Thesis Lighting Design Proposal

1
Thesis Lighting Design Proposal
Hall Corporate Headquarters
Dan Rusnack 12/9/03 Lighting/Electrical
option Senior Thesis project
2
Hall Corporate Headquarters

• Location
• Virginia Beach, Virginia
• Occupant
• Hall Automotive Car Dealership
• Architects Engineers
• Clark Nexsen
• Contractor
• Commonwealth Construction
• Building size
• 30,000 Sq. Ft. , 3 stories

N
Foot print
North elevation
3
The Spaces to Redesign

• Training Room
• - First floor
• Conference Room
• - Third floor
• Board Room
• - Second Floor
• Lobby
• - Entrance to building
• Exterior Facade
• Walkway and front of building and roof

4
Introduction to the Space

• Training Room
• Large workspace located on the first floor
• Employee training and meeting area with 34 desk
  workstations
• Speaker area and white board located in front of
  room for presentations
• Room Characteristics
• Ceiling is 2x2 acoustical tile, Ref 0.8
• Walls are a light beige color, Ref 0.52
• Carpet is a a north sea color, Ref 0.25
• Ceiling height is 8-6

5
Training RoomCurrent Lighting Design
The A and B show the two switching options in the
room
6
The Training Room

• Design Criteria
• Integration of daylight
• Large windows located on west and south walls
• Use of motorized shading to control amount of
  daylight entering space
• Facial rendering
• Meeting place for employees
• Horizontal illuminance
• 30 Fc on work plane

7
The Training Room

• Direct glare from fixtures
• Keep in compliance with luminance ratios
• Luminance ratios
• 31 between task and adjacent dark surroundings
• 101 between task and nonadjacent dark
  surroundings
• Light distribution
• Uniform distribution on work plane

8
Lighting Concept

• Light ceiling to open up space
• Lighting system that will integrate well with
  natural daylight
• Multiple levels of light achieved with dimming
  controls
• Create uniform distribution of light on work
  plane
• Provide proper light levels on work plane for
  writing and reading tasks

9
Possible Concept Solutions

• Recessed system
• Create layout with coverage for entire space
  where work stations will be located
• Indirect system
• Provide a uniform level of light on work space by
  use of pendant fixtures
• Ceiling height in the space may need to raised
  for this lighting system to work
• Additional light
• Front of room will have a speaker area with white
  board
• Downlights to be used to add appropriate light
  needed in this area
• Wall sconces used above cabinet area for
  decorative purposes

10
Possible Fixtures
Downlight
Indirect fixture
Sconces
11
Visualization of Concept
Downlights
Indirect fixtures
Sconces
Hand sketch of northward view into training room
12
Introduction to the Space

• Conference Room
• Group conference/meeting area located on the
  third floor
• Triangle shape space with curved glass exterior
  wall
• Glass walls separate room from open office space
• Oval shaped table in center of room with 8 chairs
• Room Characteristics
• Ceiling is 2x2 acoustical tile and plaster, Ref
  0.8
• Walls are a light beige color, Ref 0.52
• Carpet is a gray steel color, Ref 0.25
• Ceiling height is 9

13
The Conference Room

• Design Criteria
• Integration of daylight
• Large windows located on southwest wall
• Use of motorized shading to control amount of
  daylight entering space
• Facial rendering
• Close interaction between occupants, facial
  rendering is of high importance
• Horizontal illuminance
• 40-50 Fc on the conference table

14
The Conference Room

• Direct glare from fixtures
• Keep in compliance with luminance ratios
• Luminance ratios
• Luminances within immediate view should not
  exceed 31 from persons face to the background
• Ratio is very important because of the facial
  rendering of the occupants
• Ceiling uniformity
• Ratio of 81 for uniformity of light on the
  ceiling not to exceed 825 Cd/m2 if less then 425
  Cd/m2 the uniformity is not such an issue

15
The Conference RoomCurrent Lighting Design
Open Office area
Lighting layout in conference room, curved wall
faces southwest
16
Lighting Concept

• Add oval shaped cove to ceiling, use cove lights
  to make space more unique
• Pendant fixture from cove to give light on work
  plane
• Emphasize curve shape of room with round light
  fixtures
• Provide proper light levels on table and peoples
  faces
• Lighting system that will provide multiple scenes
  for different tasks in the space by dimming
  controls

17
Possible Concept Solutions

• Track fixtures
• Directed towards individual seats around table
• Provides key light on peoples faces
• CFL Downlights
• Located around room to give ambient light to
  space
• Oval shaped cove added to ceiling
• Use of cove fixtures to light ceiling above table
• Pendant with direct and indirect light component
• Provide light on table and ceiling for good
  uniform distribution
• Indirect light produces good uniform distribution
  for facial rendering

18
Possible Fixtures
Indirect / Direct Pendant
Track light
Downlight
Cove light
19
Visualization of Concept
Cove lights
Track lights
Downlights
Hand sketch of conference room looking southwest
20
Introduction to the Space

• The Board Room
• Located on second floor used for large board
  meetings
• Table located in center of room surrounded by
  chairs
• Projection screen and white board in front of
  room
• Room Characteristics
• Ceiling is 2x2 acoustical tile in center of
  room with plaster section around perimeter, Ref
  0.8
• Walls are a light beige color, Ref 0.52
• Carpet is a gray steel color, Ref 0.25
• Ceiling height is 9

21
The Board Room

• Design Criteria
• Integration of daylight
• Large amount of windows located on north and east
  walls
• Use of motorized shading to control amount of
  daylight entering space
• Video Conferencing
• Multi levels of light controlled by dimming
  switches
• Facial rendering is of high importance
• Close interaction between occupants
• Luminance ratios between faces and background 31

• Horizontal illuminance
• 40-50 Fc on the conference table

22
The Board Room

• Direct glare from fixtures
• Keep in compliance with luminance ratios
• Luminance ratios
• Luminances within immediate view should not
  exceed 31 from persons face to the background
• Ratio is very important because of the facial
  rendering of the occupants
• Ceiling uniformity
• Ratio of 81 for uniformity of light on the
  ceiling not to exceed 825 Cd/m2 if less then 425
  Cd/m2 the uniformity is not such an issue

23
The Board Room Current Lighting Design
Windows on north and east facing walls
24
Lighting Concept

• Add rectangular cove to ceiling, use of cove
  lights to make space more unique
• Pendant fixtures from cove to give additional
  light on work plane
• Provide proper light level on table and peoples
  faces for good facing rendering
• Lighting system that will provide multiple scenes
  for different tasks in the space by dimming
  controls

25
Possible Concept Solutions

• Downlights
• Compact fluorescent lamps Located around room to
  give ambient light to space
• Wallwash lenses used in downlights in front of
  room
• Cove added to ceiling
• Use of cove fixtures to light ceiling above table
• Pendant with direct and indirect light component
• Provide light on table and ceiling for good
  uniform distribution
• One linear pendant or multiple round pendants
• Indirect light is good for facial rendering

26
Possible Fixtures
Direct/Indirect Pendants
Cove lights
Downlight
27
Visualization of Concept
Cove lights
Downlights
Pendants
Hand sketch of view looking into board room north
east windows
28
Introduction to the Space

• Lobby
• Large open space as you enter building
• Reception desk located directly to back of lobby
• 2 car show room located in the lobby
• Open to second floor with 23 ceiling
• Large curved stairwell to second floor
• Room Characteristics
• Floor has Beige and Black color tile, Ref 0.32
• Walls are a light beige color, Ref 0.52
• Ceiling is 2x2 acoustical tile with plaster,
  Ref 0.8

29
The Lobby

• Design Criteria
• Integration of day light
• Large windows located on southwest wall
• Use of motorized shading to control amount of
  light entering space
• Appearance
• Welcoming space to the building, lighting should
  set a standard for the rest of the building
• Points of interest
• Reception desk located to the rear of the lobby
  should be lit to attract attention of visitors
  and clients
• Cars located in lobby will be lit brightly to
  show off their paint well
• Horizontal illuminance
• 10 Fc for lobby area
• 30 Fc for reception area
• 20-30 Fc on the cars

30
The Lobby Current Lighting Design
Reception Desk
Staircase
Main entrance lower left, Reception desk upper
right corner
31
Lighting Concept

• Draw attention to the reception area in rear of
  lobby
• - Create movement through lobby
• Light cars so paint looks flawless and shinny
• Draw attention to second floor and high ceiling
• - Emphasize large open space
• Light staircase steps and railing
• - Create movement to second floor
• Choose fixtures that resemble car like shapes
• - Round headlights and wheels, curved shaped
  frame
• Create bright welcoming feel to the space

32
Possible Concept Solutions

• General downlights throughout space
• Reflected light onto cars as to light entire car
• Addition of spot lights directed on the cars to
  add shine to certain areas of cars
• MR-16 downlights above desk of reception area
• Cold cathode lamp running along staircase wall
• Wall sconces for decorative ambient light
  throughout space

33
Possible Fixtures
Downlight
Sconces
Cold cathode
MR-16
Mirror reflected light fixtures
34
Visualization of Concept
Downlights
Sconces
Mirror reflected light fixture
Reception
Cold cathode
Hand sketch of lobby as you enter the building
35
Visualization of Concept
Cold Cathode
MR-16
Downlights
Hand sketch of reception desk to the rear of the
lobby
36
Introduction to the Space

• Exterior Façade
• Front façade of building is an L shape
• with walkway leading the center
• Façade is constructed of field brick with metal
  trim around windows and along the edge of the
  roof
• Walkway to building is also brick with concrete
  accents
• Circular architectural feature atop building to
  hide mech. Equip.
• Curved glass wall extending from second to third
  floor
• Walkway to entrance has no light on it in
  existing system

37
The Exterior Facade

• Design Criteria
• Appearance
• Accent architectural features, building should
  look prominent compared to dark background
• Luminance ratio
• Ratio of 201 between building and/or surrounding
  neighboring sites
• Points of interest
• The main entrance door and canopy over the door
• Circular architectural feature atop of roof
• Walkway leading to building
• Light pollution
• Stay in accordance with local and state laws
  about light pollution onto adjacent properties
• Vertical illuminance
• 5 10 FC average on façade

38
Lighting Concept

• Wallwash façade to make building glow
• Have lights in conference room and lobby left on
  at night as to light up glass above canopy
• Light walkway leading towards entrance to create
  a direction of motion towards building
• Emphasize circular roof top architectural feature
  with floodlight

39
Possible Concept Solutions

• Wallwash of front façade with metal halide lamps
• Downlights under entrance canopy to light
  entrance doors
• Bollards leading down walkway
• Wallwash of circular roof top structure with
  metal halide lamps
• Exterior wall sconces spaced around the
  surrounding perimeter of the building

40
Possible Fixtures
Flood lamp for wallwash
Downlight
Wall sconce
Flood lamp for roof top structure
Bollard for walkway
41
Visualization of Concept
Flood lights
Lights from interior
Flood lights
Wall sconces
Downlights
Exterior north elevation façade
42
Visualization of Concept
Floodlights
Bollards
Wall Sconces
Building Footprint
43
Conclusions

• Make spaces easy to work in with proper light
  levels on work plane
• Create comfortable and welcoming feeling
  throughout building
• Integration of daylight into all spaces because
  of large amount of glazing in building
• Use of multiple fixtures with dimming
  capabilities in spaces to allow the occupant to
  get desired light level they like
• Use of similar fixtures in all rooms for
  uniformity in systems
• Use lighting systems that are energy efficient

44
The End

• Comments ?
• Questions ?
