Physics 111: Mechanics Lecture 14

1
Physics 111 Mechanics Lecture 14

• Dale Gary
• NJIT Physics Department

2
Life after Phys 111

• The course material of Phys 111 has given you a
  taste of a wide range of topics which are
  available to you as a student. Prerequisite is
  Phys 121 or Phys 121H.
• For those of you who have an interest in
  gravitation/astronomy, I suggest the following
  electives
• Phys 320, 321 Astronomy and Astrophysics I and
  II
• Phys 322 Observational Astronomy
• For those of you interested in the biological or
  BME/medical aspects, I suggest the following
  electives
• Phys 350 Biophysics I, Phys 451 - Biophysics II
• For those of your interested in light, optics,
  and photonics, I suggest the following elective
  which Federici will be teaching this fall and
  Fall 2014
• OPSE 301 Introduction to Optical Science and
  Engineering

3
Oscillatory Motion

• Periodic motion
• Spring-mass system
• Differential equation of motion
• Simple Harmonic Motion (SHM)
• Energy of SHM
• Pendulum
• Torsional Pendulum

4
Periodic Motion

• Periodic motion is a motion that regularly
  returns to a given position after a fixed time
  interval.
• A particular type of periodic motion is simple
  harmonic motion, which arises when the force
  acting on an object is proportional to the
  position of the object about some equilibrium
  position.
• The motion of an object
• connected to a spring is a
• good example.

5
Recall Hookes Law

• Hookes Law states Fs -kx
• Fs is the restoring force.
• It is always directed toward the equilibrium
  position.
• Therefore, it is always opposite the displacement
  from equilibrium.
• k is the force (spring) constant.
• x is the displacement.
• What is the restoring force for a surface water
  wave?

6
Restoring Force and the Spring Mass System

• In a, the block is displaced to the right of x
  0.
• The position is positive.
• The restoring force is directed to
• the left (negative).
• In b, the block is at the equilibrium
  position.
• x 0
• The spring is neither stretched nor compressed.
• The force is 0.
• In c, the block is displaced to the left of x
  0.
• The position is negative.
• The restoring force is directed to
• the right (positive).

7
Differential Equation of Motion

• Using F ma for the spring, we have
• But recall that acceleration is the second
  derivative of the position
• So this simple force equation is an example of a
  differential equation,
• An object moves in simple harmonic motion
  whenever its acceleration is proportional to its
  position and has the opposite sign to the
  displacement from equilibrium.

8
Acceleration

• Note that the acceleration is NOT constant,
  unlike our earlier kinematic equations.
• If the block is released from some position x
  A, then the initial acceleration is kA/m, but
  as it passes through 0 the acceleration falls to
  zero.
• It only continues past its equilibrium point
  because it now has momentum (and kinetic energy)
  that carries it on past x 0.
• The block continues to x A, where its
  acceleration then becomes kA/m.

9
Analysis Model, Simple Harmonic Motion

• What are the units of k/m, in
  ?
• They are 1/s2, which we can regard as a
  frequency-squared, so lets write it as
• Then the equation becomes
• A typical way to solve such a differential
  equation is to simply search for a function that
  satisfies the requirement, in this case, that its
  second derivative yields the negative of itself!
  The sine and cosine functions meet these
  requirements.

10
SHM Graphical Representation

• A solution to the differential
• equation is
• A, w, f are all constants
• A amplitude (maximum position
• in either positive or negative x direction,
• w angular frequency,
• f phase constant, or initial phase angle.
• A and f are determined by initial conditions.

Remember, the period and frequency are
11
Motion Equations for SHM
The velocity is 90o out of phase with the
displacement and the acceleration is 180o out of
phase with the displacement.
12
SHM Example 1

• Initial conditions at t 0 are
• x (0) A
• v (0) 0
• This means f 0
• The acceleration reaches extremes
• of w2A at A.
• The velocity reaches extremes of
• wA at x 0.

13
SHM Example 2

• Initial conditions at t 0 are
• x (0) 0
• v (0) vi
• This means f - p / 2
• The graph is shifted one-quarter
• cycle to the right compared to the
• graph of x (0) A.

14
Consider the Energy of SHM Oscillator

• The spring force is a conservative force, so in a
  frictionless system the energy is constant
• Kinetic energy, as usual, is
• The spring potential energy, as usual, is
• Then the total energy is just

15
Transfer of Energy of SHM

• The total energy is contant at all times, and is
  (proportional to the square of
  the amplitude)
• Energy is continuously being transferred between
  potential energy stored in the spring, and the
  kinetic energy of the block.

16
Simple Pendulum

• The forces acting on the bob are the tension and
  the weight.
• T is the force exerted by the string
• mg is the gravitational force
• The tangential component of the gravitational
  force is the restoring force.
• Recall that the tangential acceleration is
• This gives another differential equation

17
Frequency of Simple Pendulum

• The equation for q is the same form as for the
  spring, with solution
• where now the angular frequency is
• Summary the period and frequency of a simple
  pendulum depend only on the length of the string
  and the acceleration due to gravity. The period
  is independent of mass.

18
Torsional Pendulum

• Assume a rigid object is suspended from a wire
  attached at its top to a fixed support.
• The twisted wire exerts a restoring torque on
  the object that is proportional to its angular
  position.
• The restoring torque is t -k q?
• k is the torsion constant of the support wire.
• Newtons Second Law gives

Section 15.5
