Hyporheic and Parafluvial Zones in

1
Hyporheic and Parafluvial Zones in
The Arctic Tundra!
2
The hydraulic characteristics and geochemistry of
hyporheic and parafluvial zones in Arctic tundra
streams, north slope, Alaska

• Edwarson et al. (2003) Advances in Water
  Resources

3

• Purpose Investigate the hydrologic and chemical
  dynamics of hyporheic and parafluvial zones in
  Arctic tundra streams
• Importance Essentially no information on Arctic
  streams
• First comprehensive description of hyporheic and
  parafluvial zones in Arctic tundra streams
• Continuous permafrost
• Limit the importance of hyporheic processes?

4
Scope of Work

• 17 conservative tracer additions on 7 streams
  from 1994-1996
• Stream reaches varied greatly
• Characterize in-stream hydrologic parameters
  using hyporheic samplers and OTIS-P simulations
• Biogeochemical and nutrient processing in
  hyporheic and parafluvial zones

5
Background Definitions and Key Concepts

• Transient storage zones
• Parafluvial
• Beaded stream
• Importance of hyporheic and parafluvial zones
• 3 key factors that control water movement in
  these zones
• DO in the hyporheic zone
• Modeling limitations

6
Study Area
7
Study Area Kuparuk R. and Oksrukuyik Cr.
fertilized Kupa
Kupa
Mouth Of Kupa
Oks
8
Whole Lotta Methods

• Hyporheic Samplers
• Tracer Additions
• Conservative Tracer Analysis
• Solute Modeling
• Vertical Hydraulic Gradient (VHG)
• Nutrient Chemistry

9
Results OTIS Modeling

• No significant relationship between As/A and
  discharge
• General relationship held true
• Average storage zone cross-sectional area of the
  Arctic streams
• 43 (Range 8 254)
• 32 (Range 8 112) without Imnavait Cr.

10
ResultsChannel, Upwelling, and Downwelling
Sites
Transient Storage Zones
11
Results Channel, Upwelling, and Downwelling
Sites
Bottom of Riffle
Top of Riffle
Parafluvial
Tracer Penetration
Hyporheic
Hyporheic
Parafluvial
12
Results Channel, Upwelling, and Downwelling
Sites
Water Quality
13
Results VHG and Temperature
VHG
Parafluvial zones in left and right point bars
Riffle
14
Results Benthic Uptake
15
Key Discussion Points and Conclusions

• Transient storage in Arctic Streams
• Similarity to temperate regions
• As/A relationship not signifcant
• ?morphology and ?stage height are boss.
• Importance of eddies
• BUT hyporheic storage still muy importante!
• Biogeochemical importance of hyporheic flowpath.

16
Key Discussion Points and Conclusions

• Permafrost
• Hyporheic flow not limited by permafrost in
  ice-free season
• Spring ice-out (thaw) may results in much lower
  As/A values due to high snow-melt Q and reduced
  interstitial area
• Water Quality
• Interstitial waters served as sources of NO3,
  NH4, PO4, and CO2
• Interstitial temperature inversely related to VHG
  and residence time in hyporheic and parafluvial
  zones.

17
