 64 and 96.

37
Confidence Intervals Example

• The upper and lower limits for the confidence
  interval can be interpreted as statistical
  benchmarks for the number of Hispanics stopped.
• The limits are determined based on
• Total number of traffic stops (408)
• Estimated number of Hispanics in the driver
  population
• Selected confidence level

38
Confidence Interval Example
1

• Example The statistical benchmarks for the
  expected number of Hispanics, 64, 96, is based
  on a confidence level of 95.
• The 95 confidence level means the margin of
  error is 5.
• A 5 margin of error means that there is 5
  chance that even with normal statistical
  variation the number of Hispanics stopped could
  fall below 64 or above 96.

39
Statistical Benchmark Example
2

• The upper and lower benchmarks for each racial
  category are shown at the bottom of the table.
• These benchmarks are compared with the actual
  number of encounters in each racial category.
• Except for Hispanics, the actual number of stops
  within each category falls within the benchmark
  limits.

40
Statistical Benchmark Example

• The number of Hispanics stopped in this example,
  98, is outside the statistical benchmarks of 64,
  96.
• THIS DOES NOT PROVE RACIAL PROFILING.
• It indicates that further investigation is needed
  to determine what special circumstances might be
  present that are influencing the number of
  Hispanics that are stopped.

41
Why Use 95?

• Use of 95 for the confidence interval is a
  conservative approach that assumes that racially
  motivated policing is not occurring unless there
  is significant evidence to the contrary.
• Justification for a conservative approach is
  appropriate in view of the many uncertainties
  associated with the data
• Difficulty in identifying race
• Different driver behaviors by race
• Different driver behaviors by gender and age
• Unknown mix of drivers by gender and age by race

42
How Can I Use Statistical Benchmarks?

• The benchmarking procedure described is based on
  statistical procedure called the two-sample test
  for proportions.
• Its use requires a basic understanding of applied
  statistics. (Note Statistical Benchmarks for
  Police Traffic Stops in seminar notebook.)
• To help departments that may want to use
  statistical benchmarking based on this procedure,
  the Center for Public Program has put an
  easy-to-use spreadsheet on its website that can
  be used to find statistical benchmarks.

43
Statistical Benchmarking Spreadsheet
44
Statistical Benchmark Spreadsheet

• The statistical benchmarking spreadsheet can be
  found on the website for the Center for Public
  Safety
• www.northwestern.edu/nucps
• Select Links
• Select Racial Profiling
• At bottom of page under Recent Articles find
• Benchmarking Spreadsheet

45
Contact Information

• William Stenzel
• 847/491-8995
• wstenzel_at_northwestern.edu
• Roy Lucke
• 847/491-3469
• rlucke_at_northwestern.edu
