Producing Emotional Speech

1
Producing Emotional Speech

• Thanks to Gabriel Schubiner

2
Papers

• Generation of Affect in Synthesized Speech
• Corpus-based approach to synthesis
• Expressive visual speech using talking head
• Demos
• Affect Editor Quiz/Demo
• Synface Demo

3
Affect in Speech

• Goals
• Addition of Emotion to Synthetic speech
• Acoustic Model
• Typology of parameters of emotional speech
• Quantification
• Addresses problem of expressiveness
• What benefit is gained from expressive speech?

4
Emotion Theory/Assumptions

• Emotion -gt Nervous System -gt Speech Output
• Binary distinction
• Parasympathetic vs Sympathetic
• based on physical changes
• universal emotions

5
Approaches to Affect

• Generative
• Emotion -gt Physical -gt Acoustic
• Descriptive
• Observed acoustic params imposed

6
Descriptive Framework

• 4 Parameter groups
• Pitch
• Timing
• Voice Quality
• Articulation
• Assumption of independence
• How could this affect design and results?

7
Pitch Timing

• Accent Shape
• Average Pitch
• Contour Slope
• Final Lowering
• Pitch Range
• Reference Line
• Exaggeration (not used)
• Fluent Pauses
• Hesitation Pauses
• Speech Rate
• Stress Frequency
• Stressed Stressable

8
Voice Quality Articulation

• Breathiness
• Brilliance
• Loudness
• Pause Discontinuity
• Pitch Discontinuity
• Tremor
• Laryngealization
• Precision

9
Implementation

• Each parameter has scale
• Each scale is independent
• from other parameters
• between positive and negative

10
Implementation

• Settings grouped into preset conditions for each
  emotion
• based on prior studies

11
Program Flow Input

• Emotion -gt parameter representation
• Utterance -gt clauses
• Agent, Action, Object, Locative
• Clause and lexeme annotations
• Finds all possible locations of affect and
  chooses whether or not to use

12
Program Flow

• Utterance -gt Tree structure -gt linear phonology
• compiled for specific synthesizer with software
  to simulate affects not available in hardware

13
(No Transcript)
14
Perception

• 30 Utterances
• 5 sentences 6 affects
• Forced choice of one of six affects
• magnitude and comments

15
Elicitation Sentences

• Intro
• Im almost finished
• Im going to the city
• I saw your name in the paper X
• I thought you really meant it
• Look at that picture

16
Pop Quiz!!!
17
Pop Quiz Solutions

• Im almost finished
• Disgust Surprise Sadness Gladness Anger
  Fear
• Im going to the city
• Surprise Gladness Anger Disgust Sadness
  Fear
• I thought you really meant it
• Anger Disgust Gladness Sadness Fear
  Surprise
• Look at that picture
• Anger Fear Disgust Sadness Gladness
  Surprise

18
Results

• approx 50 recognition rate
• 91 sadness

19
(No Transcript)
20
Conclusions

• Effective?
• Thoughts?

21
Corpus-based Approach to Expressive Speech
Synthesis
22
Corpus

• Collect utterances in each emotion
• emotion-dependent semantics
• One speaker
• Good news, Bad news, Question

23
Model Feature Vector

• Features
• Lexical stress
• Phrase-level stress
• Distance from beginning of phrase
• Distance from end of phrase
• POS
• Phrase-type
• End of syllable pitch

24
Model Classification

• Predicts F0
• 5 syllable window
• Uses feature vector to predict observation vector
• observation vector log(p), ?p
• p end of syllable pitch
• Decision Tree

25
Model Target Duration

• Similar to predicting F0
• build tree with goal of providing Gaussian at
  leafs
• Use mean of class as target duration
• discretization

26
Models

• Uses acoustic analogue of n-grams
• captures sense of context
• compared to describing full emotion as sequence
• compare to Affect Editor
• Uses only F0 and length (comp. A E)
• Include information about from which utterance
  the features are derived
• intentional bias, justified?

27
Model Synthesis

• Data tagged with original expression and emotion
• expression-cost matrix
• noted trade-off
• emotional intensity vs. smoothness
• Paralinguistic events

28
SSML

• Compare to Cahns typology
• Abstraction layers

29
Perception Experiment

• Distinguish same utterance spoken with neutral
  and affected prosody
• Semantic content problematic?

30
Results

• Binary decision
• Reasonable gain over baseline?

31
Conclusion

• Major contributions?
• Paths forward?

32
Synthesis of Expressive Visual Speech on a
Talking Head
33
lt Not these Talking Heads... gt
34
Synthesis Background

• Manipulation of video images
• Virtual model with deformation parameters
• Synchronized with time-aligned transcription
• Articulatory Control Model
• Cohen Massaro (1993)

35
Data

• Single actor
• Given specific emotion as instruction
• 6 emotions neutral

36
Facial Animation Parameters

• Face independent
• FAP Matrix scaling factor position0
• Weighted deformations of distance between
  vertices and feature point

37
Modeling

• Phonetic segments assigned target parameter
  vector
• temporal blending over dominance functions
• Principal components

38
ML

• Separate models for each emotion
• 61 trainingtesting ratio
• models -gt PC traj -gt FAP traj emotion param
  matrix

39
Results

• More extreme emotions easier to perceive
• 73 sad, 60 angry, 40 sad

40
Synface Demo
41
Discussion

• Changes in approach from Cahn to Eide
• Production compared to Detection
