Election Algorithms

1
Election Algorithms
2
Topics

• Issues
• Detecting Failures
• Bully algorithm
• Ring algorithm

3
Readings

• Van Steen and Tanenbaum 5.4
• Coulouris 11.3

4
Election Algorithms

• Remember using Lamport clocks for total order
• Can you think of another way to do this?
• It turns out that you can use a sequencer.
• All operations go to a sequencer
• The sequencer assigns numbers to each message
  before the message goes to each replica
• What if the sequencer goes down?

5
Election Algorithms

• Many distributed algorithms require a process to
  act as a coordinator.
• The coordinator can be any process that organizes
  actions of other processes.
• A coordinator may fail
• How is a new coordinator chosen or elected?

6
Election Algorithms

• Assumptions
• Each process has a unique number to distinguish
  them.
• One process per machine (which suggests that an
  IP address can be the unique identifier)
• Processes know each others process number
• Processes do not know which ones are currently up
  and which ones are down.
• General Approach
• Locate the process with the process with the
  highest process number and designate it as the
  coordinator.
• Election algorithms differ in how they do this.

7
Issues in Dealing with Coordinator Failure

• Detecting Failure
• Any node might detect failure first
• Multiple processes might detect failure at once.
• Election
• Must run without coordination
• Must deal with arbitrary process failures
• All nodes must agree on when election is over and
  who the new coordinator is.

8
Detecting Failures

• Timeouts are used to detect failures
• T 2Ttrans Tprocess
• Where Ttran is maximum transmission delay and
  Tprocess represents the maximum delay for
  processing a message.
• If a process fails to respond to a message
  request within T seconds then an election is
  initiated.

9
Bully Algorithm

• When a process, P, notices that the coordinator
  is no longer responding to requests, it initiates
  an election.
• P sends an ELECTION message to all processes with
  higher numbers.
• If no one responds, P wins the election and
  becomes a coordinator.
• If one of the higher-ups answers, it takes over.
  Ps job is done.

10
Bully Algorithm

• When a process gets an ELECTION message from one
  of its lower-numbered colleagues
• Receiver sends an OK message back to the sender
  to indicate that he is alive and will take over.
• Receiver holds an election, unless it is already
  holding one.
• Eventually, all processes give up but one, and
  that one is the new coordinator.
• The new coordinator announces its victory by
  sending all processes a message telling them that
  starting immediately it is the new coordinator.

11
Bully Algorithm

• If a process that was previously down comes back
• It holds an election.
• If it happens to be the highest process currently
  running, it will win the election and take over
  the coordinators job.
• Biggest guy always wins and hence the name
  bully algorithm.

12
The Bully Algorithm (Example)

• The bully election algorithm
• Process 4 holds an election
• Process 5 and 6 respond, telling 4 to stop
• Now 5 and 6 each hold an election

13
The Bully Algorithm (Example)

1. Process 6 tells 5 to stop
2. Process 6 wins and tells everyone

14
Bully AlgorithmAnalysis

• Best case
• The node with second highest identifier detects
  failure
• Total messages N-2
• One message for each of the other processes
  indicating the process with the second highest
  identifier is the new coordinator.
• Worst case
• The node with lowest identifier detects failure.
  This causes N-1 processes to initiate the
  election algorithm each sending messages to
  processes with higher identifiers.
• Total messages O(N2)

15
Bully Algorithm Discussion

• How many processes are used to detect a
  coordinator failure?
• As many as you want. You could have all other
  processes check out the coordinator.
• It is impossible for two processes to be elected
  at the same time.

16
Ring Algorithm

• Use a ring (processes are physically or logically
  ordered, so that each process knows who its
  successor is).
• Algorithm
• When a process notices that coordinator is not
  functioning
• Builds an ELECTION message (containing its own
  process number)
• Sends the message to its successor (if successor
  is down, sender skips over it and goes to the
  next member along the ring, or the one after
  that, until a running process is located).
• At each step, sender adds its own process number
  to the list in the message.

17
Ring Algorithm

• Algorithm (continued)
• When the message gets back to the process that
  started it all
• Process recognizes the message that contains its
  own process number
• Changes message type to COORDINATOR
• Circulates message once again to inform everyone
  else Who the new coordinator is (list member
  with highest number) Who the members of the new
  ring are.
• When message has circulated once, it is removed.
• Even if two ELECTIONS started at once, everyone
  will pick same leader since node with highest
  identifier is picked.

18
Ring Algorithm
19
Ring Algorithm
20
Ring Algorithm contd
21
Ring Algorithm Analysis

• At best 2(N-1 ) messages are passed
• One round for the ELECTION message
• One round for the COORDINATOR
• Assumes that only a single process starts an
  election.
• Multiple elections cause an increase in messages
  but no real harm done.

22
Summary

• Synchronization between processes often requires
  that one process acts as a coordinator.
• The coordinator is not fixed.
• Election algorithms determine the coordinator.
