NUMERICAL ANALYSIS OF PROCESSES

1
NUMERICAL ANALYSIS OF PROCESSES
NAP4
NONLINEAR MODELS of systems described by ordinary
differential equations Initial problem (Runge
Kutta, Adams) Time delay Strange attractors
Rudolf Žitný, Ústav procesní a zpracovatelské
techniky CVUT FS 2010
2
Models ODE initial problem
NAP4
Systems which are described by a system of
ordinary differential equations and their
solutions are fully described by the initial
state, are for example integral models of mass
and enthalpy balances elementary units ("lumped
parameter" or "compartment" models). The aim is
to determine the evolution of state variables
(concentration, temperature) at the time, so it
is an evolutionary problems.
These elementary units may be specific devices
(reactors, absorbers, columns, tanks, filters,
...) in "spread sheets" or zones in apparatuses
in which the state can be characterized by mean
temperature, and the concentration of components
(ideal mixers, plug flow zone). An example is the
description of a stirred vessel system of ideal
mixers below and above a turbine stirrer or a
replacement shell and tube heat exchanger by a
systém of elementary exchangers between the
baffles. Each elementary unit correspond to
ordinary differential equations describing the
mass balance (one for each component of the
differential equation describing the rate of
change of concentration) and a enthalpy
balance (or total energy balance) describing
temperature evolution in the department
volumetric flowrate from neigbouring compartments
volumetric hear source
wnthalpic flows from neighbouring compartments
3
Models ODE initial problem
NAP4
A system need not be described by ordinary
differential equations with only first
derivatives. Eg. the equations of vibration
include also the second time derivative
(acceleration)
But every such equation can be replaced by a
system of equations with only first derivatives,
e.g.
The initial problem is characterized by the fact
that each computed variable corresponds to one
differential equation of the first order and to
one initial condition (value) corresponding to
the initial state.
or how many equations so many initial conditions
corresponding to one value of independent
variable.
4
Models ODE initial problem
NAP4
backmixing model (dispersion, diffusiion)
Example of continuous system
(1rb)Q
6
5
(1r)Q
4
Q,x(t)
1
2
bQ
Ci, Ti
sQ
rQ
3
7
model of stagnant zone
recirkulation with transport delay
Differential equations for concentrations
Parameters determining distribution of flowrates
(s-stagnant zone, r-recirculation, b-backmixing)
must be specified, r-from flowmeter measurement,
b-from correlations. Also the volume of
individual compartments must be known. These
parameters are most frequently identiofied from
fit of predicted characteristics (for example RTD
- residence time distribution) with experiment.
As a result information about the size of dead
zones, recirculation zones, shortcuts, intensity
of dispersion etc. are obtained.
5
Models ODE Fourier transform
NAP4
The models can be solved by the Fourier
transformation method (see previous lecture
NAZP3). It is not enough to apply only a
convolution, because the model includes
compartments with back mixing, stagnant zone ...
However, you can come out of these differential
equations, transformed by FFT. For the Fourier
transform of derivation applies (assuming that
the concentration at time zero is infinity)
Differential equations are transformed to
algebraic equations, where instead of time t is
frequency f.
This system of algebraic equations (linear!) is
already fairly easy to solve, and the result will
be the Fourier transform of concentration.
Concentration courses in time are then get back
by FFT. The solution is accurate and fast (using
FFT), but is limited to linear models. The
procedure is preferred when the coefficients of
the system (r, b, s) are constant. Otherwise, it
was necessary to compute the Fourier transform of
the product of two functions (and it is not equal
to the product of the transformation). In the
general case with nonlinear terms is therefore
better to stay in the time domain and seek
solutions to the numerical integration of the ODE.
6
Models ODE Laplace transform
NAP4
Similar relationships hold also for Laplace
transform the same convolution, correlation and
transformation of derivatives
Inverse Laplace transform is usually searched in
dictionaries, for example
7
ODE initial problem numerical solutions
NAP4
One-step methods approximate solution at time
tk1tk? by estimating mean value of derivative
in interval lttk,tk1gt
Euler metods are easily programmable even in Excel
first order of accuracy means that the error is
directly proportional to the step ?
when you write a Taylor expansion for one time
step, the error is O(?2), a second-order
accuracy. Errors, however, accumulate, so 1/?
steps will result in an error O(?).
Euler method explicit order of accuracy ?
(first) stable only for small integration steps ?
Euler method implicit order of accuracy ?
(first) stable, but iterations are necessary
(because ck1 is unknown)
8
ODE initial problem numerical solutions
NAP4
One-step methods approximate solution at time
tk1tk? by estimating mean value of derivative
in interval lttk,tk1gt
Runge Kutta methods calculate mean value of
derivative as a weighted average of derivatives
f(t,c). The most often used version calculates
four points (endpoints tk, tk1 and two midpoints
at tk1/2)
This variant is implemented in MATLABu as a
function ode45
Weight coefficients (1/6,1/3,1/3,1/6) and
increments c are designed so that the order of
accuracy is the highest (4th order of accuracy in
this case). Generally, the order of accuracy of
RK methods is the same as the number of evaluated
points.
9
ODE initial problem numerical solutions
NAP4
Multistep methods approximate solution at time
tk1 on the basis of several previous values for
example at times tk, tk-1 (two), or tk-2
(three-step method).
This is usually a combination of predictor
(explicit) and corrector (default formula with
higher precision and stable)
it is sufficient to evaluate just one value
Both formulas are second order accuracy but
corrector (implicit formula) has the absolute
value of the error about 9-fold lower (implicit
formulas tend to have an error less than
explicit, even if the order errors is the
same). The disadvantage is that for the first two
steps a single-step method, for example RK, must
be used. On the other hand, number of computed
derivatives is smaller.
10
ODE initial problem numerical solutions
NAP4
Dynamic adjustment of integration step ?
The simplest solution is that each step is
performed twice, once with step ? and then with
increments ?/2 (twice). If the difference is
greater than the specified tolerance, the step ?
shrinks. Using the two calculated values (for
full and half step) the accuracy of the final
value can be improved by so called Aitken
extrapolation. MATLAB uses a dynamic choice of
the time step automatically.
Stiff problem
When you solve a system of equations may be that
the integration step is dictated by the equation
with an extremely short time constant, and the
stability of the solution then requires extremely
short integration step (the calculation time is
prohibitively increased). We say that the system
is stiff. Some methods of integrating ODE this
unpleasant impact suppresses (an example is
Gearova method).
Transport delay (time shift)
Time delay was included in the previous example.
In this case the solver should remember the whole
history of calculated results and not only the
last step. Even the values for negative times
(before the initial time) have to be defined.
11
ODE initial problem numerical solutions
NAP4
Stability analysis
Consider a differential equation describing e.g.
the rate of a chemical reaction of the first order
stability condition restriction of time step ?
(coef. of gain less than 1)
Euler explicit integration formula of the first
order
Euler implicit integration formula of the first
order
gain less than 1 for arbitrary ?
12
ODE examples in MATLAB
NAP4
ode45, ode23 Runge-Kutta (one step method with
different order of accuracy) ode113 Adams
(multistep method) ode15s Stiff (Gear multistep
method with variable accuracy order-suitable for
stiff problems) dde23 transport delay
13
RTD series of mixers 1/4
NAP4
An example has been solved in the previous
lectures using FFT. Series 4 ideally mixed
vessels (container volume, flow rate Q). The aim
is to find the time courses of concentrations
c1,,c4 for arbitrary initial conditions and for
arbitrary course of concentration at inlet x(t).
Mass balances
tm2 odpovídá pomeru V/Q0.5 (to je strední doba
prodlení jedné nádoby)
As an initial concentration x(t) is applied
impulse response of a set of two mixers (the same
volume of tanks) and zero initial concentration
in all tanks. The reason for such an assignment
is that there is an analytical solution that can
be compared with the results of numerical
solution of the ODE. Stimulus function x(t) is
the impulse response of E (t) for N2 and tm1
outlet concentration y(t)c4(t) should be
impulse response for N6 and tm3
14
RTD series of mixers 2/4
NAP4
MATLAB provides for the solution of ODE variety
of methods (ode45, ode113, ode15s, ...) which can
automatically adjust the integration step so as
to achieve the required accuracy. Procedure is
always the same, first define a function whose
output is the vector of first derivatives for a
given value of integration variable (time) and a
solution vector.
In our case it is necessary to define a function
whose result is a column vector (4x1) of
right-hand sides of 4 differential equations. It
will be assumed that the stimulus function x(t)
is the impulse response of nx series mixers, with
a mean time tmx. The parameter tm is the mean
time of the modeled system of 4 mixers.
function dy serie4(t,y,tm,tmx,nx) dy
zeros(4,1) xxefun(t,tmx,nx) tm1tm/4 dy(1)(xx
-y(1))/tm1 dy(2)(y(1)-y(2))/tm1 dy(3)(y(2)-y(3
))/tm1 dy(4)(y(3)-y(4))/tm1
It would probably be smarter if the stimulus
function x(t) was directly the next formal
parameter of the function serie4. I have a little
problem with that in Matlab, I need advice.
The Efun function can be defined as a
sub-function in the m-file serie4.m, but maybe
it's better to define it as a separate m-file
efun.m
function yefun(t,tm,n) ynnt(n-1)/(factorial(n
-1)tmn)exp(-tn/tm)
15
RTD series of mixers 3/4
NAP4
Integration ODE by Runge Kutta method Sol
ode45(function describing right side, time range,
initial conditions) in our case for example
solode45(_at_(t,y)serie4(t,y,2,1,1), 0 10 ,
0 0 0 0)
Vector of initial conditions (zero concentrations)
solver 'ode45' extdata 1x1 struct
x 1x29 double y 4x29 double
stats 1x1 struct idata 1x1 struct.
Integration from t0, to t10. It is not possible
to specify a constant integration step in Matlab
Using a function as an actual parameter looks a
bit strange in Matlab. It is not possible to
write simply the name of this function (serie4)
because ode45 expects only two parameters (t, y)
and the function serie4 has 5 parameters.
Therefore, the so-called anonymous function
_at_(t,y)expression.must be used.
Result is the structure sol containing vector of
time steps sol.x (in this specific case 29 steps
was necessary for prescribed accuracy) and a
corresponding matrix sol.y of calculated
concentrations (four rows for four concentrations)
16
RTD series of mixers 4/4
NAP4
Numerical solution by Runge Kutta (ode45) can be
compared with the analytical solution E(t) for
N6 and tm3
This is demonstration how to define a one-line
function (without using a m-file)
e_at_(t,tm,n) nn.t.(n-1)./(factorial(n-1)tmn).
exp(-n.t/tm) tlinspace(0,10.23,1024) ye(t,3,6)

Standard function linspace generates vector of
1024 equidistant time steps
Sydeval(sol,t)
these points are results of ode45 with
automatically adjusted integration time steps
function deval interpolates the nonequidistant
results sol.y according to the prescribed time
scale t
17
RTD time delay (transport delay)
NAP4
In the case that there are time delays (long
connecting pipelines, recycles) it is not
possible to use the standard integration
functions (ode23,ode45,), but a different
family of MATLAB functions which is capable to
save previous results (with prescribed vector of
time delays ?1 ?2 )
18
RTD delay in recycle 1/2
NAP4
Example continuous system formed by two mixed
tanks with time delay ? in recycle. It is quite
common connecting pipelines are usually modeled
by a time delay. The aim is to find time
courses of concentrations c1(t), c2(t), for given
flowrate (Q), recirculation ratio (r) and volume
of tanks (V1,V2), for prescribed time course of
inlet concentration x(t). The system is described
by the mass balances
time delay
19
RTD delay in recycle 2/2
NAP4
Special ODE solvers must be used in MATLAB (dde23
for a constant time delay, and ddesd for
variable time delay) soldde23(_at_derivatives,
?1, ?2, history for tlttmin, tmin,tmax)
function dcdtdclag(t,c,z) q1 v12 v21 r10
if tlt.2 x1 else x0 end dcdtzeros(2,1
) clagz(,1) dcdt(1)q/v1(x-c(1)) dcdt(2)q/v
2(c(1)rclag(2)-(1r)c(2))
q-flowrate,v1,v2 volumes, r-recycle ratio,
impulse stimulus function x(t) with duration 0.2
seconds
z is the matrix of solutions in times t-?k.
Column index (1) is the index in vector of delays
zero history c1c20 for tlt0
soldde23(_at_dclag,1,00,0,20) plot(sol.x,sol.y)
vector of delays ?11 (there is only one delay)
20
Trajectory of particles
NAP4
The initial problem is also description of motion
of particles under action of forces. Examples are
trajectory of droplets in the spray drying
chamber, motion of particles in a fluidized bed,
burning coal particles in the combustion chamber,
particles in the mixer, a settling tank, etc. The
equations of motion are ODE of the type
acceleration
buoyant, centrifugal, electrical forces
drag for in fluid moving with velocity v
21
Trajectories of particles
NAP4
In the last lecture of the course we will pay
attention to the type of modern methods of DEM
(Discrete Element Method), which simulates the
dynamic behavior of particulate systems such as
hoppers, silos, mills, mixers, separators, solid
and fluid bed. Calculations are based on the
solution of ordinary differential equations of
motion and the consideration of interactions of
individual particles.
Verlet integration of dynamic equations
22
Theory of chaos strange attractor
NAP4
Trajectories of particles calculated also the
meteorologist E.Lorenz (1963) who tried to model
the natural convection in atmosphere, the layer
of air that is heated from below and cooled from
above. After drastic simplifications he obtained
the three ordinary differential equations for the
coordinates x, y, z of a particle in the
atmosphere
Rayleigh-Bénárdova instability
The model has only 3 parameters, Rayleigh number
Ra, Prandtl number Pr and the parameter b is a
slenderness ratio of rotating cells. These 3
equations can be solve easily in MATLAB see next
slide
23
Theory of chaos strange attractor
NAP4
trajektory pf particle fopr Ra10, Pr28, b8/3
function dy chaos(t,y) dy zeros(3,1) dy(1)
10(y(2)-y(1)) dy(2) -y(1)y(3)28y(1)-y(2)
dy(3) y(1)y(2)-8/3y(3) solode45(_at_chaos,0
30,.10001 .1 .1) plot(sol.y(2,),sol.y(3,))
ttlinspace(0,30,3000) sydeval(sol,tt) plot(
sy(2,),sy(3,))
initial coordinates x,y,z
integration up to 30 s
plot graph y-z fro automatically calculated
integration steps
24
Theory of chaos strange attractor
NAP4
Numerically calculated trajectories behave
erratically for Prgt 1 (they do not converge to a
trivial steady steate solution x y z 0),
but they create something that looks like a
counter-rotating swirls of final dimensions, and
these seemingly random trajectories "jump" from
the left to the right wing, and never intersect.
The trajectories are extremely sensitive to
initial conditions and to any disturbances
(including approximation errors of numerical
integration). This limiting state is called
strange attractor
parametric trajectory of particle
z
Such behavior (deterministic chaos) appears at
nonlinear systems when a stability limit is
exceeded (eg Prantl, Reynolds or Rayleigh
numbers). Deterministic chaos is typical for
turbulent flow.
y
25
EXAM
NAP 4
ODE Initial problem numerical solutions, stability
26
Exam - remember
NAP4
Fourier transform of derivatives
What is it initial problem What is it order of
accuracy O(?n) Explicit and implicit Euler
method Principles of RK and multistep methods
(predictor, corrector) Principle of stability
analysis Principle of integration step
optimisation
