SIMD, Associative, and Multi-Associative Computing

1
SIMD, Associative, and Multi-Associative
Computing

• Computational Models and Algorithms

2
Associative Computing Topics

• Introduction
• References for Associative Computing
• Motivation for the MASC model
• The MASC and ASC Models
• A Language Designed for the ASC Model
• Two ASC Algorithms and Programs
• ASC and MASC Algorithm Examples
• ASC version of Prims MST Algorithm
• ASC version of QUICKHULL
• MASC version of QUICKHULL.

3
Associative Computing References

• Note Below KSU papers are available on the
  website http//www.cs.kent.edu/parallel/
• (Click on the link to papers)
• Maher Atwah, Johnnie Baker, and Selim Akl, An
  Associative Implementation of Classical Convex
  Hull Algorithms, Proc of the IASTED International
  Conference on Parallel and Distributed Computing
  and Systems, 1996, 435-438
• Johnnie Baker and Mingxian Jin, Simulation of
  Enhanced Meshes with MASC, a MSIMD Model, Proc.
  of the Eleventh IASTED International Conference
  on Parallel and Distributed Computing and
  Systems, Nov. 1999, 511-516.

4
Associative Computing References

• Mingxian Jin, Johnnie Baker, and Kenneth Batcher,
  Timings for Associative Operations on the MASC
  Model, Proc. of the 15th International Parallel
  and Distributed Processing Symposium, (Workshop
  on Massively Parallel Processing, San Francisco,
  April 2001.
• Jerry Potter, Johnnie Baker, Stephen Scott,
  Arvind Bansal, Chokchai Leangsuksun, and Chandra
  Asthagiri, An Associative Computing Paradigm,
  Special Issue on Associative Processing, IEEE
  Computer, 27(11)19-25, Nov. 1994. (Note MASC
  is called ASC in this article.)
• First reading assignment
• Jerry Potter, Associative Computing - A
  Programming Paradigm for Massively Parallel
  Computers, Plenum Publishing Company, 1992.

5
Associative Computers

• Associative Computer A SIMD computer with a few
  additional features supported in hardware.
• These additional features can be supported (less
  efficiently) in traditional SIMDs in software.
• The name associative is due to its ability to
  locate items in the memory of PEs by content
  rather than location.

6
Associative Models

• The ASC model (for ASsociative Computing) gives a
  list of the properties assumed for an associative
  computer.
• The MASC (for Multiple ASC) Model
• Supports multiple SIMD (or MSIMD) computation.
• Allows model to have more than one Instruction
  Stream (IS)
• The IS corresponds to the control unit of a SIMD.
• ASC is the MASC model with only one IS.
• The one IS version of the MASC model is
  sufficiently important to have its own name.

7
ASC MASC are KSU Models

• Several professors and their graduate students at
  Kent State University have worked on models
• The STARAN and the ASPRO fully support the ASC
  model in hardware. The MPP can easily support ASC
  but not in hardware.
• Prof. Batcher was chief architect or consultant
• Dr. Potter developed a language for ASC
• Dr. Baker works on algorithms for models and
  architectures to support models
• Dr. Walker and his students have investigated a
  hardware design to support the ASC and MASC
  models.
• Dr. Batcher and Dr. Potter are currently not
  actively working on ASC/MASC models but still
  provide advice.

8
Motivation

• The STARAN Computer (Goodyear Aerospace, early
  1970s) and later the ASPRO provided the
  motivation for the ASC model.
• ASC extends the data parallel programming style
  to a complete computational model.
• ASC provides a practical model that supports
  massive parallelism.
• MASC provides a hybrid data-parallel, control
  parallel model that supports associative
  programming.
• Descriptions of these models allow them to be
  compared to other parallel models

9
The ASC Model
C
Cells
E
PE
Memory
L
L






IS
N

E


PE
Memory
T
W
O
R
PE
Memory
K
10
Basic Properties of ASC

• Instruction Stream
• The IS has a copy of the program and can
  broadcast instructions to cells in unit time
• Cell Properties
• Each cell consists of a PE and its local memory
• All cells listen to the IS
• A cell can be active, inactive, or idle
• Inactive cells listens to but does not execute IS
  commands until reactivated
• Idle cells contain no essential data and are
  available for reassignment
• Active cells execute IS commands synchronously

11
Basic Properties of ASC

• Responder Processing
• The IS can detect if a data test is satisfied by
  any of its responder cells in constant time
  (i.e., any-responders property).
• The IS can select an arbitrary responder in
  constant time (i.e., pick-one property).

12
Basic Properties of ASC

• Constant Time Global Operations (across PEs)
• Logical OR and AND of binary values
• Maximum and minimum of numbers
• Associative searches
• Communications
• There are at least two real or virtual networks
• PE communications (or cell) network
• IS broadcast/reduction network (which could be
  implemented as two separate networks)

13
Basic Properties of ASC

• The PE communications network is normally
  supported by an interconnection network
• E.g., a 2D mesh
• The broadcast/reduction network(s) are normally
  supported by a broadcast and a reduction network
  (sometimes combined).
• See posted paper by Jin, Baker, Batcher (listed
  in associative references)
• Control Features
• PEs and the IS and the networks all operate
  synchronously, using the same clock

14
Non-SIMD Properties of ASC

• Observation The ASC properties that are unusual
  for SIMDs are the constant time operations
• Constant time responder processing
• Any-responders?
• Pick-one
• Constant time global operations
• Logical OR and AND of binary values
• Maximum and minimum value of numbers
• Associative Searches
• These timings are justified by implementations
  using a resolver in the paper by Jin, Baker,
  Batcher (listed in associative references and
  posted).

15
Typical Data Structure for ASC Model
Busy- idle
1
Make, Color etc. are fields the programmer
establishes Various data types are supported.
Some examples will show string data, but they are
not supported in the ASC simulator.
16
The Associative Search
IS asks for all cars that are red and on the
lot. PE1 and PE7 respond by setting a mask bit in
their PE.
17
MASC Model

• Basic Components
• An array of cells, each consisting of a PE and
  its local memory
• A PE interconnection network between the cells
• One or more Instruction Streams (ISs)
• An IS network
• MASC is a MSIMD model that supports
• both data and control parallelism
• associative programming

18
MASC Basic Properties

• Each cell can listen to only one IS
• Cells can switch ISs in unit time, based on the
  results of a data test.
• Each IS and the cells listening to it follow
  rules of the ASC model.
• Control Features
• The PEs, ISs, and networks all operate
  synchronously, using the same clock
• Restricted job control parallelism is used to
  coordinate the interaction of the multiple ISs.

19
Characteristics of Associative Programming

• Consistent use of style of programming called
  data parallel programming
• Consistent use of global associative searching
  and responder processing
• Usually, frequent use of the constant time global
  reduction operations AND, OR, MAX, MIN
• Broadcast of data using an IS bus allows the use
  of the PE network to be restricted to synchronous
  parallel data movement.

20
Characteristics of Associative Programming

• Tabular representation of data (i.e., 2D
  arrays)
• Use of searching instead of sorting
• Use of searching instead of pointers
• Use of searching instead of the ordering provided
  by linked lists, stacks, queues
• Promotes an highly intuitive programming style
  that promotes high productivity
• Uses structure codes (i.e., numeric
  representation) to represent data structures such
  as trees, graphs, embedded lists, and matrices.
• Examples of the above are given in
• Ref Nov. 1994 IEEE Computer article.
• More examples given in Associative Computing
  book by Potter.

21
Languages Designed for the ASC

• Professor Potter has created several languages
  for the ASC model.
• ASC is a C-like language designed for ASC model
• ACE is a higher level language than ASC that uses
  natural language syntax e.g., plurals, pronouns.
• Anglish is an ACE variant that uses an
  English-like grammar (e.g., their, its)
• An OOPs version of ASC for the MASC was discussed
  (by Potter and his students), but never designed.
• Language References
• ASC Primer Copy available on parallel lab
  website www.cs.kent.edu/parallel/
• Associative Computing book by Potter 11
  some features in this book were never fully
  implemented in his ASC compiler

22
Algorithms and Programs Implemented in ASC

• A wide range of algorithms have been implemented
  in ASC without the use of the PE network
• Graph Algorithms
• minimal spanning tree
• shortest path
• connected components
• Computational Geometry Algorithms
• convex hull algorithms (Jarvis March, Quickhull,
  Graham Scan, etc)
• Dynamic hull algorithms

23
ASC Algorithms and Programs(not requiring PE
network)

• String Matching Algorithms
• all exact substring matches
• all exact matches with dont care (i.e., wild
  card) characters.
• Algorithms for NP-complete problems
• traveling salesperson
• 2-D knapsack.
• Data Base Management Software
• associative data base
• relational data base

24
ASC Algorithms and Programs (not requiring a PE
network)

• A Two Pass Compiler for ASC not the one we will
  be using. This compiler runs on an associative
  computer uses ASC parallelism.
• first pass
• optimization phase
• Two Rule-Based Inference Engines for AI
• An Expert System OPS-5 interpreter
• PPL (Parallel Production Language interpreter)
• A Context Sensitive Language Interpreter
• (OPS-5 variables force context sensitivity)
• An associative PROLOG interpreter

25
Associative Algorithms Programs (using a
network)

• There are numerous associative algortihms or
  programs that use a PE network
• 2-D Knapsack ASC Algorithm using a 1-D mesh
• Image processing algorithms using 1-D mesh
• FFT (Fast Fourier Transform) using 1-D nearest
  neighbor Flip networks
• Matrix Multiplication using 1-D mesh
• An Air Traffic Control Program (using Flip
  network connecting PEs to memory)
• Demonstrated using live data at Knoxville in mid
  70s.
• All but first were created and/or implemented in
  assembler for STARAN at Goodyear Aerospace

26
Example 1 - MST

• A graph has nodes labeled by some identifying
  letter or number and arcs which are directional
  and have weights associated with them.
• Such a graph could represent a map where the
  nodes are cities and the arc weights give the
  mileage between two cities.
• A B
• C D
• E

3
5
2
4
5
27
The MST Problem

• The MST problem assumes the weights are positive,
  the graph is connected, and seeks to find the
  minimal spanning tree,
• i.e. a subgraph that is a tree1, that includes
  all nodes (i.e. it spans), and
• where the sum of the weights on the arcs of the
  subgraph is the smallest possible weight (i.e. it
  is minimal).
• Why would an algorithm solving this problem be
  useful?
• Note The solution may not be unique.
• 1 A tree is a set of points called vertices,
  pairs of distinct vertices called edges, such
  that (1) there is a sequence of edges called a
  path from any vertex to any other, and (2) there
  are no circuits, that is, no paths starting from
  a vertex and returning to the same vertex.

28
An Example
2
4
7
3
6
5
1
2
3
2
6
4
8
2
1
As we will see, the algorithm is simple. The ASC
program is quite easy to write. A SISD solution
is a bit messy because of the data structures
needed to hold the data for the problem
29
An Example Step 0
2
4
7
3
6
5
1
2
3
2
6
4
8
2
1
We will maintain three sets of nodes whose
membership will change during the run. The first,
V1, will be nodes selected to be in the tree. The
second, V2, will be candidates at the current
step to be added to V1. The third, V3, will be
nodes not considered yet.
30
An Example Step 0
2
4
7
3
6
5
1
2
3
2
6
4
8
2
1
V1 nodes will be in red with their selected edges
being in red also. V2 nodes will be in light blue
with their candidate edges in light blue also. V3
nodes and edges will remain white.
31
An Example Step 1
2
4
7
3
6
5
1
2
3
2
6
4
8
2
1
Select an arbitrary node to place in V1, say
A. Put into V2, all nodes incident with A.
32
An Example Step 2
2
4
7
3
6
5
1
2
3
2
6
4
8
2
1
Choose the edge with the smallest weight and put
its node, B, into V1. Mark that edge with red
also. Retain the other edge-node combinations in
the to be considered list.
33
An Example Step 3
2
4
7
3
6
5
1
2
3
2
6
4
8
2
1
Add all the nodes incident to B to the to be
considered list. However, note that AG has
weight 3 and BG has weight 6. So, there is no
sense of including BG in the list.
34
An Example Step 4
2
4
7
3
6
5
1
2
3
2
6
4
8
2
1
Add the node with the smallest weight that is
colored light blue and add it to V1. Note the
nodes and edges in red are forming a subgraph
which is a tree.
35
An Example Step 5
2
4
7
3
6
5
1
2
3
2
6
4
8
2
1
Update the candidate nodes and edges by including
all that are incident to those that are in V1 and
colored red.
36
An Example Step 6
2
4
7
3
6
5
1
2
3
2
6
4
8
2
1
Select I as its edge is minimal. Mark node and
edge as red.
37
An Example Step 7
2
4
7
3
6
5
1
2
3
2
6
4
8
2
1
Add the new candidate edges. Note that IF has
weight 5 while AF has weight 7. Thus, we drop AF
from consideration at this time.
38
An Example after several more passes, C is
added we have
2
4
7
3
6
5
1
2
3
2
6
4
8
2
1
Note that when CH is added, GH is dropped as CH
has less weight. Candidate edge BC is also
dropped since it would form a back edge between
two nodes already in the MST. When there are no
more nodes to be considered, i.e. no more in V3,
we obtain the final solution.
39
An Example the final solution
2
4
7
3
6
5
1
2
3
2
6
4
8
2
1
The subgraph is clearly a tree no cycles and
connected. The tree spans i.e. all nodes are
included. While not obvious, it can be shown that
this algorithm always produces a minimal spanning
tree. The algorithm is known as Prims Algorithm
for MST.
40
The ASC Program vs a SISD solution in , say, C,
C, or Java

• First, think about how you would write the
  program in C or C.
• The usual solution uses some way of maintaining
  the sets as lists using pointers or references.
• See solutions to MST in Algorithms texts by Baase
  in the posted references.
• In the ASC language, pointers are not even
  supported as they are not needed and their use is
  likely to result in inefficient SIMD algorithms
• An ASC algorithm will be developed for Prims
  sequential algorithm using a pseudocode that is
  based on the ASC language.
• The ASC language users guide is posted at
  www.cs.kent.edu/parallel/, but its use is not
  required.
• The ASC algorithm can be used to create a program
  in ASC for the ASC simulator or in Cn for
  ClearSpeed.

41
ASC-MST Algorithm Preliminaries

• Next, a data structure level presentation of
  Prims algorithm for the MST is given.
• The data structure used is illustrated in the
  next two slides.
• This example is from the Nov. 1994 IEEE Computer
  paper cited in the references.
• There are two types of variables for the ASC
  model, namely
• the parallel variables (i.e., ones for the PEs)
• the scalar variables (ie., the ones used by the
  IS).
• Scalar variables are essentially global
  variables.
• Could replace each scalar variable with its
  scalar value stored in each entry of a parallel
  variable.

42
ASC-MST Algorithm Preliminaries (cont.)

• In order to distinguish between variable types
  here, the parallel variables names will end with
  a symbol.
• Each step in this algorithm takes constant time.
• One MST edge is selected during each pass through
  the loop in this algorithm.
• Since a spanning tree has n-1 edges, the running
  time of this algorithm is O(n) and its cost is
  O(n 2).
• Definition of cost is (running time) ? (number of
  processors)
• Since the sequential running time of the Prim MST
  algorithm is O(n 2) and is time optimal, this
  parallel implementation is cost optimal.
• Cost optimality will be covered in parallel
  algorithm performance evaluation chapter (See Ch
  7 of Quinn)

43
Graph used for Data Structure

• Figure 6 in Potter, Baker, et. al.

44
Data Structure for MST Algorithm
45
Short Version of Algorithm ASC-MST-PRIM(root)

• Initialize candidates to waiting
• If there are any finite values in roots field,
• set candidate to yes
• set parent to root
• set current_best to the values in roots
  field
• set roots candidate field to no
• Loop while some candidate contain yes
• for them
• restrict mask to mindex(current_best)
• set next_node to a node identified in the
  preceding step
• set its candidate to no
• if the value in their next_nodes field are
  less than current_best, then
• set current_best to value in
  next_nodes field
• set parent to next_node
• if candidate is waiting and the value in
  its next_nodes field is finite
• set candidate to yes
• set parent to next_node
• set current_best to the values in
  next_nodes field

46
Comments on ASC-MST Algorithm

• The three preceding slides are Figure 6 in
  Potter, Baker, et.al. IEEE Computer, Nov 1994.
• Preceding slide gives a compact, data-structures
  level pseudo-code description for this algorithm
• Pseudo-code illustrates Potters use of pronouns
  (e.g., them, its) and possessive nouns.
• The mindex function returns the index of a
  processor holding the minimal value.
• This MST pseudo-code is much shorter and simpler
  than data-structure level sequential MST
  pseudo-codes
• e.g., see one of Baases textbooks cited in
  references
• Algorithm given in Baases books is identical to
  this parallel algorithm, except for a sequential
  computer
• Next, a more detailed explanation of the
  algorithm in preceding slide will be given next.

47
Tracing 1st Pass of MST Algorithm on Figure 6
(Put below chart Figure 6 on board)
48
Algorithm ASC-MST-PRIM

• Initially assign any node to root.
• All processors set
• candidate to wait
• current-best to ?
• the candidate field for the root node to no
• All processors whose distance d from their node
  to root node is finite do
• Set their candidate field to yes
• Set their parent field to root.
• Set current_best d.

49
Algorithm ASC-MST-PRIM (cont. 2/3)

• While the candidate field of some processor is
  yes,
• Restrict the active processors to those whose
  candidate field is yes and (for these
  processors) do
• Compute the minimum value x of current_best.
• Restrict the active processors to those with
  current_best x and do
• pick an active processor, say node y.
• Set the candidate value of node y to no
• Set the scalar variable next-node to y.

50
Algorithm ASC-MST-PRIM (cont. 3/3)

• If the value z in the next_node column of a
  processor is less than its current_best value,
  then
• Set current_best to z.
• Set parent to next_node
• For all processors, if candidate is waiting
  and the distance of its node from next_node y is
  finite, then
• Set candidate to yes
• Set current_best to the distance of its node
  from y.
• Set parent to y

51
Quickhull Algorithm for ASC

• Reference
• Maher, Baker, Akl, An Associative
  Implementation of Classical Convex Hull
  Algorithms
• Sequential Quickhull Algorithm
• Suffices to find the upper convex hull of points
  that are on or above the line
• Select point h so that the area of triangle weh
  is maximal.
• Eliminate points inside triangle
• Proceed recursively with the sets of points on or
  above the lines and .

h
e
w
52
Previous Illustration
53
Example for Data Structure
54
Data Structure for Preceding Example
55
Algorithms Assumption

• Basic algorithms exist for the following problems
  in Euclidean geometry for plane
• Determine whether a third point lies on, above,
  or below the line determined by two other points.
• Compute the area of a triangle determined by
  three points.
• Standard Assumption
• Three arbitrary points do not all lie on the same
  line.
• Reference Introduction to Algorithms by Cormen,
  Leisterson, Rivest, ( Stein), McGraw Hill,
  Chapter on Computational Geometry.

56
ASC Quickhull Algorithm(Upper Convex Hull)

• ASC-Quickhull( planar-point-set )
• Initialize ctr 1, area 0, hull 0
• Find the PE with the minimal x-coord and let w
  be its point
• Set its hull value to 1
• Find the PE with the PE with maximal x-coord and
  let e be its point
• Set its hull to 1
• All PEs set their left-pt to w and right-pt to e.
• If the point for a PE lies above the line
• Then set its job value to 1
• Else set its job value to 0

57
ASC Quickhull Algorithm (cont)

• Loop while parallel job contains a nonzero value
• The IS makes its active cell those with a maximal
  job value.
• Each (active) PE computes and stores the area of
  triangle (left-pt, right-pt, point ) in area
• Find the PE with the maximal area and let h be
  its point.
• Set its hull value to 1
• Each PE whose point is above
• sets its job value to ctr
• sets its right-pt to h
• Each PE whose point is above
• sets its job to ctr
• sets its left-pt to h
• Each PE with job lt ctr -2 sets its job value
  to 0

58
Highest Job Order Assigned to Points Above Lines
59
Order that Triangles are Computed
60
Performance of ASC-Quickhull

• Average Case
• Assume either of the following
• For some integer kgt1, on average 1/k of the
  points above each line being processed are
  eliminated each round.
• For example, consider k 3, as one of three
  different areas are eliminated each round
• O(lg n) points are on the convex hull.
• For randomly generated points, the number of
  convex hull points is very close to lg(n) points.

61
Performance of ASC-Quickhull (cont)

• Either of above assumptions imply the average
  running time is O(lg n).
• For example, each pass through algorithm loop
  produces one convex hull point.
• The average cost is O(n lg n)
• Worst Case
• Running time is O(n).
• Cost is O(n2)
• Recall The definition of cost is
• Cost (running time) ? (nr. of processors)

62
Master/Slave IS Control Structure for MASC Model

• Instruction Streams
• 1 IS manager
• forks and joins tasks
• manages the job pool idle IS pool
• 2 worker ISs
• Available to execute tasks
• Task work pool of tasks
• Data parallel tasks that are ready to be assigned
  to idle worker instruction streams

63
Master/Slave IS Control Structure for the MASC
Model

• The master IS is connected to each worker IS by
  an IS broadcast/reduction network.
• A more minimal network may also be adequate,
  especially when the number of worker ISs is small
  which is typical.
• Efficient communications need to be supported
  between the master IS and each worker IS. The
  data size of these communications is small.
• Worker ISs do not need to communicate with each
  other.
• The master IS maintains a pool of unassigned jobs
  and a pool of idle ISs
• A job consists of a task to be performed and the
  idle PEs which will perform this job.
• When the job and IS pools are nonempty, the
  master IS will assign a job to an idle worker IS.
• An active IS will return any jobs it creates that
  need to be reassigned to the master IS to place
  in job pool.

64
MASC Quickhull Algorithm

• MASC Modification of ASC Quickhull Algorithm
• Initially, the master IS executes the
  initialization phase of the ASC Quicksort, using
  all the PEs.
• Alternately, it could assign a worker IS to do
  this.
• The master IS maintains the scalar variable
  ctr. Whenever the job pool and the IS pool are
  both nonempty, the master IS will assign a job to
  an IS.
• Each IS computes the steps in the loop in
  ASC-Quickhull. If two jobs are created, one is
  added to the job pool.
• If a job is added to the job pool, the value in
  the ctr scalar variable is assigned as the job
  number and the Master IS increments the ctr
  variable.
• The algorithm will terminate when there are no
  more jobs in the job pool and all ISs are idle.

65
Approximate Order MASC Quickhull Processes
Triangles(Assuming sufficient ISs)
66
Analysis for MASC Quickhull

• Average Case
• Assumptions
• The remaining unidentified hull points are
  roughly evenly distributed among the partitions
  in each recursive level.
• O(lg n) Instruction Streams are available.
• There are O(lg n) convex hull points
• The time for master IS to assign a task to an IS
  is a small constant and this time will be
  included with the time required to execute the
  task.
• The average running time is O(lg lg n) and the
  average cost is O(n lg lg n).
• O(lg lg n) increases so slowly that it is
  essentially a constant for practical values of n.

67
Analysis for MASC Quickhull (cont)

• Worst Case
• O(n)
• Happens if all points are hull points and all
  remaining points always lie on one side of each
  triangle selected.
• E.g., all points lie on a non-horizonal line
  above the x-y axis.
• Also, can happen if most of the points are hull
  points
• E.g., if all but a constant number of triangles
  selected have all of the remaining points they
  are assigned to lie on one side of the triangle.
• Bad Case which is O(lg n)
• All points are hull points, so only one point can
  be eliminated each time code is executed.

68
Comments Previous Average Time Analysis

• Since each job creates 0-2 sub-jobs, the total
  set of jobs created can be represented as a
  binary tree.
• Assume there are at most ??lg n? convex hull
  points
• Further, assume that the remaining unidentified
  hull points at each level of the binary tree are
  roughly distributed evenly among the jobs at that
  level.
• Such a the binary tree is roughly complete (or
  full).
• To simplify this calculation, we assume above
  binary tree is complete and let m be the number
  of hull points.
• Then m is O(lg n), the height h O(lg m)
• The number of internal nodes and leaves is O(m)
• Jobs at higher levels in the tree should be given
  higher priority
• Each level of the binary tree can be calculated
  in constant time.
• Note some levels of binary tree may have more
  jobs than there are ISs, but can still be
  calculated in several passes in constant time.
• Conclusion When the binary jobs tree is
  roughly complete and there are O(lg n) convex
  hull points, the running time for this algorithm
  O(lg lg n).

69
Comments on MASC Quickhull

• For one million randomly generated points, this
  algorithm would require a maximum of ?lg n? 20
  ISs on any level.
• Note that 33.5 million randomly generated points
  only requires 25 ISs at each level, or 5 more
  than required for 1 million
• By using virtual IS-parallelism, fewer ISs can
  be used.
• Even if ?(lg n) ISs are available for this
  algorithm, there may be occasions during
  execution when the IS pool is empty and the job
  pool is non-empty.
• Additionally, this algorithm will provide a
  speedup, even if only a small constant number kgt0
  of ISs are available.
• The complexity of the running time only be O(lg
  n).
• However, the actual running time should be close
  to k times faster than for one IS.
• There will be a small loss of efficiency due to
  IS interactions.
• This algorithm works, whether or not sufficient
  ISs are available.

70
Additional Comments on ASC and MASC Algorithms

• The full convex hull algorithm requires that an
  order (e.g., clockwise) list of convex hull
  points be returned.
• Preceding algorithms for ASC and MASC can be
  extended to handle this.
• This detail is omitted here to keep the
  algorithms simpler.
• More information can be found in the paper An
  Associative Implementation of Classical Convex
  Hull Algorithms by Atwah, Baker, and Akl and in
  Maher Atwahs masters thesis at KSU.

71
END OF SLIDE SET
72
Teaching Tool(Tracing MST Algorithm on Figure 6)

• The following slide should be used to trace the
  first pass of the MST algorithm on Figure 6
• Print a copy of next slide for each student prior
  to covering detailed MST algorithm.
• This will allow students to copy dynamic trace of
  algorithm during class.

73
Tracing 1st Pass of MST Algorithm on Figure 6
