CPE 626 The SystemC Language

1
CPE 626 The SystemC Language

• Aleksandar Milenkovic
• E-mail milenka_at_ece.uah.edu
• Web http//www.ece.uah.edu/milenka

2
Outline

• Motivation for SystemC
• What is SystemC?
• Modules
• Processes

3
Standard Methodology for ICs

• System-level designers write a C or C model
• Written in a stylized, hardware-like form
• Sometimes refined to be more hardware-like
• C/C model simulated to verify functionality
• Parts of the model to be implemented in hardware
  are given to Verilog/VHDL coders
• Verilog or VHDL specification written
• Models simulated together to test equivalence
• Verilog/VHDL model synthesized

4
Designing Big Digital Systems

• Current conditions
• Every system company was doing this differently
• Every system company used its own simulation
  library
• System designers dont know Verilog or VHDL
• Verilog or VHDL coders dont understand system
  design
• Problems with standard methodology
• Manual conversion from C to HDL
• Error prone and time consuming
• Disconnect between system model and HDL model
• C model becomes out of date as changes are made
  only to the HDL model
• System testing
• Tests used for C model cannot be run against HDL
  model gt they have to be converted to the HDL
  environment

5
Idea of SystemC

• C and C are being used as ad-hoc modeling
  languages
• Why not formalize their use?
• Why not interpret them as hardware specification
  languages just as Verilog and VHDL were?
• SystemC developed at Synopsys to do just this

6
SystemC Design Methodology

• Refinement methodology
• Design is slowly refined in small sections to
  add necessary hardware and timing constructs
• Written in a single language
• higher productivity due to modeling at a higher
  level
• testbenches can be reusedsaving time
• Future releases will have constructs to model
  RTOS

7
What Is SystemC?

• A subset of C that models/specifies
  synchronous digital hardware
• A collection of simulation libraries that can be
  used to run a SystemC program
• A compiler that translates the synthesis
  subset of SystemC into a netlist

8
What Is SystemC?

• Language definition is publicly available
• Libraries are freely distributed
• Compiler is an expensive commercial product
• See www.systemc.org for more information

9
Quick Overview

• A SystemC program consists of module definitions
  plus a top-level function that starts the
  simulation
• Modules contain processes (C methods) and
  instances of other modules
• Ports on modules define their interface
• Rich set of port data types (hardware modeling,
  etc.)
• Signals in modules convey information between
  instances
• Clocks are special signals that run periodically
  and can trigger clocked processes
• Rich set of numeric types (fixed and arbitrary
  precision numbers)

10
Modules

• Hierarchical entity
• Similar to Verilogs module
• Actually a C class definition
• Simulation involves
• Creating objects of this class
• They connect themselves together
• Processes in these objects (methods) are called
  by the scheduler to perform the simulation

11
Modules
SC_MODULE(mymod) // struct mymod sc_module
/ port definitions / / signal definitions
/ / clock definitions / / storage and
state variables / / process definitions /
SC_CTOR(mymod) / Instances of processes
and modules /
12
Ports

• Define the interface to each module
• Channels through which data is communicated
• Port consists of a direction
• input sc_in
• output sc_out
• bidirectional sc_inout
• and any C or SystemC type

SC_MODULE(mymod) sc_inltboolgt load, read
sc_inoutltintgt data sc_outltboolgt full /
rest of the module /
13
Signals

• Convey information between modules within a
  module
• Directionless module ports define direction of
  data transfer
• Type may be any C or built-in type

SC_MODULE(mymod) / port definitions /
sc_signalltsc_uintlt32gt gt s1, s2 sc_signalltboolgt
reset / / SC_CTOR(mymod) /
Instances of modules that connect to the signals
/
14
Instances of Modules

• Each instance is a pointer to an object in the
  module

Connect instances ports to signals
SC_MODULE(mod1) SC_MODULE(mod2)
SC_MODULE(foo) mod1 m1 mod2 m2
sc_signalltintgt a, b, c SC_CTOR(foo) m1
new mod1(i1) (m1)(a, b, c) m2 new
mod2(i2) (m2)(c, b)
15
Positional Connection
// filter.h include "systemc.h // systemC
classes include "mult.h // decl. of
mult include "coeff.h // decl. of
coeff include "sample.h // decl. of
sample SC_MODULE(filter) sample s1 //
pointer declarations coeff c1 mult m1
// signal declarations sc_signalltsc_uintlt32gt gt
q, s, c SC_CTOR(filter) // constructor
s1 new sample ("s1") // create obj.
(s1)(q,s) // signal mapping c1 new coeff
("c1") (c1)(c) m1 new mult ("m1")
(m1)(s,c,q)
16
Named Connection
include "systemc.h // systemC classes include
"mult.h // decl. of mult include "coeff.h
// decl. of coeff include "sample.h // decl.
of sample SC_MODULE(filter) sample s1
coeff c1 mult m1 sc_signalltsc_uintlt32gt gt
q, s, c SC_CTOR(filter) s1 new sample
("s1") s1-gtdin(q) // din of s1 to signal q
s1-gtdout(s) // dout to signal s c1 new
coeff ("c1") c1-gtout(c) // out of c1 to
signal c m1 new mult ("m1") m1-gta(s)
// a of m1 to signal s m1-gtb(c) // b of m1
to signal c m1-gtq(q) // q of m1 to signal c

17
Internal Data Storage

• Local variables to store data within a module
• May be of any legal C, SystemC, or user-defined
  type
• Not visible outside the module unless it is made
  explicitly

// count.h include "systemc.h" SC_MODULE(count)
sc_inltboolgt load sc_inltintgt din // input
port sc_inltboolgt clock // input port
sc_outltintgt dout // output port int count_val
// internal data storage void count_up()
SC_CTOR(count) SC_METHOD(count_up) //Method
process sensitive_pos ltlt clock
// count.cc include "count.h" void
countcount_up() if (load) count_val
din else // could be count_val
count_val count_val 1 dout count_val
18
Processes

• Only thing in SystemC that actually does anything
• Functions identified to the SystemC kernel and
  called whenever signals these processes are
  sensitive to change value
• Statements are executed sequentially until the
  end of the process occurs, or the process is
  suspended using wait function
• Very much like normal C methods Registered
  with the SystemC kernel
• Like Verilogs initial blocks

19
Processes (contd)

• Processes are not hierarchical
• no process can call another process directly
• can call other methods and functions that are not
  processes
• Have sensitivity lists
• signals that cause the process to be invoked,
  whenever the value of a signal in this list
  changes
• Processes cause other processes to execute by
  assigning new values to signals in the
  sensitivity lists of the processes
• To trigger a process, a signal in the sensitivity
  list of the process must have an event occur

20
Three Types of Processes
Determines how the process is called and executed

• METHOD
• Models combinational logic
• THREAD
• Models testbenches
• CTHREAD
• Models synchronous FSMs

21
METHOD Processes

• Triggered in response to changes on inputs
• Cannot store control state between invocations
• Designed to model blocks of combinational logic

22
METHOD Processes
Process is simply a method of this class
SC_MODULE(onemethod) sc_inltboolgt in
sc_outltboolgt out void inverter()
SC_CTOR(onemethod) SC_METHOD(inverter)
sensitive(in)
Instance of this process created
and made sensitive to an input
23
METHOD Processes

• Invoked once every time input in changes
• Should not save state between invocations
• Runs to completion should not contain infinite
  loops
• Not preempted

void onemethodinverter() bool internal
internal in out internal
Read a value from the port
Write a value to an output port
24
THREAD Processes

• Triggered in response to changes on inputs
• Can suspend itself and be reactivated
• Method calls wait() function that suspends
  process execution
• Scheduler runs it again when an event occurs on
  one of the signals the process is sensitive to
• Designed to model just about anything

25
THREAD Processes
Process is simply a method of this class
SC_MODULE(onemethod) sc_inltboolgt in
sc_outltboolgt out void toggler()
SC_CTOR(onemethod) SC_THREAD(toggler)
sensitive ltlt in
Instance of this process created
alternate sensitivity list notation
26
THREAD Processes

• Reawakened whenever an input changes
• State saved between invocations
• Infinite loops should contain a wait()

Relinquish control until the next change of a
signal on the sensitivity list for this process
void onemethodtoggler() bool last false
for () last in out last wait()
last in out last wait()
27
CTHREAD Processes

• Triggered in response to a single clock edge
• Can suspend itself and be reactivated
• Method calls wait to relinquish control
• Scheduler runs it again later
• Designed to model clocked digital hardware

28
CTHREAD Processes
SC_MODULE(onemethod) sc_in_clk clock
sc_inltboolgt trigger, in sc_outltboolgt out
void toggler() SC_CTOR(onemethod)
SC_CTHREAD(toggler, clock.pos())
Instance of this process created and relevant
clock edge assigned
29
CTHREAD Processes

• Reawakened at the edge of the clock
• State saved between invocations
• Infinite loops should contain a wait()

Relinquish control until the next clock cycle in
which the trigger input is 1
void onemethodtoggler() bool last false
for () wait_until(trigger.delayed()
true) last in out last wait()
last in out last wait()
Relinquish control until the next clock cycle
30
A CTHREAD for Complex Multiply
struct complex_mult sc_module sc_inltintgt
a, b, c, d sc_outltintgt x, y sc_in_clk
clock void do_mult() for () x
a c - b d wait() y a d
b c wait()
SC_CTOR(complex_mult) SC_CTHREAD(do_mult,
clock.pos())
31
Put It All Together
Process Type SC_METHOD SC_THREAD SC_CTHREAD
Exec. Trigger Signal Events Signal Events Clock Edge
Exec. Suspend NO YES YES
Infinite Loop NO YES YES
Suspend / Resume by N.A. wait() wait() wait_until()
Construct Sensitize Method SC_METHOD(call_back) sensitive(signals) sensitive_pos(signals) sensitive_neg(signals) SC_THREAD(call_back) sensitive(signals) sensitive_pos(signals) sensitive_neg(signals) SC_CTHREAD( call_back, clock.pos()) SC_CTHREAD( call_back, clock.neg())
32
Watching

• SC_THREAD and SC_CTHREAD processes typicallyhave
  infinite loops that will continuously execute
• Use watching construct to jump out of the loop
• Watching construct will monitor a specified
  condition
• When condition occurs control is transferred
  from the current execution point to the
  beginning of the process

33
Watching An Example
// datagen.h include "systemc.h" SC_MODULE(data_g
en) sc_in_clk clk sc_inoutltintgt data
sc_inltboolgt reset void gen_data()
SC_CTOR(data_gen) SC_CTHREAD(gen_data,
clk.pos()) watching(reset.delayed() true)

// datagen.cc include "datagen.h" void
gen_data() if (reset true) data
0 while (true) data data 1
wait() data data 2 wait() data
data 4 wait()
Watching expressions are tested at the wait() or
wait_until() calls. All variables defined locally
will lose their value on the control exiting.
34
Local Watching

• Allows us to specify exactly which section of
  the process is watching which signal, and where
  event handlers are located

W_BEGIN // put the watching declarations
here watching(...) watching(...) W_DO // This
is where the process functionality
goes ... W_ESCAPE // This is where the handlers
// for the watched events go if (..)
... W_END
W_BEGIN macro marks the beginning of the local
watching block. W_BEGIN W_DO watching
declarations W_DO W_ESCAPEprocess
functionality W_ESCAPE W_ENDevent
handlers W_END macro ends local watching block
35
Local Watching Rules

• All of the events in the declaration block have
  the same priority. If a different priority is
  needed then local watching blocks will need to be
  nested
• Local watching only works in SC_CTHREAD processes
• The signals in the watching expressions are
  sampled only on the active edges of the process.
  In an SC_CTHREAD process this means only when the
  clock that the process is sensitive to changes
• Globally watched events have higher priority than
  locally watched events

36
D-FF in SystemC
// dff.h include "systemc.h" SC_MODULE(dff)
sc_inltboolgt din // data input sc_inltboolgt
clock // clock input sc_outltboolgt dout //
data output void doit() // method in the
module SC_CTOR(dff) // constructor
SC_METHOD(doit) // doit type is SC_METHOD //
method will be called whenever a //
positive edge occurs on port clock
sensitive_pos ltlt clock
// dff.cc include "dff.h" void dffdoit()
dout din
37
Bus Controller in SystemC

• Assumptions
• 32-bit internal data path 8-bit external data
  path
• every address and data transaction will have to
  be multiplexed over the 8-bit bus
• Protocol
• 32-bit address is sent to the bus controller (BC)
  process
• address will be multiplexed byte by byte and sent
  to MC
• bus controller will wait for ready signal from
  memory
• receive the data
• send the data to microcontroller

38
Bus Controller bus.h
// bus.h include "systemc.h" SC_MODULE(bus)
sc_in_clk clock sc_inltboolgt newaddr
sc_inltsc_uintlt32gt gt addr sc_inltboolgt ready
sc_outltsc_uintlt32gt gt data sc_outltboolgt start
sc_outltboolgt datardy sc_inoutltsc_uintlt8gt gt
data8 sc_uintlt32gt tdata sc_uintlt32gt taddr
void xfer() SC_CTOR(bus) SC_CTHREAD(xfer,
clock.pos()) // ready to accept new address
datardy true
39
Bus Controller bus.cc
// bus.cc include "bus.h" void busxfer()
while (true) // wait for a new address to
appear wait_until( newaddr.delayed()
true) // got a new address so process it
taddr addr.read() datardy false //
cannot accept new address now data8
taddr.range(7,0) start true // new addr
for memory controller wait() // wait 1
clock between data transfers data8
taddr.range(15,8) start false wait()
data8 taddr.range(23,16) wait() data8
taddr.range(31,24) wait()
40
Bus Controller bus.cc (contd)
// now wait for ready signal from memory
controller wait_until(ready.delayed()
true) // now transfer memory data to databus
tdata.range(7,0) data8.read() wait()
tdata.range(15,8) data8.read() wait()
tdata.range(23,16) data8.read() wait()
tdata.range(31,24) data8.read() data
tdata datardy true // data is ready, new
addresses ok
41
Local Watching Example

• Modify bus controller by allowing the bus
  controller to be interrupted during the transfer
  from the memory but not to the memory

... // now wait for ready signal from
memory controller wait_until(ready.delayed()
true)
42
Local Watching Example
W_BEGIN watching(reset.delayed()) //
Active value of reset will trigger watching
W_DO // the rest of this block is as before
tdata.range(7,0) data8.read() // now
transfer memory data to databus wait()
tdata.range(15,8) data8.read() wait()
tdata.range(23,16) data8.read()
wait() tdata.range(31,24) data8.read()
data tdata datardy true // data is
ready, new addresses ok W_ESCAPE if
(reset) datardy false W_END
