Introduction to fibre

1
Introduction to fibre textile technology
2
What is fibre ?
Fibre Units of matter characterised by
flexibility, fineness and a high ratio of
length to thickness. (defined by the Textile
Institute)
The length/diameter ratio should be at least
10001
3
General fibre classification
Natural fibres Cellulosic Protein Mineral Cotto
n(seed hair) Wool Asbestos Flax
(bast) Silk Jute (bast) Mohair Sisal
(leaf) Cashmere Ramie (bast)
4
Typical cross sectional shapes and fiber contour
5
Man-made fibres Regenerated Modified
Synthetic Mineral Viscose Cellulose
Polyamide Glass rayon diacetate
Polyester Steel Cellulose Polyacrylic
Carbon triacetate Polyolefin
Polyvinyl
6
Fibre Properties To analyse a fabric to
predict its performance, one usually starts
with the fibre content.   ?The external
structure ?The chemical composition ?The
internal structure
7
? External structure or morphology  1. Length
Filament, Staple, Filament tow
8
2. Fineness (diameter, size, denier)
Diameter range (microns) Diameter range (microns)
Cotton 16-20 microns
Flax 12-16 microns
Wool 10-50 microns
Silk 11-12 microns
9
Denier the weight in grams of 9,000 metres of
yarn (or fibre) Decitex the weight in grams of
10,000 metres 1 decitex 0.9 denier 1 tex 10
decitex 1000 millitex
Q. If 5000 meters of a fibre has a mass of 0.6
grams then the linear density is tex.
10
3. Cross - sectional shape (see
figure) Luster, body, texture or feel of a
fabric Different between natural fibre and
m.m. fibre
11
4. Surface contour important to the hand and
texture Luster the gloss or shine that a
fabric posses. It depends on amount of light
reflect on fibres.
Specular
12
Lustrous fibres
13
5. Fibre parts Natural fibres (except silk)
cuticle or skin, inner area, central
core Manmade fibre skin and solid core
14
 ? Chemical composition Type Characteristic
linkage Polyamide - NH CO - Protein, wool,
silk - NH CO - Polyester - CO O
Cellulose - O C
15

• Internal structure or molecular arrangement
• Degree of polymerisation
• - Molecular weight
• - Molecular arrangement
• oriented, amorphous, crystalline

16
(Stretching or drawing MM. Fibre)   The amount
of crystallinity and orientation relates to
the physical prop. such as strength,
elongation, moisture absorption and abrasion
resistance. (See Fibre property charts)
17
- Refractive index A measure of how light is
bent as it passes through the surface of a
material.
Reflactive indices in fibre
18
Tensile strength, stress, strain  In engineering
term, stress load area of
cross section Specific tensile stress
load

mass per unit length
(Ntex -1 or mNtex -1)
19
Tensile strain elongation original
length   Extension () tensile strain x 100
20
Stress/strain curves The values for particular
textile depend on - Type of specimen (single
fibres, yarn, fabric) - The dimensions of the
sample - The atmospheric conditions in the
laboratory - Speed of testing machine
21
Typical stressstrain curve for a fibre
22
Modulus (Tan ?) Yield point In this area
small changes in load produce large changes in
length Elasticity Elastic recovery
recovered extension total extension
23
Fibres and moisture Relative humidity (R.H.) is
the amount of water vapour in air. R.H. ()
percentage of the maximum amount that the air can
hold at the particular temperature.
24
Moisture content () mass of moisture in the
sample x 100 mass of the undried sample
Moisture regain () mass of moisture in the
sample x 100 mass of the dry sample
