SOS8

1
Big and Not so Big Iron at SNL
2
SNL CS RD AccomplishmentPathfinder for MPP
Supercomputing

• Sandia successfully led the DOE/DP revolution
  into MPP supercomputing through CS RD
• nCUBE-10
• nCUBE-2
• IPSC-860
• Intel Paragon
• ASCI Red
• Cplant
• and gave DOE a strong, scalable parallel
  platforms effort

Computing at SNL is an Applications
success (i.e., uniquely-high scalability
reliability among FFRDCs) because CS RD
paved the way
Cplant
Note There was considerable skepticism in the
community that MPP computing would be a success
3
Our Approach

• Large systems with a few processors per node
• Message passing paradigm
• Balanced architecture
• Efficient systems software
• Critical advances in parallel algorithms
• Real engineering applications
• Vertically integrated technology base
• Emphasis on scalability reliability in all
  aspects

4
A Scalable Computing Architecture
5
ASCI Red

• 4,576 compute nodes
• 9,472 Pentium II processors
• 800 MB/sec bi-directional interconnect
• 3.21 Peak TFlops
• 2.34 TFlops on Linpack
• 74 of peak
• 9632 Processors
• TOS on Service Nodes
• Cougar LWK on Compute Nodes
• 1.0 GB/sec Parallel File System

6
Computational Plant

• Antarctica - 2,376 Nodes
• Antarctica has 4 heads with a switchable
  center section
• Unclassified Restricted Network
• Unclassified Open Network
• Classified Network
• Compaq (HP) DS10L Slates
• 466MHz EV6, 1GB RAM
• 600Mhz EV67, 1GB RAM
• Re-deployed Siberia XP1000 Nodes
• 500Mhz EV6, 256MB RAM
• Myrinet
• 3D Mesh Topology
• 33MHz 64bit
• A mix of 1,280 and 2,000 Mbit/sec technology
• LANai 7.x and 9.x

• Runtime Software
• Yod - Application loader
• Pct - Compute node process control
• Bebopd - Allocation
• OpenPBS - Batch scheduling
• Portals Message Passing API
• Red Hat Linux 7.2 w/2.4.x Kernel
• Compaq (HP) Fortran, C, C
• MPICH over Portals

7
Institutional Computing Clusters

• Two (classified/unclassified), 256 Node Clusters
  in NM
• 236 compute nodes
• Dual 3.06GHz Xeon processors, 2GB memory
• Myricom Myrinet PCI NIC (XP, REV D, 2MB)
• 2 Admin nodes
• 4 Login nodes
• 2 MetaData Server (NDS) nodes
• 12 Object Store Target (OST) nodes
• 256 port Myrinet Switch
• 128 node (unclassified) and a 64 Node
  (classified) Clusters in CA

• Compute nodes
• RedHat Linux 7.3
• Application Directory
• MKL math library
• TotalView client
• VampirTrace client
• MPICH-GM
• OpenPBS client
• PVFS client
• Myrinet GM

• Login nodes
• RedHat Linux 7.3
• Kerberos
• Intel Compilers
• C, C
• Fortran
• Open Source Compilers
• Gcc
• Java
• TotalView
• VampirTrace
• Myrinet GM

• Administrative Nodes
• Red Hat Linux 7.3
• OpenPBS
• Myrinet GM w/Mapper
• SystemImager
• Ganglia
• Mon
• CAP
• Tripwire

8
Usage
9
Red Squall Development Cluster

• Hewlett Packard Collaboration
• Integration, Testing, System SW support
• Lustre and Quadrics Expertise
• RackSaver BladeRack Nodes
• High Density Compute Server Architecture
• 66 Nodes (132 processors) per Rack
• 2.0GHz AMD Opteron
• Same as Red Storm but w/commercial Tyan
  motherboards
• 2 Gbytes of main memory per node (same as RS)
• Quadrics QsNetII (Elan4) Interconnect
• Best in Class (commercial cluster interconnect)
  Performance
• I/O subsystem uses DDN S2A8500 Couplets with
  Fiber Channel Disk Drives (same as Red Storm)
• Best in Class Performance
• Located in the new JCEL facility

10
(No Transcript)
11
Red Storm Goals

• Balanced System Performance - CPU, Memory,
  Interconnect, and I/O.
• Usability - Functionality of hardware and
  software meets needs of users for
• Massively Parallel Computing.
• Scalability - System Hardware and Software scale,
  single cabinet system to
• 20,000 processor system.
• Reliability - Machine stays up long enough
  between interrupts to make real
• progress on completing application run (at least
  50 hours MTBI), requires full
• system RAS capability.
• Upgradability - System can be upgraded with a
  processor swap and additional
• cabinets to 100T or greater.
• Red/Black Switching - Capability to switch major
  portions of the machine
• between classified and unclassified computing
  environments.
• Space, Power, Cooling - High density, low power
  system.
• Price/Performance - Excellent performance per
  dollar, use high volume
• commodity parts where feasible.

12
Red Storm Architecture

• True MPP, designed to be a single system.
• Distributed memory MIMD parallel supercomputer.
• Fully connected 3-D mesh interconnect. Each
  compute node and service and I/O node processor
  has a high bandwidth, bi-directional connection
  to the primary communication network.
• 108 compute node cabinets and 10,368 compute node
  processors.
• (AMD Opteron _at_ 2.0 GHz)
• 10 TB of DDR memory _at_ 333 MHz
• Red/Black switching - 1/4, 1/2, 1/4.
• 8 Service and I/O cabinets on each end (256
  processors for each color).
• 240 TB of disk storage (120 TB per color).
• Functional hardware partitioning - service and
  I/O nodes, compute nodes, and RAS nodes.
• Partitioned Operating System (OS) - LINUX on
  service and I/O nodes, LWK (Catamount) on compute
  nodes, stripped down LINUX on RAS nodes.
• Separate RAS and system management network
  (Ethernet).
• Router table based routing in the interconnect.
• Less than 2 MW total power and cooling.
• Less than 3,000 square feet of floor space.

13
Red Storm Layout

• Less than 2 MW total power and cooling.
• Less than 3,000 square feet of floor space.
• Separate RAS and system management network
  (Ethernet).

• 3D Mesh 27 x 16 x 24 (x, y, z)
• Red/Black split 2688 4992 2688
• Service I/O 2 x 8 x 16

14
Red Storm Cabinet Layout

• Compute Node Cabinet
• 3 Card Cages per Cabinet
• 8 Boards per Card Cage
• 4 Processors per Board
• 4 NIC/Router Chips per Board
• N1 Power Supplies
• Passive Backplane
• Service and I/O Node Cabinet
• 2 Card Cages per Cabinet
• 8 Boards per Card Cage
• 2 Processors per Board
• 2 NIC/Router Chips per Board
• PCI-X for each Processor
• N1 Power Supplies
• Passive Backplane

15
Red Storm Software

• Operating Systems
• LINUX on service and I/O nodes
• LWK (Catamount) on compute nodes
• LINUX on RAS nodes
• File Systems
• Parallel File System - Lustre (PVFS)
• Unix File System - Lustre (NFS)
• Run-Time System
• Logarithmic loader
• Node allocator
• Batch system - PBS
• Libraries - MPI, I/O, Math

• Programming Model
• Message Passing
• Support for Heterogeneous Applications
• Tools
• ANSI Standard Compilers - Fortran, C, C
• Debugger - TotalView
• Performance Monitor
• System Management and Administration
• Accounting
• RAS GUI Interface
• Single System View

16
Red Storm Performance

• Based on application code testing on production
  AMD Opteron processors we are now expecting that
  Red Storm will deliver around 10 X performance
  improvement over ASCI Red on Sandias suite of
  application codes.
• Expected MP-Linpack performance - 30 TF.
• Processors
• 2.0 GHz AMD Opteron (Sledgehammer)
• Integrated dual DDR memory controllers _at_ 333 MHz
• Page miss latency to local processor memory is
  80 nano-seconds.
• Peak bandwidth of 5.3 GB/s for each processor.
• Integrated 3 Hyper Transport Interfaces _at_ 3.2
  GB/s each direction
• Interconnect performance
• Latency lt2 µs (neighbor) lt5 µs (full machine)
• Peak Link bandwidth 3.84 GB/s each direction
• Bi-section bandwidth 2.95 TB/s Y-Z, 4.98 TB/s
  X-Z, 6.64 TB/s X-Y
• I/O system performance
• Sustained file system bandwidth of 50 GB/s for
  each color.
• Sustained external network bandwidth of 25 GB/s
  for each color.

17
HPC RD Efforts at SNL

• Advanced Architectures
• Next Generation Processor Interconnect
  Technologies
• Simulation and Modeling of Algorithm Performance
• Message Passing
• Portals
• Application characterization of message passing
  patterns
• Light Weight Kernels
• Project to design a next-generation lightweight
  kernel (LWK) for compute nodes of a distributed
  memory massively parallel system
• Assess the performance, scalability, and
  reliability of a lightweight kernel versus a
  traditional monolithic kernel
• Investigate efficient methods of supporting
  dynamic operating system services
• Light Weight File System
• only critical I/O functionality (storage,
  metadata mgmt, security)
• special functionality implemented in I/O
  libraries (above LWFS)
• Light Weight OS
• Linux configuration to eliminate the need of a
  remote /root
• Trimming the kernel to eliminate unwanted and
  unnecessary daemons
• Cluster Management Tools
• Diskless Cluster Strategies and Techniques
• Operating Systems Distribution and Initialization

18
More Information

• Computation, Computers, Information and
  Mathematics Center
• http//www.cs.sandia.gov
