Telescopes and the Atmosphere

1
Telescopes and the Atmosphere
2
Attendance Quiz
Are you here today? (a) yes (b) no (c) here? do
you mean physically, mentally, or what?
3
Midterm 1
4
Exam Grades

• To help those of you who may have struggled on
  the first midterm, I am instituting the following
  exam grading policy
• The lower of your two midterms scores can be
  replaced by your final exam, if your final score
  is higher than either midterm
• Thus, if you get a final exam score higher than
  either midterm, the exam portion of your grade
  (which is 60 of your total grade) will be 40
  final exam, 20 higher midterm
• If you get a final exam score lower than both
  midterms, your exam grade will be 20 final exam,
  20 each of the two midterms
• Thus, even if you bombed the first midterm, you
  can still do well in this class
• This policy only applied to exams you take. If
  you skip the second midterm, it will count as a
  zero, no matter what!
• Remember, there is no curve in this class, so
  everyone wins with this policy!

5
Todays Topics

• Telescopes
• Your eye v. a telescope
• Collecting area
• Angular resolution
• Reflecting v. refracting telescopes
• What are telescopes used for?
• Non-optical telescopes
• The Atmosphere
• Light pollution
• Twinkling
• Atmospheric transmission
• Telescopes in space

6
Your Eye v. a Telescope I

• Fundamentally, your eye and a telescope work in a
  similar manner - light is bent by a lens (or
  mirror) to make an image

7
Your Eye v. a Telescope II

• There are three major
• advantages that a telescope
• has over your eye
• A telescope has a larger area to collect light
  and therefore can see fainter objects
• A detecting device can be attached to a telescope
  to collect light for a longer time
• A telescope has better angular resolution than
  your eye

8
Collecting Area

• The sensitivity to light of a telescope is a
  function of its collecting area
• This is the area of the primary light collecting
  surface
• Most telescopes are described by the diameter of
  their primary mirror (or lens)
• Area pr2 p(D/2)2 (p/4)D2 0.8D2
• For Gemini, the area is 0.8(8m)2 50m2
• (about 106 times your dilated pupil)
• Since collecting area is proportional to the
  square of the diameter, a telescope with twice
  the diameter will have four times the collecting
  area

9
Collecting Area Quiz
One Keck telescope on Mauna Kea has a diameter of
10m, compared to 5m for the Palomar telescope.
The light gathering power of the Keck is larger
by a factor of a) 2 b) 4 c) 15 d) 50 e) There
is not enough information to tell
10
Angular resolution

• Angular resolution refers to the ability to
  distinguish two objects that appear very close
  together in the sky
• In the absence of blurring effects from the
  atmosphere, the angular resolution of a telescope
  is determined by the wavelength of light and the
  diameter of the telescope
• A small angular resolution is good because it
  means you can separate objects that are very
  close together
• Angular resolution is determined by the formula ?
  ?/D

11
Angular Resolution Quiz
The Hubble Space Telescope has a primary mirror
diameter of 2.4 m. The Keck telescopes, which
use adaptive optics to correct for atmospheric
effects, have a primary mirror diameter of 10 m.
The angular resolution (ability to see details)
of the Keck telescopes is smaller (better) than
the Hubble Telescope by a factor of about a)
2.4 b) 4 c) 10 d) 16 e) 24
12
Refracting v. Reflecting Telescopes

• Refracting telescopes use a lens (like your eye
  but larger) to create an image
• Reflecting telescopes use a mirror to focus light
• Advantages of a reflecting over a refracting
  telescope
• A lens of a given size is heavier than a mirror,
  which can be made of a thin or honeycombed
  lightweight material with a thin aluminum coating
• The lens of a large refracting telescope will
  distort (sag) under its own weight
• The lens in a refracting telescope must be very
  high quality
• Different colors of light are bent differently,
  so colors are not all focussed together in a
  refracting telescope (chromatic aberration)

13
What are telescopes used for? - Imaging

• The primary use of a telescope is to make an
  image of an object
• Originally, images were captured on photographic
  film modern detectors are electronic (like the
  CCD chip in your digital camera)
• Every image consists of only certain wavelengths
  of light
• Astronomers often use filters that only allow
  certain colors or wavelengths to pass through
• The image at right is actually a composite image
  of 3 colors
• Most color images in astronomy are made this way

14
What are telescopes used for? - Spectroscopy

• Another common use of telescopes is to take a
  spectrum of an object, a process known as
  spectroscopy
• A spectrum consists of a plot of relative
  brightness of an object as a function of
  wavelength
• The resolution of a spectrum (the spectral
  resolution) determines how much detail can be
  seen (similar to how angular resolution
  determines how much spatial detail can be seen in
  an image
• As we will learn later, the spectrum of an object
  can be like a signature for certain elements
  being present in the object

15
Electromagnetic Spectrum

• There are many types of EM radiation besides
  visible light
• Astronomers are interested in all types of EM
  radiation from astronomical objects
• Some things can only be learned by observing
  outside the visible portion of the spectrum

16
Non-optical telescopes

• Telescopes, and detectors, can be built to detect
  radiation from throughout the EM spectrum
• Because of the spectral resolution equation (?
  ?/D), radio telescopes are often much larger than
  optical telescopes
• It is also possible to combine multiple
  telescopes to create a telescope with the angular
  resolution (but not collecting area) of a larger
  telescope

Arecibo Radio Telescope Diameter is 305 m (1000
ft)
17
Very Long Baseline Array (VLBI)
18
Non-optical telescopes

• As we will see shortly, the atmosphere only
  transmits certain wavelengths thus, to observe
  those wavelengths it is necessary to observe from
  balloons, airplanes, and space

19
Telescopes and the Atmosphere

• The atmosphere is vital to our existence, not
  least because we breathe it!
• However, for astronomers, the atmosphere is a
  nuisance, and sometimes they need to work around
  its limitations
• One example of this is light pollution
• Notice the difference between this image of the
  sky from a city
• and this one from a dark site

20
Telescopes and the Atmosphere

• The atmosphere is turbulent, causing light from
  space to appear to jitter or jump around
• This happens so fast, that our eyes perceive this
  as twinkling, and the image of a star is
  smeared out
• By going into space (or by using fancy correction
  schemes known as adaptive optics) it is possible
  to eliminate this problem, and reach the
  theoretical angular resolution of the telescope
  (? ?/D)

21
Telescopes and the Atmosphere

• The atmosphere absorbs and scatters radiation
  from space
• This can be beneficial, as in the case of UV
  radiation
• However, astronomers see the atmosphere as a
  nuisance, and sometimes need to work around its
  limitations
• Some wavelengths can only be seen on mountaintops
  (e.g., IR), others from airplanes or balloons
  (far-infrared, gamma rays) and still others only
  from space (UV, X-rays)

22
Non-ground-based telescopes

• As we have seen, there are many reasons for some
  telescopes to be placed in other places besides
  the ground
• Moving to a mountaintop can improve observing at
  visible wavelengths, and most major observatories
  are at high altitude
• Some wavelengths (e.g., far-infrared) can be
  observed from airplane altitudes
• Some wavelengths can only be observed from space
• In addition, there are advantages (but also
  costs) of observing all wavelengths in space
  (e.g., Hubble)

23
Telescopes Quiz I
Which of the following wavelengths can be easily
observed by a telescope located on the Earths
surface? a) gamma ray b) X-ray c) ultraviolet
d) radio e) none of the above wavelengths
24
Lecture Tutorial Telescopes Earths
Atmosphere, pp. 49-51

• Work with one or more partners - not alone!
• Get right to work - you have 15 minutes
• Read the instructions and questions carefully.
• Discuss the concepts and your answers with one
  another. Take time to understand it now!!!!
• Come to a consensus answer you all agree on.
• Write clear explanations for your answers.
• If you get stuck or are not sure of your answer,
  ask another group.
• If you get really stuck or dont understand what
  the Lecture Tutorial is asking, ask me for help.

25
Telescopes Quiz II
Imagine that you are the head of a funding agency
that can afford to build one telescope. Which
of the following proposed telescopes would be
best to support? a) a radio telescope in orbit
around Earth b) an ultraviolet telescope in orbit
around Earth c) an X-ray telescope located in
New Mexico
26
Telescopes Quiz III

• For the last question of the tutorial, you had to
  choose between
• Project Zeta, a radio telescope, on the desert
  floor, which will be used to detect potential
  communications from distant civilizations, and
• Project Epsilon, an infrared telescope, located
  in the high-elevation mountains of Chile, which
  will be used to view newly forming stars
• Which did you choose to fund?
• Project Zeta
• Project Epsilon

27
Cal Poly Pomona students participate in SETI
researchAstrobiology and the Search for
Extraterrestrial Intelligence

• Research at the SETI Institute in Mountain View,
  California
• Projects include
• IR spectrocsopy of ethane/water mixtures to study
  early solar system (Ashley Curry)
• Planetary geology and geomorphology of Mars
  (Amber Butcher)
• Mapping of meteor showers to study matter in the
  Solar System (Steffi Valkov)

Part of the Allen Telescope Array (ATA)
SETI Gurls
28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
Real life v. the Movies
32
Special Public Lecture

• Are We Alone?
• Dr. Jill Tarter
• Director for SETI Research
• SETI Institute
• Friday, May 6
• 7pm
• Ursa Major C
• 5 clicker points extra credit for attending
