Wave Behavior

1
Wave Behavior

• Relfection, Refraction, Diffraction.

2
Reflection

• Reflection occurs when a wave strikes an object
  and bounces off of it.
• All types of waves?including sound, water, and
  light waves?can be reflected

3
Reflection

• When a wave bounces off a barrier or surface it
  is said to be reflected. How much of the wave
  that is reflected depends on the impedance
  between the two mediums.
• Impedance describes the difference in densities
  of the two mediums, the greater the difference in
  mediums, the greater the impedance.
• As the impedance increases, more of the wave's
  energy is reflected instead of being transmitted
  into the next medium.

4
Echo

• Sometimes when the sound waves hit another
  object, they reflect off it and come back to you.

• Your ears hear the sound again, a few seconds
  after you first heard your footstep.

5
Sonar

• How does a bat use reflection to find food?

6
Law of Reflection

• The angle formed by the incident beam and the
  normal is the angle of incidence.
• The angle formed by the reflected beam and the
  normal is the angle of refection.
• According to the law of reflection, the angle of
  incidence is equal to the angle of refection.
  All reflected waves obey this law.

7
Types of Reflection
8
Refraction

• When a wave passes from one medium to
  another?such as when a light wave passes from air
  to water?it changes speed.
• If the wave is traveling at an angle when it
  passes from one medium to another, it changes
  direction, or bends, as it changes speed.

9
Glass and light
10
Refraction

• Refraction is the bending of a wave caused by a
  change in its speed as it moves from one medium
  to another.

11
Sound refraction

• Sound wave will refract if there is a difference
  in air temperature.
• The different densities cause the waves to bend.

12
Snells Law

• n1 index of refraction for incidence medium
• q1 angle of incidence
• n2 index of refraction for refractive medium
• q2 angle of refraction
• __________________________________________________
  _______________
• Speed of an EM wave in a Medium
• v c/n

The index of refraction is defined as the speed
of light in vacuum divided by the speed of light
in the medium.
13
Critical Angle

• The angle of incidence that produces total
  internal reflection.

14
Interference

• When waves appear at the same point in space and
  time and combine. (superposition)

Constructive
Destructive
15
Diffraction

• Diffraction occurs when an object causes a wave
  to change direction and bend around it.
• Diffraction and refraction both cause waves to
  bend. The difference is that refraction occurs
  when waves pass through an object, while
  diffraction occurs when waves pass around an
  object.

16
Diffraction
17
