Caliciviruses

1
(No Transcript)
2
Themes
Picorna, calici Picorna, Calici Calici Calici
Reo
Persistent infections Antigenic
variation Immune evasion, Emerging
disease Arthropod-transmitted viruses
3
Picornaviruses and Caliciviruses
pico- calici-
genome ss RNA ve sense ss RNA ve sense
genome size 8kb 8kb
capsid icosahedral icosahedral
envelope none none
virion size 25 40
Stable in environment
4
Replication

• replicate in cytoplasm
• ve sense genome
• (genome RNA is infectious)
• encode viral polymerase
• mature viral proteins generated
• through proteolytic cleavage
• virions released on cell lysis

5
PicoRNAviruses
ss, positive sense RNA, icosahedral capsid, 25nm,
and no envelope
Pico small Greek
Positive sense ICOsahedral RNA genome
4 coat proteins VP1, VP2, VP3,VP4 simple capsid
60 capsomere (composed of VP1,2,3)
6
Picornaviruses

• Restricted host range (except FMD)
• Resistant in environment
• Transmission faecal-oral (fomites, aerosol)
• Antigenic variation
• Persistent infection (FMD)
• Associated with vesicular disease and
  encephalomyelitis
• Diagnosis usually by ELISA (Ag detection) or
  virus isolation

7
Picornaviridae
9 genera Important veterinary viruses
Cardiovirus encephalomyocarditis virus ECMV
Hepatovirus avian encephalomyelitis
Enterovirus swine vesicular disease,
porcine enteroviruses
Aphthovirus foot and mouth disease
Teschovirus porcine teschovirus
8
FMDV

• virus extremely infectious
• rapid replication cycle, high virus yield
• large volumes in aerosols, virus stable
• short incubation period
• wide host range
• dissemination pre-diagnosis - virus excreted up
  to 4 days pre-clinical signs mild clinical
  picture in some hosts (sheep)
• carriers - persists in pharynx
• transmitted by animals/contaminated items/
  people/environment, windborne

9
Foot and Mouth Disease Virus

• Aphthovirus genus NOTIFIABLE

First animal virus discovered (1898) one of
most contagious viruses
cloven hoofed animals - cattle, pigs, sheep..
low mortality but high morbidity - fever,
oral/feet/teat lesions dairy herds - reduced milk
yield beef cattle - reduced growth
10
FMD excretion
11
FMD broad host range
Amount of virus shed Clinical picture Sensitivit
y to infection Carriers
amplifier hosts
12
FMDV serotypes
endemic in south america, africa, asia, middle
east
7 immunologically distinct FMD types
(serotypes)
SAT3
SAT1
C
Asia-1

• animal with immune response to one serotype is
  not protected against infection
• by a different serotype
• vaccines must contain serotypes of all strains
  circulating in that region

13
Foot and mouth disease UK 2001
2030 cases Slaughter policy 9500 premises 4
million animals 40 total 8 billion
Serotype O
FMD-free areas
? illegal importation of W. Asian meat
inadequate treatment of swill fed to pigs
14
Control
FMD-free countries post vaccination/eradication
campaigns importation controls - animals, meat,
animal products surveillance and reporting
procedures World Reference Lab UK Ban on swill
feeding (instigated due to 2001 outbreak) -
outbreak UK 2001 - slaughter policy (infected,
contact premises), animal (
personnel) movement controls, disinfection
Endemic countries vaccination (multivalent)
first virus eradicated worldwide smallpox
1977 first animal virus rinderpest
(paramyxovirus) goal 2010 second targeted
virus poliovirus (picornavirus) ongoing
15
Caliciviruses
ss, positive sense RNA, icosahedral capsid, 40nm,
no env
EM - Star of David - cup-shaped on capsid
surface (calyxcup)
- single capsid protein - 2 or 3 open reading
frames

• caliciviruses typically associated with
  respiratory,
• vesicular, haemorrhagic disease,
  gastroenteritis
• emerging diseases Rabbit haemorrhagic disease
  virus (RHDV)
• Humans main cause of non-bacterial
  gastroenteritis

16
Veterinary Caliciviruses
vesivirus feline and canine calicivirus
vesicular exanthema of swine lagovirus
rabbit haemorrhagic disease virus
European brown hare syndrome virus
Caliciviruses exist in marine species Ocean
reservoir
17
Feline Calicivirus
respiratory disease - (40 cases), usually
associated with feline herpesvirus (cat flue)
main clinical feature chronic stomatitis -
nasal/ocular discharge (rhinitis/conjunctivitis,
oral lesions, fever, lameness), can be fatal in
kittens
18
Theme virus persistence

• FCV (calicivirus) vs FHV (herpesvirus)
• major viral causes of upper respiratory tract
  disease (cat 'flu) note NOT influenza virus
  (orthomyxovirus)
• upper respiratory tract, mouth ulcers
• FCV - chronic, productive infection
• FHV - periodic virus shedding (due to
  reactivation of latent virus)

19
Rabbit haemorrhagic disease virus

• European rabbit necrotic hepatitis - death in 2
  days, acute respiratory/cardiac failure, up to
  95 mortality

Notifiable

• foecal/oral transmission
• (inhalation, insects)
• some rabbits may be carriers
• control inactivated vaccines
• available (infected rabbits)

20
Birna- and reoviruses
birna- reo-
genome dsRNA linear segmented dsRNA linear segmented
capsid icosahedral icosahedral
envelope No No
genome size 6 (2 segs) 22 (10-12 segs)
virion size 60 80
replicate in cytoplasm, virus polymerase stable
in environment potential for reassortment
21
Bi-rna-viridae
dsRNA, non-enveloped, 60nm
Two segments
RNA genome
60nm
aquabirnavirus
infectious pancreatic necrosis (IPN) fish
avibirnavirus infectious bursal disease chickens
22
Infectious pancreatic necrosis (IPN)

• affects young salmon, trout
• high mortality - gut haemorrhage, pancreatic
  necrosis
• Shetland 10 production (gt1 million fish) 2
  million 2001
• IPN ( Infectious salmon anaemia) - major
  threat to salmon
• farming industry

23
Infectious bursal disease of chicks IBDV (Gumboro
disease)

• 3-6 week old chicks
• Virus kills immature B-lymphocytes in
• bursa of Fabricius
• Virus kills T-lymphocytes in the thymus
• Causes severe combined immunodeficiency
• Very virulent (VV) strains 50 mortality
• Recovered chicks immunosuppressed
• - increased susceptibility to pathogens
• - decreased efficacy of vaccines
• Vaccination of breeders, chicks

enlarged bursa of fabricius
Notifiable
24
Reoviridae
ds RNA, non-enveloped, cubic symmetry, double
capsid, 60nm.
Respiratory Enteric Orphan VIRUS

• Rotavirus
• Orbivirus

11 genera important veterinary genera -
outer capsid (ico)
inner capsid (ico)
capsid - layered
core
25
Rotavirus
latin 'wheel'

• a major cause of diarrhoea (scours) in very
  young calves,
• - foecal/oral transmission (waterborne)
• - vaccines available for dam - boost colostral Ab

26
Rotavirus infection
infection of enterocytes at TIPS of villi in
small intestine
27
Orbiviruses
latin 'ring'
Bluetongue African horse sickness
Theme Arthropod transmitted
arboviruses - replicate in insect vectors
28
Bluetongue

• Africa, Middle East, Asia, Americas
• 24 serotypes antigenically diverse
  (vaccination implications)
• Disease in sheep (deer)
• Cattle important reservoirs (subclinical)
• Transmitted by midge vectors late summer

fever, changes to the mucous linings of the
mouth, nose (cyanosis of tongue), coronary band
reproductive disorder, vascular disease

Notifiable disease
29
Culicoides spp. 'no-see-ums'

• female midges feed every 4 d (2 month lifespan)
• once infected pass virus in saliva

30
African Horse Sickness

• endemic in Africa (outbreaks in Spain, Portugal
  1980s)
• gt75 mortality (horses)
• with VEE, most important, lethal viral disease
  of horses
• cardiac/respiratory disease - death
  within 1 week
• horse sickness fever - mild zebra,
  donkeys (maintenance hosts)
• fever swelling forebody, coughing
• transmitted by midge (culicoides) vectors
• control vector control, quarantine, vaccination

Notifiable disease
