Title: Waves and Sound


1
Waves and Sound
  • Chapter 17

2
(No Transcript)
3
Characteristics of Waves
Waves A rhythmic disturbance that carries energy.
Medium A material through which waves transfer.
4
Mechanical Waves
  • A mechanical wave is created when a source of
    energy causes a vibration to travel through a
    medium.

5
(No Transcript)
6
Transverse Wave
7
Transverse Wave
8
(No Transcript)
9
Transverse Wave
A wave in which the medium moves at a right angle
to the direction the wave is traveling.
10
Crest The top of the wave.
Trough The bottom or valley of the wave.
11
Longitudinal Waves
Matter vibrates in the same direction as the
wave travels.
12
(No Transcript)
13
(No Transcript)
14
(No Transcript)
15
Longitudinal Waves
Rarefaction
16
(No Transcript)
17
Surface Wave
18
Surface Wave
A wave that travels along a surface separating
two media.
19
(No Transcript)
20
(No Transcript)
21
Homework
Section 17.1Due 4/28/09
22
(No Transcript)
23
Amplitude The greatest distance the particles in
a wave rise or fall from their rest position. The
energy of the wave depends on the amplitude.
24
Wavelength(?- lambda, m) The distance between a
point on one wave and the same identical point on
the next wave.
25
Wave Velocity(v, m/s) The distance traveled by
any point on the wave in one second.
Wave Velocity depends on the medium the wave is
traveling in.
26
Frequency(f, Hz) The number of waves that pass a
point in a second.
Hertz(Hz) The unit used to measure frequency.
One Hz is equal to one wave per second.
27
Period (T, s) How fast one wave passes a point.
Measured in seconds.
28
Relationship between Frequency and Period
29
velocity wavelength X frequency
30
Wheel of Answers
? x f
v
v
?
?
f
f
31
Example 1 A tuning fork has a frequency of 256
hertz. The wavelength of the sound produced by
the fork is 1.32 meters. Calculate the velocity
of the wave.
Given ? 1.32m Find v f
256Hz
Basic Equation v ? X f
Solve v ? X f (1.32m) X (256Hz)
v 338m/s
32
Example 2 A wave has a wavelength of 1.20
meters. Its velocity is 0.75 meters per second.
What is the frequency of the wave.
Given ? 1.20m Find f v 0.75m/s
Basic Equation f v/?
Solve f (0.75m/s) (1.20m)
f 0.63Hz
33
Homework
Practice Problems 9-10Page 507Section
17.2Due 5/05/09
34
Reflection
  • The interaction that occurs when a wave bounces
    off a surface that it cannot
  • pass through.

35
(No Transcript)
36
(No Transcript)
37
Reflection
  • Reflection does not change the speed or frequency
    of a wave, but the wave can be flipped upside
    down.

38
Reflection at a Boundary
  • If reflection occurs at a fixed boundary, then
    the reflected wave will be upside down compared
    to the original wave.

If reflection occurs at a loose boundary, then
the reflected wave will be unchanged.
39
Refraction
  • The bending of a wave as it enters a new medium
    at an angle.

40
Refraction
41
Refraction
  • When a wave enters a medium at an angle,
    refraction occurs because one side of the wave
    moves more slowly or faster than the other side.

42
(No Transcript)
43
Diffraction
  • The bending of a wave as it moves around an
    obstacle or passes through a narrow opening.

44
Diffraction
The bending of a wave as it passes through an
opening or around the edge of an object.
45
Diffraction
  • A wave diffracts more if its wavelength is large
    compared to the size of an opening or obstacle.

46
Interference
Interference occurs when two or more waves come
together. When two crests or two troughs come
together we get a bright line. When a crest and
a trough come together we get a dark line.
47
(No Transcript)
48
(No Transcript)
49
Standing wave
  • A wave that appears to stay in one place and does
    not seem to move through a medium.

50
Standing Wave
  • A standing wave forms only if half a wavelength
    or a multiple of half a wavelength fits exactly
    into the length of a vibrating cord.

51
Homework
Section 17.3Due 5/5/09
52
Diffraction Grating
53
Homework 18-1
B
G






A
D
I
H
C
F
E
54
Homework 18-1
B






2
A
8
4
55
Homework 18-1






4
2
A
8
56
Homework 18.1










Y
X
57
The Nature of Sound
What is Sound???
Sound is a Longitudinal Wave traveling through
matter.
58
Sound from a Tuning Fork
59
Sound Waves
60
Speed of Sound
Sound is transmitted through matter.
The Velocity of Sound depends on the matter that
carries it.
61
Sound travels at a velocity of 332m/s in air at
0?C.
At 20?C sound travels at 344m/s.
62
Speed of Sound
Velocity of Sound through Various Substances at
0?C air 332 m/s water 1454
m/s wood 3828 m/s iron 5103
m/s stone 5971 m/s
63
Human Hearing
Frequency of Sound 20 Hz to 20,000 Hz.
Sound above 20,000 Hz - Ultrasonic
Sound less than 20 Hz Subsonic
(Infrasonic)
64
Frequency and Pitch
  • The frequency of a sound as a listener perceives
    it.

65
Ultrasound
  • Ultrasound is used in a variety of applications,
    including sonar and ultrasound imaging.

66
Sonar
  • A technique for determining the distance to an
    object under water.

Sonar stands for sound navigation and ranging.
67
(No Transcript)
68
Intensity and Loudness
Intensity of Sound Depends on the amplitude of
the wave.
Loudness Describes a persons response to sound
intensity.
69
Loudness is measured in Decibels(dB)
For every 10dB change the sound doubles!! 70dB
is twice 60dB 80dB is four times 60dB
70
Faintest Sound Heard 0dB Whisper 15dB Rust
ling Leaves 20dB Purring Cat 25dB Averag
e Home 50dB Vacuum Cleaner 75dB Noisy
Restaurant 80dB Power Mower 100dB Chain
Saw 115dB ------Painful -------
120dB Jet Plane Taking Off 150dB
71
The Doppler Effect
The change in wave frequency caused by the motion
of the sound source or the motion of the
observer.
72
The Doppler Effect
73
The Doppler Effect
74
The Doppler Effect
75
(No Transcript)
76
The outer ear gathers and focuses sound into the
middle ear.
77
The middle ear receives and amplifies the
vibrations.
78
The inner ear uses nerve endings to sense
vibrations and send signals to the brain.
79
Sound Reproduction
Electrical Signal
80
Music
  • Most musical instruments vary pitch by changing
    the frequency of
  • standing waves.

81
Harmonics
  • 1st

2nd
3rd
82
Resonance
  • The response of a standing wave to another wave
    of the same frequency, will dramatic increase in
    amplitude of the standing wave.

83
Homework 17-4
Worksheet 17-4 Due 5/06/09 Test
5/14/09 Project 6/2/09
84
Homework
Wordwise/Math Due 5/07/09 Test
5/14/09 Project 6/2/09
85
Homework 18-3
SWUP 18-3 Page515 Worksheet Due 5/5/04
86
Music to Your Ears
A back and forth motion is set up in a string,
resulting in a regular vibration. The vibration
is called a standing wave the location of the
crests and troughs are always in the same place.
87
In a wind instrument, holes are opened and
closed, changing the length of the vibrating
column of air. This changes the size of the
standing wave.
88
Noise
Sound with no regular pattern or definite pitch.
89
Tone Quality
The differences among sounds of the same pitch
and loudness.
90
Music
Musical Sounds Based on a series of notes called
a musical scale.
91
Fundamental
Frequency
262Hz
First Overtone

524Hz
Second Overtone

786Hz
Third Overtone

1048Hz
92
Harmony
Notes that sound pleasing together. The ratio of
the frequencies of tones that are in harmony
are small whole numbers.
         Notes that are one octave apart.
Middle C and C 524/262 2/1

         Notes E and C 330/262 5/4
93
Interference
Constructive Interference Occurs when the
compressions and rarefactions of two or more
waves come together.
Louder Sound
94
Interference
Destructive Interference Occurs when a
compression of one wave arrives at the same time
as a rarefaction of another wave.
Quieter Sound
95
Interference
Beats The result of compressions and rarefactions
of two slightly different frequencies reaching
your ears together.
Beats
96
Acoustics
The study of the science of sound.
Design auditoriums.
Design communication systems.
Study materials.
Study hearing......
97
Reverberation
The result of many different reflections of sound
in a large room.
98
Speed of Sound
99
Speed of Sound
100
Homework 18-4
SWUP 18-3 Pg515 SWUP 18-4,Pg521
Worksheet Due 5/5/04 Test 5/6/05
101
Homework 18-5
Vocabulary Pg523 Mult. Choice Pg524 Due
5/10/04 Test 5/6/05
102
Homework 18-6
Review Questions 11-24, Due 4/11/04 Test 5/6/05
