Exploiting Instruction Streams To Prevent Intrusion

1
Exploiting Instruction StreamsTo Prevent
Intrusion

• Milena Milenkovic

2
Outline

• Introduction
• Related Work
• Trusted Instruction Execution Framework
• The Framework Potential
• Conclusion

3
Introduction

• Most of todays computers connected to Internet,

• Even more in the future, including embedded
  devices
• One of the major security problems the
  execution of the unauthorized code
• A lot of applications may be vulnerable
• Attack examples
• buffer overflow (heap, stack)
• format string attack

4
Introduction

• Stack-smashing

5
Introduction

• One solution allow only execution of trusted
  instructions
• Trusted instructions with a valid signature
• Previous researchlimited number of instruction
  streams(dynamic basic blocks)
• Use basic block signaturesrun-time verification
  of the last basic block in an instruction stream
• Signatures calculated during trusted
  installation

6
Related Work

• Two categories
• Static source code analysis
• Dynamic detection/prevention
• Static code analysis false alarms
• Dynamic
• Secure Program Execution Framework (SPEF)
• Tag spurious data
• Monitoring program behavior (system calls,
  performance monitoring registers)
• Split stack for data/addresses, or secure stack
• Compilers, compiler and library patches

7
Related Work

• Most related SPEF a given program binary has
  numerous representations with the same
  functionality
• During installation, each instruction block is
  transformed verified in the run-time
• compute transformation-invariant hash of the
  instruction block
• encrypt the hash value with the secret key
• use encrypted value to select a transformation
  (e.g., a particular instruction order in case
  of instruction scheduling)
• 7.5-17.1 increased execution time, Mediabench
• Also related tamper-proof techniques, but
  different granularity

8
Trusted Instruction Execution

• Requirements
• prevent the execution of unauthorized code
• the security features should not significantly
  increase the program execution time
• This project proposes a framework that
  satisfies requirements

9
Trusted Instruction Execution

• Atomic code unit protected by its signature a
  basic block
• Verify all basic blocks?
• It is enough to verify the signatureof the last
  basic block (LBB) in the instruction stream,
  when LBB generated a cache miss
• Signatures on hard disk encrypted

10
Architecture for Trusted Computing
BBST Basic Block Signature Table BBST_M
Basic Block Signature Table (Memory) BBSVU
Basic Block Signature Verification Unit
L1D
MMU
Datapath
L1I
FPUs
IF
BBST
Control
BBSVU
11
Signature Generation

• MISR (Multiple input signature register)
• Linear feedback coefficients based on the
  processor secret key

12
Phases of the Security Mechanism

• Compilation and program installation
• Signature table (BBST_M) is generated, encrypted
  and appended to the program binary
• Program loading in the memory
• BBST_M is decrypted, loaded in the memory
• Program execution
• Signature of each last basic block with cache
  miss is verified
• If no match, generate trap to OS kill process

13
Program Execution
14
The Framework Potential

• 32-bit MISR
• I-cache 4 ways, 128 sets, 64B line
• BBST 4 ways, 4B line, 128/256 sets
• LRU replacement
• Traces of SPEC CPU2000 benchmarks for Alpha
  architecture
• F2B, M2B segments
• 10 integer (CINT), 11 floating-point benchmarks
  (CFP)

15
The Framework Potential
16
The Framework Potential
17
The Framework Potential
18
The Framework Potential

• Also measured
• the number of instruction cache misses
• the number of BBST accesses
• The number of BBST misses very small
• Trusted instruction overheadwill not
  significantly hurt performance

19
Conclusion

• Proposed a framework for trusted instruction
  execution,evaluated potential
• Promises to be faster than SPEF, with additional
  hardware resources and BBST appended to program
  binary
• Future work
• asses different BBST organizations
• preload BBST?
• simulate execution time
• evaluate an alternative implementationsignature
  embedded in the code
