Lecture 5: Build-A-Cloud

1
Lecture 5 Build-A-Cloud

• http//www.cs.columbia.edu/sambits/

2
Life Cycle in a Cloud

• Build a image(s) for the software/application
  that we want to host on cloud (lecture 4)
• Request a VM pass appropriate parameters such
  as resource needs and image details (lecture 3)
• When the VM is started up, parameters are passed
  to it at appropriate run levels to auto-configure
  the software image (lecture 4)
• Now in this lecture
• Lets monitor the provisioned VM
• Manage it at run time
• As workload changes, make changes to the amount
  of requested resource

3
What we shall learn

• We shall put together a cloud piece by piece
• Open Nebula as the cluster manager
• KVM as the hypervisor for host machines
• Creating and managing guest VMs
• Creating Cluster Application(s) using VMs
• Application level management
• Interesting Sub-topics which we will touch
• Monitoring cluster and applications in such an
  environment
• Example application level management
• How to add on-demand resource scaling using Open
  Nebula and Ganglia

4
Cloud Setup

• Basic Management
• Image Management
• VM Monitoring Management
• Host Monitoring Management

private cloud client
Management Layer
Image Management
VM Management
Host Management
VN Management
Infrastructure Info
5
Our stack for the cloud

• Open Nebula for managing a set of host machines
  that have hypervisor on them
• KVM hypervisor on the host machines
• Ganglia for monitoring the guest VMs
• Glue code for implementing Application
  management e.g. resource scaling

6
OpenNebula Setup

• Install OpenNebula management node
• Download and compile the src on the mgmt-node
  (easy installation, install root as oneadmin)
• Setup sshd on all hosts which have to be added
  (also install ruby on them)
• Allow root of the mgmt-node to have password-less
  access to all the managed hosts
• Setup image repository (shared FS based setup is
  required for live migration)
• If you do not have linux-server (download
  VirtualBox) and create a linux VM on your laptop
• Open Nebula Architecture
• Tools written om top of OpenNebula interact with
  core via XML-RPC
• The core exposes VM, Host, Network management
  APIs
• Core stores all installation and monitoring
  information in SQLite3 (or MySQL) DB.
• Most of the DB information can be accessed using
  XML-RPC calls
• All the drivers are written in ruby as run as
  daemons, which in-turn call small shell-scripts
  to get the work-done.

7
Create a Cloud

• Start the one daemon
• Edit ONEHOME/etc/oned.conf for necessary changes
  (quite intuitive)
• Put loginpasswd in ONEHOME/etc/one_auth
• one start does that
• Keeps all the DB and logs in ONEHOME/var/
• NOTE if you want to do a fresh setup, simply
  stop oned and delete ONEHOME/var/ and again
  start the OpenNebula daemon
• Setup ssh on host machines (allow oneadmin as
  password-less entry)
• Concatenate the .ssh/id_rsa of admin-node on the
  host-servers .ssh/authorized_keys
• chmod 600 .ssh/authorized_keys
• Add hosts to OpenNebula
• Use command onehost
• Command is written in Ruby
• Command basically makes XMLRPC call to the
  OpenNebula servers HostAllocate call
• E.g.

8

• Configure network
• Fixed defines fixed set of IP-MAC pairs
• Ranged defines a class network
• e.g. fixed set network setting (assuming you have
  a set of static IP addresses allotted to you then
  how will you set it up).

Note good site for helphttp//www.opennebula.org
/documentationrel1.4vgg
9
How to access OpenNebula

• All API can be called using XML-RPC client
  libraries
• Nebula command line client (Ruby)
• Java Client

10
Setup Monitoring

• Requirements of Monitoring
• Need something which stores resource monitoring
  data as a time series
• Exposes interfaces for querying it and simple
  aggregation of data
• Automatically archives the older data
• How to achieve it?
• Install Ganglia !
• Tune the VM-images to automatically report their
  monitoring via ganglia
• Install gmond on host-servers
• What is Ganglia
• Its an open-source S/W (BSD License)
• Distributed monitoring of clusters and grids
• Stores time-series data and historical data as
  archives (RRDs)
• How to get Ganglia
• Download the source-code from (http//ganglia.info
  /downloads.php)
• For some Linux distributions, RPMs are available

11
Components of ganglia

• It has two prime daemons
• Gmond a multi-threaded daemon, which runs on
  monitored nodes
• Collects data on monitored notes and broadcasts
  the monitored data as XML (can be accessed at
  port 8649)
• Configuration script (/etc/gmond.conf)
• Gmetad
• periodically polls a collection of children
  data-sources
• parses the collected XML and saves all numeric
  metrics to round-robin databases
• exports the aggregated XML over a TCP socket to
  clients (8651)
• Configuration file /etc/gmetad.conf
• One for each cluster
• Round Robin Database
• RRDtool is a well known tool for creating and
  storing and retrieving/plotting RRD data
• Maintains data at various granularities e.g.
  defaults are
• 1-hour data averaged over 15-sec (rra0)
• 1-day data averaged over 6-min (rra1)
• 1-week-data averaged over 42-min (rra2)
• The web GUI tools
• These are a collection of PHP scripts started by
  the Webserver to extract the ganglia data and
  generate the graphs for the website
• Additional tools

Note good site for help http//www.ibm.com/devel
operworks/wikis/display/WikiPtype/ganglia
12
How to get monitoring-data?

• How to get the time-series data?
• Ganglia stores all RRDs in /var/lib/ganglia/rrds/
  cluster_name/machine_ip
• There is a rrd file for each metric
• Data is collected at a fixed time-interval
  (default is 15 sec )
• One ca retrieve the complete time series of
  monitored data using rrdtool from each rrd file
  e.g.
• Get average load_one for every 15 sec of the the
  last 1-hour
• rrdtool fetch load_one.rrd AVERAGE -end now
  -start e-1h -r 15

13
How to get monitoring-data?

• How to access this data from inside a program
• Either use sshlib (for perl, python or Java) and
  remotely execute the rrdtool command with correct
  parameters
• Write a small XML-RPC server which exposes a
  function to run rrdtool fetch queries.
• E.g. perl XML RPC server

use FrontierDaemon my d FrontierDaemon-gtn
ew( methods gt sum gt \sum,,
LocalAddr gt server_ip, LocalPort gt
server_port, debug gt 1, ) sub sum
my (auth, arg1, arg2) _at__ my bool
1 my (package, filename, line,
subroutine, hasargs, wantarray, evaltext,
is_require, hints, bitmask) caller(0)
log-gtinfo("subroutine - " . _1)
log-gtdebug("subroutine _at__")
log-gtdebug("subroutine - " . join("",_at__))
return SUCCESSgtbool, MESSAGEgtarg1 arg2
14
Create a Multi-tiered Clustered Application

• Lets us consider a two-tired TPC-W (web server
  and database performance benchmark)
• How to create an application on custom-images
• Create a 6-GB file using dd (utility for
  converting and copying files)
• Attach a loop-back device to it
• Format it like a file-system (say ext3)
• Partition it into 3(swap, boot and root)
• Install complete OS and application stack on the
  relevant partitions.
• Install gmond and configure it.
• Save it as a custom-image
• For TPC-W one will need,
• apache tomcat-server,
• java-implementation of TPC-W
• MySQL Server.
• We will need a load-balancer, which can route
  http-packets to various backend-servers (and also
  http-session aware)
• I am using HAProxy (easy to install and
  configure)
• Nginx, lighttpd are also other popular http-proxy
  servers.

15
Installing a multi-tier application
Client

• Install a two-tiered Application
• Create a template of load-balancer
• Create a template of TPCW
• Deploy the LB-VM (using OpenNebula)
• Deploy the TPCW-VM (using OpenNebula)
• Attach TPCW application VMs to LB-VM
• Test using Web-browser if setup is working
• Create a Client-template
• Deploy the client VM
• Test client

LoadBalancer
TPCW-0
TPCW-1
16
Application Level Operation

• One needs to maintain Application level
  information, for e.g. which VM is a load-balancer
  and which VMs are backend servers).
• Keep Application level knowledge in some local
  database.
• Application Level Operation e.g. Dynamic
  provisioning
• Case 1 increasing capacity using replication
• Monitor the average utilization of VMs over say
  1-min (using ganglia)
• If the average utilization of all the VMs under
  the load-balancer is above say 70
• provision a new VM using OpenNebula (reactive
  provisioning also supported by EC2)
• Run the post-install script to add the new VM to
  the application
• Case 2 increase capacity using
  migration/resizing
• Monitor the average utilization of VMs over say
  1-min (using ganglia)
• If only one-vm is over-utilized and the host does
  not have more resources
• migrate it to another host and re-size it to
  higher capacity (note nebula does not support it)
• Migrate-and-resize VM
• Migrate the image to another host
• Change the VM-configuration file to new
  configuration
• Start the VM with new configuration file (with
  more RAM and CPU)

17
Application Level Operations (e.g. Dynamic
Provisioning)

• Where and How to implement the application-scaling
  logic
• Application scaling logic needs knowledge of
  application topology
• It obviously resides above Infrastructure
  management layer (I.e. OpenNebula)
• Choose an easy to build language (Perl, Python,
  Ruby, Java etc).
• XML-RPC client is required to make access to
  OpenNebula
• Write a management program using language of your
  choice which
• Installs a multi-tier Application and stores
  application topology in local DB
• Periodically monitors
• average load on each server
• Proxy errors
• Implement case-1 and case-2
• Post-install script is adding the VM to the
  load-balancer and restarting it.
• Problem live-resize or migrate-and-resize are
  not present in OpenNebula
• Hack create a script which does the following
  (very dirty but it works)
• Migrate the current VM to destination host
• Alter the configuration file of this migrate VM
• Destroy and recreate the VM.
• Neater solution
• Add a class in include/RequestManager.h (say
  VirtualMachineResize similar to that of class
  VirtualMachineMigrate)

18
Solution Architecture

• Application Manager (written above OpenNebula)
  The high level control flow is
• Periodically monitor the workload-change and
  Application performance
• Manage the current configuration and actuate
  configuration change
• Calculate the changed capacity (using some model
  and feedback from monitoring block)
• Find the new configuration of application
• Go ahead and start the process of actuating the
  new change

19
How to use (demo!)

• Command line scripts
• VM Lifecycle steps
• Creation show template and image-naming
• Suspension just the command
• Migration migration (suspend and migrate)
• Deletion removing the image
• Show ganglia monitoring
• Host monitoring through VM-lifecycle
• VM monitoring

20
Cloud Management using this Setup

• Integrate Nebula monitoring with ganglia and make
  it more efficient
• Use monitoring for VM placement on hosts.
• Use monitoring to do reactive provisioning
