WEKA and Machine Learning Algorithms

1
WEKA and Machine Learning Algorithms
2
Algorithm Types

• Classification (supervised)
• Given -gt A set of classified examples
  instances
• Produce -gt A way of classifying new examples
• Instances described by fixed set of features
  attributes
• Classes discrete or continuous classification
  regression
• Interested in
• Results? (classifying new instances)
• Model? (how the decision is made)
• Clustering (unsupervised)
• There are no classes
• Association rules
• Look for rules that relate features to other
  features

3
Classification
4
Clustering
5
Clustering

• It is expected that similarity among members of a
  cluster should be high and similarity among
  objects of different clusters should be low.
• The objectives of clustering
• knowing which data objects belong to which
  cluster
• understanding common characteristics of the
  members of a specific cluster

6
Clustering vs Classification

• There is some similarity between clustering and
  classification.
• Both classification and clustering are about
  assigning appropriate class or cluster labels to
  data records. However, clustering differs from
  classification in two aspects.
• First, in clustering, there are no pre-defined
  classes. This means that the number of classes or
  clusters and the class or cluster label of each
  data record are not known before the operation.
• Second, clustering is about grouping data rather
  than developing a classification model.
  Therefore, there is no distinction between data
  records and examples. The entire data population
  is used as input to the clustering process.

7
Association Mining
8
Overfitting

• Memorization vs generalization
• To fix, use
• Training data to form rules
• Validation data to decide on best rule
• Test data to determine system performance
• Cross-validation

9
Baseline Experiments

• In order to evaluate the efficiency of the
  classifiers used in experiments, we use
  baselines
• Majority based random classification (Kappa0)
• Class distribution based random classification
  (Kappa0)
• Kappa statistics, is used as a measure to assess
  the improvement of a classifiers accuracy over a
  predictor employing chance as its guide.
• P0 is the accuracy of the classifier and Pc is
  the expected accuracy that can be achieved by a
  randomly guessing classifier on the same data
  set. Kappa statistics has a range between 1 and
  1, where 1 is total disagreement (i.e., total
  misclassification) and 1 is perfect agreement
  (i.e., a 100 accurate classification).
• Kappa score over 0.4 indicates a reasonable
  agreement beyond chance.

10
Data Mining Process
11
WEKA the software

• Machine learning/data mining software written in
  Java (distributed under the GNU Public License)
• Used for research, education, and applications
• Complements Data Mining by Witten Frank
• Main features
• Comprehensive set of data pre-processing tools,
  learning algorithms and evaluation methods
• Graphical user interfaces (incl. data
  visualization)
• Environment for comparing learning algorithms

12
Wekas Role in the Big Picture
13
WEKA Terminology

• Some synonyms/explanations for the terms used by
  WEKA
• Attribute feature
• Relation collection of examples
• Instance collection in use
• Class category

14
WEKA only deals with flat files

• _at_relation heart-disease-simplified
• _at_attribute age numeric
• _at_attribute sex female, male
• _at_attribute chest_pain_type typ_angina, asympt,
  non_anginal, atyp_angina
• _at_attribute cholesterol numeric
• _at_attribute exercise_induced_angina no, yes
• _at_attribute class present, not_present
• _at_data
• 63,male,typ_angina,233,no,not_present
• 67,male,asympt,286,yes,present
• 67,male,asympt,229,yes,present
• 38,female,non_anginal,?,no,not_present
• ...

numeric attribute
nominal attribute
15
(No Transcript)
16
Explorer pre-processing the data

• Data can be imported from a file in various
  formats ARFF, CSV, C4.5, binary
• Data can also be read from a URL or from an SQL
  database (using JDBC)
• Pre-processing tools in WEKA are called filters
• WEKA contains filters for
• Discretization, normalization, resampling,
  attribute selection, transforming and combining
  attributes,

17
Explorer building classifiers

• Classifiers in WEKA are models for predicting
  nominal or numeric quantities
• Implemented learning schemes include
• Decision trees and lists, instance-based
  classifiers, support vector machines, multi-layer
  perceptrons, logistic regression, Bayes nets,
• Meta-classifiers include
• Bagging, boosting, stacking, error-correcting
  output codes, locally weighted learning,

18
Classifiers - Workflow
LearningAlgorithm
Classifier
Predictions
19
Evaluation

• Accuracy
• Percentage of Predictions that are correct
• Problematic for some disproportional Data Sets
• Precision
• Percent of positive predictions correct
• Recall (Sensitivity)
• Percent of positive labeled samples predicted as
  positive
• Specificity
• The percentage of negative labeled samples
  predicted as negative.

20
Confusion matrix

• Contains information about the actual and the
  predicted classification
• All measures can be derived from it
• accuracy (ad)/(abcd)
• recall d/(cd) gt R
• precision d/(bd) gt P
• F-measure 2PR/(PR)
• false positive (FP) rate b /(ab)
• true negative (TN) rate a /(ab)
• false negative (FN) rate c /(cd)

predicted predicted

true a b
true c d
21
Explorer clustering data

• WEKA contains clusterers for finding groups of
  similar instances in a dataset
• Implemented schemes are
• k-Means, EM, Cobweb, X-means, FarthestFirst
• Clusters can be visualized and compared to true
  clusters (if given)
• Evaluation based on loglikelihood if clustering
  scheme produces a probability distribution

22
Explorer finding associations

• WEKA contains an implementation of the Apriori
  algorithm for learning association rules
• Works only with discrete data
• Can identify statistical dependencies between
  groups of attributes
• milk, butter ? bread, eggs (with confidence 0.9
  and support 2000)
• Apriori can compute all rules that have a given
  minimum support and exceed a given confidence

23
Explorer attribute selection

• Panel that can be used to investigate which
  (subsets of) attributes are the most predictive
  ones
• Attribute selection methods contain two parts
• A search method best-first, forward selection,
  random, exhaustive, genetic algorithm, ranking
• An evaluation method correlation-based, wrapper,
  information gain, chi-squared,
• Very flexible WEKA allows (almost) arbitrary
  combinations of these two

24
Explorer data visualization

• Visualization very useful in practice e.g. helps
  to determine difficulty of the learning problem
• WEKA can visualize single attributes (1-d) and
  pairs of attributes (2-d)
• To do rotating 3-d visualizations (Xgobi-style)
• Color-coded class values
• Jitter option to deal with nominal attributes
  (and to detect hidden data points)
• Zoom-in function

25
Performing experiments

• Experimenter makes it easy to compare the
  performance of different learning schemes
• For classification and regression problems
• Results can be written into file or database
• Evaluation options cross-validation, learning
  curve, hold-out
• Can also iterate over different parameter
  settings
• Significance-testing built in!

26
The Knowledge Flow GUI

• New graphical user interface for WEKA
• Java-Beans-based interface for setting up and
  running machine learning experiments
• Data sources, classifiers, etc. are beans and can
  be connected graphically
• Data flows through components e.g.,
• data source -gt filter -gt classifier -gt
  evaluator
• Layouts can be saved and loaded again later

27
Beyond the GUI

• How to reproduce experiments with the
  command-line/API
• GUI, API, and command-line all rely on the same
  set of Java classes
• Generally easy to determine what classes and
  parameters were used in the GUI.
• Tree displays in Weka reflect its Java class
  hierarchy.

gt java -cp galley/weka/weka.jar
weka.classifiers.trees.J48 C 0.25 M 2 -t
lttrain_arffgt -T lttest_arffgt
28
Important command-line parameters

• where options are
• Create/load/save a classification model
• -t ltfilegt training set
• -l ltfilegt load model file
• -d ltfilegt save model file
• Testing
• -x ltNgt N-fold cross validation
• -T ltfilegt test set
• -p ltSgt print predictions attribute selection S

gt java -cp galley/weka/weka.jar
weka.classifiers.ltclassifier_namegt
classifier_options options
29
Problem with Running Weka
Problem Out of memory for large data set
Solution java -Xmx1000m -jar weka.jar
