Evolution of bacterial regulatory systems

1
Evolution of bacterial regulatory systems

• Mikhail Gelfand
• Research and Training Center Bioinformatics
• Institute for Information Transmission Problems
• Moscow, Russia

ASM, Philadelphia, 18.IV.2009
2
Catalog of events

• Expansion and contraction of regulons
• New regulators (where from?)
• Duplications of regulators with or without
  regulated loci
• Loss of regulators with or without regulated loci
• Re-assortment of regulators and structural genes
• especially in complex systems
• Horizontal transfer

3
Trehalose/maltose catabolism in
alpha-proteobacteria
Duplicated LacI-family regulators
lineage-specific post-duplication loss
4
The binding motifs are very similar (the blue
branch is somewhat different to avoid
cross-recognition?)
5
Utilization of an unknown galactoside in
gamma-proteobacteria
Yersinia and Klebsiella two regulons, GalR and
Laci-X
Erwinia one regulon, GalR
Loss of regulator and merger of regulons It
seems that laci-X was present in the common
ancestor (Klebsiella is an outgroup)
6
Utilization of maltose/maltodextrin in Firmicutes
Displacement invasion of a regulator from a
different subfamily (horizontal transfer from a
related species?) blue sites
7
Orthologous TFs with completely different
regulons (alpha-proteobaceria and Xanthomonadales)
8
Cryptic sites and loss of regulators
Loss of RbsR in Y. pestis (ABC-transporter also
is lost)
RbsR binding site
Start codon of rbsD
9
Regulon expansion, or how FruR has become CRA

• CRA (a.k.a. FruR) in Escherichia coli
• global regulator
• well-studied in experiment (many regulated genes
  known)
• Going back in time looking for candidate
  CRA/FruR sites upstream of (orthologs of) genes
  known to be regulated in E.coli

10
Common ancestor of gamma-proteobacteria
Mannose
Glucose
ptsHI-crr
manXYZ
edd
epd
eda
adhE
aceEF
icdA
ppsA
pykF
mtlD
mtlA
Mannitol
pckA
gpmA
pgk
gapA
fbp
pfkA
aceA
tpiA
fruK
fruBA
Fructose
aceB
Gamma-proteobacteria
11
Common ancestor of the Enterobacteriales
Mannose
Glucose
ptsHI-crr
manXYZ
edd
epd
eda
adhE
aceEF
icdA
ppsA
pykF
mtlD
mtlA
Mannitol
pckA
gpmA
pgk
gapA
fbp
pfkA
aceA
tpiA
fruK
fruBA
Fructose
aceB
Gamma-proteobacteria Enterobacteriales
12
Common ancestor of Escherichia and Salmonella
Mannose
Glucose
ptsHI-crr
manXYZ
edd
epd
eda
adhE
aceEF
icdA
ppsA
pykF
mtlD
mtlA
Mannitol
pckA
gpmA
pgk
gapA
fbp
pfkA
aceA
tpiA
fruK
fruBA
Fructose
aceB
Gamma-proteobacteria Enterobacteriales E. coli
and Salmonella spp.
13
Regulation of amino acid biosynthesis in the
Firmicutes

• Interplay between regulatory RNA elements and
  transcription factors
• Expansion of T-box systems (normally RNA
  structures regulating aminoacyl-tRNA-synthetases)

14
Why T-boxes?

• May be easily identified
• In most cases functional specificity may be
  reliably predicted by the analysis of the
  specifier codons (anti-anti-codons)
• Sufficiently long to retain phylogenetic signal
• gt T-boxes are a good model of regulatory
  evolution

15
Partial alignment of predicted T-boxes
TGG T-box
Aminoacyl-tRNA synthetases
Amino acid biosynthetic genes
Amino acid transporters
16
continued (in the 5 direction)
anti-anti (specifier) codon
Aminoacyl-tRNA synthetases
Amino acid biosynthetic genes
Amino acid transporters
17
805 T-boxes in 96 bacteria

• Firmicutes
• aa-tRNA synthetases
• enzymes
• transporters
• all amino acids excluding glutamate
• Actinobacteria (regulation of translation
  predicted)
• branched chain (ileS)
• aromatic (Atopobium minutum)
• Delta-proteobacteria
• branched chain (leu enzymes)
• Thermus/Deinococcus group (aa-tRNA synthases)
• branched chain (ileS, valS)
• glycine
• Chloroflexi, Dictyoglomi
• aromatic (trp enzymes)
• branched chain (ileS)
• threonine

18
Recent duplications and bursts ARG-T-box in
Clostridium difficile
19
caused by loss of transcription factor AhrC
20
Duplications and changes in specificity
ASN/ASP/HIS T-boxes
21
Blow-up 1
22
Blow-up 2. Prediction

• Regulators lost in lineages with expanded
  HIS-T-box regulon??

23
and validation

• conserved motifs upstream of HIS biosynthesis
  genes
• candidate transcription factor yerC co-localized
  with the his genes
• present only in genomes with the motifs upstream
  of the his genes
• genomes with neither YerC motif nor HIS-T-boxes
  attenuators

Bacillales (his operon)
Clostridiales Thermoanaerobacteriales Halanaerobia
les Bacillales
24
The evolutionary history of the his genes
regulation in the Firmicutes
25
More duplications THR-T-box in C. difficile and
B. cereus
26
T-boxes Summary / History
27
Life without Fur
28
Regulation of iron homeostasis (the Escherichia
coli paradigm)

• Iron
• essential cofactor (limiting in many
  environments)
• dangerous at large concentrations
• FUR (responds to iron)
• synthesis of siderophores
• transport (siderophores, heme, Fe2, Fe3)
• storage
• iron-dependent enzymes
• synthesis of heme
• synthesis of Fe-S clusters
• Similar in Bacillus subtilis

29
Regulation of iron homeostasis in a-proteobacteria

• Experimental studies
• FUR/MUR Bradyrhizobium, Rhizobium and
  Sinorhizobium
• RirA (Rrf2 family) Rhizobium and Sinorhizobium
• Irr (FUR family) Bradyrhizobium, Rhizobium and
  Brucella

30
Distribution of transcription factors in genomes
Search for candidate motifs and binding sites
using standard comparative genomic techniques
31
FUR/MUR branch of the FUR family
32
FUR and MUR boxes
Erythrobacter litoralis
Caulobacter crescentus
Novosphingobium aromaticivorans
Zymomonas mobilis
Sphinopyxis alaskensis
Oceanicaulis alexandrii
Rhodospirillum rubrum
Gluconobacter oxydans
Magnetospirillum magneticum
Parvularcula bermudensis -
Identified Mur-binding sites
Bacillus subtilis
Sequence logos for the known Fur-binding sites
in Escherichia coli and Bacillus subtilis
Mur
a
of - proteobacteria -
Escherichia coli
33
Irr branch of the FUR family
34
Irr boxes

• Rhizobiaceae plus
• Bradyrhizobiaceae
• Rhodobacteriaceae
• Rhodospirillales

35
RirA/NsrR family (Rhizobiales)
36
IscR family
37
Regulation of genes in functional subsystems
Rhizobiales
Bradyrhizobiaceae
Rhodobacteriales
The Zoo (likely ancestral state)
38
Reconstruction of history
Frequent co-regulation with Irr
Strict division of function with Irr
Appearance of theiron-Rhodo motif
39
All logos and Some Very Tempting Hypotheses
2

1. Cross-recognition of FUR and IscR motifs in the
   ancestor.
2. When FUR had become MUR, and IscR had been lost
   in Rhizobiales, emerging RirA (from the Rrf2
   family, with a rather different general
   consensus) took over their sites.
3. Iron-Rhodo boxes are recognized by IscR directly
   testable

1
3
40
Summary and open problems

• Regulatory systems are very flexible
• easily lost
• easily expanded (in particular, by duplication)
• may change specificity
• rapid turnover of regulatory sites
• With more stories like these, we can start
  thinking about a general theory
• catalog of elementary events how frequent?
• mechanisms (duplication, birth e.g. from enzymes,
  horizontal transfer)
• conserved (regulon cores) and non-conserved
  (marginal regulon members) genes in relation to
  metabolic and functional subsystems/roles
• (TF family-specific) protein-DNA recognition code
• distribution of TF families in genomes
  distribution of regulon sizes etc.

41
People

• Andrei A. Mironov software, algorithms
• Alexandra Rakhmaninova SDP, protein-DNA
  correlations
• Olga Kalinina (on loan to EMBL) SDP
• Yuri Korostelev protein-DNA correlations
• Olga Laikova LacI
• Dmitry Ravcheev CRA/FruR
• Dmitry Rodionov (on loan to Burnham Institute)
  iron etc.
• Alexei Vitreschak T-boxes and riboswitches
• Andy Jonson (U. of East Anglia) experimental
  validation (iron)
• Leonid Mirny (MIT) protein-DNA, SDP
• Andrei Osterman (Burnham Institute)
  experimental validation

• Howard Hughes Medical Institute
• Russian Foundation of Basic Research
• Russian Academy of Sciences, program Molecular
  and Cellular Biology
