Title: Unit and Functional Testing Your Flex Applications


1
Unit and Functional Testing Your Flex Applications
  • Mike Nimer
  • Dir. Of Engineering
  • nomee.com

2
The goal(s) of testing
Isolate each part of the program and show that
the individual parts are correct. Provide a
strict, written contract that the piece of code
must satisfy. Find problems early in the
development cycle. Unit testing allows the
programmer to re-factor code at a later date, and
make sure the module still works
correctly --wikipedia
3
Types of Testing
  • Manual
  • Humans create test scripts.
  • Step by Step instructions (word doc).
  • Humans execute those tests.
  • Low cost to begin. High cost over the life of a
    project
  • Testing generally happens less often
  • Automated
  • Humans create test methods. Machines execute
    those tests.
  • Higher cost to develop. Much lower cost over the
    life of a project
  • Testing can happen continually
  • On every check-in

4
Automated Testing
  • Testing as part of Development
  • As developers create code, they create tests
  • Test Driven Development tests first, code 2nd
  • Tests are continually executed by developer to
    ensure new code does not break existing features
  • Automated build/test environments
  • Part of Continuous Integration
  • Code checked out and built automatically
  • Code continually tested with your tests and
    reports generated
  • Automated QA ensuring a last minute check in does
    not break a release

5
Types of Automated Testing
  • Unit
  • Tests the smallest unit of code that is possible
  • Usually tests a single method or function
  • Multiple tests for every path through a method
  • Usually created by Developer
  • Integration / functional
  • Tests a combination of units
  • Can be used to test UI Components
  • Confirms that individual pieces of code work
    together
  • Created by Developer or QA

6
Tools for Unit Testing
  • Unit Testing
  • (before)
  • FlexUnit - The original Flex/ActionScript 3.0
    unit testing framework.
  • Fluint Written for better asynchronous support
    and support for testing UI components.
  • (today)
  • FlexUnit 4 A merge of FlexUnit 3 and Fluint.
    Providing better asyncronous testing support,
    support for UIComponent testing and IDE
    integration.

7
Tools for Automated Testing
  • These products all use the Flex Automation API,
    to monitor, manipulate, and control the Flex
    application.
  • FlexMonkey
  • TestComplete
  • Selenium (with SeleniumFlex project)
  • Mercury QuickTest Pro 9.1 (QTP)
  • Borland SilkTest
  • IBM Rational Functional Tester

8
Testing Terminology
  • Test Method - A test method is the smallest unit
    of the testing process. A test method executes
    code and checks the outcome.
  • At the end of the test method the developer
    generally makes an assertion, stating the
    expected outcome of this executed code.
  • Test Case - A test case is a collection of test
    methods that share a common test environment,
    also referred to as a test fixture.
  • Test Suite - A test suite is a collection of test
    cases.
  • Test Runner - A test runner is an application
    that executes the test methods in your suites and
    cases.

9
Understanding Assertions
  • assertEquals()Accepts two parameters and is a
    valid assertion if the two values are equal ().
  • assertStrictlyEquals()Accepts two parameters and
    is a valid assertion if the two values are
    strictly equal ().
  • assertTrue()Accepts a single parameter and is a
    valid assertion if the value is true.
  • assertFalse()Accepts a single parameter and is a
    valid assertion if the value is false.
  • assertNull()Accepts a single parameter and is a
    valid assertion if the value is null.
  • assertNotNull()Accepts a single parameter and is
    a valid assertion if the value is not null.
  • fail() Marks the test failed.

10
Whats new in FlexUnit 4
  • Support for all Junit 4 features
  • Support for UI testing
  • Metadata driven
  • Exception handling
  • New attribute of Test Metadata allows you to
    define expected exceptions (instead of using
    try/catch)
  • Test(expectsTypeError)
  • Async test support
  • Support for multiple Runners
  • Hamcrest support
  • Uses the Hamecrest AS3 project for a richer set
    of Asserts.
  • Theories and Assumptions
  • IDE Support
  • Beta 1 now available.

11
Understanding Metadata
  • FlexUnit 4 can be driven off of specific
    flexmetadata (similar to java annotations). This
    allows you to define tests as you see fit, with
    your own naming conventions or in existing code.
  • Before metadata you had to name your test methods
    a certain way, and your tests had to extend
    specific classes.
  • Test
  • Suite
  • Before
  • After
  • BeforeClass
  • AfterClass
  • Ignore
  • DataPoints
  • Theory
  • RunWith

12
Creating A Basic Unit Test
  • package simpleTest.tests
  • import org.flexunit.Assert
  • public class SimpleTestCase
  • Test
  • public function testMath()void
  • var xint 5 3
  • Assert.assertEquals( 8, x )

13
Creating A Basic Test Suite
  • package simpleTest
  • import flexunit.framework.TestSuite
  • import simpleTest.tests.SimpleTestCase
  • Suite
  • RunWith("org.flexunit.runners.Suite")
  • public class SimpleTestSuite
  • // define a var for each test case.
  • public var simpleTestCaseSimpleTestCase

14
Creating A Test Runner
  • lt?xml version"1.0" encoding"utf-8"?gt
  • ltmxApplication xmlnsmx"http//www.adobe.com/200
    6/mxml"
  • creationComplete"runMe()"
  • xmlnsflexUnitUIRunner"http//www.adobe.com/2009/
    flexUnitUIRunner" gt
  • ltmxScriptgtlt!CDATA
  • import simpleTest.SimpleTestSuite
  • import org.flexunit.listeners.UIListener
  • import org.flexunit.runner.FlexUnitCore
  • private var coreFlexUnitCore
  • public function runMe()void
  • core new FlexUnitCore()
  • //Listener for the UI, optional
  • core.addListener( new UIListener( uiListener ))
  • core.run( SimpleTestSuite )
  • gtlt/mxScriptgt
  • ltflexUnitUIRunnerTestRunnerBase
  • id"uiListener"

15
Asynchronous Testing
  • Asynchronous Tests examples
  • Server calls
  • Timers
  • AIR Sqlite
  • AIR File Access

16
Creating an Asynchronous Unit Test
Setup/Teardown
Before(async) public function
setUp()void timer new Timer( 500, 3
) After(async) public function
tearDown()void if ( timer )
timer.stop() timer null
17
Creating an Asynchronous Test Test Method
Test(async) public function testInTimePass()
void var objObject expected3 timer.dela
y 100 timer.addEventListener(TimerEvent.TIMER_
COMPLETE, Async.asyncHandler( this,
completehandler, 500, obj, null) , false, 0,
true ) timer.start() protected function
completehandler( eventEvent, data_Object)void
if( event.type "timerComplete
) Assert.assertEquals(Timer(event.target).curren
tCount, data_.expected )
else Assert.fail("wrong event type")
18
Integration Testing
  • UIComponents
  • A common goal when developing Flex applications
    is to test UIComponents in a repeatable way
  • UIComponents are internally asynchronous

19
Integration Testing (FlexUnit)
  • FlexUnit Sequences
  • Sometimes a test of a UIComponent can require
    many steps to setup.
  • For example, you may need to create a Login Form,
    populate it and then click a button before you
    can decide if everything worked
  • Sequences are a shorthand to simplify that work
    into a readable set of steps

20
Testing UIComponents setup
public var formLoginForm Before(async,ui) pub
lic function setUp()void form new
LoginForm() Async.proceedOnEvent( this, form,
FlexEvent.CREATION_COMPLETE, 200
) UIImpersonator.addChild( form
) After(async,ui) public function
tearDown()void UIImpersonator.removeChild(
form ) form null
21
Testing UIComponents test method
Test(async,ui) public function
testLogin()void var passThroughDataObject
new Object() passThroughData.username
'myuser1' passThroughData.password
'somepsswd' var sequenceSequenceRunner new
SequenceRunner( this ) sequence.addStep( new
SequenceSetter( form.usernameTI,
textpassThroughData.username )
) sequence.addStep( new SequenceWaiter(
form.usernameTI, FlexEvent.VALUE_COMMIT, 100 )
) sequence.addStep( new SequenceSetter(
form.passwordTI, textpassThroughData.password
) ) sequence.addStep( new SequenceWaiter(
form.passwordTI, FlexEvent.VALUE_COMMIT, 100 )
) sequence.addStep( new SequenceEventDispatcher(
form.loginBtn, new MouseEvent( 'click', true,
false ) ) ) sequence.addStep( new
SequenceWaiter( form, 'loginRequested', 100 )
) sequence.addAssertHandler( handleLoginEvent,
passThroughData ) sequence.run() protected
function handleLoginEvent( eventTextEvent,
passThroughDataObject )void Assert.assertEqual
s( passThroughData.password, event.text )
22
Testing UIComponents test method
var sequenceSequenceRunner new
SequenceRunner( this ) sequence.addStep( new
SequenceSetter( form.usernameTI,
textpassThroughData.username )
) sequence.addStep( new SequenceWaiter(
form.usernameTI, FlexEvent.VALUE_COMMIT, 100 )
) sequence.addStep( new SequenceSetter(
form.passwordTI, textpassThroughData.password
) ) sequence.addStep( new SequenceWaiter(
form.passwordTI, FlexEvent.VALUE_COMMIT, 100 ) )
  1. Create a new Sequence
  2. Set a property on a UIComponent
  3. Wait for the valueCommit event to fire, so you
    know the property was set correctly.

23
Testing UIComponents test method
sequence.addStep( new SequenceEventDispatcher(
form.loginBtn, new MouseEvent( 'click', true,
false ) ) ) sequence.addStep( new
SequenceWaiter( form, 'loginRequested', 100 )
) sequence.addAssertHandler( handleLoginEvent,
passThroughData ) sequence.run()
  1. Add a new step that simulates a user clicking on
    the login button.
  2. Wait for the loginRequested event.
  3. Add an assertHandler to check the login when it
    is completed.
  4. Run the test.

24
Testing UIComponents test method
//sequence.addAssertHandler( handleLoginEvent,
passThroughData ) protected function
handleLoginEvent( eventTextEvent,
passThroughDataObject )void Assert.assertEqua
ls( passThroughData.password, event.text )
  1. Use the assertHandler method to test the results
    of the login action (server call)
  2. If the right data exists, success.

25
Integration Testing (FlexMonkey)
  • Recording Scripts
  • Replaying Scripts

26
Tips
  • All Software projects should be thoroughly
    tested!!
  • Automated testing saves you money by preventing
    bugs form returning again and again.
  • A getting started rule of thumb for writing a new
    test case
  • Write one test that passes the usual case
  • Write one test that passes by testing the
    extremes
  • Write one test that is supposed to fail
  • Continue building your test cases, by writing a
    test case for every bug that is submitted
    before you close the bug as fixed.
  • Tests cases should clean up after themselves
  • Any developer should be able to run the tests
    without custom setup if possible.

27
Questions
?
28
FlexUnit 4 http//opensource.adobe.com/wiki/displa
y/flexunit/FlexUnit Flex Monkey http//code.googl
e.com/p/flexmonkey/ More on Continuous
Integration http//www.martinfowler.com/articles/c
ontinuousIntegration.html
Write a Comment
User Comments (0)
About PowerShow.com
