Chapter Sixteen

1
Chapter Sixteen

• Carboxylic Acids, Esters, and Other Acid
  Derivatives

2
Carboxylic Acids

• Fig. 16.1
• The three simplest carboxylic acids methanoic
  acid, ethanoic acid, and propanoic acid.

3
Carboxylic Acids

• Fig. 16.2
• Benzoic acid molecule

4
Carboxylic Acids

• Carboxylic acids contain the carboxyl group on
  carbon 1.
• A carboxyl group is a carbonyl attached to a
  hydroxyl
• Acts differently than an alcohol or a carbonyl
  compound
• O
• ??
• CH3 COH CH3COOH
• carboxyl group

5
Naming Carboxylic Acids

• Formula IUPAC Common
• alkan -oic acid prefix ic acid
• HCOOH methanoic acid formic acid
• CH3COOH ethanoic acid acetic
  acid
• CH3CH2COOH propanoic acid propionic
  acid
• CH3CH2CH2COOH butanoic acid
  butyric acid

6
Naming Rules

• Identify longest chain containing the carboxyl
  group
• (IUPAC) Number carboxyl carbon as 1
• (Common) Assign ?, ?, g to carbon atoms adjacent
  to carboxyl carbon
• CH3
• CH3 CHCH2 COOH
• IUPAC 3-methylbutanoic acid
• Common ?-methylbutryic acid

7
Aromatic Carboxylic Acids

• Benzoic Acid is the aromatic carboxylic acid
• Locates substituents by assigning 1 to the carbon
  with the carboxyl group

3-chlorobenzoic acid
Benzoic acid
4-methylbenzoic acid
8
(No Transcript)
9
(No Transcript)
10
Properties of Carboxylic Acids

• Like alcohols, carboxylic acids form strong
  intermolecular hydrogen bonds.
• Most carboxylic acids exist as dimers.
• Boiling points higher than alkanes of similar MW.
• Small carboxylic acids (1-4 carbons) are soluble
  in water

11
(No Transcript)
12
Synthesis of Carboxylic Acids

• Synthesized from aromatic rings, primary
  alcohols and aldehydes.

Carboxylic Acid
13
Oxidation of Aromatic Compounds

• Benzene does not react with KMnO4.
• Alkyl groups on the ring (-R) are readily
  oxidized though.
• One product for all reactions.

14
Oxidation of Aromatic Compoundswith KMnO4
15

• Oxidation of primary alcohols and aldehydes

16

• Oxidation of alcohols to carboxylic acids.

17
Properties

• Carboxylic acids are weak acids
• Stronger acids than alcohols
• CH3COOH H2O CH3COO H3O
• Neutralized by a base
• CH3COOH NaOH CH3COO Na H2O

18

• Carboxylic acids are obviously acidic.
• Stronger acids than alcohols, but weaker than
  mineral acids.
• Will react with NaOH to give metal carboxylates.
• There is a large range of acidities depending on
  the substituents on a carboxylic acid.

19
Carboxylate Ions

• The conjugate base of a carboxylic acid
• Formed when a carboxylic acid loses a proton
• Named by dropping the -ic acid ending and
  replacing it with ate
• CH3CH2COO- Propionate
• CH3COO- Ethanoate (Acetate)
• CH3CH2CH2COO- Butanoate

20
Carboxylate Salts

• An ionic compound in which the negative ion is a
  carboxylate ion
• Naming the positive ion is named first,
  followed by a separate word giving the name of
  the negative ion
• Converted back to a carboxylic acid by the
  addition of a strong acid
• CH3CH2COO-Na Sodium Propionate
• CH3COO-K Potassium Ethanoate
• CH3CH2CH2COO-Li Lithium Butanoate

21
Carboxylic Acids

• Table 16.3

22
Esters

• Fig. 16.12
• Methyl and ethyl esters of acetic acid.

23
Ester

• In an ester, the H in the carboxyl group is
  replaced with an alkyl group
• O
• ??
• CH3 CO CH3 CH3COO CH3
• ester group
• Sulfur analogs of esters are called thioesters
  (sulfur replaces the hydroxyl oxygen)

24
Naming Esters

• Name the alkyl from the alcohol O-
• Name the acid with the CO with ate
• acid alcohol
• O
• ?? methyl
• CH3 CO CH3
• Ethanoate methyl ethanoate (IUPAC)
• (acetate) methyl acetate (common)

25
(No Transcript)
26
Esters
27
Esterification Preparation of Esters

• Reaction of a carboxylic acid and alcohol
• Acid catalyst
• O
• ?? H
• CH3 COH HOCH2CH3
• O
• ??
• CH3 COCH2CH3 H2O

28
Hydrolysis Breaking Up Esters

• Esters react with water and acid catalyst
• Split into carboxylic acid and alcohol
• O
• ?? H
• H COCH2CH3 H2O
• O
• ??
• H COH HOCH2CH3

29
Hydrolysis
30
Saponification

• Esters react with bases
• Produce the salt of the carboxylic acid and
  alcohol
• O
• ?? H2O
• CH3COCH2CH3 NaOH
• O
• ??
• CH3CO Na HOCH2CH3
• salt of carboxylic acid
• Saponification reactions produce soaps

31
Soaps

• Carboxylate salts

32

• The following figure represents soap.
• Which end of the anion is hydrophobic?

33

• How does soap interact with grease?

34
(No Transcript)
35
(No Transcript)
36
(No Transcript)
37
Dicarboxylic Acids
38
The C2 dicarboxylic acid, oxalic acid,
contributes to the tart taste of rhubarb stalks.
39
Polyfunctional Carboxylic Acids

• Carboxylic acids that contain one or more
  additional functional groups
• Unsaturated acids
• Contain a multiple bond
• Hydroxy acids
• Contains an additional hydroxyl group
• Keto acids
• Contains an additional carbonyl group
• Many monoacids and polyfunctional carboxylic
  acids are intermediates in metabolic reactions
