Nucleotides, Nucleic Acids and Heredity

1
Nucleotides, Nucleic Acids and Heredity

• Bettelheim, Brown, Campbell and Farrell
• Chapter 25

2
Nucleic Acids--Intro

• Chromosomes contain genetic information
• found primarily in nucleus
• Chromatin tightly packed DNA and histones
• Chromosomes contain DNA and basic proteins
  (histones)
• Can be seen during cell division
• Nucleic acids are responsible for genetic
  information

3
Introduction

• Cells contain thousands of different proteins
• How do cells know which proteins to synthesize?
• First thought that transmission of hereditary
  information took place in the nucleus (in
  chromosomes) beginning late in 19th century
• Hereditary information thought to be in genes
  within the chromosomes
• Chemical analysis of nuclei showed chromosomes
  are made up largely of proteins called histones
  and nucleic acids

4
Introduction

• By the 1940s it became clear that
  deoxyribonucleic acids (DNA) carry the hereditary
  information
• Other work in the 1940s demonstrated that each
  gene controls the manufacture of one protein
• Thus, the expression of a gene in terms of an
  enzyme protein led to the study of protein
  synthesis and its control

5
Categories of Nucleic Acids

• Deoxyribonucleic Acid (DNA)
• Found in nucleus (in chromosomes)
• Contain genes which contain genetic
  information
• Ribonucleic Acid (RNA)
• Some found in nucleus (but not in chromosomes)
• Also found in cytoplasm

6

• Both DNA and RNA contain
• A Nitrogenous Base
• Sugar
• Phosphate
• Nucleoside contains just a base and a sugar
• Nucleotide contains all three components

7
Nucleic Acid Bases
8
Purine BasesAdenine Guanine
9
Pyrimidine BasesCytosine Thymine Uracil
10
Pyrimidine/Purine Bases
11
DNA and RNA Bases

• DNA RNA
• Adenine Adenine
• Thymine Uracil
• Guanine Guanine
• Cytosine Cytosine

12
Sugar
Ribose
2-Deoxyribose
13

• Both DNA and RNA contain
• A Nitrogenous Base
• Sugar
• Phosphate
• Nucleoside contains just a base and a sugar
• Nucleotide contains all three components

14
Nucleoside
15
Nucleosides

• Nucleoside a compound that consists of D-ribose
  or 2-deoxy-D-ribose bonded to a purine or
  pyrimidine base by a ?-N-glycosidic bond

16
Nucleotide
17
Nucleotides

• Nucleotide a nucleoside in which a molecule of
  phosphoric acid is esterified with an -OH of the
  monosaccharide, most commonly either the 3 or
  the 5-OH

18
Nucleotides

• adenosine 5-triphosphate (ATP) serves as a
  common currency into which energy gained from
  food is converted and stored

19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
Structure of DNA and RNA

• Primary Structure the sequence of bases along
  the pentose-phosphodiester backbone of a DNA or
  RNA molecule
• base sequence is read from the 5 end to the 3
  end

23
Nucleic Acid - 1 Structure

• A schematic diagram of a nucleic acid

24
Fig. 24.3
3 end of one sugar to phosphate to 5 end of
second sugar
3,5 phospho-diester linkage
Each nonterminal phosphate has -1 charge
25
Pyrimidine BasesCytosine Thymine Uracil
26
Fig. 24.3, p.602
27
Structure of DNA and RNA

• Primary Structure the sequence of bases along
  the pentose-phosphodiester backbone of a DNA or
  RNA molecule
• base sequence is read from the 5 end to the 3
  end

28
Nucleic Acid Structure

• DNA has a double helix structure
• Phosphates on outside
• Complementary Base Pairs on inside
• RNA is single stranded
• Messenger RNA (m-RNA)
• Transfer RNA (t-RNA) has some double stranded
  loops

29
DNA - 2 Structure

• Secondary structure the ordered arrangement of
  nucleic acid strands
• Double helix model of DNA 2 structure was
  proposed by James Watson and Francis Crick in
  1953
• Based on two primary sources of information
• Irwin Chargaff A T and C G
• X-ray diffraction picture of DNA taken by
  Rosalind Franklin

30
Irwin Chargaff Base Composition in Many
Different Species
Table 24.2, p.602
31
(No Transcript)
32
Rosalind Franklin
p. 640
33
James Watson Francis Crick
p. 640
34

• Double helix
• a type of 2 structure of DNA molecules in which
  two anti-parallel polynucleotide strands are
  coiled in a right-handed manner about the same
  axis

35
DNA Double Helix

• Double helix
• Two DNA strands
• Anti-parallel strands
• One is 3 to 5 Other is 5 to 3
• Strands are coiled in a right-handed helix about
  the same axis
• Backbone has alternating sugar and phosphate
  groups
• Complementary Base Pairs on inside of helix

36
The DNA Double Helix
Each turn is 3.4 nm
37
Complementary Base Pairs

• DNA Base Pairs Double-Stranded
• A-T A T
• C-G C G
• RNA Base Pairs Single-Stranded
• A-U
• C-G

38
Complementary Base Pairs

• Must be one purine and one pyrimidine to fit
  properly
• Two purines too big
• Two pyrimidines too small
• Not every purine-pyrimidine pair forms naturally

39
Fig. 24.6, p.605
40
Complementary Base Pairs
2 H-bonds
TA pair
GC pair
3 H-bonds
41
Non-Complementary Base Pairs
42
Chains are anti-parallel
43
Fig. 24.5
44
Fig. 24.4
45
Higher Structure of DNA

• DNA is coiled around proteins called histones
• Histones are rich in the basic amine acids Lys
  and Arg, whose side chains have a positive charge
• DNA molecules (with charge) and histones (with
  charge) attract each other and form units
  called nucleosomes
• nucleosome a core of eight histone molecules
  around which the DNA helix is wrapped
• nucleosomes are condensed into chromatin
• chromatin fibers are organized into loops and
  then bands in the superstructure of chromosomes

46
Chromosomes
47
Chromosomes
48
Chromosomes
49
Chromosomes
50
DNA and RNA

• The three differences in structure between DNA
  and RNA are
• DNA bases are A, G, C, and T the RNA bases are
  A, G, C, and U
• the sugar in DNA is 2-deoxy-D-ribose in RNA it
  is D-ribose
• DNA is always double stranded there are several
  kinds of RNA, all of which are single-stranded
