ATOMS AND MOLECULES

1
ATOMS AND MOLECULES

• THE CHEMICAL
• BASIS OF LIFE

2
ATOMS AND MOLECULES

• Elements are not changed in normal chemical
  reactions
• Each element has a unique chemical symbol
• 92 naturally occurring elements range from
  hydrogen to uranium

3
ATOMS AND MOLECULES

• Four elements make up 96 of most living
  organisms
• What are they?
• What other elements are necessary for US to live
  (think about what you eat)?
• Trace elements are necessary, but present in
  small quantities

4
http//periodic.lanl.gov/
5
ATOMS ARE THE FUNDAMENTAL PARTICLES OF ELEMENTS

• Atoms are the smallest component of an element
  that retains the chemical properties of the
  element
• Atoms contain protons, neutrons, and electrons

6
(No Transcript)
7
(No Transcript)
8
ATOMS ARE THE FUNDAMENTAL PARTICLES OF ELEMENTS

• An atom is uniquely identified by its number of
  protons
• A proton is a subatomic particle with one unit of
  positive charge

9
ATOMS ARE THE FUNDAMENTAL PARTICLES OF ELEMENTS

• An atom is uniquely identified by its number of
  protons
• A proton is a subatomic particle with one unit of
  positive charge

• The periodic table depicts the elements in order
  of their atomic numberthe number of protons in
  the nucleus A proton is a subatomic particle with
  one unit of positive charge

10
ATOMS ARE THE FUNDAMENTAL PARTICLES OF ELEMENTS

• An atom is uniquely identified by its number of
  protons
• A proton is a subatomic particle with one unit of
  positive charge

• The periodic table depicts the elements in order
  of their atomic numberthe number of protons in
  the nucleus A proton is a subatomic particle with
  one unit of positive charge

• Atomic numbers are written in subscript to the
  left of the chemical symbol

11
ATOMS ARE THE FUNDAMENTAL PARTICLES OF ELEMENTS

• Proton plus neutrons determine atomic mass
• Atomic mass units (amus) are also known as
  daltons
• One amu equals the approximate mass of a proton
  or neutron

12
ATOMS ARE THE FUNDAMENTAL PARTICLES OF ELEMENTS

• Isotopes differ in number of neutrons
• Some isotopes are unstable (radioisotopes)
• Many radioisotopes are important in scientific
  research

13
(No Transcript)
14
(No Transcript)
15
ATOMS ARE THE FUNDAMENTAL PARTICLES OF ELEMENTS

• Electrons occupy orbitals corresponding to energy
  levels
• The outer electrons are known as the valence
  electrons and contain the most energy
• These outer electrons occupy the valence shell

16
(No Transcript)
17
ATOMS UNDERGO CHEMICAL REACTIONS

• Atoms form molecules and compounds
• Two or more atoms combined chemically form a
  molecule
• Molecules may be composed of different or similar
  atoms

18
(No Transcript)
19
(No Transcript)
20
ATOMS UNDERGO CHEMICAL REACTIONS

• A substance can be defined by a chemical formula
• Chemical formulas indicate ratios of atoms in a
  molecule
• Structural formulas show the arrangement of atoms
  in a molecule

21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
ATOMS UNDERGO CHEMICAL REACTIONS

• One mole of any substance contains the same
  number of units
• The molecular mass of a substance is the sum of
  the atomic masses of the atoms composing the
  molecule
• The molecular weight is dimensionless

25
ATOMS UNDERGO CHEMICAL REACTIONS

• One mole of any substance contains the same
  number of units
• The molecular mass of a substance is the sum of
  the atomic masses of the atoms composing the
  molecule
• The molecular weight is dimensionless
• The number of units in a mole is Avogadros
  number- One mole is 6.02 X 1023 atoms or molecules

26
Avogadro
27
ATOMS UNDERGO CHEMICAL REACTIONS

• Chemical equations describe chemical reactions
• Reactants are written on the left side of the
  equation
• Products are written on the right side of the
  equation
• Reversible reactions are indicated by double
  arrows between reactants and products

28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
ATOMS ARE JOINED BY CHEMICAL BONDS

• In covalent bonds electrons are shared
• The electrons in the outer shell are the valence
  electrons
• Atoms tend to be reactive if the valence shell is
  not full
• The Lewis structure of the atoms represents the
  valence electrons

32
(No Transcript)
33
ATOMS ARE JOINED BY CHEMICAL BONDS

• In covalent bonds electrons are shared
• The electrons in the outer shell are the valence
  electrons
• Atoms tend to be reactive if the valence shell is
  not full
• The Lewis structure of the atoms represents the
  valence electrons

• Covalent bonds result in filled valence shells
• A single electron pair shared between two atoms
  is a single covalent bond
• Double and triple covalent bonds are formed by
  two or three shared electron pairs, respectively
• Hydrogen forms one covalent bond
• Carbon forms a maximum of four covalent bonds

34
(No Transcript)
35
(No Transcript)
36
(No Transcript)
37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
ATOMS ARE JOINED BY CHEMICAL BONDS

• Ionic bonds form between cations and anions
• An atom becomes an ion when it gains or loses one
  or more electrons
• Cations are positively charged ions
• Anions are ions with a negative charge, and are
  named with the suffix -ide

41
ATOMS ARE JOINED BY CHEMICAL BONDS

• Ionic bonds form between cations and anions
• An atom becomes an ion when it gains or loses one
  or more electrons
• Cations are positively charged ions
• Anions are ions with a negative charge, and are
  named with the suffix ide
• An ionic bond forms between cations and anions
• Ionic compounds tend to dissociate in water
  (ionize)

42
ATOMS ARE JOINED BY CHEMICAL BONDS

• Hydrogen bonds are weak attractions involving
  partially charged hydrogen atoms
• In the water molecule, hydrogen is partially
  positively charged
• Hydrogen bonds form between the hydrogen atom in
  a water molecule and a partially negatively
  charged atom
• Hydrogen bonds individually are weak, but
  collectively very strong

43
(No Transcript)
44
ELECTRONS AND THEIR ENERGY ARE TRANSFERRED IN
REDOX REACTIONS

• Oxidation and reductions reactions occur
  simultaneously, hence they are called redox
  reactions
• Reduction is a process in which an atom, ion, or
  molecule gains electrons
• Reduction is so named because the gain of
  electrons reduces the positive charge.

45
(No Transcript)
46
REDOX REACTIONS
Redox reactions are important in both cellular
respiration and photosynthesis
47
(No Transcript)
48
(No Transcript)
49
WATER IS ESSENTIAL TO LIFE
Water is important because most organisms are
composed of water and may live in water
50
(No Transcript)
51
WATER IS ESSENTIAL TO LIFE

• Water molecules are polar
• Hydrogen atoms in the water molecule have a
  partial positive charge
• Each water molecule can form up to 4 hydrogen
  bonds

52
(No Transcript)
53
(No Transcript)
54
WATER IS ESSENTIAL TO LIFE

• Hydrogen make water cohesive and adhesive
• Water molecules tend to hydrogen bond to each
  other, making water cohesive
• Water molecules tend to hydrogen bond to other
  molecules, making water adhesive
• Capillary action is a result of adhesion and
  cohesion

55
(No Transcript)
56
WATER IS ESSENTIAL TO LIFE

• Hydrogen make water cohesive and adhesive
• Water molecules tend to hydrogen bond to each
  other, making water cohesive
• Water molecules tend to hydrogen bond to other
  molecules, making water adhesive
• Capillary action is a result of adhesion and
  cohesion
• Cohesion results in water moving upwards in
  plants
• Hydrogen bonding also results in surface tension

57
(No Transcript)
58
(No Transcript)
59
(No Transcript)
60
(No Transcript)
61
Water with dish washing detergent
Distilled Water
Water with food coloring added
62
(No Transcript)
63
ACIDS ARE PROTON DONORS AND BASES ARE PROTON
ACCEPTORS

• Water tends to slightly dissociate into hydrogen
  and hydroxide ions
• The concentration of hydrogen ions in pure water
  is 10-7 moles per liter, equals the hydroxide ion
  concentration

64
(No Transcript)
65
ACIDS ARE PROTON DONORS AND BASES ARE PROTON
ACCEPTORS

• Acids are substances that dissociate in a
  solution to yield H ions and Hydronium ions
• Acids are proton donors
• Acidic solutions have a higher hydrogen ion
  concentration than hydroxide ion concentration

66
ACIDS ARE PROTON DONORS AND BASES ARE PROTON
ACCEPTORS

• Bases dissociate in solution to yield hydroxide
  ions
• Bases are proton acceptors
• Basic solutions have a lower hydrogen ion
  concentration than hydroxide ion concentration

67
(No Transcript)
68
(No Transcript)
69
(No Transcript)
70
(No Transcript)
71
(No Transcript)
72
(No Transcript)
73
ACIDS ARE PROTON DONORS AND BASES ARE PROTON
ACCEPTORS

• pH is a convenient measure of acidity
• The pH of a solution is the negative log of the
  hydrogen ion concentration expressed in moles per
  liter
• A pH below 7 is acidic, above 7 is basic
• The pH of most living cells is slightly above 7.0

74
(No Transcript)
75
(No Transcript)
76
ACIDS ARE PROTON DONORS AND BASES ARE PROTON
ACCEPTORS

• Buffers minimize pH change
• Weak acids and weak bases act as buffers

77
ACIDS ARE PROTON DONORS AND BASES ARE PROTON
ACCEPTORS

• An acid and a base react to form a salt
• When an acid and base are mixed, water is formed
  from the hydrogen ions of the acid, and the
  hydroxide ions of the base
• The cation of the base and the anion of the acid
  form the salt

78
(No Transcript)
79
ACIDS ARE PROTON DONORS AND BASES ARE PROTON
ACCEPTORS

• An acid and a base react to form a salt
• When an acid and base are mixed, water is formed
  from the hydrogen ions of the acid, and the
  hydroxide ions of the base
• The cation of the base and the anion of the acid
  form the salt
• Electrolytes are salts, acids, or bases that can
  conduct an electrical current when dissolved in
  water
• Nonelectrolytes are molecules that do not
  dissociate in water and therefore do not conduct
  an electrical current
