About This Presentation
Title:

FCC

Description:

Chapter 5 FCC (Federal Communications Commission) Rules and Regulations HARL M PORTER 05/ 18/ 95 * * * Operator license required for VHF-FM only if: not in either ... – PowerPoint PPT presentation

Number of Views:120
Avg rating:3.0/5.0
Slides: 39
Provided by: Por187
Category:
Tags: fcc

less

Transcript and Presenter's Notes

Title: FCC


1
Chapter 5
  • FCC
  • (Federal Communications Commission)
  • Rules and Regulations

gtgt
2
Overview
  • Communications Act of 1934
  • FCC Rules (CFR Title 47, Part 80)
  • Maritime Radio Licenses
  • Frequency Plan
  • Summary

gtgt
3
Communications Act of 34
  • Keel of Maritime Radio Rules
  • CFR Title 47, Part 80
  • Stations in the Maritime Services
  • Last revised 1 Oct 2002
  • In revision right now
  • Purpose
  • Safety of Life at Sea
  • Effective use of maritime bands
  • Know and comply with Rules and Regulations
  • Reduce interference
  • To emergency/distress communications

gtgt
4
CFR Title 47, Part 80
Code of Federal Regulations Title 47, Volume
5 TITLE 47--TELECOMMUNICATION
PART 80--STATIONS IN THE MARITIME
SERVICES 80.1 General This section contains
the statutory basis for this part of the rules
and provides the purpose for which this part is
issued. (a) Basis. The rules for the maritime
services (b) Purpose. This part states
the conditions under which radio may be licensed
and used in the maritime services. These rules do
not govern radio stations operated by agencies of
the U.S. Government.
Available online
gtgt
5
FCC Rules
  • Categories of Ships
  • Authorized Users
  • Monitoring Requirement
  • Priority of Communications
  • Security of Communications
  • Violations

gtgt
6
Categories of Ships
  • Compulsory
  • Licensed to carry more than 6 passengers
  • Cargo and passenger ships
  • Must have radios and navigational equipment
  • Voluntary
  • Recreational vessels under 65 feet
  • If 65 feet or over, vessel must carry a radio and
    have a Ship Station License

gtgt
7
Authorized Uses
  • Primary safety
  • Secondary needs of the vessel
  • Prohibited Uses
  • Profane, obscene or indecent language
  • False distress signals
  • Social conversations
  • General calls
  • Not addressed to specific station
  • Except distress, alarm, urgency, safety signals
    or test

gtgt
8
Monitoring Requirements
  • If you have VHF-FM DSC radio
  • Must monitor DSC channel 70 (done automatically)
  • Should also monitor channel 16
  • Unless communicating on working channel
  • USPS pledge to render assistance, whenever
    possible to anyone afloat who is disabled or in
    distress
  • If you do NOT have a VHF-FM DSC radio
  • Must monitor channel 16
  • Unless communicating on working channel
  • Scanning radios monitor several channels
  • Suggest 09, 13, 16 and working

gtgt
9
Priority of Communications
  • Distress (MAYDAY)
  • Urgency (PAN PAN) Pahn-pahn
  • Safety (SECURITY) Saycure-it-tay
  • Navigation, movements and needs of ship
  • Government
  • All Other (non-emergency)
  • Most communications from recreational craft

gtgt
10
Prevention of Interference
  • Determine that frequency is not in use
    before making a call
  • If you may cause interference to a call in
    progress, cease transmitting
  • Priority of communications prevents interference
    to most important calls

gtgt
11
Station Identification
  • At the beginning and end of each communication
  • Not during transmission
  • Details will be provided in chapter 6
  • At 15 minute intervals
  • In English

gtgt
12
Security of Communications
  • Communications Act of 1934 protects privacy of
    radio communications
  • A radio operator may NOT divulge
  • Content of message
  • Existence of message
  • A radio listener may NOT divulge
  • Content of message
  • Existence of message
  • Knowledge gained
  • Cannot be used for any purpose

gtgt
13
Violations
  • Violations can be charged against
  • Radio operator
  • and/or licensee
  • and/or owner/captain
  • Notifications to Violators
  • Warning (requires no reply)
  • Official Notice (requires answer within 10 days)
  • Notice of Apparent Liability
  • Fine
  • Answered per instructions in notice

gtgt
14
Serious Violations
  • Transmitting false MAYDAYs
  • Interfering with distress signals
  • Willfully interfering with another station
  • Using obscene, profane or indecent language

gtgt
15
Common Violations 1
  • Transmitting
  • Without required license
  • Ship Station or Operators License
  • With unauthorized call sign
  • With non-type accepted equipment
    or with too much power
  • On an unauthorized frequency
  • Interfering
  • With distress or other priority signals

gtgt
16
Common Violations - 2
  • Failure to
  • Obey a cease and desist order
  • Reply to a violation notice from FCC
  • Maintain Radio Silence when required
  • Performing or allow unauthorized adjustments on
    transmitter

gtgt
17
Penalties
  • Violations can be charges against
  • Radio operator
  • and/or licensee
  • and/or owner/captain
  • Penalties
  • License revocation
  • Equipment forfeiture
  • Fines (up to 10,000)
  • Imprisonment (up to 2 years)
  • Civil Liabilities

gtgt
18
Maritime Radio Licenses
  • Ship Station
  • Operator

gtgt
19
Ship Station License
  • Required for
  • MF/HF SSB radios
  • Satellite radios
  • INMARSAT
  • Mini C
  • Mini M
  • MMSI issued
  • VHF-FM radios
  • MF/HF SSB radios
  • INMARSAT terminals
  • EPIRB must be registered with NOAA
  • Owner must update both the MMSI and NOAA databases

gtgt
20
Ship Station License
  • NOT required for
  • VHF-FM radios (voluntary)
  • Satellite phones
  • Globalsat
  • Iridium
  • IsatPhone
  • Sky Mate
  • VHF satellite system
  • EPIRB
  • Radar

gtgt
21
Ship Station License
Required for MF/HF SSB Radio and INMARSAT
terminals
gtgt
22
How to Obtain Station License
  • Need FCC Registration Number (FRN)
  • Electronically at http//wireless.fcc.gov/uls

gtgt
23
How to Obtain - 2
  • Complete FCC form 605
  • Electronically at http//wireless.fcc.gov/uls

0.44 hours to complete 2 page form
gtgt
24
How to Obtain - 3
Complete Schedule E of FCC form
605 Electronically at http//wireless.fcc.gov/uls
The date of birth will not be made available for
public inspection.
gtgt
25
How to Obtain - 4
  • Pay processing fee of 160
  • Electronically at http//wireless.fcc.gov/uls

FCC form 159
gtgt
26
Details on Ship License
  • Eligibility
  • Individuals or Corporations
  • Not to Foreign Governments
  • or their representatives
  • Call Sign
  • Name of Vessel
  • or FCC issued Call Sign
  • Posting of License
  • Not Required
  • Must be readily available
  • Renewable, 10-year license

gtgt
27
Operator Licenses
  • VHF-FM Required
  • Minimum of RR, if not in
  • US waters
  • International waters
  • Minimum of MP
  • If 65 feet or larger
  • Commercial
  • MF/HF SSB Required
  • Minimum of RR
  • Regardless of length
  • In any waters

gtgt
28
Operator Licenses
  • Not Required for
  • VHF-FM Recreational
  • Under 65 feet
  • In US waters
  • In International waters
  • In case of emergency
  • Anyone may transmit a Mayday
  • License is NOT required

gtgt
29
Types of Licenses - RR
  • Restricted Radiotelephone Operator Permit
  • Meets all recreational boater needs
  • No exam, lifetime license
  • Application and fee

gtgt
30
How to Obtain RR License
  • By application, no exam
  • Need FCC Registration Number (FRN)
  • Electronically at http//wireless.fcc.gov/uls
  • Complete FCC from 605 and its schedule E
  • Electronically at http//wireless.fcc.gov/uls
  • Pay processing fee of 60
  • With FCC form 159
  • Electronically at http//wireless.fcc.gov/uls
  • Can use credit card
  • Lifetime license (no expiration date)

gtgt
31
Advanced Licenses
  • Details on Marine Radio Operators Permit or MP
    are covered in Appendix B
  • Required if vessel is 65 feet or larger
  • If carrying more than 6 passengers for hire
  • Non-technical license
  • Details on General Radiotelephone Operators
    License also in Appendix B
  • Combination Operators Maintainer License
  • Written technical (electronics) exam

gtgt
32
Marine Radio Frequency Plan
gtgt
33
Overview
  • Maritime Radio Bands
  • Sea Areas

gtgt
34
Maritime Radio Bands
  • Marine Radiotelephone Bands
  • 2 to 3 MHz Medium Frequency SSB (AM)
  • 4 to 27.5 MHz High Frequency SSB (AM)
  • 156 to 162 MHz Very High Frequency FM
  • Bands by Sea Area
  • Sea Area A1 use VHF-FM (20 mile range)
  • Sea Area A2 use MF-SSB (100 mile range)
  • Sea Area A3 use INMARSAT or HF-SSB
  • Sea Area A4 use HF-SSB

gtgt
35
Sea Areas
  • A1 - Shore out to 20 nm
  • A2 - From 20 out to 100 nm from shore
  • A3 - Over 100 nm from shore 70º N to 70º S
  • A4 - Polar regions beyond 70º

gtgt
36
Marine Frequencies Channels
  • Details on Marine Radio Frequencies are found in
    Appendix A
  • Details on NOAA Weather Channels are also found
    in Appendix A

gtgt
37
Summary
  • Marine radios are for safety needs of vessel
  • Prohibited false distress, social all
    stations
  • Priorities Mayday, Urgency (Pan-Pan), Safety
    (Security), Navigation, Government, then other
  • NO license for domestic VHF
  • RR for foreign VHF and/or all MF/HF
  • Must monitor either Channel 16 or 70 (DSC)
  • Unless using a working channel

gtgt
38
Summary - 2
  • Three bands for Marine Radio
  • VHF-FM (156 to 162 MHz) Primary
  • Radio Line-of-Sight
  • MF (2 to 3 MHz) when VHF will not reach
  • HF (4 to 27 MHz) when MF will not reach
  • Suggest scanning 09, 13, 16 and working
  • DSC always monitoring 70

gtgt
