The Magnetic Tower of Hanoi

1
The Magnetic Tower of Hanoi
2
The Classical Tower of Hanoi
3
Classical ToH video-clip 1 (053)
Click link to play a YouTube video 1.
http//www.youtube.com/watch?vEHtk7kZqoVY
4
Positional Notations
5
Babylonian mathematics (3-rd millennium BC)
It originated with the ancient Sumerians in the
3rd millennium BC, was transmitted to the
Babylonians, and is still used - in modified
form - for measuring time, angles, and
geographic coordinates.
http//en.wikipedia.org/wiki/Base_60
6
A short reminder of bases (Positional Notation)
Indian mathematicians developed the Hindu-Arabic
numeral system, the modern decimal positional
notation, in the 9-th century.
2506 2 x 103 5 x 102 0 x 101 6 x 100
7
A short reminder of bases base 2
Base 2
20 21 22 23 24 Weight
1 2 3 4 5 Position
1 1 1 0 1 Number
10111(2) 124 023 122 121 120
10111(2) 16(10) 4(10) 2(10) 1(10)
23(10)
http//en.wikipedia.org/wiki/Place_value_system
8
A short reminder of bases base 3
Base 3
30 31 32 33 34 Weight
1 2 3 4 5 Position
2 2 1 0 1 Number
10122(3) 134 033 132 231 230
10122(3) 81(10) 9(10) 6(10) 2(10)
98(10)
http//en.wikipedia.org/wiki/Place_value_system
9
The Classical Tower and base 2
10
A. The Classical Tower of Hanoi ToH
The classical Tower of Hanoi "puzzle" or
"mathematical game" invented by the French
mathematician Edouard Lucas in 1883.
http//en.wikipedia.org/wiki/Tower_of_Hanoi
11
Classical ToH video-clip 2 (114)
Click link to play a YouTube video 2.
http//www.youtube.com/watch?v3eGBhSSxffM
12
ToH Puzzle Description
Puzzle Components Three equal posts A set of N
different-diameter disks Puzzle-start setting
N disks arranged in a bottom-to-top
descending-size order on a "Source"
Post Move Lift a disk off one Post and land it
on another Post Disk-placement rules The Size
Rule A small disk can not "carry" a larger one
(Never land a large disk on a smaller
one) Puzzle-end state N disks arranged in a
bottom-to-top descending-size order on a
"Destination" Post (one of the two
originally-free posts)
13
ToH Recursive Relations
14
ToH Number of Moves
2N - 1 SUM 8 7 6 5 4 3 2 1 k N
1 1 1 1
3 3 2 1 2
7 7 4 2 1 3
15 15 8 4 2 1 4
31 31 16 8 4 2 1 5
63 63 32 16 8 4 2 1 6
127 127 64 32 16 8 4 2 1 7
255 255 128 64 32 16 8 4 2 1 8
15
Classical ToH spans base 2
2N - 1 SUM 4 3 2 1 k N
1 1 1 1

3 3 2 1 2

7 7 4 2 1 3

15 15 8 4 2 1 4

21-1 20
22-1 21 20
22 21 20
23-1 22 21 20
23 22 21 20
24-1 23 22 21 20
16
A Base 2 game
Base 2
5 4 3 2 1 Element (k)
16 8 4 2 1 of moves
24 23 22 21 20 of moves
17
The Classical Tower Spans base 2
18
Challenge invent a base 3 game
Can we invent a game that Spans base 3?
19
Elements of aBase 3 game
Base 3
5 4 3 2 1 Element (k)
81 27 9 3 1 of moves
34 33 32 31 30 of moves
20
Challenge invent a base 3 game
So - can we invent a game that Spans base 3?
21
Yes we can
22
MToH video-clip 3 (129)
Click link to play a YouTube video 3.
http//www.youtube.com/watch?vnUoHHeaJ4eI
23
B. The Magnetic Tower of Hanoi MToH
24
MToH when we where Young and Brave
Yaron (10) and a home-made Magnetic Tower of
Hanoi Rehovot, Israel - Autumn 1984.
25
MToH Puzzle Description

• Puzzle Components
• Three equal posts. A set of N different-diameter
  disks
• Each disk's "bottom" surface is colored Blue and
  its "top" surface is colored Red
• Puzzle-start setting
• N disks arranged in a bottom-to-top
  descending-size order on a "Source" Post
• The Red surface of every disk in the stack is
  facing upwards
• Move
• Lift a disk off one post
• Turn the disk upside down and land it on another
  post
• Disk-placement rules
• The Size Rule A small disk can not "carry" a
  larger one (Never land a large disk on a smaller
  one)
• The Magnet Rule Rejection occurs between two
  equal colors (Never land a disk such that its
  bottom surface will touch a co-colored top
  surface of the "resident" disk)
• Puzzle-end state
• N disks arranged in a bottom-to-top
  descending-size order on a "Destination" Post
  (one of the two originally-free posts)

26
MToH Solving the N2 Puzzle
27
Colored MToH video-clip 4 (124)
Click link to play a YouTube video 4.
http//www.youtube.com/watch?vD_xfuCOh1S0
28
B1. The Colored MToH
29
The Colored MToH Number of Moves
(3N - 1)/2 SUM 8 7 6 5 4 3 2 1 k N
1 1 1 1
4 4 3 1 2
13 13 9 3 1 3
40 40 27 9 3 1 4
121 121 81 27 9 3 1 5
364 364 243 81 27 9 3 1 6
1093 1093 729 243 81 27 9 3 1 7
3280 3280 2187 729 243 81 27 9 3 1 8
30
Colored MToH spans base 3
(3N1)/2 SUM 5 4 3 2 1 k N
1 1 1 1

4 4 3 1 2

13 13 9 3 1 3

40 40 27 9 3 1 4

(31-1)/2 30
(32-1)/2 31 30
22 21 20
(33-1)/2 32 31 30
23 22 21 20
(34-1)/2 33 32 31 30
31
Challenge met
And the fun just begins
32
MToH The Three Versions
B1. The Colored MToH B2. The Semi-Free MToH B3.
The Free MToH
33
B2. The Semi-Free MToH

• An MToH is Semi-Free if
• One of its posts say S, is permanently
  colored say Red
• Another post say D, is permanently and
  oppositely colored
• The third post I - is Free (has a Neutral
  color at the start of the algorithm)
• We need to move N disks from Post S to Post D
  using Post I

34
The Semi-Free MToH Number of Moves
SUM 8 7 6 5 4 3 2 1 k N
1 1 1
4 3 1 2
11 7 3 1 3
32 21 7 3 1 4
93 61 21 7 3 1 5
276 183 61 21 7 3 1 6
823 547 183 61 21 7 3 1 7
2464 1641 547 183 61 21 7 3 1 8
35
The Semi-Free MToH Duration Ratio
36
The Free MToH

• The 67 Algorithm
• The 62 Algorithm

37
The Free MToH video-clip 5 (243)
Click link to play a YouTube video 5.
http//www.youtube.com/watch?vbZtx5gexddI
38
MToH FREEDOM
It is (this) FREEDOM that makes the Magnetic
Tower of Hanoi Puzzle so COLORFUL
39
B3. The Free MToH The 67 Algorithm
40
The 67 Algorithm Number of Moves
3(N-1) N-1 SUM 8 7 6 5 4 3 2 1 k N
1 1 1 1
4 4 3 1 2
11 11 7 3 1 3
30 30 19 7 3 1 4
85 85 55 19 7 3 1 5
248 248 163 55 19 7 3 1 6
735 735 487 163 55 19 7 3 1 7
2194 2194 1459 487 163 55 19 7 3 1 8
41
The 67 Algorithm Duration Ratio
42
B3. The Free MToH The 62 Algorithm
43
The 62 Algorithm Number of Moves
SUM 8 7 6 5 4 3 2 1 k N
1 1 1
4 3 1 2
11 7 3 1 3
30 19 7 3 1 4
83 53 19 7 3 1 5
236 153 53 19 7 3 1 6
691 455 153 53 19 7 3 1 7
2050 1359 455 153 53 19 7 3 1 8
44
The 62 Algorithm Duration Ratio
45
SF 67 62 Duration Ratio
46
SF 67 62 Duration-Ratio Curves
47
The double-pan balance Puzzle
48
Effective (minimum of) weights for a balance
49
Minimum of weights - continue
27
9
3
1
50
Minimum of weights - continue
51
Elegance of the 67 Algorithm
52
The 67 Algorithm find a simple rule
SUM 8 7 6 5 4 3 2 1 k N
1 1 1
4 3 1 2
11 7 3 1 3
30 19 7 3 1 4
85 55 19 7 3 1 5
248 163 55 19 7 3 1 6
735 487 163 55 19 7 3 1 7
2194 1459 487 163 55 19 7 3 1 8
53
What about the total number of moves?
The Free 67 Magnetic Tower of Hanoi Total
number of moves
SUM N
1 1
4 2
11 3
30 4
85 5
54
Recursive Relations
55
Recursive Relations - 1
The 100 Algorithm
The 67 Algorithm
56
Recursive Relations - 2
The SF Algorithm
57
Recursive Relations - 3
The 62 Algorithm
58
Recursive Relations - 4
All without exception
59
Color Crossings
60
MToH Color Crossings - 1
61
MToH Internet Movie
A "movie" showing the "62" Algorithm solving a
height five MToH in (only) 83 moveshttp//www.nu
merit.com/maghanoi/
62
MToH Internet Movie
Shown in the movie solution of the height 5
MToH puzzle by (only) 83 moves
Click link to play a YouTube video 6.
http//www.youtube.com/watch?vsysN4-6zXNo
It is Freedom that makes the MToH so colorful.
63
MToH Color Crossings - 2
The 100 Algorithm NO color crossings
64
MToH Color Crossings - 3
The 62 Algorithm EIGHT color crossings
65
Next
66
Tower Theory Further Modifications

• Further expansions
• Puzzle-start setting
• Number of posts
• Disk" structure (may "quickly" lose its circ.
  symmetry)
• Move rules
• Puzzle-end state
• ? "Tower Field in Number Theory?

67
References
68
Gathering 4 Gardner 9 Atlanta, GA (March 10)
69
Gathering 4 Gardner 9 Atlanta, GA (March 10)
Game inventor Martin Gardner
70
Gathering 4 Gardner 9 mini-MToH
71
G4G9 - Handouts
72
References
1 "The Magnetic Tower of Hanoi", Uri
Levy, Journal of Recreational Mathematics
353, to be published (May 2010) 2 Paper
download http//arxiv.org/abs/1003.0225 3 "M
ovie (and paper download, different Abstract)
http//www.numerit.com/maghanoi 4 Contact
uri_at_vicsor.com
73
Cornell University Library
http//arxiv.org/abs/1003.0225
74
Realization
75
The Magnetic Tower of Hanoi Realization
76
The Colored Magnetic Tower of Hanoi
77
Free or Classical MToH
78
Oops!
79
Illegal Move!
80
One-Two-Three GO!
81

The End
