Week 2

1
Week 2 Cryptography
2
Cryptography Concepts
3
Cryptography
Latin
Crypt
secret
Cryptography
Graphia
writing

• Concerned with developing algorithms
• Conceal the context of some message from all
• except the sender and recipient (privacy or
  secrecy),
• and/or

4
Cryptography

• Concerned with developing algorithms
• Verify the correctness of a message to the
  recipient
• (authentication)
• Form the basis of many technological solution to
  computer
• and communications security problems

cryptography - study of encryption
principles/methods
5
Goals Setting

• To ensure security of communication across
• an insecure channel.
• The ideal channel

Dedicated, untappable, impenetrable
Pipe/tube
6
Secure Channel
ISP/Office
7
Secure Channel
8
Secure Channel
9
Secure Channel
10
Secure Channel
11
Secure Channel
12
Secure Channel
Authenticated
13
Secure Channel
14
Secure Channel
Connected
15
Secure Channel
Connection Established
ISP/Office
16
Goal Setting
Adversary (Attacker)
The source of all possible threats
Not all aspect of an ideal channel can be
emulated
17
Basic Terminology

• plaintext - the original message
• ciphertext - the coded message
• cipher - algorithm for transforming plaintext to
  ciphertext
• key - info used in cipher known only to
  sender/receiver
• encipher (encrypt) - converting plaintext to
  ciphertext
• decipher (decrypt) - recovering ciphertext to
  plaintext

18
Simple Process
Receiver
Sender
Plaintext
Plaintext
The secret message is You can get A-/A in
SKR5200 (however depend on you)
The secret message is You can get A-/A in
SKR5200 (however depend on you)
Encryption
Decryption
ciphertext
hjfjghkf_at__at_jklll 098GHJFD!_at_
19
Categories of cryptography
20
Comparison between two categories of cryptography
21
Encryption Method
Cryptography
Symmetric Encryption
Asymmetric Encryption

• uses two keys a public a private key
• asymmetric since parties are not equal
• uses clever application of number
• theoretic concepts to function
• complements rather than replaces
• private key crypto

• conventional / private-key / single-key
• sender and recipient share a common key
• all classical encryption algorithms are
• private-key

22
Symmetric Encryption
23
Symmetric Encryption Technique
Symmetric Encryption
Classical
Modern
Stream cipher
Block cipher
24
Symmetric Encryption

• conventional / private-key / single-key
• sender and recipient share a common key
• 2 Techniques Classical Modern
• Classical Techniques
• Substitution
• Caesar Cipher
• Monalphabatic Cipher
• Playfair Cipher
• Hill Cipher
• Polyalphabetic Cipher
• One-Time Pad
• Transposition
• Rotor Machines
• Steganography
• Modern Techniques

25
Basic of Symmetric Cryptography
Classical Substitution Cipher
Classical Transpositions Cipher
Summary
26
Symmetric Encryption

• or conventional / private-key / single-key
• sender and recipient share a common key
• all classical encryption algorithms are
  private-key
• was only type prior to invention of public-key in
  1970s

27
Basic Terminology

• plaintext - the original message
• ciphertext - the coded message
• cipher - algorithm for transforming plaintext to
  ciphertext
• key - info used in cipher known only to
  sender/receiver
• encipher (encrypt) - converting plaintext to
  ciphertext
• decipher (decrypt) - recovering ciphertext from
  plaintext
• cryptography - study of encryption
  principles/methods
• cryptanalysis (codebreaking) - the study of
  principles/ methods of deciphering ciphertext
  without knowing key
• cryptology - the field of both cryptography and
  cryptanalysis

28
Symmetric Cipher Model
29
Requirements

• two requirements for secure use of symmetric
  encryption
• a strong encryption algorithm
• a secret key known only to sender / receiver,
  have
• plaintext X
• ciphertext Y
• key K
• encryption algorithm Ek
• decryption algorithm Dk
• Ciphertext Y EK(X) Plaintext X DK(Y)
• assume encryption algorithm is known
• implies a secure channel to distribute key

30
Cryptography

• can characterize by
• type of encryption operations used
• substitution / transposition / product
• number of keys used
• single-key or private / two-key or public
• way in which plaintext is processed
• block / stream

31
Types of Cryptanalytic Attacks

• ciphertext only
• only know algorithm / ciphertext, statistical,
  can identify plaintext
• known plaintext
• know/suspect plaintext ciphertext to attack
  cipher
• chosen plaintext
• select plaintext and obtain ciphertext to attack
  cipher
• chosen ciphertext
• select ciphertext and obtain plaintext to attack
  cipher
• chosen text
• select either plaintext or ciphertext to
  en/decrypt to attack cipher

32
Simple Question

• What are the essential ingredients of a symmetric
  cipher?
• How many keys are required for two people to
  communicate via a cipher?

33
Simple Question

• What are the essential ingredients of a symmetric
  cipher?
• Plaintext, encryption algorithm, secret key,
  ciphertext, decryption algorithm.
• How many keys are required for two people to
  communicate via a cipher?
• One secret key.

34
Basic of Symmetric Cryptography
Classical Substitution Cipher
Classical Transpositions Cipher
Summary
35
Classical Substitution Ciphers

• where letters of plaintext are replaced by other
  letters or by numbers or symbols
• or if plaintext is viewed as a sequence of bits,
  then substitution involves replacing plaintext
  bit patterns with ciphertext bit patterns

36
Caesar Cipher

• earliest known substitution cipher
• by Julius Caesar
• first attested use in military affairs
• replaces each letter by 3rd letter on
• example
• meet me after the toga party
• PHHW PH DIWHU WKH WRJD SDUWB

37
Caesar Cipher

• can define transformation as
• Plain a b c d e f g h i j k l m n o p q r s t u
  v w x y z
• CipherD E F G H I J K L M N O P Q R S T U V W X
  Y Z A B C
• mathematically give each letter a number
• a b c d e f g h i j k l m
• 0 1 2 3 4 5 6 7 8 9 10 11 12
• n o p q r s t u v w x y Z
• 13 14 15 16 17 18 19 20 21 22 23 24 25
• then have Caesar cipher as
• C E(p) (p k) mod (26)
• p D(C) (C k) mod (26)

38
Example 1

• Caesar used a shift of 3
• Using this encryption, the message
• treaty impossible
• Would be encoded as
• t r e a t y i m p o s s i b l e

• WUHDWB LP S RVVLEOH

39
Example 2

• Caesar used a shift of 5
• Using this encryption, the message
• treaty impossible
• Would be encoded as
• t r e a t y i m p o s s i b l e

40
To test your understanding
Ceasar wants to arrange a secret meeting with
Marc Anthony, either at the Tiber (the river) or
at the Colisuem (the arena). He sends the
ciphertext EVIRE. However, Anthony doest not know
the key, so he tries all possibilities. Where
will he meet Caesar?
41
To test your understanding
Ceasar wants to arrange a secret meeting with
Marc Anthony, either at the Tiber (the river) or
at the Colisuem (the arena). He sends the
ciphertext EVIRE. However, Anthony doest not know
the key, so he tries all possibilities. Where
will he meet Caesar? Among the shifts of EVIRE,
there are two words arena and river. Therefore,
Anthony cannot determine where to meet Caesar.
42
Cryptanalysis of Caesar Cipher

• only have 26 possible ciphers
• A maps to A,B,..Z
• could simply try each in turn
• a brute force search
• given ciphertext, just try all shifts of letters
• do need to recognize when have plaintext
• eg. break ciphertext "GCUA VQ DTGCM"

43
Summary of Substitutions
Substitutions are effective cryptographic
devices. In fact, they were the basis of many
cryptographic algorithms used for diplomatic
communication through the first half of the
century. But substitution is not only kind of
encryption technique. The goal of substitution is
confusion the encryption method is an attempt
to make it difficult for cryptanalyst or intruder
to determine how a message and key were
transformed into ciphertext.
44
Basic of Symmetric Cryptography
Classical Substitution Cipher
Classical Transpositions Cipher
Summary
45
Transpositions (permutations)
A transposition is an encryption in which the
letters of the message are re arranged. With
transposition is an encryption in which the
letters of the message are rearranged. With
transposition, the cryptography aims for
diffusion, widely spreading the information from
the message or key across the ciphertext.
Transpositions try to break established patterns.
Because a transposition is re arranged of the
symbols of a message, it also known as a
permutation.
46
Transposition Ciphers

• now consider classical transposition or
  permutation ciphers
• these hide the message by rearranging the letter
  order
• without altering the actual letters used
• can recognise these since have the same frequency
  distribution as the original text

47
Rail Fence cipher

• write message letters out diagonally over a
  number of rows
• then read off cipher row by row
• eg. write message out as
• meet me after the toga party
• giving ciphertext
• MEMATRHTGPRYETEFETEOAAT

48
Row Transposition Ciphers

• a more complex scheme is to write the message in
  a rectangle, row by row, and read the message
  off, column by column, but permute the order of
  the columns. The order of the columns then
  becomes the key of the algorithm.
• write letters of message out in rows over a
  specified number of columns
• then reorder the columns according to some key
  before reading off the rows
• Key 4 3 1 2 5 6 7
• Plaintext a t t a c k p
• o s t p o n e
• d u n t i l t
• w o a m x y z
• Ciphertext TTNAAPTMTSUOAODWCOIXKNLYPETZ

49
Product Ciphers

• ciphers using substitutions or transpositions are
  not secure because of language characteristics
• hence consider using several ciphers in
  succession to make harder, but
• two substitutions make a more complex
  substitution
• two transpositions make more complex
  transposition
• but a substitution followed by a transposition
  makes a new much harder cipher
• this is bridge from classical to modern ciphers

50
Basic of Symmetric Cryptography
Classical Substitution Cipher
Classical Transpositions Cipher
Summary
51
Summary
Stream cipher that is, they convert one symbol
of plaintext immediately into a symbol of
ciphertext. (The exception is the columnar
transposition cipher). The transformation depends
only on the symbol, the key, and the control
information of the enciperment algorithm. A
model of stream enciphering is shown
Encryption
wdhuw
ISSOPMI
Plain text
Ciphertext
Key (optional)
52
Summary
Some kinds of errors, such as skipping a
character in the key during encryption, affect
the encryption of all future characters. However,
such errors can sometimes be recognized during
encryption because the plan text will be
properly recovered up to a point, and then all
following characters will be wrong.
If that is the case, the receiver may be able to
recover from the error by dropping a character of
the key on the receiving end. Once the receiver
has successfully recalibrated the key with the
ciphertext, there will be no further effects from
this error.
To address this problem and make it harder for
cryptanalyst to break the code, Therefore, a
block chipper has been introduced.
53
Summary easy to break
The Caesar Cipher allows simple straightforward
encoding and decoding. Therefore, it allows
unauthorized message recipients to crack such
encoded messages easily. If an eavesdropper
manages to obtain the encoded message, he only
has to test the 26 possible shifts in order to
find the original message. This message-cracking
attack is called brute force and is best
performed with the aid of computers. In our
example, however, the pen and pencil approach is
sufficient.
54
Summary easy to break
eulqj fvmrk gwnsl hxotm iypun jzqvo karwp lbsxq mc
tyr nduzs oevat pfwbu ogxcv
rhydw sizex tjafy ukbgz vlcha wmdib xnejc yofkd zp
gle aqhmf arena csjoh dtkpi
55
Classical Techniques
Substitution Technique

• where letters of plaintext are replaced by other
  letters or by numbers or symbols
• or if plaintext is viewed as a sequence of bits,
  then substitution involves replacing
• plaintext bit patterns with ciphertext bit
  patterns.

Transposition Technique

• transposition or permutation ciphers
• these hide the message by rearranging the letter
  order
• without altering the actual letters used
• can recognise these since have the same
  frequency distribution as the original text

56
Stream Cipher Structure

• A typical stream cipher encrypts plaintext one
  byte at a time.
• Use a key as input to a pseudorandom bit
  generator that
• produces a stream of 8-bit numbers that are
  apparently random.
• Pseudorandom stream is one that is unpredictable
  without knowledge of the
• input key.

Key K
Key K
Pseudorandom byte Generator (key stream
generator)
Pseudorandom byte Generator (key stream
generator)
K
K
Ciphertext Byte stream C
Plaintext Byte stream M
Plaintext Byte stream M


Encryption
Decryption
57
Stream Cipher Structure

• The output of the generator, called a keystream,
  is combined one byte at a time
• with the plaintext stream using the bitwise
  exclusive-OR (XOR) operation.

11001100 Plaintext
01101100 key stream

10100000 Ciphertext
Decryption requires the use of the same
pseudorandom sequence
10100000 Ciphertext
01101100 key stream

11001100 Plaintext
58
Symmetric Encryption Technique
Symmetric Encryption
Classical
Modern
Focus
Stream cipher
Block cipher
59
Block Ciphers / Feistel Cipher
60
Block Ciphers

• A block cipher is one in which a block of
  plaintext is treated as a
• whole and used to produce a ciphertext block of
  equal length.
• Typically, a block size of 64 or 128 bits is
  used.
• Block cipher algorithms can operate in many
  Modes. A block cipher
• algorithm can be a
• Electronic Codebook Mode
• Cipher block Chaining Mode
• Cipher Feedback Mode
• Output Feedback Mode
• Counter Mode
• provide secrecy and/or authentication services

61
Feistel Cipher Design Principles

• block size
• increasing size improves security, but slows
  cipher
• key size
• increasing size improves security, makes
  exhaustive key searching harder, but may slow
  cipher
• number of rounds
• increasing number improves security, but slows
  cipher
• subkey generation
• greater complexity can make analysis harder, but
  slows cipher
• round function
• greater complexity can make analysis harder, but
  slows cipher
• fast software en/decryption ease of analysis
• are more recent concerns for practical use and
  testing

62
Block Cipher Design

• Divide input bit stream into n-bit sections,
  encrypt only that section, no
  dependency/history between sections

• In a good block cipher, each output bit is a
  function of all n input bits and all k key bits

63
Fiestel Cipher Encryption
Plaintext
Ln 1 Rn
64
Fiestel Cipher Encryption
65
Fiestel Cipher Decryption
Rn Ln - 1
Ln
66
Fiestel Cipher Decryption
Plaintext
Rn
Ln
Round 1
Round i
Round n
Ciphertext
67
Fiestel Cipher Decryption
Plaintext
Rn
Ln
Round 1
Round i
Round n
Ciphertext
68
Fiestel Cipher Algorithm
Input T 2t bits of clear text k1, k2, ...,
kr r round keys f a block cipher with bock
size of t Output C 2t bits of cipher
text Algorithm (L0, R0) T, dividing T in
two t-bit parts (L1, R1) (R0, L0 f(R0,
k1)) (L2, R2) (R1, L1 f(R1, k2)) ......
C (Rr, Lr), swapping the two parts is the
XOR operation.
69
One of Security Implementations
ATM PIN SECURITY
70
ATM Introduction

• Automated Teller Machines (ATM) have become
  ubiquitous and let you withdraw money from
• your bank account 24 hrs a day and 7 days a week
  with your ATM card. The ATM card
• constitutes of two things
• the Card number and
• the Personal Identification Number or PIN.
• Each bank issues a card number that is unique to
  each customer. If it is a debit card, the card
• number will also be unique worldwide.
• The PIN is like a password to verify a
  customers authenticity.
• Cash dispensers in the ATM verify both the card
  number and the PIN.

71
Working Principle of ATM

• The ATM systems have three main components
• Cash dispenser, ATM Server and PIN machine.
• The Cash dispenser reads the Card number and the
  PIN entered by a customer and sends
• them to a central ATM Server.
• The ATM Server has a database which stores ATM
  card no. and PIN details.
• The third component, the PIN machine is used to
  authenticate the customer s ATM PIN.
• It is directly connected to the ATM Server and
  is a tamper proof device that stores a single
• secret key.

72
Working Principle of ATM
Leased Line
ATM Server
PIN Machine
Customer Account Holding Server
73
Working Principle of ATM

• After the customer enters an ATM counter, he
  inserts his ATM card into the machine and
• types his PIN on a numeric keypad.
• The Cash dispenser reads the card number from
  the magnetic strip and the PIN that he has
• typed and sends them to the ATM Server.
• The ATM Server verifies the PIN against the card
  number with the help of the PIN machine
• and sends a positive or negative
  acknowledgement to the Cash dispenser.
• At this point, the customer is authenticated and
  can use his account.

74
ATM PIN Security

• The security of the ATM PIN is a critical
  element in the entire process.
• There are two ways that an attacker could try to
  get the ATM PIN
• He could either sniff the network when the Cash
  dispenser is transmitting the PIN to
• ATM Server or
• he could compromise the ATM Server and PIN
  machine to extract the PIN of a user.
• How these threats have been addressed in todays
  ATM systems?
• how.

75
ATM PIN Security

• To prevent the sniffing of the PIN during the
  transmission, PIN is encrypted using DES
• or 3DES encryption algorithm and then
  transmitted from Cash dispenser to ATM Server.
• The shared secret key is stored in Cash
  dispenser as well as in ATM Server. This
  application
• stores the shared DES key in encrypted form
  using vendors proprietary algorithm (e.g. ACI
• ATM software).
• The solution for the second problem is
  interesting. The system splits each customers
  PIN into
• two parts and stores them in two different
  machines. So even if one of the machines is
• compromised, the PIN is still secure. Now the
  problem is of course how to split the PIN
• securely into two parts. Here we also have to
  keep in mind that customer can always change
• his PIN.

76
ATM PIN Security

• An algorithm has been designed that allows the
  customers PIN to be split and
• also allows the customer to change his PIN.
• Let the customer PIN be a and lets say it is
  split into two parts b and c .
• a b c
• b is a variable part of the PIN and is called
  PIN Offset.
• The PIN Offset is stored in the ATM
  Server
• c is the constant part of the PIN and is called
  Natural PIN.
• The Natural PIN is generated in the
  PIN machine each time.
• How does the PIN Machine generate the constant c
  for each customer and yet keep it a secret?
• Remember that the ATM card number of a customer
  is unique. So, the constant part c can be
• a cryptographic function of the card number.
• c f (card)

77
ATM PIN Security
There are different methods to derive a constant
number from a card number and a popular method is
to derive it using the DES algorithm. The PIN
machine stores a DES key in its Electrically
Erasable Programmable Read Only Memory (EEPROM).
This key is used to encrypt the card number and
generate DES encrypted value.
The DES key is stored in the EEPROM of the
machine. EEPROM is chip which is fixed on
machines circuit board. To retrieve the key,
one has to open the box case, remove the circuit
board from the box, connect the EEPROM to a
EEPROM reader to get the key. So physical
security is very important for ATM Server room.
78
ATM PIN Security
Card DES key DES encrypted value This DES
encrypted value is then converted into
decimalized form and the first four digits of the
value are taken. That is the Natural PIN, c .
Once again, to summarize, the path is DES
encrypted value ? Decimalized value ? First 4
digits of the value c The Natural PIN, the
constant part, c is not stored anywhere in the
entire process. Nobody can get the PIN by
compromising the PIN machine. The PIN Offset or
b is the variable part. When a customer changes
his/her PIN only this part is changed. So even if
the ATM Server is compromised only b will be
revealed and it is useless without c to get
actual Customer PIN a .
The DES key is stored in the EEPROM of the
machine. EEPROM is chip which is fixed on
machines circuit board. To retrieve the key,
one has to open the box case, remove the circuit
board from the box, connect the EEPROM to a
EEPROM reader to get the key. So physical
security is very important for ATM Server room.
79
ATM PIN Authentication Process

• The mechanism for authenticating the ATM PIN is
  quite simple. When a customer inserts his
• ATM card and type the PIN, the card number and
  PIN are sent to the ATM Server encrypted.
• The ATM Server decrypts the card number and the
  PIN it first validates the card number
• against its database.
• The valid card number, the PIN Offset b of that
  card and the PIN typed by the customer are
• sent to the PIN machine.
• Now the PIN machine generates the Natural PIN c
  from the card no., adds it with PIN Offset b
• and generates the true Customer PIN a .
• Then it compares the actual Customer PIN a with
  the customer supplied PIN. If the two of
• them matched then it sends positive
  acknowledgement to ATM Server indicating that the
• customer is authenticated.
• Note that in this process, the Natural PIN never
  leaves the tamper proof PIN Machine, and
• the PIN machine does not have to store
  individual PINs of all the users. Instead, it
  securely
• stores the DES key for generating the Natural
  PIN from each users card number.

80
Generation Distribution of ATM PIN

• The ATM system deals with critical customer
  information and is more secure by design.
• But there can still be security risks during the
  generation and distribution of a new card and PIN
  .
• The Card number is generated by the ATM Server
  and the PIN is generated by the PIN
• machine from the card number as mentioned
  above.
• But for the first time, the PIN Offset of the
  new PIN is randomly generated by the PIN machine.
• There are two ways to print the PIN mailer.
• In the first method, the operator will generate
  a new PIN using the PIN machine,
• get the PIN and generate the printout of the
  PIN mailer.
• In the second method, the operator requests the
  PIN machine to generate a new PIN.
• The PIN machine generates the PIN and
  directly prints it to a connected printer and
  seals
• the print mailer before giving it to the
  operator.
• The second method is clearly more secure than
  first one as the operator never comes to know

81
Modern Techniques (Block Ciphers) Asymmetric
Cipher
82
Using Key in Cryptography
83
Definition of Key

• A sequence of symbols that controls the operation
  of a cryptographic transformation (e.g.
  encipherment, decipherment).
• In practice a key is normally a string of bits
  used by a cryptographic algorithm to transform
  plain text into cipher text or vice versa. The
  key should be the only part of the algorithm that
  it is necessary to keep secret.

84
Key Length

• The key length is usually expressed in bits, 8
  bits to one byte. Bytes are a more convenient
  form for storing and representing keys because
  most computer systems use a byte as the smallest
  unit of storage (the strict term for an 8-bit
  byte is octet).
• Just remember that most encryption algorithms
  work with bit strings. It's up to the user to
  pass them in the required format to the
  encryption function they are using. That format
  is generally as an array of bytes, but could be
  in hexadecimal or base64 format.
• In theory, the longer the key, the harder it is
  to crack encrypted data. The longer the key,
  however, the longer it takes to carry out
  encryption and decryption operations.

85
Analogy - Strength
86
Analogy - Breaking
87
Key Length

• Block cipher encryption algorithms like AES and
  Blowfish work by taking a fixed-length block of
  plaintext bits and transforming it into the same
  length of ciphertext bits using a key.
• Most other block cipher encryption methods have a
  fixed length key. For example, DES has a 64-bit
  key (but only uses 56 of them) and Triple DES has
  a 192-bit key (but only uses 168 of them).
• IDEA uses a 128-bit key.
• The Advanced Encryption Algorithm (AES) has a
  choice of three key lengths 128, 192 or 256
  bits.
• Public key encryption algorithms like RSA
  typically have key lengths in the order of
  1000-2000 bits. Be careful with the difference in
  key lengths for block cipher algorithms and
  public key algorithms.
• 192-bit Triple DES key is equivalent in security
  terms to a 2048-bit RSA key, and an AES-128 key
  is equivalent to a 3072-bit RSA key

88
Relevant of Key Length

• To crack some ciphertext encrypted with a 64-bit
  key by the brute-force method of trying every
  combination of keys possible means you have 264
  possible combinations or 1.8 x 1019 (that's 18
  followed by 18 naughts).
• We can expect, on the average, to find a correct
  answer in half this number of tries. If we have a
  computer that can carry out one encryption
  operation every millisecond, it will take about
  292 million years to find the correct value.
  Speed up your computer by a million times and it
  will still take about 3 centuries to solve.
• The equivalent brute force technique for a
  128-bit key will, in theory, take a "long time",
  probably past the expected life of the universe.
  But, in practice, a set of supercomputers
  operating in parallel can crack a 64-bit key in a
  relatively short time.
• If an attacker has access to a large selection of
  messages all encrypted with the same key, there
  are other techniques that can be used to reduce
  the time to derive the key.

89
How do encryption schemes fail?

• Most encryption schemes are cracked not by brute
  force trying of all possible combinations of key
  bits, but by using other knowledge about how the
  sender derived the key.
• This could be a faulty random number generator
  known to used by the system, or knowledge that
  the user derived the key solely from a password
  of only the letters a to z, or just used simple
  English words. Or perhaps by finding out the
  keystrokes typed on the keyboard by the user with
  a keystroke logger, or by bribing (or torturing)
  someone to give them the key, or by reading the
  post-it note the user has conveniently left on
  the side of the computer with the password
  written on it. The traps are many and subtle and
  even the experts get it wrong.
• Why spend hours trying to pick the expensive
  security lock when the owner of the house has
  left a window open?

90
How do encryption schemes fail?

• Strictly, it's not the length of the key, but the
  "entropy" in the method used to derive the key.
  There is approximately one bit of entropy in an
  normal ASCII character.
• If you derive a 128-bit key from a password or
  pass phrase, you will need a very long pass
  phrase to get enough theoretical entropy in the
  key to match the security of the underlying key
  length Bruce Schneier estimates that you need a
  98-character English pass phrase for a 128-bit
  key. Most people can't be bothered with such a
  cumbersome pass phrase.

91
How do encryption schemes fail?

• Using AES with a 128-bit key should provide
  adequate security for most purposes. The longer
  you intend to keep the encrypted data secret, the
  longer the key you should use, on the principle
  that cracking techniques will continue to improve
  over time. Bruce Schneier recommends a 256-bit
  key for data you intend to keep for 20-30 years.
• No one is going to criticise you for using a key
  that is too long provided your software still
  performs adequately. However, the biggest danger
  in using a key that is too large is the false
  sense of security it provides to the implementers
  and users. "Oh, we have n-million-bit security in
  our system" may sound impressive in a marketing
  blurb, but the fact that your private key is not
  adequately protected or your random number
  generator is not random or you have used an
  insecure algorithm may mean that the total
  security is next to useless.
• Remember it is the security of the total system
  that counts, including procedures followed by
  users.

92
Choice of Algorithm

• Whatever you use, use an accepted algorithm
• DES, Triple DES, RSA, AES, Blowfish, IDEA, etc.
• Don't try making up your own algorithm we
  (learners) aren't that good. The only secret
  should be in the value of the key.

93
Password, Pass Phrase Key

• People often get confused between "password" and
  "key". A password is typically a series of ASCII
  characters typed at a keyboard, e.g. "hello123"
  or "my secret pass phrase". This makes it easier
  for users to remember. They are, of course, much
  easier to crack because there are significantly
  fewer combinations to choose from.
• A pass phrase is simply a password that consists
  of several words in a string, e.g. "she sells sea
  shells", so the terms "password" and "pass
  phrase" are equivalent for our purposes. In
  principle, a pass phrase makes it easier for a
  user to remember a long combination of
  characters. In practice, this adds to security
  only if the pass phrase is something known only
  to the user. Don't use quotes from famous
  literature - hackers read them, too.

94
Password, Pass Phrase Key

• A password is typically a series of ASCII
  characters typed at a keyboard, e.g. "hello123"
  or "my secret pass phrase". This makes it easier
  for users to remember. They are, of course, much
  easier to crack because there are significantly
  fewer combinations to choose from.
• A pass phrase is simply a password that consists
  of several words in a string, e.g. "she sells sea
  shells", so the terms "password" and "pass
  phrase" are equivalent for our purposes. In
  principle, a pass phrase makes it easier for a
  user to remember a long combination of
  characters. In practice, this adds to security
  only if the pass phrase is something known only
  to the user.
• A key used by an encryption algorithm is a bit
  string. A 128-bit key will have exactly 128 bits
  in it, i.e. 16 bytes. You will often see keys
  written in hexadecimal format where each
  character represents 4 bits, e.g.
  "FEDCBA98765432100123456789ABCDEF" represents 16
  bytes or 128 bits. The actual bits in this
  example are
• 1111 1110 1101 1100 1011 1010 1001 1000 0111 0110
  0101 0100 0011 0010 0001 0000 0000 0001 0010 0011
  0100 0101 0110 0111 1000 1001 1010 1011 1100 1101
  1110 1111

95
Just to test 1

• In a university, a student needs to encrypt her
  password (with a unique symmetric key) before
  sending it when she logs in. Does encryption
  protect the university or the student? Explain
  your answer.

96
Answer for the Just to test 1

• In a university, a student needs to encrypt her
  password (with a unique symmetric key) before
  sending it when she logs in. Does encryption
  protect the university or the student? Explain
  your answer.
• The encryption protects the student and the
  university for the first time. However, the
  intruder can intercept the encrypted password and
  replay the process some other times. The intruder
  does not have to know the password in plaintext
  the encrypted password suffices for replaying.
  The university system cannot determine if the
  student has encrypted the message again or the
  intruder is replaying it.

97

• How should I derive the key?

98
Just to test 2

1. What are two basic functions used in encryption
   algorithm? Explain how each of these methods
   works and please include the example.

99
Answer for the Just to test 2

• What are two basic functions used in encryption
  algorithm? Explain how each of these methods
  works and please include the example.
• Substitution and Transposition/Permutation
• Substitution
• where letters of plaintext are replaced by other
  letters or by numbers or symbols. Or if plaintext
  is viewed as a sequence of bits, then
  substitution involves replacing plaintext bit
  patterns with ciphertext bit patterns.
• Transposition/Permutation
• A transposition is an encryption in which the
  letters of the message are re arranged. With
  transposition is an encryption in which the
  letters of the message are rearranged. With
  transposition, the cryptography aims for
  diffusion, widely spreading the information from
  the message or key across the ciphertext.
  Transpositions try to break established patterns.
  Because a transposition is re arranged of the
  symbols of a message, it also known as a
  permutation.

100
Block Cipher

• A block cipher is a function E 0,1k x 0,1n ?
  0,1n . This notation means that E takes two
  inputs, one being a k-bit string and the other an
  n-bit string, and returns an n-bit string. The
  first input is the key. The second might be
  called the plaintext, and the output might be
  called a ciphertext. The key-length k and the
  block-length n are parameters associated to the
  block cipher. They vary from block cipher to
  block cipher.

101
Block Cipher

• For each key K ? 0,1k we let Ek 0,1n ?
  0,1n be the function defined by EK(M) E(K,M).
  For any block cipher, and any key K, it is
  required that the function EK be a permutation on
  0,1n. This means that it is a bijection (ie., a
  one-to-one and onto function) of 0,1n to 0,1n
  . (For every C ?0,1n there is exactly one M ?
  0,1n such that EK(M) C.) Accordingly EK has
  an inverse, and we denote it (EK)-1.

102
Block Cipher

• This function also maps
• 0,1n ? 0,1n , and of course we have
• (EK)-1(EK(M)) M and
• EK ((EK)-1(C)) C
• for all M, C ? 0,1n .
• We let
• E-1 0,1k x 0,1n ? 0,1n be defined by
  E-1(K,C) (EK)-1(C). This is the inverse block
  cipher to E.
• Note
• ? implies ? set membership
• A ? B means if A is true then B is also true if
  A is false then nothing is said about B.
• a ? S means a is an element of the set S

103
Block Cipher

• The block cipher E is a public and fully
  specified algorithm. Both the cipher E and its
  inverse E-1 should be easily computable, meaning
  given K,M we can readily compute E(K,M), and
  given K,C we can readily compute E-1(K,C). By
  readily compute" we mean that there are public
  and relatively efficient programs available for
  these tasks.

104
Before Start, Just Review Back
Block Ciphers / Feistel Cipher
DES
DES of Modes Operation
105
DES Data Encryption Standard

• A Block cipher
• Data encrypted in 64-bit blocks using a 56-bit
  key (effective key) Ciphertext is of 64-bit long
• Encrypts by series of substitution and
  transpositions (or permutations)

106
DES - Basics

• DES uses the two basic techniques of cryptography
  - confusion and diffusion.
• At the simplest level, diffusion is achieved
  through numerous permutations and confusions is
  achieved through the XOR operation and the
  S-Boxes.
• This is also called an S-P network.

107
DES - Basics

• Fundamentally DES performs only two operations on
  its input, bit shifting (permutation), and bit
  substitution.
• The key controls exactly how this process works.
• By doing these operations repeatedly and in a
  non-linear manner you end up with a result which
  can not be used to retrieve the original without
  the key.

108
Input of DES

• Data need to be broken into 64-bit blocks add
  pad at the last message if necessary.
• e.g. X(3 5 0 7 7 F 1 0 A B 1 2 F C 6 5)HEX
• Secret key
• Any string of 64 bits long including 8 parity
  bits.
• 1 parity bit in each 8-bit byte of the key may be
  utilized for error detection in key generation,
  distribution, and storage
• K(k1k7k8 k15k16k17k24k32 k40 k48 k56
  k64)
• The parity bits k8,k16,k24,k32,k40,k48,k56,k64
  help ensure that each byte is of odd parity

109
DES Block cipher
110
DES Encryption
111
DES Encryption Diagram
64-bit plaintext
Initial permutation
K1
Iteration 1
Iteration 2
K2
16 subkeys of each 48-bits
Iteration 16
K16
32-bit Swap
Inverse permutation
64-bit ciphertext
112
How to use DES?

• Four modes of operations were defined for DES in
  ANSI standard ANSI X3.106-1983 Modes of Use
• subsequently now have 5 for DES and AES
• have block and stream modes

113
Handle long messages

• Block ciphers encrypt fixed size blocks
• eg. DES encrypts 64-bit blocks, with 56-bit key
• How to encrypt arbitrary amount of information ?
• Message is broken into blocks of 64 bits
• At end of message, handle possible last short
  block
• by padding either with known non-data value (eg
  nulls)
• or pad last block with count of pad size
• eg. b1 b2 b3 0 0 0 0 5 lt- 3 data bytes, then 5
  bytes padcount
• Then they are encrypted and decrypted in various
  combinations of keys and texts.

114

• Details for DES, Please refer and read
• Stallings, W. (2006). Cryptography and Network
  Security. New Jersey Prentice-Hall. Page 63 - 90

115
Chapter 3 Public-Key Cryptography
116
Overview
Symmetric Cryptography Summary
Public-Key Cryptography
Example RSA
Discussion
117
Categories of cryptography
118
ASYMMETRIC-KEY CRYPTOGRAPHY
An asymmetric-key (or public-key) cipher uses two
keys one private and one public. We discuss one
algorithms RSA
Topics discussed in this section
RSA
119
Asymmetric Cryptography
120
Comparison between two categories of cryptography
121
Symmetric Cryptography Summary
Public-Key Cryptography
Example RSA
Discussion
122
Symmetric Concept
Man needs Woman, Woman Needs Money for
shopping
123456696 096785403 657849302 610395867 567484509
121212347
Man needs Woman, Woman Needs Money for
shopping
Authentication only from Alice, therefore is
cannot be altered in transit
No signature - Bob could forge the message
- Sender could deny the message
123
Symmetric Cryptography Summary
Public-Key Cryptography
Example RSA
Discussion
124
Private-Key Cryptography Definition

• public-key/two-key/asymmetric cryptography
  involves the use of two keys
• a public-key, which may be known by anybody, and
  can be used to encrypt messages, and verify
  signatures
• a private-key, known only to the recipient, used
  to decrypt messages, and sign (create) signatures
• is asymmetric because
• those who encrypt messages or verify signatures
  cannot decrypt messages or create signatures

125
Private-Key Cryptography - Concept

• allows users to communicate securely without
  having prior access to a shared secret key,
• by using a pair of cryptographic keys, designated

• as public key and
• private key, which are related mathematically.
• the private key is generally kept secret, while
  the public key may be widely distributed.
• In a sense, one key "locks" a lock while the
  other is required to unlock it. It should not be
  possible to deduce the private key of a pair
  given the public key.

126
Public-Key Basic Concept
Message is encrypted
EB
Bobs Public Key (EB)
Bobs Private Key (DB)
127
Public-Key Basic Concept

• This model provides no authentication because
  any party
• could also use Bobs public key to encrypt
  Message (M)

128
Private-Key Cryptography
129
Public-Key Cryptography Options
There are many forms of public-key cryptography,
including public key encryption keeping a
message secret from anyone that does not possess
a specific private key. public key digital
signature allowing anyone to verify that a
message was created with a specific private
key. key agreement generally, allowing two
parties that may not initially share a secret
key to agree on one.
130
Private-Key Cryptography
The most obvious application of a public key
encryption system is confidentiality a message
which a sender encrypts using the recipient's
public key can only be decrypted by the
recipient's paired private key. Public-key
digital signature algorithms can be used for
sender authentication. For instance, a user can
encrypt a message with his own private key and
send it. If another user can successfully
decrypt it using the corresponding public key,
this provides assurance that the first user (and
no other) sent it.
131
To Provide Authentication Signature

• This model does provide authentication and
  digital signature

• But, this scheme not provide confidentiality,
  because anyone
• has Alices public key can decrypt the
  ciphertext.

132
To Provide Confidentiality, Authentication and
Signature
Message (M) Plaintext
Message (M) Plaintext
Alice
Ciphertext
Bob
Man needs Woman, Woman Needs Money for
shopping
123456696 096785403 657849302 610395867 567484509
121212347
Man needs Woman, Woman Needs Money for
shopping
123456696 096785403 657849302 610395867 567484509
121212347
123456696 096785403 657849302 610395867 567484509
121212347

• Bottleneck The public-key algorithm is complex
  and must be exercised
• four times rather than two
  in each communication

133
Why Public-Key Cryptography?

• developed to address two key issues
• key distribution how to have secure
  communications in general without having to trust
  a KDC with your key
• digital signatures how to verify a message
  comes intact from the claimed sender
• Need to read page

134
Public-Key Applications

• can classify uses into 3 categories
• encryption/decryption (provide secrecy)
• digital signatures (provide authentication)
• key exchange (of session keys)
• some algorithms are suitable for all uses, others
  are specific to one

135
Security of Public Key Schemes

• like private key schemes brute force exhaustive
  search attack is always theoretically possible
• but keys used are too large (gt512bits)
• security relies on a large enough difference in
  difficulty between easy (en/decrypt) and hard
  (cryptanalyse) problems
• more generally the hard problem is known, its
  just made too hard to do in practise
• requires the use of very large numbers
• hence is slow compared to private key schemes

136
Example of Public-Key Cryptographic Techniques

• 1) Well-regarded public-key techniques include
• Diffie-Hellman
• RSA encryption algorithm
• ElGamal
• DSS (Digital Signature Standard), which
  incorporates the
• Digital Signature Algorithm.
• Various Elliptic Curve techniques
• Various Password-authenticated key agreement
  techniques
• Paillier cryptosystem
• 2) Protocols using asymmetric key algorithms
  include
• PGP Pretty Good Privacy
• GNU Privacy Guard (GPG) an implementation of
  OpenPGP
• Secure Shell (SSH)
• SSL now implemented as an IETF standard
• Trasnsport Layer Security (TLS)

137
Course Work Presentation
Symmetric Cryptography Summary
Public-Key Cryptography
Example RSA
Discussion
138
Cryptographers

• As previously mentioned, this algorithm was
  created by Ron Rivest, Adi Shamir, and Len
  Adleman of MIT.
• Dr. Ron Rivest received his Bachelors Degree in
  Mathematics from Yale University in 1969, while
  obtaining his Doctorate Degree in Computer
  Science from Stanford University in 1974. He is
  most famously known for his work in the RSA
  algorithm, along with his creation of the
  symmetric key encryption algorithms (RC2, RC4,
  RC5, and RC6).
• Dr. Rivest is currently working as a senior
  Professor of Computer Science in the Department
  of Electrical Engineering and Computer Science at
  MIT.

139
Cryptographers

• Dr. Adi Shamir received his Bachelors Degree in
  Mathematics from Tel-Aviv University in 1973, and
  received his MSc and PhD Degrees in Computer
  Science from the Weizmann Institute of Israel in
  1975 and 1977, respectively. During the latter
  half of the 1970s Dr. Shamir participated in
  research at the facilities of MIT, where he took
  part in inventing the RSA algorithm. Apart from
  the RSA algorithm, Dr. Shamir is well known for
  breaking the Merkle-Hellman cryptosystem and for
  his creation of the Shamir secret sharing scheme
  (cryptography).
• Presently, Dr. Shamir is a faculty member of the
  Weizmann Institute in the Department of
  Mathematics and Computer Science.

140
Cryptographers

• Dr. Len Adleman received his Bachelors Degree in
  Mathematics in 1968 and his Doctorate Degree in
  Computer Science in 1976 from the University of
  California, Berkeley. In addition to his
  involvement in designing the RSA algorithm, Dr.
  Adleman is widely known for creating the initial
  field of DNA Computing at the University of
  Southern California (USC).
• At the present time Dr. Adleman is working as a
  Professor of Computer Science and Molecular
  Biology at USC.
• In 2002 Dr. Rivest, Dr. Shamir, and Dr. Adleman
  received the ACM Turing Award, awarded on behalf
  of the Association of Computing Machinery in
  recognition of their discovery of the RSA
  encryption algorithm. (This award is commonly
  referred to as the Nobel Prize of Computer
  Science.)

141
RSA
142
Selecting Keys

• Bob use the following steps to select the private
  and public keys
• Bob chooses two very large prime numbers p and q.
  Remember that a prime number is one that can be
  divided evenly only by 1 and itself.
• Bob multiplies the above two primes to find n,
  the modulus for encryption and decryption. In
  other words, n p x q.
• Bob calculate another number ? (p-1) x (q-1).
• Bob chooses a random integer e. He then
  calculates d so that d x e 1 mod ?.
• Bob announces e and n to the public he keeps ?
  and d secret.

143
Need To Know
In RSA, e and n are announced to the public d
and F are kept secret.
144
Encryption

• Anyone who needs to send a message to Bob can use
  n and e. For example, if Alice needs to send a
  message to Bob, she can change the message,
  usually a short one, to an integer. This is the
  plaintext. She then calculates the ciphertext,
  using e and n.
• Alice sends C, the ciphertext, to Bob.

C Pe (mod n)
145
Decryption

• Bob keeps ? and d private. When he receives the
  ciphertext, he uses his private key d to decrypt
  the message.

P Cd (mod n)
146
Example 2 - Question

• Bob chooses 7 and 11 as p and q and calculates n
  7- 11 77. The value of Ø(7-1) or 60. Now he
  chooses two keys, e and d. if he chooses e to be
  13, then d is 37. Now Alice sends the plaintext 5
  to Bob. She uses the public key 13 to encrypt 5.

147
Example 2 - Answer

• Bob chooses 7 and 11 as p and q and calculates n
  7 11 77. The value of Ø(7-1) or 60. Now he
  chooses two keys, e and d. if he chooses e to be
  13, then d is 37. Now Alice sends the plaintext 5
  to Bob. She uses the public key 13 to encrypt 5.

Plaintext 5 C 513 26 mod 77 Ciphertext 26
Bob receives the ciphertext 26 and uses the
private key 37 to decipher the ciphertext
Ciphertext 26 P 2637 5 mod 77 Plaintext
5 Intended message sent by Alice
The plaintext 5 sent by Alice is received as
plaintext 5 by Bob.
148
Example 3
Let me give a realistic example. We choose a
512-bit p and q. We calculate n and ?. We then
choose e and test for relative primeness with
?(n). We calculate d. Finally, we show the
results of encryption and decryption. A program
written in Java/C/C to do so this type of
calculation cannot be done by a calculator.
The integer q is a 160-digit number.
149
Example 3
We calculate n. It has 309 digits
We calculate F. It has 309 digits
150
Example 3
We choose e 35,535. We then find d.
Alice wants to send the message THIS IS A TEST
which can be changed to a numeric value by using
the 0026 encoding scheme (26 is the space
character).
151
Example 3
The ciphertext calculated by Alice is C Pe,
which is.
Bob can recover the plaintext from the ciphertext
by using P Cd, which is
The recovered plaintext is THIS IS A TEST after
decoding.
152
Example 4
Bob chooses 7 and 11 as p and q and calculates n
7 11 77. The value of F (7 - 1) (11 - 1)
or 60. Now he chooses two keys, e and d. If he
chooses e to be 13, then d is 37. Now imagine
Alice sends the plaintext 5 to Bob. She uses the
public key 13 to encrypt 5.
153
Example 4
Bob receives the ciphertext 26 and uses the
private key 37 to decipher the ciphertext
The plaintext 5 sent by Alice is received as
plaintext 5 by Bob.
154
Example 5
Jennifer creates a pair of keys for herself. She
chooses p 397 and q 401. She calculates n
159,197 and F 396 400 158,400. She then
chooses e 343 and d 12,007. Show how Ted can
send a message to Jennifer if he knows e and n.
155
Example 5
Solution Suppose Ted wants to send the message
NO to Jennifer. He changes each character to a
number (from 00 to 25) with each character coded
as two digits. He then concatenates the two coded
characters and gets a four-digit number. The
plaintext is 1314. Ted then uses e and n to
encrypt the message. The ciphertext is 1314343
33,677 mod 159,197. Jennifer receives the message
33,677 and uses the decryption key d to decipher
it as 33,67712,007 1314 mod 159,197. Jennifer
then decodes 1314 as the message NO. Figure
30.25 shows the process.
156
Example 5
157
Example 6 - Question

• Alice wants to send a cellphone text message to
  Bob securely, over an insecure communication
  network. Alice's cellphone has a RSA public key
  KA and matching private key VA likewise, Bob's
  cellphone has KB and VB. Let's design a
  cryptographic protocol for doing this, assuming
  both know each other's public keys. Here is what
  Alice's cellphone will do to send the text
  message m
• Alice's phone randomly picks a new AES session
  key k and computes c RSA- Encrypt(KB, k), c
  AES-CBC-Encrypt(k, m), and t RSA-Sign(VA, (c,
  c)).
• Alice's phone sends (c, c, t) to Bob's phone.
• And here is what Bob's cellphone will do, upon
  receiving (c, c, t)
• Bob's phone checks that t is a valid RSA
  signature on (c, c) under public key KA. If
  not, abort.
• Bob's phone computes k RSA-Decrypt(VB, c) and
  m AES-CBC-Decrypt(k, c).
• Bob's phone informs Bob that Alice sent message
  m.

158
Example 6 - Question

• Does this protocol ensure the confidentiality of
  Alice's messages? Why or why not?
• Does this protocol ensure authentication and data
  integrity for every text message Bob receives?
  Why or why not?
• Suppose that Bob is Alice's stockbroker. Bob
  hooks up the output of this protocol to an
  automatic stock trading service, so if Alice
  sends a text message Sell 100 shares MSFT using
  the above protocol, then this trade will be
  immediately and automatically executed from
  Alice's account. Suggest one reason why this
  might be a bad idea from a security point of view.

159
Example 6 - Answer

• Does this protocol ensure the confidentiality of
  Alice's messages? Why or why not?
• Yes. Since AES-CBC-Encrypt is secure, no one can
  recover m from c without knowledge of k. Also,
  since RSA-Encrypt is secure, only someone who
  knows KBnamely, Bobcan recover k.
• Does this protocol ensure authentication and data
  integrity for every text message Bob receives?
  Why or why not?
• Yes. Since RSA-Sign is secure, if (c, c) passes
  step 1, then only someone who knew vAnamely,
  Alicecould have sent (c, c). Now (c, c)
  uniquely determines m, the message that Alice
  wanted to send.
• Conclusion If Bob accepts m in step 3, then
  Alice sent m.

160
Example 6 - Answer

• Suppose that Bob is Alice's stockbroker. Bob
  hooks up the output of this protocol to an
  automatic stock trading service, so if Alice
  sends a text message Sell 100 shares MSFT using
  the above protocol, then this trade will be
  immediately and automatically executed from
  Alice's account. Suggest one reason why
