Analog Filters

1
Lecture 6 Higher Order Filters Using Inductor
Emulation
2
Inductor Emulation Using Two-port Network
GIC (General Impedance Converter)
GII (General Impedance Inverter)
3
Gyrator
Positive Impedance Inverter
Floating inductor
4
Gyrator Example
Gyration resistance1/g11/g2R
5
Riordan Gyrator
6
Example
For Gyration resistance1kO
7
Antoniou GIC
8
Antoniou GIC
Inductance emulation is optimum in case of no
floating inductors i.e., LC high-pass filters
9
Example
3rd Order LPF
6th Order BPF
10
Brutons transformation
11
FDNR
Brutons inductor simulation based on FDNR Most
suitable for LC LPF with minimum cap realization
12
Filter Performance Design Trade-offs

• Transfer function
• (?0 , Q or BW, Gain, out-of-band attenuation,
  etc.)
• Sensitivity (component variations, parasitics)
• Dynamic range (DR)
• Maximum input signal (linearity)
• Minimum input signal (noise)
• Power dissipation Area

13
Maximum signal (supply limited)
14
Voltage swing scaling
15
Power dissipation
For nth order
16
Minimum signal (noise limited)

• Thermal noise of a resistor

17

• Example low-pass filter

18
Simple Example
Large power, large area
Large C, Small R
Large noise, parasitic sensitive
Large R, Small C
