Magnetism Challenge

1
MagnetismChallenge
2
If an iron bar is placed in a magnetic field,
which one of the figures represents the
distortion of the field?
Ans. a
3
What is the strength of the B-field at point P?
Ans. 4.8 x 10-5 T
4
What is the direction of the B-field at point P?
Ans. Out of screen
5
Electrons flow along a wire directed out of the
page. What is the direction of the magnetic
force on the wire?
Ans. down
6
What is the magnitude of the B-field at point P,
if the current is 1 A?
Ans. 5 x 10-6 T
7
Which diagram shows the correct magnetic field
around the wire?
Ans. A (careful it is showing electron flow)
8
Which one is the correct representation?
Ans. A
9
Which one is correct?
Ans. C
10
When the switches are closed will these two bars
attract or repel?
Ans. attract
11
Which is correct?
Ans. B and D
12
What is the correct polarity on the paper clips?
Ans. D
13
Where is the North pole?
Ans. C (ignore current arrows look at , - to
determine current flow)
14
What is the direction of the magnetic field at
the center of the loop?
Ans. Into screen
15
Where is the South pole?
Ans. D
16
What happens to the strength of the field if the
resistance decreases?
Ans. strengthens
17
What is the resistance? Where is the North pole?
Ans. 8 ? D
18
What is the direction of the magnetic force on
the segment AB?
Ans. Out of screen
19
What is the direction of electron flow in the
wire?
Ans. Down wire from B to A
20
What is the direction of the current in the coil?
Ans. Down in front
21
Where is the field strongest?
Ans. C
22
What is the pole at K?
Ans. N
23
What is the force on segment bc? (magnitude and
direction)
Ans. 0.03 Newtons (assume 1 A current) directed
into screen
24
If this wire were made from a loose chain, would
it expand to form a circle, compact to a point,
or nothing?
Ans. compact
25
Which shows the correct electric field around a
negative charge?
Ans. D
26
Which is correct?
Ans. C
27
Which shows the correct magnetic field around a
positive current moving into the board?
Ans. A
