Carol Beer (Little Britain)

1
Carol Beer (Little Britain)
2
Computer says no
3
Question Answering

• Lecture 1 (Today)Introduction History of QA
  Architecture of a QA system Evaluation.
• Lecture 2 (Friday)Question Classification NLP
  techniques for question analysis POS-tagging
  Parsing Semantic analysis WordNet.
• Lecture 3 (Next Monday)Retrieving Answers
  Document pre-processing Tokenisation Stemming
  Lemmatisation Named Entity Recognition Anaphora
  Resolution Matching Use of knowledge resources
  Reranking Sanity checking.

4
What is Question Answering?

• ?

5
Information Pinpointing

• Information required Average number of car
  accidents per year in Sweden.
• Two ways of getting this information
• Ask Google or a similar search engine (good
  luck!)
• Ask a QA system the questionWhats the rate of
  car accidents in Sweden?

6
QA vs IR

• Traditional method for information access IR
  (Information Retrieval)
• Think of IR as finding the right book in a
  library
• Think of QA as a librarian giving you the book
  and opening it on the page with the information
  youre looking for

7
QA vs IE

• Traditional method for information access IE
  (Information Extraction)
• Think of IE as finding answers to a pre-defined
  question (i.e., a template)
• Think of QA as asking any question you like

8
What is Question Answering?

• Questions in natural language, not queries!
• Answers, not documents!

9
Why do we need QA?

• Information overload problem
• Accessing information using traditional methods
  such as IR and IE are limited
• QA increasingly important because
• Size of available information grows
• There is duplicate information
• There is false information
• More and more computer illiterates accessing
  electronically stored information

10
Information Avalanche

• Available information is growing
• 1999 250MB pp for each person on earth
• 2002 800MB pp for each person on earth
• People want specific information
• source M.de Rijke
  2005

11
People ask Questions
source M.de Rijke 2005
12
Why is QA hard? (1/3)

• Questions are expressed in natural language (such
  as English or Italian)
• Unlike formal languages, natural languages allow
  a great deal of flexibility
• Example
• What is the population of Rome?
• How many people live in Rome?
• Whats the size of Rome?
• How many inhabitants does Rome have?

13
Why is QA hard? (2/3)

• Answers are expressed in natural language (such
  as English or Italian)
• Unlike formal languages, natural languages allow
  a great deal of flexibility
• Example
• is estimated at 2.5 million residents
• current population of Rome is 2817000
• Rome housed over 1 million inhabitants

14
Why is QA hard? (3/3)

• Answers could be spread across different
  documents
• Examples
• Which European countries produce wine?Document
  A contains information about Italy, and document
  B about France
• What does Bill Clintons wife do for a
  living?Document A explains that Bill Clintons
  wife is Hillary Clinton, and Document B tells us
  that shes a politician

15
History of QA (de Rijke Webber 2003)

• QA is by no means a new area!
• Simmons (1965) reviews 15 implemented and working
  systems
• Many ingredients of todays QA systems are rooted
  in these early approaches
• Database oriented systems, domain independent, as
  opposed to todays systems that work on large
  sets of unstructured texts

16
Examples of early QA systems

• BASEBALL (Green et al. 1963)Answers English
  questions about scores, locations and dates of
  baseball games
• LUNAR (Woods 1977)Accesses chemical data on
  lunar material compiled during the Apollo
  missions
• PHLIQA1 (Scha et al. 1980)Answers short
  questions against a database of computer
  installations in Europe

17
Recent work in QA

• Since the 1990s research in QA has by and large
  focused on open-domain applications
• Recently interest in restricted-domain QA has
  increased, in particular in commercial
  applications
• Banking, entertainment, etc.

18
Architecture of a QA system
corpus
IR
query
Question Analysis
question
documents/passages
Document Analysis
answer-type
question representation
passage representation
Answer Extraction
answers
19
Question Analysis

• InputNatural Language Question
• OutputExpected Answer Type(Formal)
  Representation of Question
• Techniques usedMachine learning, parsing

20
Document Analysis

• InputDocuments or Passages
• Output(Formal) Representation of Passages that
  might contain the answer
• Techniques usedTokenisation, Named Entity
  Recognition, Parsing

21
Answer Retrieval

• InputExpected Answer TypeQuestion (formal
  representation)Passages (formal representation)
• OutputRanked list of answers
• Techniques usedMatching, Re-ranking, Validation

22
Example Run
corpus
IR
query
Question Analysis
question
documents/passages
Document Analysis
answer-type
question representation
passage representation
Answer Extraction
answers
23
Example Run
How long is the river Thames?
corpus
IR
query
Question Analysis
question
documents/passages
Document Analysis
answer-type
question representation
passage representation
Answer Extraction
answers
24
Example Run
length river thames
corpus
IR
query
Question Analysis
question
documents/passages
Document Analysis
answer-type
question representation
passage representation
Answer Extraction
answers
25
Example Run
corpus
MEASURE
IR
query
Question Analysis
question
documents/passages
Document Analysis
answer-type
question representation
passage representation
Answer Extraction
answers
26
Example Run
corpus
IR
query
Question Analysis
question
Answer(x) length(y,x) river(y)
named(y,thames)
documents/passages
Document Analysis
answer-type
question representation
passage representation
Answer Extraction
answers
27
Example Run
A NYT199802-31 B APW199805-12 C NYT200011-07
corpus
IR
query
Question Analysis
question
documents/passages
Document Analysis
answer-type
question representation
passage representation
Answer Extraction
answers
28
Example Run
A 30(u) mile(u) length(v,u) river(y) B
60(z) centimeter(z) height(v,z) dog(z) C
230(u) kilometer(u) length(x,u) river(x)
corpus
IR
query
Question Analysis
question
documents/passages
Document Analysis
answer-type
question representation
passage representation
Answer Extraction
answers
29
Example Run
corpus
IR
query
Question Analysis
question
documents/passages
C 230 kilometer A 30 milesB 60 centimeter
Document Analysis
answer-type
question representation
passage representation
Answer Extraction
answers
30
Evaluating QA systems

• International evaluation campaigns for QA systems
  (open domain QA)
• TREC (Text Retrieval Conference)http//trec.nist.
  gov/
• CLEF (Cross Language Evaluation
  Forum)http//clef-qa.itc.it/
• NTCIR (NII Test Collection for IR
  Systems)http//www.slt.atr.jp/CLQA/

31
TREC-QA (organised by NIST)

• Annual event, started in 1999
• Difficulty of the QA task increased over the
  years
• 1999 Answers in snippets, ranked list of
  answers
• 2005 Exact answers, only one answer.
• Three types of questions
• Factoid questions
• List questions
• Definition questions

32
QA_at_CLEF

• CLEF is the European edition of TREC
• Monolingual (non-English) QA
• Bulgarian (BG), German (DE), Spanish (ES),
  Finnish (FI), French (FR), Italian (IT), Dutch
  (NL), Portuguese (PT)
• Cross-Lingual QA
• Questions posed in source language, answer
  searched in documents of target language
• All combinations possible

33
Open-Domain QA

• QA at TREC is considered Open-Domain QA
• Document collection is Acquint Corpus(over a
  million documents)
• Questions can be about anything
• Restricted-Domain QA
• Documents described a specific domain
• Detailed questions
• Less redundancy of answers!

34
TREC-type questions

• Factoid questions
• Where is the Taj Mahal?
• List questions
• What actors have played Tevye in Fiddler on the
  Roof'?
• Definition/biographical questions
• What is a golden parachute?
• Who is Vlad the Impaler?

35
What is a correct answer?

• Example Factoid Question
• When did Franz Kafka die?
• Possible Answers
• Kafka died in 1923.
• Kafka died in 1924.
• Kafka died on June 3, 1924 from complications
  related to Tuberculosis.
• Ernest Watz was born June 3, 1924.
• Kafka died on June 3, 1924.

36
What is a correct answer?

• Example Factoid Question
• When did Franz Kafka die?
• Possible Answers
• Kafka died in 1923.
• Kafka died in 1924.
• Kafka died on June 3, 1924 from complications
  related to Tuberculosis.
• Ernest Watz was born June 3, 1924.
• Kafka died on June 3, 1924.

Incorrect
37
What is a correct answer?

• Example Factoid Question
• When did Franz Kafka die?
• Possible Answers
• Kafka died in 1923.
• Kafka died in 1924.
• Kafka died on June 3, 1924 from complications
  related to Tuberculosis.
• Ernest Watz was born June 3, 1924.
• Kafka died on June 3, 1924.

Inexact (under-informative)
38
What is a correct answer?

• Example Question
• When did Franz Kafka die?
• Possible Answers
• Kafka died in 1923.
• Kafka died in 1924.
• Kafka died on June 3, 1924 from complications
  related to Tuberculosis.
• Ernest Watz was born June 3, 1924.
• Kafka died on June 3, 1924.

Inexact (over-informative)
39
What is a correct answer?

• Example Question
• When did Franz Kafka die?
• Possible Answers
• Kafka died in 1923.
• Kafka died in 1924.
• Kafka died on June 3, 1924 from complications
  related to Tuberculosis.
• Ernest Watz was born June 3, 1924.
• Kafka died on June 3, 1924.

Unsupported
40
What is a correct answer?

• Example Question
• When did Franz Kafka die?
• Possible Answers
• Kafka died in 1923.
• Kafka died in 1924.
• Kafka died on June 3, 1924 from complications
  related to Tuberculosis.
• Ernest Watz was born June 3, 1924.
• Kafka died on June 3, 1924.

Correct
41
Answer Accuracy

• correct
  answers
• Answer Accuracy ---------------------------
•
  questions

42
Correct answers to list questions
Example List Question Which European countries
produce wine?

• System A
• France
• Italy

System B Scotland France
Germany Italy Spain
Iceland Greece the Netherlands Japan
Turkey Estonia
43
Evaluation metrics for list questions

• Precision (P)
  answers judged correct distinct
  P ------------------------------------------
  ----
  answers returned
• Recall (R) answers
  judged correct distinct R
  ------------------------------------------------
  total
  answers
• F-Score (F) 2PR
  F ------------
  PR

44
Correct answers to list questions
Example List Question Which European countries
produce wine?

• System A
• France
• Italy

System B Scotland France
Germany Italy Spain
Iceland Greece the Netherlands Japan
Turkey Estonia
P 1.00 R 0.25 F 0.40
P 0.64 R 0.88 F 0.74
45
Other evaluation metrics

• System A Ranked answers (Accuracy 0.2)

Q1 Q2 Q3 Q4 Q6 Q7 Q8 Q9 . Qn
A1 W W C W C W W W . W
A2 W W W W W W W W . W
A3 W W W W W W W W . W
A4 W W W W W W W W . W
A5 W C W W W C W W . W
System B Ranked answers (Accuracy 0.1)
Q1 Q2 Q3 Q4 Q6 Q7 Q8 Q9 . Qn
A1 W W W W C W W W . W
A2 C W C W W C C W . C
A3 W C W W W W W W . W
A4 W W W C W W W W . W
A5 W W W W W W W W . W
46
Mean Reciprocal Rank (MRR)

• Score for an individual question
• The reciprocal of the rank at which the first
  correct answer is returned
• 0 if no correct response is returned
• The score for a run
• Mean over the set of questions in the test

47
MRR in action

• System A MRR (.211.2)/10 0.24

Q1 Q2 Q3 Q4 Q6 Q7 Q8 Q9 . Qn
A1 W W C W C W W W . W
A2 W W W W W W W W . W
A3 W W W W W W W W . W
A4 W W W W W W W W . W
A5 W C W W W C W W . W
System B MRR (.5.33.5.251.5.5.5)/100.42
Q1 Q2 Q3 Q4 Q6 Q7 Q8 Q9 . Qn
A1 W W W W C W W W . W
A2 C W C W W C C W . C
A3 W C W W W W W W . W
A4 W W W C W W W W . W
A5 W W W W W W W W . W
48
Open-Domain Question Answering

• TREC QA Track
• Factoid questions
• List questions
• Definition questions
• State-of-the-Art
• Hard problem
• Only few systems withgood results

49
Friday

• QA Lecture 2
• Question Classification
• NLP techniques for question analysis
• POS-tagging
• Parsing
• Semantic analysis
• Use of lexical resources such as WordNet

50
Question Classification (preview)

• How many islands does Italy have?
• When did Inter win the Scudetto?
• What are the colours of the Lithuanian flag?
• Where is St. Andrews located?
• Why does oil float in water?
• How did Frank Zappa die?
• Name the Baltic countries.
• Which seabird was declared extinct in the 1840s?
• Who is Noam Chomsky?
• List names of Russian composers.
• Edison is the inventor of what?
• How far is the moon from the sun?
• What is the distance from New York to Boston?
• How many planets are there?
• What is the exchange rate of the Euro to the
  Dollar?
• What does SPQR stand for?
• What is the nickname of Totti?
• What does the Scottish word bonnie mean?
• Who wrote the song Paranoid Android?
