IPC144 - Session2

1
IPC144 Session 2 Computer Organization, Problem
Analysis and Program Design
1
2

• Objectives
• By the end of this session, the student will be
  able to
• List the first three stages of the evolution of
  computer languages
• Compare the three stages from a programmer's
  point of view
• List other 3GL languages
• Construct Boolean Logic Charts
• Apply Boolean Logic to problems
• List the steps in a model Systems Development
  Life Cycle
• Describe the purpose of each of the model steps
• List the 7 steps of a model Program Development
  Cycle
• Describe the purpose of each step of the PDC
• List the steps that occur when compiling a
  computer program

4
3
Software

• Software
• Software is a set of instructions that cause the
  computer to perform specific tasks in a specific
  order, and make simple decisions about the data
  it encounters. The software must be written by
  people in order to be supplied to the computer.
  The software is written in a specialized
  language.
• There have been many generations of computer
  languages
• machine language
• assembly language
• high-level language (3GL)?
• very high-level language (4GL)?
• natural language

5
4
Software, continued

• Machine Language Software
• This software is in the language of the
  processor. This language is not easily readable
  by humans as it consists of numbers only.
• The instructions will consist of
• op-codes (operation codes) and,
• operands (sometimes)?
• Op-codes
• The op-codes are fetched and decoded by the
  Control Unit, and executed by the ALU.
• Operands
• The operands are either scalar data (a fixed
  number, such as 5) or a memory address where data
  is stored. These are also fetched by the Control
  Unit for use by the ALU.

6
5
Software, Continued
Machine language for Motorola 6809 (8-bit
CPU)? 00 01 02 03 04 05 06 07 08 09 0A 0B 0C 0D
0E 0F 10 11 12 4F 97 13 96 12 27 09 4A 97 12 96
13 9B 11 20 F1 3E 02 05 address op-code operand d
ata The above program multiplies two numbers by
repeated addition. i.e. 5 x 2 2 2 2 2
2
7
6
Software, Continued
Assembly language This is a small step forward.
The numeric instructions from machine language
have been replaced by mnemonics. This makes the
programs must easier to read, however it still
takes patience and a disciplined approach. There
are some pockets of assembly programming that
still exist. The mnemonics are designed for each
individual processor, however there are some
mnemonics that you may see from processor to
processor. These mnemonics are not understood by
the computer, so a simple program, called an
Assembler, converts the mnemonics to numbers,
and ultimately you end up with machine
language. The advantage of assembly is that the
programs written are very compact and run very
fast.
8
7
Software, Continued
Assembly language for Motorola 6809 (8-bit
CPU)? 0000 4F CLRA 0001 97 13 LOOP STA
_at_13 0003 96 12 LDA _at_12 0005 27 09 BEQ
DONE 0007 4A DECA 0008 97 12 STA
_at_12 000A 96 13 LDA _at_13 000C 9B 11 ADD
_at_11 000E 20 F1 BRA LOOP 000F 3E DONE HLT 00
11 02 0012 05 0013 Address Machine
Language (output from assembler)? Assembly
Language (written by programmer)?
9
8
Software, continued
High-level language There are many high-level
languages that exist. In these languages, the
programmer is using something that almost passes
as a human language. However, programs written
in these languages must be converted to machine
language. The advantage to these languages is
that there are relatively easy to learn, although
you might not believe me when we start talking
about C. The disadvantage is that the machine
code that is generated is not as optimized as
code written directly in machine language. These
languages are not specific to a particular
processor- therefore they are easily transported
from processor to processor.
10
9
Software, continued
High-level language, continued The assembly
program in C How it would actually be written
in C i 5 i 5 j 2 j 2 k
0 k i j while (i gt 0)? k k
j i--
11
10
Software, continued

• High-level language, continued
• Other 3GL languages
• TAL (for Tandem computers)?
• Turing (developed by University of Toronto, to
  teach well structured programming)?
• COBOL (a language for business applications)?
• FORTRAN (FORmula TRANslation - scientific and
  engineering applications)?
• PASCAL (a simple well structured language)?
• BASIC (a simple initially unstructured language
  for learning programming)?

12
11
Boolean Logic

13
12
Boolean Logic
Boolean logic Developed by George Boole in the
19th century. A form of logical algebra, as
opposed to mathematical algebra. We are
concerned with TRUE or FALSE values instead of
numbers. Sometimes the digits 1 and 0 or the
letters T and F are used to represent the values
of TRUE and FALSE respectively. The algebra will
consist of statements that can be evaluated to
being either TRUE or FALSE 'Today is Saturday'
- FALSE 'You are in a lecture' - TRUE 'You are
asleep in the lecture' - ??
14
13
Boolean Logic, continued
Boolean logic, continued The expressions being
evaluated will be mathematical expressions in
this course 5 6 a gt b a 4 lt c - 1 These
expressions will evaluate to either TRUE or FALSE
depending on the algebraic value of the
variables. a gt b would be TRUE if 'a' was 5 and
'b' was 4. a gt b would be FALSE if 'a' was 4 and
'b' was 5. We can now take the results of the
expressions and apply Boolean operators to them.
15
14
Boolean Logic, continued

• Truth Tables
• The Boolean algebra is summarized in 'Truth
  Tables'. There are two sections to the Truth
  Table
• Conditions
• Result
• Conditions
• There are 1 or more columns in the Conditions
  section, depending on the number of possible
  combinations of TRUE and FALSE being tested.
• 1 column 2 possible conditions
• 2 columns 4 possible conditions
• 3 columns 8 possible conditions
• n columns 2n possible conditions
• Result
• The result column will contain only 1 possible
  outcome for each condition, the result will be
  either TRUE or FALSE.

16
15
Boolean Logic, continued
Boolean NOT operator The Boolean NOT operator
simply reverses the values of TRUE and FALSE.
There is only one possible column in the
conditions section Examples
(assuming x is TRUE, y is FALSE) NOT x result
is FALSE NOT y result is TRUE NOT (5 lt
6) result is FALSE
17
16
Boolean Logic, continued
Boolean OR operator The Boolean OR (also known as
Inclusive-OR) looks for any conditions that
contains at least one TRUE value Ex
amples (assuming x is TRUE, y is FALSE) x OR
y result is TRUE y OR y result is FALSE x OR
x result is TRUE (7 gt 8) OR (1 lt 2) result is
TRUE
18
17
Boolean Logic, continued
Boolean OR operator, continued An extended OR
Truth Table
19
18
Boolean Logic, continued
Boolean AND operator The Boolean AND looks for
any conditions that contain all TRUE
values Examples (assuming x is
TRUE, y is FALSE) x AND y result is FALSE y
AND y result is FALSE x AND x result is
TRUE (7 gt 8) AND (1 lt 2) result is FALSE
20
19
Boolean Logic, continued
Boolean AND operator, continued An extended AND
Truth Table
21
20
Boolean Logic, continued
Boolean Exclusive-OR operator The Boolean XOR
looks for any conditions that contain an odd
number of TRUE values Examples
(assuming x is TRUE, y is FALSE) x XOR
y result is TRUE y XOR y result is FALSE x
XOR x result is FALSE (7 gt 8) XOR (1 lt
2) result is TRUE
22
21
Boolean Logic, continued
Boolean XOR operator, continued An extended XOR
Truth Table
23
22
Boolean Logic, continued
Order of Precedence Just as in mathematics, you
have an order of precedence when calculating an
expression. What is the result of 5 22 x 2 /
4 (7 6 x 7) - 2 x 7 In Boolean Algebra, the
order of precedence, (unless overridden by
brackets) is perform NOT operations
first, followed by AND operations, followed by
XOR operations, followed by OR. Just like
multiplication is transitive in Mathematics, the
Boolean AND, OR and XOR are transitive. a x b x c
c x b x a b x a x c c x a x b b x c x a
a x c x b a b c c b a b a c c
a b b c a a c b What is the Truth
Table for a AND b XOR c? a AND b XOR NOT
c OR b?
24
23
Boolean Logic, continued
Order of Precedence What is the Truth Table
for a AND b XOR c?
25
24
Boolean Logic, continued
Order of Precedence What is the Truth Table
for a AND b XOR NOT c OR b?
26
25
Boolean Logic, continued
Exercises 1) What is the Truth Table for a AND
NOT b OR NOT a AND b 2) TRUE AND FALSE OR NOT
FALSE Assuming the variables X, Y and Z have
been assigned the values 5, 7 and 12
respectively, what is the result (TRUE or FALSE)
of the following expressions 3) X 5 4) X lt
Y 5) X Y gt Z 6) (X gt 5) OR (Y gt 5)? 7) NOT (X
5)? 8) (X Y gt Z) AND (Z lt 24) OR NOT (Y lt
3)? 9) Create an expression that will result in
TRUE when any of the variables (A, B, C) are
greater than 0. A, B, C can be any number,
positive, negative, fractional. 10) Create an
expression that will result in FALSE only when
all three variables (A, B, C) are equal to 0) A,
B, C can be any number, positive, negative,
fractional.
27
26
Boolean Logic, continued
Exercises 1) What is the Truth Table for a AND
NOT b OR NOT a AND b - see XOR table 2) TRUE AND
FALSE OR NOT FALSE - TRUE Assuming the variables
X, Y and Z have been assigned the values 5, 7 and
12 respectively, what is the result (TRUE or
FALSE) of the following expressions 3) X 5 -
TRUE 4) X lt Y - TRUE 5) X Y gt Z - FALSE 6) (X gt
5) OR (Y gt 5) - TRUE 7) NOT (X 5) - FALSE 8) (X
Y gt Z) AND (Z lt 24) OR NOT (Y lt 3) - TRUE 9)
Create an expression that will result in TRUE
when any of the variables (A, B, C) are greater
than 0 - (Agt0) OR (Bgt0) OR (Cgt0)? 10) Create an
expression that will result in FALSE only when
all three variables (A, B, C) are equal to 0) -
NOT (A0) OR NOT(B0) OR NOT (C0)?
28
27
Systems Development Life Cycle


29
28
Systems Development Life Cycle

• Background
• As systems become more complex, and businesses
  become more reliant on computers, means to
  structure the way new software is delivered is
  needed. There are two aspects that will be
  discussed
• System Development Life Cycle
• Program Development Cycle
• The Program Development Cycle is a subset of the
  System Development Life Cycle.
• The following slides will provide an overview of
  SDLC and PDC. The section on PDC will be
  investigated closer for the remainder of the
  course.

30
29
Systems Development Life Cycle

• System Development Life Cycle
• The steps of the System Development Life Cycle
  are
• Analyse System
• Define System Requirements
• Design New System
• Develop New System
• Accept New System
• Implement System
• These steps are guidelines, and are not cast in
  stone. Each company will have some variation of
  these steps. There may be more steps, or some
  steps will be combined.

31
30
Systems Development Life Cycle

• SDLC Analyse System
• Performed on existing manual systems as well as
  existing automated systems
• Performed by System Analyst
• Most effectively performed by interviewing the
  users
• Identify what is done, and how
• Identify any problems with current system
• Go-No Go Decision based on ROI estimates

32
31
Systems Development Life Cycle

• SDLC Define System Requirements
• What changes are required
• System Analyst works with Business Analyst
• Develop 'look and feel' of new system
• Determine what needs to be done (not how)?
• Every input, output and process is documented
• Output reports, screen designs
• Input what data, where does it come from
• Process what activities are required to produce
  the output
• Go-No Go Decision

33
32
Systems Development Life Cycle

• SDLC Design New System
• Define all programs, files, databases, manual
  processes
• System Flowcharts are a common tool
• Like a program flowchart
• Major inputs
• Major outputs
• Inter-relationships between entities in system
• No details as to how the programs work

34
33
Systems Development Life Cycle

• SDLC Develop New System
• Involves designing, coding and unit-testing
• Uses Program Development Cycle
• Goal is high-quality well structured programs
• Main focus of the remainder of this course

35
34
Systems Development Life Cycle

• SDLC Accept New System
• Performed by Business user or Representative who
  has intimate knowledge of Business functionality
  of the system
• Entire system is tested to ensure it conforms to
  the System Requirements (Phase 2)?
• Assumes no knowledge of internal workings of
  system
• System documentation reviewed
• Implementation strategies discussed
• Users trained

36
35
Systems Development Life Cycle

• SDLC Implement New System
• When the new system is implemented into the
  production environment
• Evaluation of new system (comparison between the
  expected objectives and the actual results)?
• Results of the evaluation may become the input to
  a subsequent SDLC

37
36
Program Development Cycle


38
37
Program Development Cycle

• Program Development Cycle
• The steps of the Program Development Cycle are
• Define the Problem
• Outline the Solution
• Develop the Solution into an Algorithm
• Test the Algorithm for Correctness
• Code the Program into a Specific Language (C)?
• Run the Program on the Computer
• Document and Maintain the Program
• These steps are guidelines, and are not cast in
  stone. Each company will have some variation of
  these steps. There may be more steps, or some
  steps will be combined.

39
38
Program Development Cycle

• PDC Define the Problem
• Must have a clear understanding of the problem
• There is no room for assumptions
• There is no difference between solving the wrong
  problem correctly and solving the right problem
  incorrectly
• To help with analysis, the problem should be
  broken into
• Inputs
• Outputs
• Processes
• IPO Charts are a tool used

40
39
Program Development Cycle

• PDC Outline the Solution
• Break problem into smaller tasks or steps
• Create a rough draft of the solution, may include
• Major processing steps
• Major sub-tasks (if any)?
• Major control structures (repetition loops)?
• Major variables and record structures
• Mainline logic of the program
• Top-down design
• Modularity and Hierarchy charts are tools used

41
40
Program Development Cycle

• PDC Develop the Outline into an Algorithm
• Computers cannot devise a plan or decide to act
• Computers can only do what they are told, exactly
  the way they are told
• Computers do what you tell them to do, not what
  you want them to do
• An algorithm is a set of precise instructions
  which describe the task to be performed and the
  order in which they are to be carried out
• Flowcharts and Pseudocode are tools to be
  discussed

42
41
Program Development Cycle

• PDC Test the Algorithm for Correctness
• One of the most important steps
• Identifies major logic errors
• Walkthroughs are a technique for testing
• Test plans are used to document and plan the
  tests necessary to prove your algorithm performs
  as required

43
42
Program Development Cycle

• PDC Code the Program
• Performed only after previous design
  considerations have been complete
• In this course the C language will be used,
  although these techniques can be used for any
  language (Fortran, COBOL, BASIC, Pascal, Turing,
  TAL...)?
• Unfortunately, this is where many people begin
  PDC or SDLC

44
43
Program Development Cycle

• PDC Run the Program
• Most will find this the most rewarding step
• This step involves the compiler, which will
  identify syntax errors and some basic
  coding/logic errors
• Further testing takes place against a Test Plan
• Can be very frustrating if the design and testing
  is incomplete before the coding is performed
• May need to be performed several times

45
44
Program Development Cycle

• PDC Document and Maintain Program
• Documentation is an ongoing task throughout the
  PDC
• External Documentation
• Internal Documentation
• Maintenance takes place during the life of the
  program, due to
• Enhancements (new functionality, new
  requirements)?
• Bugs

46
45
Compile Process


47
46
Compile Process
Compile Process As mentioned, a high-level
language must be converted to machine language.
This process is referred to as compiling the
program. The program is a file that contains
instructions written in the high-level language.
It is used as data to the compiler, which
generates machine language.
48
47
Compile Process
Compile Process The compile process starts by
taking the source file (the file containing the
high-level instructions) and converts it into an
object file. The object file contains some
machine language and some points that additional
code needs to be attached to. The object file is
linked into the operating system, and the final
result is an executable file containing the
machine language instructions ready to run.
Compiler
Translator
Linker
Object File
Source file (3GL Language Text File)?
Executable file
Library files (for O/S)?
49
