Performance Management (Best Practices)

1
Performance Management(Best Practices)

• REFwww.cisco.com
• Document ID 15115

2
Introduction

• Performance Management involves optimization of
  network response time and management of
  consistency and quality of individual and overall
  network services
• Need to measure the user/application response time

3
Performance management issues

• User performance
• Application performance
• Capacity planning
• Proactive fault management
• It is important to note that with newer
  application like video and voice performance
  management is the key success

4
Indicators for performance management (1/3)

• Document the network management business
  objectives
• Create detailed and measurable service level
  objectives
• Provide documentation the service level agreement
  (SLA) with charts or graphs that show the success
  or failure of how these agreements are met over
  the time

5
Indicators for performance management (2/3)

• Collect a list of the variables for the baseline
  such as polling interval, network management
  overhead incurred, possible trigger threshold
• Have a periodic meeting that reviews the analysis
  of the baseline and trends.

6
Indicators for performance management (3/3)

• Have a what-if analysis methodology documented.
• When thresholds are exceed, develop documentation
  on the methodology used to increase network
  resources.

7
Performance management process flow (1/3)
8
Performance management process flow (1/3)

• 1 develop a network management concept of
  operation
• Define the required features Services,
  Scalability and Availability objectives
• Define availability and network management
  objectives
• Define performance SLAs and Metrics
• Define SLA

9
Performance management process flow (2/3)

• 2 Measure Performance
• Gather network baseline data
• Measure availability
• Measure response time
• Measure accuracy
• Measure utilization
• Capacity planning

10
Performance management process flow (3/3)

• 3 perform a proactive fault analysis
• Use threshold for proactive fault management
• Network management implementation
• Network operation metrics

11
Performance management process flow
12
Develop a network management concept of operation
(1/3)

• The purpose is to describe the overall desired
  system characteristics from an operational
  standpoint
• The use of this document is to coordinate the
  overall business goals of network operation,
  engineering, design other business units and the
  end users.

13
Define the required features Services,
Scalability objectives (1/2)

• Define services objectivesWhat services the
  network provide
• to understand applications, basic traffic flows,
  users and site counts
• Define scalability objectives How many users to
  use the network, also the capacity consumed on
  the network
• media capacity, number of routes and users

14
Define the required features Services,
Scalability objectives (2/2)

• These are the standard performance goals
• Response time
• Utilization
• Throughput
• Capacity (maximum throughput rate)

15
Define availability and network management
objectives (1/2)

• Define Availability objectives
• define the level of services (service level
  requirements)
• define different class of service for a
  particular organization
• Higher availability objective might necessitate
  increased redundancy and support procedures

16
Define availability and network management
objectives (2/2)

• Define manageability objectives
• To ensure that overall network management does
  not lack management functionality
• Must understand the process and tools for
  organization
• Uncover all important MIB or network tool
  information

17
Define performance SLAs and Metrics

• The performance SLAs metrics such as
• average expected volume of traffic,
• peak volume of traffic,
• average response time and maximum response time
  allowed
• Availability
• Down Time

18
Define SLAs

• SLA (Service Level Agreement) - enterprise
• SLM (Service Level Management) service provider

• SLM include definitions for problem types and
  severity and help desk responsibilities
• Escalation path, time before escalation at each
  tier support level
• Time to start work on the problem
• Time to close target based on priority
• Service to provide in the area of capacity
  planning, hardware replacement

19
Performance management process flow
20
Measure Performance

• Gather Network Baseline data
• Perform a baseline of the network before and
  after a new solution deployment
• A typical router/switch baseline report includes
  capacity issues related to CPU, memory, buffer,
  link/media utilization, throughput
• Application baseline bandwidth used by app per
  time period

21
Measure availability

• Availability is the the measure of time for which
  a network system or application is available to a
  user
• Coordinate the help desk phone calls with the
  statistics collected from managed devices
• Check scheduled outages
• Etc

22
Measure Response Time

• Network response time is the time required to
  travel between two points
• Simple level pings from the network management
  station to key points I the network. (not
  accuracy)
• Server-centric polling SAA (Service Assurance
  Agent) on router (Cisco) to measure response time
  to a destination device
• Generate traffic that resembles the particular
  application or technology of interest

23
Measure accuracy

• Accuracy is the measure of interface traffic that
  does not result in error and can be expressed in
  term of percentage
• Accuracy 100 error rate
• Error rate ifInErrors 100 / (ifInUcastPkts
  IfInNUcastPkts)

24
Measure Utilization (1)

• Utilization measure the use of a particular
  resource over time
• Percentage in which the usage of a resource is
  compared with its maximum operational capacity
• High utilization is not necessarily bad
• Sudden jump in utilization can indicate unnormal
  condition

25
Measure Utilization (2)

• Input utilization
• ifInOctets 8100/(time in second)ifSpeed
• Output Utilization
• ifOutOctets 8100/(time in second)ifSpeed

26
Capacity planning

• The following are potential areas for concern
• CPU
• Backplane or I/O
• Memory
• Interface and pip sizes
• Queuing, latency and jitter
• Speed and distance
• Application characteristics

27
Performance management process flow
28
Perform a Proactive fault analysis

• One method to perform fault management is through
  the use of RMON alarms and event groups
• Distributed management system that enables
  polling at a local level with aggregation of data
  at a manager to manager

29
Use threshold for proactive fault management (1/2)

• Threshold is the point of interest in specific
  data stream and generate event when threshold is
  triggered
• 2 classes of threshold for numeric data
• Continuous threshold apply to continuous or time
  series data such as data stored in SNMP counter
  or gauges
• Discrete threshold apply to enumerated objects or
  discrete numeric data such as Boolean objects

30
Use threshold for proactive fault management (2/2)

• 2 different forms of continuous threshold
• Absolute use with gauges
• Relative (delta) use with counter
• Step to determine threshold
• 1 select the objects
• 2 select the devices and interfaces
• 3 determine the threshold values for each object
  or interface
• 4 determine the severity for the event generated
  by each threshold

31
Network management implementation

• The organization should have an implemented
  network management system.
• SNMP/RMON or other network management system tools
