FCP-1: Cell Biology

1
FCP-1 Cell Biology

• 1st contact session cell membranes, cytoplasmic
  organelles, the cytoskeleton, intercellular
  connections, cell adhesion molecules, transport
  across cell membranes, ATP production

2
Part 1 intracellular structures and organelles
3
Simplified depiction of a cell
4
Cell membrane components

• Main component phospholipids
• (hydrophilic outside, hydrophobic
• inside, spontaneous bi-layer)
• Selectively permeable
• Inner membranes have similar
• structure
• Proteins integral vs peripheral
• Modifications
• Anchors

Cell adhesion molecules, pumps, channels,
receptors, enzymes
5
Mitochondria (1)
Main function energy production
through oxidative phosphorylation
6
Mitochondria (2)

• Used to be free-living bacteria
• Contains the components of the electron transport
  chain
• (energy production) in the inner membrane
• Contains own genome (smaller than nucleus) and
  ribosomes (protein synthesis machinery)
• Zygote mitochondria come from the ovum maternal
  inheritance of mtDNA
• Very ineffective DNA repair leads to mistakes
  results in a large number of rare diseases
  associated with defects in energy metabolism

7
Mitochondria (3)
Electron transport chain (oxidative
phosphorylation, generation of ATP/energy)
Later
8
Lysosomes rubbish bins

• Large, irregular structures in the cytoplasm
• Acidic interior, digest endocytosed bacteria and
  discarded cell components
• Filled with acid hydrolases, cannot function at
  normal cellular pH, will not destroy other cell
  components
• Lysosomal storage diseases result from absence of
  enzyme, accumulation/engorgement of lysosomes

9
Peroxisomes detox and more

• Catalyse various anabolic and catabolic
  reactions, e.g. breakdown of very long chain
  fatty acids, production of plasmalogen (myelin),
  production of bile acids
• Enzymes oxidize substrates, generating toxic
  H2O2, used to oxidize other substrates,
  neutralizing H2O2
• NB for the detox of ethanol
• PXR gene product is outer pxome receptor, PEX
  gene products import proteins into pxome, and
  enzymes are targeted into pxome by PTS signal
• Errors in pxome assembly result in Zellweger
  syndrome, neonatal adrenoleukodystrophy and
  infantile Refsum disease (lethal in infants)

10
Nucleus command HQ

• Contains all of the DNA (nuclear genome)
  required for gene expression, in the form of
  chromatin
• Site of gene expression (DNA ? mRNA)

11
Nucleus

• DNA (chromosomes) normally unravelled,
  disorganized chromatin
• Individual chromosomes condense before cell
  division
• Nucleolus contains RNA, proteins
• ribosome assembly
• Nuclear envelope a double-layer membrane
• Contains pore complexes for shuttling of
• proteins, ribosomes and RNA ribosomes and
  RNA produced in nucleus, must shuttle to
  cytoplasm for protein synthesis, some proteins
  (i.e. transcription factors) must shuttle back to
  nucleus

12
Ribosomes protein assembly lines
13
Endoplasmic reticulum processing

• Complex series of tubules in the cytoplasm
• Contiguous to the nuclear membrane
• Smooth ER steroid synthesis
• Rough ER covered with ribosomes,
• protein synthesis, folding and
• modification

14
Golgi apparatus add some sugar

• Stacked membrane-enclosed sacs
• Proper glycosylation (sticking on
  carbohydrate/sugar chains) of lipids and proteins
• Directional (cis?trans)
• Vesicles shuttle from the ER, through the Golgi,
  out for secretion

15
Cytoskeleton intracellular highways

• Maintains structure, helps to move and change
  shape
• Also moves proteins and organelles around

16
Molecular motors to move cargo
Kinesin, dynein, myosin all use ATP (energy)
17
Part 2 Intercellular connections
18
Holding cells together Tight junctions

• Surround the outer layer of epithelial cells
  (intestinal mucosa, renal tubules, choroid plexus
  in brain)
• Also contribute to endothelial barrier function
• Totally obliterates the gap between cells,
  prevents protein
• leakage between cells

19
Holding cells together zonula adherens
20
Holding cells together desmosomes

• - Adhesion protein cadherin, helps to withstand
  shear stress in epithelium,
• particularly in epidermis
• - Defining feature dense plaques on cytoplasmic
  side, attached to
• cytoskeletal filaments
• Blistering diseases (Pemphigus) are auto-immune,
  attack desmogleins
• (cadherins), cause layers of skin to pull apart

21
Attaching cells to the basal lamina
hemidesmosomes and focal adhesions
22
Gap junctions intercellular communication

• 1 subunit connexin
• Pore with 6 connexins
• connexon
• permit passage of ions
• and small metabolites
• between cells
• highly selective (20 diff
• connexin genes, each for
• different flow-through)

23
Cell adhesion molecules

• All intercellular connections consist of cell
  adhesion
• molecules (CAMs)
• 4 broad families integrins, cadherins,
  selectins and
• IgG adhesion molecules
• Not just for adhesion, but also for signalling
• cells that lose contact with other cells undergo

• dissociation-induced apoptosis (anoikis)
• collagen-integrin interaction essential for
  osteoblast
• differentiation

24
Part 3 transport across cell membranes
25
Exo- and endocytosis
Note that the cytoplasmic side of the membrane
always remains the cytoplasmic side
26
Endocytosis continued

• Phagocytosis eating of bacteria, dead tissue by
  leukocytes
• Pinocytosis drinking of solutes
• Both processes involve invagination of the plasma
  membrane before pinching off vesicle inside the
  cell
• Clathrin-mediated endocytosis three-legged
  clathrin
• molecules cover endocytotic vesicle
• (NB for receptor internalization and
• synaptic function)

27
How do molecules move across the cell membrane?

• Small non-polar and neutral polar molecules
  diffuse directly across (O2, N2 CO2)
• Everything else needs help!
• Transport proteins form channels for transport of
  various molecules
• Even water! (through aquaporins)
• Some are non-selective ion
• channels, some are very selective

28
How do molecules move across the cell membrane?

• Some channels are gated
• (opened upon a particular
• stimulus)

29
How do molecules move across the cell membrane?

• Carrier proteins transport molecules WITH a
  concentration or electrical gradient facilitated
  diffusion, does not require energy (example
  glucose)
• Other carriers transport molecules AGAINST a
  gradient active transport, requires energy
• Many carrier proteins are therefore ATPases
  hydrolyses ATP for energy for transport
• Secondary active transport transport of one
  molecule coupled to the transport of another
  (often Na)
• Symport two molecules moving in the same
  direction
• Antiport exchange of molecules in opposite
  directions

30
Ion channels
Possible configurations
31
Part 4 Energy (ATP) production
32
ATP hydrolysis energy
ATP ? ADP Pi 30-50 kJ energy
Energetically unfavourable (unstable)
Energetically more stable
Interesting factoid 60 of energy goes towards
maintenance of body temp
33
Main site of ATP production the citric acid
cycle
cytoplasm
mitochondria
But before we get to this point..
34
Glycolysis (Embden-Meyerhof pathway)
1x 6-carbon
2x 3-carbon
Net gain (1 mol glucose) 4 ATP 2 ATP 2 ATP
2 pyruvate 2 NADH
35
Or.Glycogen breakdown
Net gain from 1 mol glucose-6-phosphate 4 ATP
1 ATP 3 ATP 2 pyruvate 2 NADH
36
OrBeta-oxidation of fatty acids

• Takes place in mitochondria long-chain fatty
  acids
• transported in by carnitine
• - 18-C fatty acid generates 8 acetyl-CoA

37
Main site of ATP production the citric acid
cycle
cytoplasm
mitochondria
38
From NADH/FADH2 to ATP
39
ATP production adding it up

• 1 pyruvate generates 4 NADH, 1 FADH2 and 1 GTP
  (ATP)
• 1 NADH 3 ATP, 1 FADH2 2 ATP
• 1 pyruvate (4x3) (1x2) 1 15 ATP
• 1 glucose (2 ATP 2 pyruvate 2 NADH) 2
  (2x15) (2x3) 38 ATP
• 1 glucose-6-P (from glycogen) 39 ATP
• 1 18-C fatty acid 8 x 15 120 ATP
• 1 triglyceride 360 ATP
